Range of wall mounted bar type thermostatic shower valves (brass body, chrome finish) incorporating quarter turn ceramic disc headwork which controls the flow with dome type operating members. Temperature is controlled independently via a thermostatic cartridge with dome type operating member which incorporates a manual override button. Both inlets incorporate an approved check valve cartridge however, the complete product has not been fully tested to demonstrate it provides backflow protection. Supplied with an optional flow regulator. Maximum working pressure 5.0 bar. Maximum operating temperature 85°C
Range of wall mounted thermostatic blending valves with chrome plated brass bodies and ceramic disc headwork with a dome type operating member. Temperature is controlled independently via a thermostatic cartridge also with a dome type operating member. Inlets incorporate single check valve cartridges however, the complete assembly has not been tested to demonstrate it provides adequate backflow protection. The products are supplied with a shower hose and handset. Maximum working pressure 10.0 Bar Maximum operating temperature 60.0°C
Range of butterfly valves incorporating blue or green epoxy coated ductile iron bodies, discs and EPDM seals. Maximum working pressure 16.0 Bar Maximum operating temperature 65.0°C
Range of float operated inlet valves incorporating with brass bodies. Maximum working pressure 10.0 bar. Cold water use only.
Range of in-line pilot operated level control valves with blue epoxy coated ductile iron bodies. The products have flow control facility controlled via a float operated valve and are supplied with auxiliary components including stainless steel pipe & fittings, spherical valves, bleed valve and a needle valve. Maximum working pressure 16.0 Bar. Maximum operating temperature 60.0°C.
Range of inline pilot operated altitude control valves with blue epoxy coated ductile iron bodies and bonnets. The pilot system consists of spherical valves, in line strainers, needle valve, non-return valve, altitude gauge and a pre-set altitude control valve. The spring rating of the pilot 10-60ft (3 to 18m). Maximum working pressure 16.0 Bar Maximum operating temperature 60.0°C
Range of swing gate, non-return valves with (blue, black or red epoxy powder coated) ductile iron bodies. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of non-return valves with ductile iron bodies and discs (coated with red epoxy). Maximum working pressure 25.0 bar. Maximum operating temperature 85°C.
Range of non-return, swing gate valve with brass bodies and brass discs. Maximum working pressure 20.0 bar Maximum operating temperature 85°C.
Range of non-return, swing gate valves with bronze bodies and bronze discs. Maximum working pressure 20.0 bar Maximum operating temperature 85°C.
Range of adjustable, bronze in-line pressure reducing valves. VIT-20-PRBZ ½”, ¾” & 1” & 1¼” size have inspection ports on the outlet only. 2” to 4” sizes have inspection ports on the inlet and outlet. The valves incorporate a stainless-steel strainer. Maximum inlet supply pressure 20.0 bar. Maximum outlet pressure 1.0 bar to 4.0 bar. Maximum operating temperature 70°C.
Range of pilot operated pressure reducing control valves with ductile iron bodies (blue epoxy coating) and EPDM diaphragm and O-rings. The products are supplied with auxiliary fittings: spheerical valves, pressure gauges, a pilot valve and a needle valve. Maximum inlet supply pressure 25.0 bar. The outlet pressure is adjustable between 1.5 - 17 bar. Maximum operating temperature 85°C.
Range of pilot operated pressure relief control valves with blue epoxy coated ductile iron bodies and supplied with auxiliary components including stainless steel pipe & fittings, spherical valves, bleed valve and a needle valve. Spring ratings of pilot valve are 0.35 - 3.5 bar, 0.7 - 5.5bar, 1.38 - 13.8 bar, 6.9 - 20.7 bar Maximum working pressure 16.0 Bar Maximum operating temperature 60.0°C
Solenoid valve with a plastic body, incorporating an EPDM diaphram and EPDM sealing rings. Maximum working pressure 8.0 bar. Maximum operating temperature 65°C.
Range of spherical valves with (brass bodies) incorporating a brass ball with PTFE seat. Maximum operating pressure - 25 bar. Maximum operating temperature - 85°C.
Range of press fit spherical valves with brass and chrome plated brass bodies. For use with copper pipe to BS EN 1057. Maximum working pressure 16.0 Bar Maximum operating temperature 85 °C.
Range of inline or angled screwdriver and lever operated isolation and servicing valves (See models), (chrome plated brass bodies) and ball, incorporating EPDM ‘O’-rings. For use with copper pipe manufactured to EN1057 Maximum working pressure: 10 bar. Maximum working temperature: 99°C.
Range of spherical valves with bronze bodies (brushed chrome plated), brass ball and PTFE seals. Incorporating a lever type operating member. Maximum working pressure 25.0 Bar Maximum operating temperature 85.0°C
Range of spherical valves with nickel plated brass bodies and a chrome plated ball. The handle can either be a flat lever handle or a T handle (See models) Maximum working pressure 25.0, 30.0, 40.0, 50.0 Bar Maximum operating temperature 60.0°C
Wall mounted shower valve (chrome plated brass body) incorporating a ceramic cartridge headwork with a single lever operating member. The outlet incorporates an approved check valve cartridge however, the complete product has not been fully tested to demonstrate it provides backflow protection. Maximum working pressure 10.0 Bar Maximum operating temperature 65.0°C
Range of lockable, key operated, in-line spherical valves with brass bodies and nickel-plated brass ball. Maximum working pressure 16.0 Bar. Maximum operating temperature 85.0°C.
Range of PVC-U double union ball valves incorporating EPDM O-rings. Maximum working pressure 16.0 Bar. Cold water use only
Range of gate valves with blue epoxy coated ductile iron bodies, EPDM coated ductile iron wedge and EPDM seals. Valves are operated via a non-rising spindle headwork. Maximum working pressure 16.0 Bar Maximum operating temperature 100.0°C
Range of gate valves with brass or DZR brass bodies, non-rising spindles and hand wheel operating members. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
2Z126 FGAXXXB16NS01 range of brass gate valves or FGAXXXD16NS42 range of DZR brass body gate valves, with PTFE washers. Valves are operated via a non-rising spindle headwork with a wheel type operating member. Maximum working pressure 16.0 or 20.0 Bar Maximum operating temperature 85.0°C
Range of gate valves incorporating either rising or non-rising spindle headworks and PTFE gaskets. The products are available as follows: Bronze body, bronze wedge and handwheel (MV40-1138.RS, MV40-1138 & MV40-1138.D models). Bronze body, bronze wedge and lock-shield (MV40-1153.LS & MV40-1138.LS models). Brass body, brass wedge and handwheel (MV40-1120 model only). Maximum working pressure 20.0 bar & 25.0 bar (model MV40-1153.LS only). Maximum operating temperature 85°C.
Range of gate valves incorporating a blue epoxy coated cast iron body, EPDM gate and seals and a non-rising stem with a handwheel operating member Maximum working pressure 16.0 bar, Maximum operating temperature 85ºC.
Range of non-rising spindle gate valves with bronze bodies, incorporating a hand wheel operating member. Maximum working pressure 16.0 Bar Maximum working temperature: 85C
Range of gate valves, (bronze bodies) incorporating either rising or non-rising spindle headworks and PTFE gaskets. The valves incorporate a hand wheel operating member. Maximum working pressure 20.0 bar Maximum operating temperature 85°C.
Range of press fit gate valves with brass bodies. For use with copper pipe to EN1057. Maximum working pressure 16.0 Bar Maximum operating temperature 85 °C.
Range of gate valves with blue epoxy ductile iron bodies, ductile iron wedge encapsulated in EPDM. Maximum working pressure 16.0 Bar. Maximum operating temperature 85°C.
Range of gate valves with brass bodies and stems, EPDM O-rings, with non-rising spindles with hand wheel operating members. Maximum working pressure 20.0 bar. Maximum operating temperature 100°C.
Range of flanged gate valves with blue epoxy coated ductile iron bodies and EPDM O-rings and disc. The valves are operated via a non-rising spindle headwork with a wheel type operating member. Maximum working pressure 16.0 Bar
Non-metallic materials and components comply with BS6920 at 80°C
Range of gate valves with blue epoxy coated ductile iron bodies and hand wheel operating members. Maximum working pressure 25.0 bar (DN50-DN300) or 10.0 bar (DN400 only) Maximum operating temperature 85ºC
AMEXSA range of resilient seated gate valves with blue epoxy coated ductile iron bodies and bonnets and ductile iron wedges encapsulated in EPDM. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 80°C.
Range of in-line pilot operated control valves with blue epoxy coated ductile iron bodies, having rate of flow control facility controlled via a pilot system. Spring ratings of pilot valve are 2 to 20 psi / 0.138 to 1.38 bar, 25 to 50 psi / 1.72 to 3.4 bar. Maximum working pressure 16.0 Bar Maximum operating temperature 60.0°C
Range of gate valves incorporating bronze bodies and discs with PTFE seals. The valves operate via a non-rising spindle headwork that incorporates a wheel type operating member. Maximum working pressure; 20 Bar Maximum operating temperature; 85°C
Range of inlet control groups with a DZR brass body, consisting of a pressure reducing valve and pressure relief valve set to 6bar. The outlet incorporates a single check valve cartridge verified by test (suitable for backflow protection against Fluid Category 2. Pressure reducing range 1 bar to 6 bar Maximum working pressure 10 Bar Maximum operating temperature 85°C
Range of inlet control valves with DZR brass bodies. The valves consist of an adjustable pressure reducing valve set at 3.0 bar, pressure relief valve set at either 4.5, 6.0 or 8.0 bar. The valves also incorporate an approved check valve cartridge, verified by test (suitable for backflow protection against Fluid Category 2). For use with copper pipe to BS EN 1057. Maximum working pressure 16.0 Bar. Maximum operating temperature 65°C.
Range of scale inhibitors with chrome plated copper bodies for use with copper pipe (manufactured to EN1057). Maximum working pressure 10.0 bar. Cold water use only.
In-line electrolytic scale reducer with copper bodies for use with copper pipe (manufactured to BS EN 1057). Maximum working pressure 10.0 bar. Maximum operating temperature 40°C.
Range of water conditioners with stainless steel bodies. Maximum working pressure 10 Bar. Maximum operating temperature 85°C.
'TENAC-C 4590'. White (translucent) coloured, injection moulded acetal material. For use with water up to 85°C.
'SF-CM1'. Factory applied, grey coloured, sulphate resistant cement mortar. Mix cement mortar, sand & water in a 2:1:0.4 mass ratio and apply as per manufacturer's user instructions 'SF-CM1', 'Vision A1' dated '2024-7'. Cure for 12 hours@23°C. For use with water up to 23°C. This material is only approved for the mixing & curing conditions that appear on the approval. If the mix and/or cure conditions are varied from those specified on the approval then the material is not covered by the scope of the approval.
'Chromapoxy H.B.F.N.Paint Blue'. Factory applied, blue coloured, two-part epoxy coating. Mix base and accelerator in a 3:1 volume ratio and apply as per manufacturer's data sheet 'NCE/200', issue date '15.01.2014'. Cure for 7 days@32°C. For use with water up to 65°C. This material is only approved for the mixing and curing conditions that appear on the approval. If the mix and/or cure conditions are varied from those specified on the approval then the material is not covered by the scope of the approval.
'LM119-1'. Factory applied, white coloured epoxy coating. Apply as per manufacturer's User Instructions 'File no.: LM-001', 'Edition: A', 'Issue date: 2024-JAN.-15th'. Cure for 10 minutes@190°C. For use with water up to 65°C. This material is only approved for the curing conditions that appear on the approval. If the cure conditions are varied from those specified on the approval then the material is not covered by the scope of the approval.
'Chromapoxy H.B.F.N.Paint Blue'. Factory applied, blue coloured, two-part epoxy coating. Mix base and accelerator in a 3:1 volume ratio and apply as per Nav Durga Chromatics Private Limited data sheet 'NCE/200', issue date '15.01.2014'. Cure for 7 days@32°C. For use with water up to 65°C. This material is only approved for the mixing and curing conditions that appear on the approval. If the mix and/or cure conditions are varied from those specified on the approval then the material is not covered by the scope of the approval.
'ZHR‐SRC'. Factory applied, grey coloured Sulphate Resistant cement. Mix cement and sand in a 2:1 mass ratio. Apply as per manufacturer's instruction sheet '2025.8.27'. Steam cure for 8 hours@50°C. For use with water up to 65°C.
'Ecocoat FBE Green Powder PFC/6018 (RAL 6018)& Ecocoat FBE Red Oxide Powder PFC/3000-Red Oxide'. Factory applied, green or red coloured epoxy coatings. Apply as per manufacturer’s Product Data Sheet revised ‘1st Jan, 2024’. Cure for 3 minutes at a metal temperature of 230°C. For use with water up to 85°C. These materials are only approved for the curing conditions that appear on the approval. If the cure conditions are varied from those specified on the approval then the materials are not covered by the scope of the approval.
‘Eurokote® 48-20 Brun Rouge’. Factory applied, red coloured, two-part epoxy coating. Mix resin and hardener in a 2.13:1 mass ratio and apply as manufacturer's TDS dated '10/12/2024'. Cure for 24 hours@20°C. For use with water up to 23°C.
'F15222 CB Silicone Lubricant' & 'PHCB042 – F15222 Centerbrand Silicone Grease'. Off-white coloured (opaque) silicone greases. Apply as per manufacturer's instructions. For use with water up to 65°C.
Tecomid NA40 GR25 NL HS QF (white coloured) and Tecomid NG40 GR30 BK250 HS QW, Tecomid NA40 GR30 BK005 HY QH & Tecomid NA40 GR30 BK250 HY QW (black coloured). Injection moulded PA materials. Tecomid NA40 GR25 NL HS QF (white coloured) & Tecomid NG40 GR30 BK250 HS QW (black coloured) are suitable for use with water up to 85°C. Tecomid NA40 GR30 BK005 HY QH (black coloured) & Tecomid NA40 GR30 BK250 HY QW (black coloured) are suitable for use with water up to 23°C.
'Synolite 5410-P-3'. Green coloured polyester resin material manufacture by hand lay-up. For use with water up to 23°C.
'Verkid PG35-GR250 Grey'. Grey coloured, compression moulded, unsaturated, glass filled polyester resin material. For use with water up to 23°C.
'Artpoly® 700'. Amber coloured (translucent), unsaturated Polyester resin manufactured by casting. For use with water up to 23°C.
'Artpoly® 705'. Amber coloured (translucent), unsaturated Polyester resin manufactured by casting. For use with water up to 23°C.
'Elysee HDPE PE 80 Blue Pipe'. Extruded, single layered (blue coloured) or dual layered (black coloured inner layer & blue coloured outer layer) HDPE pipes. For use with water up to 23°C.
'Flomasta Blue PE 80 Pipe'. Extruded, single layered (blue coloured) or dual layered (black coloured inner layer & blue coloured outer layer) HDPE pipes. For use with water up to 23°C.
'Proofex HDPE B125'. White coloured, extruded HDPE waterproofing membrane. For use with water up to 60°C.
'SABIC® PP 48M10'. White coloured, injection moulded polypropylene material. For use with water up to 85°C.
'SABIC® PP 56M10'. White coloured, injection moulded polypropylene material. For use with water up to 85°C.
'Tecoflex TU40 GR30 GR128 HS D6 QF'. Light grey coloured, injection moulded TPU material. For use with water up to 23°C.
'10 EPR 'O' rings'. Black coloured, injection moulded EPDM 'O' rings. Shore hardness 70. Tested in-radius size 1.5mm. For use with water up to 85°C.
'15 EPR, 22 EPR & 28 EPR 'O' rings'. Black coloured, injection moulded 'O' rings. Shore hardness 60. Tested in-radius size 1.8mm. For use with water up to 85°C.
'EXJ2024'. Black coloured, compression moulded EPDM material. Shore hardness 65. Tested in-radius size 1.0mm. For use with water up to 85°C.
'HT5697-50'. Black coloured, injection moulded EPDM material. Shore hardness 67 ShA. Tested in-radius size 1.0mm. For use with water up to 60°C.
'VL1001P279'. Blue coloured, compression moulded silicone rubber. Shore hardness 60. Tested in-radius size 0.99mm. For use with water up to 65°C.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| LT0188-B01 | Black | 1/2" BSP (F) | 9 bar | 65 °C | Mediclinics | Body | No | Solenoid | Not Applicable | Aerator |
Range of deck mounted, single hole, single outlet (fixed) electronically controlled tap assemblies (chrome plated stainless steel bodies). The flow is controlled by a solenoid valve that is activated via an infrared sensor, and the spout outlets incorporate plastic aerators. Maximum working pressure 8.0 Bar Maximum operating temperature 65.0°C
Range of single hole, single outlet (fixed) combination tap assemblies (chrome plated brass). Flow is controlled by a solenoid valve activated via an infra-red sensor. The spout outlets incorporate plastic aerators. Maximum working pressure:8.0 Bar Maximum operating temperature:65 °C
Concealed WC dual flushing cisterns with a vertical BS 1212-4(2016) float operated inlet valve providing a Type AG air gap arrangement and a dual flush outlet valve. The flush volume is operated by a two-push button assembly. The product also incorporates a servicing valve and flexible hose on the inlet supply. Maximum working pressure 10 Bar, cold water use only.
Concealed WC dual flushing cistern with a bottom entry BS 1212 - 4(2016) float operated inlet valve providing a Type AG air gap arrangement and a dual flush outlet valve. The flush volume is operated by a two-push button assembly for a 6 or 3 litre flush volume. Maximum working pressure 10.0 bar, cold water use only.
WC Cistern incorporating a side or bottom entry float operated inlet valve and a Syphon (Phantom S), Pneumatic Drop Valve (Phantom V) or Cable Operated Drop Valve (Phantom T) with full flush volumes of up to 6 litres and a reduced flush of up to 4 litres. The cistern can be operated by lever or push button. Maximum working pressure 10.0 bar. Cold water use only.
W/C suite with pan (polyester) and a concealed flushing cistern incorporating a side entry compact type float operated inlet valve providing a Type AG air gap with a single flush drop valve for full flush volumes of up to 6 litres. The cistern is operated by a manual push button and incorporates a servicing valve and flexible hose on the inlet supply. Maximum working pressure 10.0 Bar. Cold water use only.
Range of deck mounted, single hole, single outlet (fixed) electronically controlled tap assemblies (chrome plated stainless steel or brass bodies, see models). The flow is controlled by a solenoid valve that is activated via an infrared sensor. Temperature is controlled independently via a single lever operating member. The spout outlets incorporate plastic aerators. Supplied with hoses that incorporate stainless steel strainers and an approved single check valve cartridge, however, the complete product has not been fully tested to demonstrate it provides backflow protection. Maximum working pressure 8.0 Bar Maximum operating temperature 65.0°C
Range of single hole, single outlet (fixed) combination tap assemblies (chrome plated brass bodies). Flow is controlled by solenoid valves activated via an infra-red sensor and the temperature is controlled independently via single lever. The spout outlets incorporate plastic aerators. Maximum working pressure 8 Bar. Maximum operating temperature 65°C.
Range of combined bath fillers and overflow waste assemblies with plastic bodies (various finishes). The outlet incorporates a plastic aerator. The products are supplied with a cable operated pop-up waste. Maximum operating temperature 60°C.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| JD-PS***-**-**** | F1/2, M15*1 | Open outlet use only bar | 85 °C | Kind, WRAS, Production date(MM.YYYY) | Ferrule | No |
Note: 1. 1st *** denotes the hose length: 15-300cm: E.g., 015 = 15cm, 100 = 100cm, 200 = 200cm. 2. 2nd ** denotes the hose size: 06=DN6, 07=DN7 3. 3rd **** denotes the connections, and can be replaced with any of the following: 01=F1/2 05=M15*1
‘Union Range’ of shower kits. Comprising of a plastic shower handset, shower hose and brass wall outlet (various finishes – See model). The shower handset incorporates an approved check valve cartridge (however the complete assembly has not been tested to demonstrate it provides backflow protection) Maximum operating temperature 60°C.
Non-verifiable double check valve assembly with DZR brass body, incorporating two spring loaded, resilient trim in-line check valve cartridges. Compression connection to be used with copper pipe BS EN1057 only. Maximum working pressure 10.0 bar. Maximum operating temperature 85°C for 12.10102.035.CP5R-8511, Maximum operating temperature 65°C for 12.10112.035.CP5R-8511.
Versol Electrical Water Heater Tank, with a stainless-steel tank body. Max working pressure 10 bar. Max operating temperature 95°C.
Single hole, single outlet (fixed) combination tap assemblies (chromium plated brass), incorporating quarter turn ceramic disc headworks with cross top operating members. The spout outlet incorporates a plastic aerator and a swivel nozzle. Maximum working pressure 10.0 bar. Maximum operating temperature 65°C.
Range of single hole, single outlet (swivel) combination tap assemblies (brass bodies, various finishes - see model) with a ceramic cartridge headworks and a single lever operating member. The spout outlet incorporates a pull-out spray with plastic aerator. The pull-out spray hose connector incorporates an approved check valve cartridge, however, the complete product has not been fully tested to demonstrate it provides backflow protection. Maximum working pressure 5.0 bar. Maximum operating temperature 60°C.
Range of single hole, single outlet (fixed) combination tap assemblies ( brass bodies - various finishes), incorporating either a ceramic cartridge or ceramic disc (see models) headworks with either a single lever or cross top (see models) operating member. The spout outlet incorporates either a plastic aerator, a plastic flow straightener or an open outlet type spout (see models). Some models are supplied with a click type waste and some are supplied with a lever type pop-up waste (see models). Maximum working pressure 5.0 Bar . Maximum operating temperature 65.0°C or 85.0°C (see models)
Range of single hole, single outlet (fixed) combination tap assemblies (brass bodies - various finishes - see model), incorporating a ceramic cartridge headwork with a single lever operating member. The spout outlets incorporate a plastic aerator. The product is supplied with a click type waste, verified by test. Maximum working pressure 5.0 bar. Maximum operating temperature 60°C.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SH-QT8202W | Chrome | G1/2,female | 10 bar | 60 °C | SHANHU | body | No | Ceramic cartridge | C-plate | Aerator | |
| SH-QT82022W | Chrome | G1/2,female | 10 bar | 60 °C | SHANHU | body | No | Ceramic cartridge | C-plate | Aerator | |
| SH-T8182W | Chrome | G1/2,female | 10 bar | 60 °C | SHANHU | body | No | Ceramic cartridge | C-plate | Aerator | |
| SH-QT8022AW | Chrome | G1/2,female | 10 bar | 60 °C | SHANHU | body | No | Ceramic cartridge | C-plate | Aerator | |
| SH-QT8882CW | Chrome | G1/2,female | 10 bar | 60 °C | SHANHU | body | No | Ceramic cartridge | C-plate | Open Outlet |
Single hole, single outlet (fixed) combination tap assembly (chromium plated brass), incorporating quarter turn ceramic disc headworks with cross top operating members. The spout outlet incorporates a plastic aerator. Maximum working pressure 10.0 bar. Maximum operating temperature 65°C.
Range of single hole, single outlet (fixed) combination tap assemblies (brass bodies -various finishes, see model) incorporating a ceramic cartridge headwork with a single lever operating member. The spout outlet incorporates a plastic aerator, (except for the 3259-XX models). Maximum working pressure 10.0 bar. Maximum operating temperature 60°C.
Range of single hole, single outlet (swivel) combination tap assemblies (brass bodies – various finishes). Incorporating quarter turn ceramic disc or ceramic cartridge headworks and single lever or cross top operating members. The spout outlets incorporate a plastic aerator. Maximum working pressure 5.0 Bar Maximum operating temperature 70.0°C.
Single hole, single outlet (swivel) combination tap assemblies (brass bodies - various finishes), incorporating ceramic cartridge headworks with single lever operating members. The spout outlet incorporates plastic flow straighteners. The products are supplied with a 15x15mm compression single check valve assembly (suitable for backflow protection against Fluid Category 2) which also incorporates an isolation valve, intended for installation at each inlet. Maximum working pressure 5.0 bar. Maximum operating temperature 65°C
Single hole, single outlet (swivel) combination tap assemblies (brass bodies - various finishes), incorporating quarter turn ceramic disc headworks with single lever operating members. The spout outlet incorporates a plastic flow straightener. Maximum working pressure 5.0 bar. Maximum operating temperature 60°C
Single hole, single outlet (swivel) combination tap assembly (chromium plated brass), Incorporating a ceramic cartridge headwork with lever type operating member. The spout outlet incorporates a plastic aerator. Maximum working pressure 5.0 bar. Maximum operating temperature 60°C
Single hole, single outlet (swivel) combination tap assembly with brass body (chromium plated), incorporating a ceramic cartridge headworks and single lever operating member. The outlet incorporates a plastic aerator. Maximum working pressure 5.0 bar. Maximum operating temperature 60°C.
Single hole, single outlet (swivel) combination tap assembly with brass body (chromium plated), incorporating a ceramic cartridge headworks and single lever operating member. The outlet incorporates a plastic aerator. One inlet hose incorporates an approved check valve cartridge, however, the complete product has not been fully tested to demonstrate it provides backflow protection. Maximum working pressure 5.0 bar. Maximum operating temperature 60°C.
Range of single hole, single outlet (swivel) combination tap assemblies (brass bodies - various finishes, see model), incorporating a ceramic cartridge headwork with a single lever operating member. The spout outlets incorporate a plastic aerator. Maximum working pressure 5.0 bar. Maximum operating temperature 60°C.
Range of single hole, single outlet (swivel) combination tap assemblies (brass body, various finishes - see model), incorporating quarter turn ceramic disc headworks with single lever operating members. The spout outlet incorporates a plastic aerator. Maximum working pressure 10.0 bar. Maximum operating temperature 85°C.
Range of single hole, single outlet (swivel) combination tap assemblies (chromium plated brass), incorporating quarter turn ceramic disc headworks and single lever operating members. The spout outlet incorporates a plastic aerator. The inlet hoses incorporate an approved check valve cartridge however, the complete product has not been fully tested to demonstrate it provides backflow protection. Maximum working pressure 5.0 bar. Maximum operating temperature 60°C.
Single hole, double outlet (swivel) combination tap assembly (chrome plated brass body). Incorporating a ceramic disc headworks and single lever operating members. The spout outlet incorporates a plastic aerator. Maximum working pressure 5.0 Bar Maximum operating temperature 70.0°C
Range of deck mounted, two hole, double outlet (swivel) combination tap assemblies (brass bodies – various finishes). Incorporating quarter turn ceramic disc headworks (DLV305B, DLT305B) or non-rising spindle headworks (CR305 BRIDGE, CR305/501 BRIDGE) and single lever or cross top operating members. Maximum operating pressure 10.0 bar. Maximum operating temperature 60°C.
Wall mounted, two hole, double outlet (swivel) combination tap assembly incorporating quarter turn ceramic disc headworks with single lever type operating members. Maximum operating pressure 10.0 bar. Maximum operating temperature 60°C.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SH-QT8204 | Chrome | G3/4,male | 10 bar | 60 °C | SHANHU | body | No | 1/4 Turn ceramic disk | Metal Backnuts | Aerator |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SH-T8184 | Chrome | G3/4,male | 10 bar | 60 °C | SHANHU | body | No | 1/4 Turn ceramic disk | Metal Backnuts | Aerator | |
| SH-QT8035 | Chrome | G3/4,male | 10 bar | 60 °C | SHANHU | body | No | 1/4 Turn ceramic disk | Metal Backnuts | Not Applicable |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SH-QT8066B | Chrome | G3/4,male | 10 bar | 60 °C | SHANHU | body | No | 1/4 Turn ceramic disk | Metal Backnuts | Aerator |
Two hole, single outlet fixed combination tap assembly (chromium plated brass) incorporating quarter turn ceramic disc headworks with single lever operating members. The product is supplied with plastic back nuts. Maximum working pressure 10.0 bar. Maximum operating temperature 65°C.
Two hole, single outlet fixed combination tap assembly (brass body - various finishes, see model) incorporating quarter turn ceramic disc headworks with single lever operating members. The 2259-XX model incorporates an open outlet spout, all other models incorporate a plastic aerator. The products are supplied with metal back nuts. Maximum working pressure 10.0 bar. Maximum operating temperature 60°C.
Two hole, single outlet fixed combination tap assembly (brass body - various finishes, see model) incorporating quarter turn ceramic disc headworks with single lever operating members. The spout outlet incorporates a plastic flow straightener. The product is supplied with metal back nuts. Maximum working pressure 10.0 bar. Maximum operating temperature 60°C.
Wall mounted two hole, single outlet (fixed) combination tap assembly (brass body, various finishes), incorporating ceramic cartridge headwork and single lever operating member. The spout incorporates a plastic aerator. Maximum working pressure: 5.0 bar. Maximum operating temperature: 60°C.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SH-T8060A | Chrome | G3/4,male | 10 bar | 60 °C | SHANHU | body | No | 1/4 Turn ceramic disk | Metal Backnuts | Aerator | Shower Hose, Handset, |
Two-hole single outlet fixed combination tap assembly (chromium plated brass) incorporating quarter turn ceramic disc headworks with cross-top operating members and a manual diverter to shower outlet. The product is supplied with a shower hose, shower handset and plastic back nuts. Maximum working pressure 10.0 bar. Maximum operating temperature 60°C.
Two hole, single outlet fixed combination tap assembly (brass body - various finishes, see model) incorporating quarter turn ceramic disc headworks with single lever operating members and a manual diverter to shower outlet. The spout outlet incorporates a plastic aerator, (except for the 1259-XX models). The products are supplied with metal back nuts. Maximum working pressure 10.0 bar. Maximum operating temperature 60°C.
Two hole, single outlet fixed combination tap assembly (brass body - various finishes, see model) incorporating quarter turn ceramic disc headworks with single lever operating members and a manual diverter to shower outlet. The spout outlet incorporates a plastic flow straightener. The product is supplied with metal back nuts. Maximum working pressure 10.0 bar. Maximum operating temperature 60°C.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| M 07119-L25 | Chrome | G3/4(M) | 10 bar | 60 °C | AMG, WRAS | Body | No | 1/4 Turn ceramic disk | Metal Backnuts | Flow Straightener | |
| M 07119-L25-B | Matt Black | G3/4(M) | 10 bar | 60 °C | AMG, WRAS | Body | No | 1/4 Turn ceramic disk | Metal Backnuts | Flow Straightener | |
| M 08119-L10 | Chrome | G3/4(M) | 10 bar | 60 °C | AMG, WRAS | Body | No | 1/4 Turn ceramic disk | Metal Backnuts | Flow Straightener | |
| M 08119-L10-B | Matt Black | G3/4(M) | 10 bar | 60 °C | AMG, WRAS | Body | No | 1/4 Turn ceramic disk | Metal Backnuts | Flow Straightener |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SL-KT010R | Various | ½" BSP (M) | 10 bar | 60 °C | Taizhou Shenglang Sanitary Ware Co., Ltd logo | Rear of body | No | 1/4 Turn ceramic disk | Metal Backnuts | Flow Straightener | |
| SL-KT008R | Various | ½" BSP (M) | 10 bar | 60 °C | Taizhou Shenglang Sanitary Ware Co., Ltd logo | Rear of body | No | Non-rising spindle | Metal Backnuts | Flow Straightener |
Various finish： (1) Without suffix to current model number: Chrome plated (2) With suffix B: Black (3) With suffix BB: Brushed brass
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| VAC BDSM C MT | Chrome | 1/2" BSP (M) | 8.0 bar | 60 °C | Bristan | Handle | No | Non-rising spindle | Metal Backnuts | Open Outlet | |
| RP3 VAC BDSM C MT | Chrome 3 | 1/2" BSP (M) | 8.0 bar | 60 °C | Bristan | Handle | No | Non-rising spindle | Metal Backnuts | Open Outlet |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| B005* | Various | ½" captive nut | 10 bar | 65 °C | WINSDRUM | On Spout | No | 1/4 Turn ceramic disk | Metal Backnuts | Aerator | Interconnecting Hoses, |
* denotes finish and can be replaced by: C - Chrome RG - Rose Gold BTG - Brushed Titanium gold BZG - Brushed Zirconium gold BRG - Brushed Rose gold MW - Matte white BS - Brushed stainless BN - Brushed nickel PN - Polished nickel GM - Gunmetal B - Matte black TG - Titanium gold ZG - Zirconium gold BC - Black+chrome W - White CW - Chrome+white Q - Quartzite ZGC - Zirconium gold+chrome TGC - Titanium gold+chrome M - Medieval A - Antique bronze CP - Champagne BL - Brushed lead BP - Polished Black
Range of three-hole, single outlet (fixed) wall mounted combination tap assemblies, (brass bodies - various finishes). Incorporating a quarter turn ceramic disc headwork with lever or cross top operating members. The spout outlet incorporates a plastic aerator. Maximum working pressure 10.0 bar. Maximum operating temperature 60°C.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| B004* | Various | 1/2" BSP (F) | 10 bar | 65 °C | WINSDRUM | Spout | No | 1/4 Turn ceramic disk | Not Applicable | Aerator | |
| B009* | Various | 1/2" BSP (F) | 10 bar | 65 °C | WINSDRUM | Rosette | No | 1/4 Turn ceramic disk | Not Applicable | Aerator |
*denotes finish and can be replaced by: C - Chrome RG - Rose Gold BTG - Brushed Titanium gold BZG - Brushed Zirconium gold BRG - Brushed Rose gold MW - Matte white BS - Brushed stainless BN - Brushed nickel PN - Polished nickel GM - Gunmetal B - Matte black TG - Titanium gold ZG - Zirconium gold BC - Black+chrome W - White CW - Chrome+white Q - Quartzite ZGC - Zirconium gold+chrome TGC - Titanium gold+chrome M - Medieval A - Antique bronze CP - Champagne BL - Brushed lead BP - Polished Black
Free standing, upright floor mounted inlet legs (chromium plated brass), incorporating stainless-steel braided PEX lined flexible hose assemblies. Maximum working pressure 6.0 bar. Maximum operating temperature 60°C.
Shock arrestor with stainless steel body and EPDM diaphragm. Maximum working pressure 15.0 bar. Maximum operating temperature 100°C.
Range of DZR brass compression fittings for use with Q-Therm PEX-b Pipes (SDR 7.4) Maximum working pressure:20 bar, cold water use only
‘LSMRI’ range of copper-nickel press fittings (‘M’ type crimp profile) for use with copper-nickel ‘LSMRI’ pipe. Above ground use only. Maximum working pressures: Press fittings: 16.0 bar, LSMRI-PN6 Series flange: 6.0 bar, LSMRI-PN10/16 Series flange: 10/16 bar. Maximum operating temperature 99°C.
Multipipe range of M type press copper crimp fittings with EPDM ‘O’-rings for use with copper tube manufactured to EN 1057. The joints are achieved by means of a crimping tool. For above ground use. Maximum working pressure: 16.0 bar. Maximum operating temperature: 85°C
‘HLBRxx’ range of brass or DZR brass compression fittings for use with copper pipe (manufactured to EN 1057). The HLBRTC‐1 tank connector, HLBRSS‐1 and HLBRBS‐1 tap connectors all incorporate an EPDM washer. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
‘3600xx’ range of brass compression fittings for use with copper pipe (manufactured to EN 1057). The 360014 tank connector, 360013 and 360017 tap connectors all incorporate an EPDM washer. Maximum working pressure 10.0 bar. Maximum operating temperature 85°C.
‘CFxx’ range of brass or DZR brass compression fittings for use with copper pipe (manufactured to EN 1057). Maximum working pressure 16.0 bar. Maximum operating temperatures: CF15 and CF16 models: 65°C. All other models: 85°C.
‘F17’ range of brass press fittings with EPDM ‘O’-rings for use with PEX/AL/PEX multilayer pipe (manufactured to EN ISO 21003). Jointing is achieved via a crimping tool using either a ‘U’, ‘TH’ or ‘H’ profile. Maximum working pressure 10.0 bar. Cold water use only.
'PlumbRight' range of push-fit fittings with PEX-b, polysulphone or PPE bodies, supplied with polysulphone inserts. For use with PEX pipe (manufactured to BSEN 7291 part 3), PB (manufactured to BSEN 7291 part 2) and copper pipe (EN1057). Maximum working pressure 12.5 bar @ 20°C. As of October 2025: Maximum working pressure/temperature 3 Bar @ 92°C.
“D-“ and “E-“ range of 304 and 316L stainless steel press fittings, in either ‘M’ press profile (D- prefix models) or ‘V’ press profile (E- prefix models) for use with stainless steel pipe (316L & 304 manufactured to EN10312). For above ground use only. Maximum working pressure 16.0 bar. Maximum operating temperature: 85°C.
Stainless steel plate heat exchangers with copper brazing.
Range of pre-assembled hydraulic blocks incorporating plate heat exchangers, pressure relief valves set at 3.0 bar, circulation pumps and flow regulators. Maximum working pressure: Primary 2.5bar & secondary 10 bar. Maximum operating temperature 80°C (CH) & 60°C (DHW).
Range of floor-standing gas combination boilers, supplied with isolation valves, expansion vessel and a pressure relief valve set at 3.0 bar. Maximum working pressure: Primary circuit 2.5 bar, secondary 10 bar. Maximum operating temperature: Primary 82°C / secondary circuit 60°C.
Range of water meters with plastic bodies and EPDM ‘O’-rings. The inlets incorporate a plastic strainer. Maximum working pressure 10.0 Bar Maximum operating temperature 50.0°C
Range of water meters with plastic bodies and plastic turbines. The inlet incorporates a plastic strainer. Maximum working pressure 16.0 bar. Maximum operating temperature 50°C.
Range of in-line water meters incorporating bronze copper alloy bodies and EPDM O rings. Maximum working pressure 10.0 Bar Maximum operating temperature 30.0°C
Range of flow sensors incorporating either brass, plastic or stainless steel bodies & EPDM ‘O’-rings. Maximum working pressure 10.0 bar for models VVXA, VVXC, VVXB. Maximum working pressure 16.0 bar for models VVXD & VVXE. Maximum operating temperature 90°C.
Range of EPDM expansion joints with flanged end conenctors. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of electromagnetic flow meters with carbon steel bodies, NBR inner liner and stainless-steel electrodes. Maximum working pressure 16.0 bar. Maximum operating temperature 80°C.
Range of pumps, with stainless steel bodies, impellers and shaft. Maximum working pressure 10.0 bar. Cold water use only.
Range of wall mounted angled overhead showers, consisting of stainless-steel bodies (various finishes) and silicone nozzles. The inlets are fitted with plastic flow limiters. Maximum operating temperature 65⁰C. Open outlet use only.
Range of brass shower arms and plastic shower heads (various finishes) incorporating EPDM seals and ‘O’-rings, silicone seals and spray insert. The 26 469 xxx model is ceiling mounted & 26 470 xxx model is wall mounted. Maximum operating temperature 60°C. Open outlet use only.
Range of wall or ceiling mounted shower arms with stainless steel bodies (various finishes - see model). Maximum operating temperature 60°C.
Range of overhead shower outlets. The inlet incorporates a stainless-steel filter washer. Maximum operating temperature 65°C.
Range of PVC lined flexible shower hoses with a black or silver finish. Open outlet use only. Maximum operating temperature 60°C.
In-line `Y`-patterned strainers with bronze bodies incorporating stainless steel mesh strainers and PTFE washers. Maximum working pressure 20.0 Bar Maximum operating temperature 85.0°C
Range of in-line `Y`-patterned strainers with bronze bodies incorporating stainless steel mesh strainers and PTFE washers. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of In-line ‘Y’ patterned strainer with ductile iron bodies (blue epoxy powder coated) and stainless-steel screens. Maximum working pressure 16.0 bar. Maximum operating temperature 85ºC.
Range of in-line `Y`-patterned strainers with bronze bodies incorporating stainless steel mesh strainers and PTFE washers. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 936L | Chrome | G3/4, male | 10 bar | 60 °C | WRAS, XINYA | BODY | No | 1/4 Turn ceramic disk | Metal Backnuts | Aerator | |
| 932L | Chrome | G1/2, male | 10 bar | 60 °C | WRAS, XINYA | BODY | No | 1/4 Turn ceramic disk | Metal Backnuts | Aerator |
Pillar taps (chromium plated brass) with quarter turn ceramic disc headworks and cross top operating members. The spout outlet incorporates a plastic flow straightener. The product is supplied with plastic back nuts. Maximum working pressure 10.0 bar. Maximum operating temperature 65°C.
Pillar taps (chromium plated brass) with quarter turn ceramic disc headworks and cross top operating members. The spout outlet incorporates a plastic flow straightener. The product is supplied with plastic back nuts. Maximum working pressure 10.0 bar. Maximum operating temperature 65°C.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 16 530 xx0 | Various | G 3/8 | 10 bar | 60 °C | AXOR | on body | Yes | 1/4 Turn ceramic disk | C-plate | Aerator |
Where xx0 denotes the surface finish (which is a non-water contact part). It will always be 3 digits, which can be any combination of numbers and/or letters, as examples: 000 = chrome optic finish, 800 = PVD stainless steel optic finish
Self closing basin tap (chromium plated brass) with spring loaded headwork and dome type operating members. The spout outlets incorporate a plastic flow straightener and the products are supplied with metal backnuts. Maximum working pressure 10.0 bar, Maximum operating temperature 85°C.
Range of EVOX stainless steel or grey nylon braided polyethylene lined flexible hose assemblies incorporating EPDM ‘O’-rings with various end connections. Maximum working pressure 10.0 bar. Maximum operating temperature 70°C.
‘KM1001 series’ of stainless steel braided EPDM lined flexible hose assemblies. Compression end connections are for use with copper pipes (manufactured to EN 1057). Compression end connections are also available with brass bodied (nickel plated) isolation valves incorporating a chrome plated brass ball. Maximum working pressure 10.0 bar. Maximum operating temperature 85°C.
Range of stainless-steel braided, EPDM lined flexible hose assemblies. Maximum working pressure 10.0 bar. Maximum operating temperature: 60°C.
Range of air venting valves with a blue epoxy coated ductile iron body, plastic float, EPDM ‘O’-rings and seals. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of wall mounted thermostatic shower valves with brass bodies (chromium plated) incorporating a ceramic disc controlling the flow to the shower (for some models it diverts the flow to a hand shower or overhead shower) using a dome type operating member. The temperature is controlled independently via a thermostatic cartridge with a dome type operating member incorporating a manual override button. Inlets incorporate stainless steel strainers and an approved single check valve cartridge; however, the complete product has not been fully tested to demonstrate it provides backflow protection. Maximum operating pressure 5.0 bar. Maximum operating temperature 50°C
Range of wall mounted, thermostatic blending valves incorporating ceramic disc diverter cartridges. Inlets incorporate an approved check valve cartridge, however the complete product has not been fully tested to verify backflow protection. Product also had manual override button, with variations of dome and single lever operating members. Maximum working pressure 10.0 bar. Maximum operating temperature 60°C.
Range of wafer or lugged butterfly valves incorporating blue epoxy coated ductile iron bodies, EPDM seats and stainless-steel discs. The LTDX71X-16Q DN40-150 size models are lever operated; all other models and sizes are gear operated. Maximum working pressure 10.0 bar or 16.0 bar. Maximum operating temperature 100°C.
Range of wafer, lugged and flanged butterfly valves with blue, black or red epoxy coated ductile iron bodies, zinc coated (galvanised) discs and EPDM seats. F700L & F703L models incorporate a hand wheel operating members and F700G & F703G incorporate a worm gear operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 70°C.
Range of butterfly valves incorporating blue epoxy coated ductile iron bodies, stainless-steel discs and EPDM seats. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of butterfly valves with blue epoxy coated ductile iron bodies and discs. The valves incorporate a hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Combined pre-set temperature and pressure relief valves (set at 7.0 bar) incorporating DZR brass body. The compression connection to be used with copper pipe BS EN 1057. Maximum working pressure 7.0 bar. Maximum operating temperature 95°C.
Combined pre-set temperature and pressure relief valves (set at 7.0 bar) incorporating DZR brass body. The compression connection to be used with copper pipe BS EN 1057. Maximum working pressure 7.0 bar. Maximum operating temperature 95°C.
Range of flow control valves incorporating quarter turn ceramic disc headworks housed within a brass body. Maximum working pressure 6 bar. Maximum operating temperature 60°C.
Range of double swing gate, wafer, non-return valves with blue, black or red epoxy coated ductile iron bodies. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of swing gate, non-return valves with (blue, black or red epoxy powder coated) ductile iron bodies. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
A range of non-return valve with blue epoxy coated ductile iron bodies, stainless-steel disc and EPDM seats. Maximum working pressure 16.0 Bar Maximum operating temperature 85.0°C
Range of adjustable, pilot operated pressure reducing control valves with ductile iron bodies (blue epoxy coated). The products are supplied with auxiliary stainless-steel tubing, fittings, strainer, spherical valve and DZR pilot valve, DZR electrically actuated spherical valve. Maximum inlet supply pressure 16.0 bar. Maximum outlet pressure between 2.0 bar – 12.5 bar. Maximum operating temperature 80°C.
Range of electronically actuated ball valves with brass bodies, chromium plated copper balls, PTFE and silica gel seals. Maximum working pressure 16.0 Bar. Maximum operating temperature 100°C.
Range of inline brass bodied or chrome plated brass bodied spherical valves, with a chrome plated brass ball and EPDM ‘O’-rings. SVB66MB and SV44MB models are lever operated. SV66MBC and SVT64MBC are screwdriver operated. The products are for use with PE-X pipe (manufactured to BS 7291-3), PB pipe (manufactured to BS 7291-2) and copper pipe (manufactured to EN 1057). Maximum working pressure 10.0 bar. Cold water use only.
Range of spherical valves with bronze bodies (brushed chrome plated), brass ball and PTFE seals. Incorporating a lever type operating member. Maximum working pressure 25.0 Bar Maximum operating temperature 85.0°C
Range of spherical valves with nickel plated brass bodies, brass ball and PTFE seats. Valves with compression connections are for use with copper pipe (manufactured to EN1057). Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of electrically operated motorised spherical valves incorporating brass bodies and stainless-steel balls. Maximum working pressure 20.0 bar. Maximum operating temperature: 85°C.
Range of gate valves incorporating either rising or non-rising spindle headworks and PTFE gaskets and Bronze body, bronze wedge and handwheel. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of blue or green polyethylene coated ductile iron gate valves incorporating an EPDM Wedge. The valves operate via a non-rising spindle headwork with hand wheel operating member. Maximum working pressure 16.0 Bar Maximum operating temperature 65.0°C
Range of resilient seated gate valves with cast iron bodies (blue epoxy coated), EPDM coated cast iron wedges and a handwheel operating member. Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of gate valves incorporating bronze bodies and discs with PTFE seals. The valves operate via a non-rising spindle headwork that incorporates a wheel type operating member. Maximum working pressure; 20 Bar Maximum operating temperature; 85°C
Range of hand wheel operated gate valves with blue epoxy coated ductile iron bodies and EPDM wedges. Maximum working pressure 10.0 Bar or 16.0 Bar Maximum operating temperature 40.0°C
Range of hand wheel operated gate valves with blue epoxy coated ductile iron bodies, ductile iron wedge encapsulated in EPDM. Maximum working pressure 16.0 Bar Maximum operating temperature 65.0°C
Range of gate valves with brass bodies, brass wedges and PTFE gaskets. The valves are operated via a non-rising spindle with a hand wheel operating member. The Z2020.028 compression model is for use with copper pipe (manufactured to EN1057). Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves with bronze bodies, bronze wedge and PTFE gaskets. The valves incorporate a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating blue epoxy coated ductile iron bodies and EPDM coated ductile iron wedges. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves with blue epoxy ductile iron bodies, ductile iron wedge encapsulated in EPDM. Maximum working pressure 16.0 Bar. Maximum operating temperature 85°C.
Range of resilient seated gate valves with blue epoxy coated ductile iron bodies and bonnets and ductile iron wedges encapsulated in EPDM. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 80°C.
Range of handwheel operated bronze bodied stop valves. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of screw down stop valves incorporating brass or bronze bodies and EPDM gaskets. Valves with compression connections are for use with copper pipe (manufactured to EN1057). Maximum working pressure 16.0 bar. Maximum operating temperature 80°C.
Range of inline plastic bodied screw down stop valves incorporating a non-rising spindle headwork with a dome type operating member. The products are for use with PE-X pipe (manufactured to BS 7291-3) and copper pipe (manufactured to EN 1057). Maximum working pressure 10.0 bar. Cold ater use only.
Range of double regulating valves available with bronze bodies. Products incorporate a non-rising spindle headwork. Products also include two test ports. Maximum working pressure 25.0 bar. Maximum operating temperature 85°C.
'PENTANOL DI 8055 BLACK'. Factory applied, black coloured Bitumen based coating. Apply as per manufacturer's TDS 'January HD 2024'. Cure for 7 days@30°C. For use with water up to 23°C. This material is only approved for the curing conditions that appear on the approval. If the cure conditions are varied from those specified on the approval then the material is not covered by the scope of the approval.
'Epilux 610 T Primer for use with Epilux 155 SF Topcoat'. Factory applied, white coloured (once applied) two-part epoxy coating. The topcoat can also be used alone, without the primer. 'Epilux 610 T Primer’ comprises of a base & hardener to be mixed in a 3:1 volume ratio and then applied as per manufacturer's TDS 'SEPTEMBER 2018 VERSION 1'. Cure for 16 hours@25°C – 28°C, 60%±10% RH. 'Epilux 155 SF Topcoat' comprises of a base & hardener to be mixed in a 4:1 volume ratio and then applied as manufacturer's TDS 'SEPTEMBER 2018 VERSION 1'. Cure for 7 days@25°C – 28°C, 60%±10% RH. For use with water up to 60°C. This material is only approved for the RH, mixing & curing conditions that appear on the approval. If the RH, mix and/or cure conditions are varied from those specified on the approval then the material is not covered by the scope of the approval.
'PMSP5112-M, PMSP5113-M, PMSP5114-M, PMSP5115-M, EP5112D01SC, EP5113D01SC, EP5114D01SC & EP5115D01SC'. Factory applied, blue coloured, Porcelain Vitreous Enamel coatings. Apply as per manufacturer's User Manual 'PEM 37', 'Edition 01', dated '14/10/2020'. Cure for 5 minutes@840°C. For use with water up to 85°C. This material is only approved for the curing conditions that appear on the approval. If the cure conditions are varied from those specified on the approval then the material is not covered by the scope of the approval.
'NMSP2251M, NMSP2265M, NMSP2266-M, NMSP2267-M, ER2251A01SM, ER2265A01SM, ER2266A01SC, ER2267A01SC'. Factory applied, blue coloured, Porcelain Vitreous Enamel coatings. Apply as per manufacturer's User Manual 'PEM 38', 'Edition 01', dated '14/10/2020'. Cure for 5 minutes@840°C. For use with water up to 85°C. This material is only approved for the curing conditions that appear on the approval. If the cure conditions are varied from those specified on the approval then the material is not covered by the scope of the approval.
'L-01 GP Blue-grey Enamel'. Factory applied, blue-grey coloured Enamel coating. Apply as per manufacturer's TDS 'Version: 01', dated '2025-01-02'. Cure for 15 minutes@200°C and then fire for 10 minutes@850°C. For use with water up to 85°C. This material is only approved for the curing/firing conditions that appear on the approval. If the cure/fire conditions are varied from those specified on the approval then the material is not covered by the scope of the approval.
‘BSS R/G System’. Grey coloured, factory applied, two-component epoxy coating comprising of ‘BSS Red and BSS Grey’. ‘BSS Red’ comprises of a base and curing agent which are mixed in a 3:1 volume ratio. ‘BSS Grey’ comprises of a base and curing agent which are mixed in a 3:1 volume ratio. Apply as per manufacturer's Product Data Sheet ‘BSS-D0003’, dated ‘2025-09-16’. Cure for 7 days@20°C. For use with water up to 23°C. This material is only approved for the mixing and curing conditions that appear on the approval. If the mixing and/or curing conditions are varied from those specified on the approval then the material is not covered by the scope of the approval.
'Epilux 610 T Primer for use with Epilux 155 SF Topcoat'. Factory applied, white coloured (once applied) two-part epoxy coating. The topcoat can also be used alone, without the primer. 'Epilux 610 T Primer’ comprises of a base & hardener to be mixed in a 3:1 volume ratio and then applied as per manufacturer's TDS 'Ver.3 Aug 25'. Cure for 16 hours@25°C – 28°C, 60%±10% RH. 'Epilux 155 SF Topcoat' comprises of a base & hardener to be mixed in a 4:1 volume ratio and then applied as manufacturer's TDS 'Ver2 Aug 25'. Cure for 7 days@25°C – 28°C, 60%±10% RH. For use with water up to 60°C. This material is only approved for the RH, mixing & curing conditions that appear on the approval. If the RH, mix and/or cure conditions are varied from those specified on the approval then the material is not covered by the scope of the approval.
‘Nitcote CM 210’. Site applied, two-part, grey coloured (once applied), Cementitious Waterproofing coating. Mix ‘CM 210 white’ liquid polymer and ‘CM 210 grey’ powder in a 1:3.6 weight ratio and apply two coats as per manufacturer's TDS 'UAE/0210/23/Z-1'. Cure Coat 1 for 3 hours@35°C and Coat 2 for 21 days@23°C. For use with water up to 65°C. This material is only approved for the mixing & curing conditions that appear on the approval. If the mix and/or cure conditions are varied from those specified on the approval then the material is not covered by the scope of the approval.
‘Nitocote EP 405’. Site applied, two-part,white coloured epoxy based Waterproofing coating. Mix 3.1 litres of the base with 0.9 litres of hardener and apply as per manufacturer’s TDS ‘UAE/0228/22/K’. Cure for 7 days@20°C. For use with water up to 23°C. This material is only approved for the mixing & curing conditions that appear on the approval. If the mix and/or cure conditions are varied from those specified on the approval then the material is not covered by the scope of the approval.
'Belzona 1111 (Super Metal)'. Grey coloured, site applied, two-component epoxy coating. Mix Part A (dark grey, opaque paste) with Part B (light grey, opaque paste) in a 5:1 weight ratio and apply as per manufacturers IFU ’02-07-23’. Cure for 1 day@30°C or 5 days at 5 °C. For use with water up to 23°C. This material is only approved for the mixing and curing conditions that appear on the approval. If the mix and/or cure conditions are varied from those specified on the approval then the material is not covered by the scope of the approval.
'Belzona 1331'. Grey coloured, site applied, two-component epoxy coating. First coat: Mix Belzona 1331 (white, opaque paste) parts A & B in a weight ratio of 2.2:1 and apply as per manufacturer’s IFU ’06-03-19’. Cure for 6-8 hours@10°C or 3-4 hours@30°C then apply: Second coat: Mix Belzona 1331 (grey, opaque paste) parts A & B in a weight ratio of 2.2:1 and apply as per manufacturer’s IFU ’06-03-19’. Cure in accordance with manufacturer’s IFU ’06-03-19’, ‘Completion of the Molecular Reaction’ table, ‘Full mechanical/thermal loading or water immersion’. For use with water up to 23°C. This material is only approved for the mixing and curing conditions that appear on the approval. If the mix and/or cure conditions are varied from those specified on the approval then the material is not covered by the scope of the approval.
'Belzona 5811DW2 (grey)'. Grey coloured, site applied, two-component epoxy coating. Mix Part A (grey, opaque glossy paste) with Part B (orange, transparent liquid) in a 4:1 mass ratio and apply as per manufacturer’s IFU ’16-03-19’. Cure for 4 days@30°C. For use with water up to 23°C. This material is only approved for the mixing and curing conditions that appear on the approval. If the mix and/or cure conditions are varied from those specified on the approval then the material is not covered by the scope of the approval.
‘Corroless RF35 (2024) Coating System’. Site applied, grey coloured (once applied), two-part epoxy coating. The primer comprises of ‘Corroless EPF (2022) Primer Base Red’ and ‘Corroless EPF (2022) Buff Temperate Hardener’, to be mixed in a 1:1 volume ratio and applied as per manufacturer’s TDS issued ‘June 2024’. Cure for 24 hours at 10°C. The coating comprises of ‘Corroless RF35 (2024) Base 00-A-01 Portland’ and ‘Corroless RF35 (2024) Hardener’, to be mixed in 5.5:1 weight ratio and applied as per manufacturer’s TDS issued ‘June 2024’. Cure for 7 days at 10°C. For use with water up to 23°C. This material is only approved for the mixing & curing conditions that appear on the approval. If the mix and/or cure conditions are varied from those specified on the approval then the material is not covered by the scope of the approval.
'REGZ40 & REGZ41'. white coloured (translucent) silicone grease. Apply as per manufacturer's instructions. For use with water up to 65°C.
'Grivory GVN-5H black 9915'. Black coloured, injection moulded PA 66 + PA 6I/X-GF50 material. For use with water up to 85°C.
'TECHNYL ® SAFE A 219WFC V30 BK’ (black coloured) & ‘TECHNYL ® SAFE A 219WFC V30 NC’ (natural, appears off-white). Injection moulded, glass fibre reinforced polyamide 6.6 materials. For use with water up to 85°C.
Grilamid LV-30H FWA natural. Grilamid LV-30H FWA black 9225. Grilamid LV-30H FWA grey 9497. Grilamid LV-43H FWA black 9225. Grilamid LV-50H FWA black 9225. Natural (appear white), black or grey, injection moulded, glass fibre reinforced nylon materials. For use with water up to 85°C.
'IP 90606'. Orange coloured, injection moulded Polyester resin material. For use with water up to 50°C.
'Innogaz'. Black coloured, injection moulded, HDPE (PE100) electrofusion fittings. For use with water up to 60°C.
'Reno 100+'. Dual layered, extruded polyethylene pipe comprising of a black coloured inner and blue coloured outer layer. For use with water up to 23°C.
'Langboone HDPE Pipe P01'. Black coloured (with blue external stripes), extruded HDPE pipe. For use with water up to 23°C.
'Langboone HDPE Fitting F01'. Black coloured, injection moulded HDPE fitting. For use with water up to 23°C.
'XS10B & XRC30B'. Black coloured, extruded, Polyethylene materials. For use with water up to 23°C.
Grades manufactured in Marietta, Ohio: Radel R-5100 NT 15, R-5000 NT, R-5000 NT ECHO RP, R-5100 NT ECHO RP, & R-5100 NT (natural). Radel R-5100 BU 1197 & R-5100 BU1197 ECHO RP (blue coloured). Grades manufactured in Oudenaarde, Belgium & Marietta, Ohio Radel R-5100 GY 1037, R-5100 GY1037 ECHO RP, R-5100 GY1037LF & R-5100 GY1037 LF ECHO RP (grey coloured). Radel R-5100 BK 937 & R-5100 BK937 ECHO RP (black coloured). Radel R-5500NT & R-5100 NT15 ECHO RP (natural). Radel 5100 BU 1197 ECHO RP (blue coloured). Injection moulded, polyphenylsulfone materials. For use with water up to 85°C.
'Lamella Profiles DW-82 PP, DW-52PP, Dek-50 PP & Dek-80 PP’. Black coloured, extruded, Polypropylene lamella profile components. For use with water up to 23°C.
'NOVATHERM Pipe'. Green coloured (with external red stripes), extruded PPR pipe. For use with water up to 60°C.
'NOVATHERM Fittings'. Green coloured, injection moulded PPR fittings. For use with water up to 60°C.
'Vesbo Pipe'. Green coloured (with external red stripes), extruded PPR pipe. For use with water up to 60°C.
'Vesbo Fittings'. Green coloured, injection moulded PPR fittings. For use with water up to 60°C.
‘Udel P-3500 NT LCD, GF-110 NT, GF-120 NT, GF-121 NT, P-1700 NT 11 MR, P-1700 NT 11, GF-121 NT ECHO RP & P-3500 NT LCD ECHO RP’ (all beige translucent). ‘Udel P-1700 Grey 8057’ (grey coloured). ‘Udel P-1700 BK 937, P-1700 BK 937 MR, GF-120 BK 937, GF-121 BK 937, GF-121 BK 937 ECHO RP, GF-120 BK 937 ECHO RP & P-1700 BK937 ECHO RP’ (all black coloured). ‘Udel P-1700 WH 7407’ (white coloured). Injection moulded, polysulphone materials. For use with water up to 85°C.
‘AQI380PRO’. Site applied, two-part (resin & hardener is automatically mixed in a 10:1 volume ratio through dispensing nozzle) anchor resins. Apply and cure as per ’Load time’ cures set out in Table B4 of European Technical Assessment ETA 19/0127’, dated ‘28/02/2019’. For use with water up to 65°C. If the cure conditions are varied from those specified in ’Load time’ cures set out in set out in Table B4 of European Technical Assessment ‘ETA 19/0127’ then the materials are not covered by the scope of the approval. For use only as a resin anchor having been tested at a reduced surface area to volume ratio of 1,000mm² per 1 litre of water.
'Polymax E708DW 'O' rings'. Black coloured, compression moulded EPDM 'O' rings. Shore hardness 70A. Tested in-radius size 1.85mm. For use with water 85°C.
'DLYY E6202'. Black coloured, compression moulded EPDM material. Shore hardness 60. Tested in-radius size 1.1mm. For use with water up to 23°C.
'WE-HR-01'. Black coloured, compression moulded EPDM rubber material. Shore hardness 75. Tested in-radius size 0.99mm. For use with water up to 85°C.
'Dutral K-Co-054'. Black coloured, compression moulded EPDM materials. Shore hardness between 52A & 80A. Tested in-radius size 1.0mm. For use with water up to 65°C.
'EP500'. Black coloured, injection moulded EPDM rubber material. Shore hardness 70. Tested in-radius size 1.0mm. For use with water up to 85°C.
'SM177'. Black coloured, compression moulded EPDM rubber. Shore hardness 70. Tested in-radius size 1.56mm. For use with water up to 23°C.
'EPDM E282'. Black coloured, compression moulded EPDM sheet material. Shore hardness 80A. Tested in-radius size 1.0 For use with water up to 85°C.
'KF011670FDA'. Black coloured, compression moulded, FKM rubber material. Shore hardness 70. Tested in-radius size 1.0mm. For use with water up to 85°C.
Range of injection moulded, VMQ rubber gaskets, seals, & `O` rings manufactured from the below compounds. The components are available in blue, green, grey, opaque (beige coloured), red, transparent & yellow. The numbers in the name of the compound indicates the shore hardness between 40 & 80. Tested in-radii sizes: Gaskets: 0.2mm - 5.0mm. Seals & `O` rings: 0.5mm - 5.0mm. S50B04E, S60B00E, S70B06E, S70B07E, S70V02E, S50V01E, S60O02E, S70O05E, S50O03E, S50O05E, S60O01E, S70O03E, S40A01E, S60A00E, S70A02E, S40R03E, S45R01E, S50R10E, S50R01E, S60R05E, S65R04E, S70R04E, S80R01E, S40R02E, S50R06E, S60R07E, S70R19E, S70R24E, S50T05E, S50T00E, S55T00E, S60T00E, S60T00T, S70T04E, S70T00E, S75T00E, S80T00E, & S70G01E. For use with water up to 85°C.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4203801-1 | chrome | 1/2" BSP | 5 bar | 60 °C | KINEN | on body | No | Ceramic cartridge | Shower Hose, Handset, |
Single hole, single outlet (fixed) electronically controlled tap assemblies (chromium plated brass), flow is controlled by a solenoid valve, activated via an infra-red sensor. The product is supplied with a combined TPE washer and stainless-steel strainer to be installed on the inlet to the solenoid. The spout outlet incorporates a plastic flow straightener. Maximum working pressure 8.0 bar. Maximum operating temperature 65°C.
Single hole, single outlet (fixed) electronically controlled tap assemblies (chromium plated brass), flow is controlled by a solenoid valve, activated via an infra-red sensor. The product is supplied with a combined TPE washer and stainless-steel strainer to be installed on the inlet to the solenoid. The spout outlet incorporates a plastic flow straightener. Maximum working pressure 8.0 bar. Maximum operating temperature 65°C.
Single hole, single outlet (fixed) electronically controlled tap assemblies (chromium plated brass), flow is controlled by a solenoid valve, activated via an infra-red sensor. The product is supplied with a combined TPE washer and stainless-steel strainer to be installed on the inlet to the solenoid. The spout outlet incorporates a plastic flow straightener. Maximum working pressure 8.0 bar. Maximum operating temperature 65°C.
Single hole, single outlet (fixed) electronically controlled tap assemblies (chromium plated brass), flow is controlled by a solenoid valve, activated via an infra-red sensor. The product is supplied with a combined TPE washer and stainless-steel strainer to be installed on the inlet to the solenoid. The spout outlet incorporates a plastic flow straightener. Maximum working pressure 8.0 bar. Maximum operating temperature 65°C.
Range of bottom and side entry BS1212-4 (2016) compact type float operated inlet valves, for WC flushing cisterns with plastic bodies and adjustable floats and a plastic flow regulator at the inlet. Maximum operating pressure: 10 bar. Maximum operating temperature: 23°C.
Side entry BS1212-4 (2016) compact type float operated valve for WC flushing cisterns. The inlet incorporates a flow restrictor. Maximum working pressure 10.0 bar. Cold water use only.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| TVT103002000xx | xx | 1/2" BSP M | 10 bar | 60 °C | Villeroy and Boch logo | handle | No | Ceramic cartridge | Aerator | ||
| TVT104001000xx | xx | 1/2" BSP M | 10 bar | 60 °C | Villeroy and Boch logo | handle | No | Ceramic cartridge | Aerator |
Where xx denotes the surface finish (which is a non-water contact part) 61 = Chrome, 74 = Brushed Chrome, 64 = Brushed Nickel Matt, 65 = Polished Nickel, 60 = English Gold, 76 = Brushed Gold, K5 = Matt black, 70 = Dune, 63 = Graphite
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| TVT105501110XX | See Below | 1/2" BSP M | 10 bar | 60 °C | Villeroy and Boch logo | Lever | No | Ceramic cartridge | Aerator |
Where xx denotes the surface finish (which is a non-water contact part) 61 = Chrome, 74 = Brushed Chrome, 64 = Brushed Nickel Matt, 65 = Polished Nickel, 60 = English Gold, 76 = Brushed Gold, K5 = Matt black, 70 = Dune, 63 = Graphite
Wall mounted two hole, single outlet (fixed) combination tap assembly (chromium plated brass) incorporating a ceramic cartridge headworks with cube operating member and incorporating a self-cancelling diverter to shower outlet with Type HC backflow protection device (verified by test - suitable for backflow protection against Fluid Category 3). The inlets incorporate a stainless-steel strainer and an approved check valve cartridge, however, the complete product has not been fully tested to demonstrate it provides backflow protection. The spout outlet incorporates a plastic aerator. Maximum working pressure 10.0 bar. Maximum operating temperature 60°C.
Range of spherical valves with DZR brass bodies, chromium plated brass balls, PTFE seats and EPDM rubber ‘O’-ring. The products also incorporate a ‘Y’- Patterned stainless steel strainer. Compression connection to be used with copper EN1057. AI-0396A062815CR incorporates an approved single check valve cartridge, verified by test - suitable for backflow protection against fluid category 2. Maximum working pressure: 25.0 bar. Maximum operating temperature: 100°C (model AI-0396A062815CR 65°).
Range of wall mounted, two-hole, single outlet (fixed) combination tap assemblies (chrome plated brass) bodies. The flow is controlled via a solenoid valve activated via an infra-red sensor. The temperature is controlled independently via a thermostatic cartridge. The products incorporate approved check valve cartridges; however, the complete product has not been fully tested to demonstrate it provides backflow protection. The inlets incorporate a stainless-steel strainer. The products are supplied with spherical valves for both inlets. Maximum working pressure 5.0 bar. Maximum operating temperature 65°C.
Range of wall mounted, two-hole, single outlet (fixed) combination tap assemblies (chrome plated brass) bodies. The flow is controlled via a solenoid valve activated via an infra-red sensor. The temperature is controlled independently via a thermostatic cartridge. The products incorporate approved check valve cartridges; however, the complete product has not been fully tested to demonstrate it provides backflow protection. The inlets incorporate a stainless-steel strainer. The products are supplied with spherical valves for both inlets. Maximum working pressure 5.0 bar. Maximum operating temperature 65°C.
Range of shower hoses. The H-38033 model has a PVC inner liner and stainless steel interlocked outer casing. The H-38034 and H-38035 models are multi-layer shower hoses with a PVC inner liner. Maximum operating temperature 60°C. Open outlet use only.
Range of T type thermostatic mixing valves with chrome plated DZR brass bodies. Compression and push-fit models for use with copper pipe manufactured to EN1057. Models 37.20122.015.CP,37.20122.022.CP, 37.21122.015.CP, 37.21122.022.CP, 37.21222.015.CP, 37.21222.022.CP, 37.20162.015.CP, 37.20162.022.CP have isolation valves and strainers on the inlet. Maximum working pressure 10.0 Bar. Maximum operating temperature 85.0°C.
Spring loaded, resilient trim check valve cartridge with plastic body and EPDM O-rings. For insertion into fittings with specifically sized bores. Maximum working pressure: 16 Bar. Maximum operating temperature: 85°C.
Range of non-verifiable single check valve assemblies with DZR brass bodies. Maximum operating pressure 10.0 bar. Maximum operating temperatures: 430357-003, 430357-004 and 430357-006 models: 85°C, 430357-008, 430357-010, 430357-011 and 430357-012 models: 65°C.
Non-verifiable single check valve assembly with a stainless-steel body. Maximum working pressure 10.0 bar. Maximum operating temperature of 85°C.
Range of double check valve assemblies, incorporating two spring loaded resilient trim in-line check valve cartridges housed in DZR brass or nickel plated DZR brass bodies. Compression connection to be used with copper pipe EN1057. Maximum working pressure 10.0 bar. Maximum operating temperature 85°C.
‘TankBoost’ range of cold-water storage cisterns, incorporating a float operated inlet valve. The C5 suffix models incorporate a Type ‘AB’ air gap with a meshed weir overflow (verified by test - suitable for backflow protection against Fluid Category 5). Cisterns with SUB in the model code incorporate a submersible pump and an expansion vessel. All models incorporate a screened warning pipe and dip tube. Models without a C5 suffix also incorporate a screened breather. Maximum working pressure 10.0 bar. Cold water use only.
‘TankBoost 5 bar’ range of cold-water storage cisterns, incorporating a float operated inlet valve. The C5 suffix models incorporate a Type ‘AB’ air gap with a meshed weir overflow (verified by test - suitable for backflow protection against Fluid Category 5). Cisterns with SUB in the model code incorporate a submersible pump and an expansion vessel. All models incorporate a screened warning pipe and dip tube. Models without a C5 suffix also incorporate a screened breather. Maximum working pressure 10.0 bar. Cold water use only.
Single hole, single outlet (fixed) over the rim (swivel nozzle) bidet combination tap assemblies with brass bodies (various finishes). Incorporating a quarter turn ceramic disc headworks and cross top operating member. The spout outlet incorporates a plastic aerator. The product is supplied with a click type waste (not verified by test). Maximum working pressure 10.0 Bar Maximum operating temperature 60.0°C
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| D22 | 22 mm | 10 bar | 85 °C | Gear, D22, Production date (DD/MM/YY) | Body | No | |||||
| D15H | 15 mm | 10 bar | 85 °C | Gear | Body | No | |||||
| D15C | 15 mm | 10 bar | 85 °C | Gear | Body | No | |||||
| R19H | 19 mm | 10 bar | 85 °C | Gear, 19H, Production date (DDMMYY) | Body | No | |||||
| R19C | 19 mm | 10 bar | 85 °C | Gear, 19C, Production date (DDMMYY) | Body | No |
Non-rising spindle headworks (cast brass body) with EPDM ‘O’-rings and seat washer. For insertion into specifically dimensioned tap assemblies. Maximum working pressure 10.0 Bar. Maximum operating temperature 85°C.
Non rising spindle headwork incorporating a brass body and NBR seals. For insertion into specifically dimensioned tap assemblies. Maximum working pressure 10.0 bar. Maximum operating temperature 85°C.
Single hole, single outlet (swivel) combination tap assembly with brass body (chromium plated), incorporating a ceramic cartridge headworks and single lever operating member. The spout outlet incorporates a pull-out spray with plastic aerator. The cold inlet and shower handset incorporates an approved check valve cartridge, however, the complete product has not been fully tested to demonstrate it provides backflow protection. Maximum working pressure 5.0 bar. Maximum operating temperature 60°C.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MA3580-Z | chrome | / | 10 bar | 60 °C | GAOAO | on body | No | Ceramic cartridge | C-plate | Aerator | |
| MA3581-Z | chrome | / | 10 bar | 60 °C | GAOAO | on body | No | Ceramic cartridge | C-plate | Aerator | |
| MA3582-Z | chrome | / | 10 bar | 60 °C | GAOAO | on body | No | Ceramic cartridge | C-plate | Aerator | |
| MA3584-Z | chrome | / | 10 bar | 60 °C | GAOAO | on body | No | Ceramic cartridge | C-plate | Aerator |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 305B1 | Chrome | M10，female | 10 bar | 60 °C | XINYA,WRAS | Body | No | Ceramic cartridge | C-plate | Aerator | |
| 824B | Chrome | M10，female | 10 bar | 60 °C | XINYA,WRAS | Body | No | Ceramic cartridge | C-plate | Open Outlet |
Range of single hole, single outlet (fixed) combination tap assemblies (chromium plated brass), incorporating ceramic cartridge headworks with a single lever operating member. The spout outlet incorporates a plastic aerator. Maximum working pressure 10.0 Bar Maximum operating temperature 60.0°C
Single hole, single outlet (fixed) combination tap assemblies (chromium plated brass), incorporating a ceramic cartridge headwork & single lever operating member. The spout outlet incorporates a plastic aerator. The aerator also includes an integral stainless-steel strainer Maximum working pressure 10.0 bar. Maximum operating temperature 85°C.
Range of single-hole, single outlet (fixed) combination tap assemblies (brass bodies – various finishes), incorporating ceramic cartridge headworks with single lever or dome type operating members. The spout outlets are either open outlet or incorporate plastic aerators. Maximum working pressure 10.0 Bar. Maximum operating temperature 60°C.
Range of single hole, single outlet (swivel) combination tap assemblies (chromium plated brass), incorporating quarter turn ceramic disc headworks with single lever operating members. The spout outlet incorporates a plastic aerator. Maximum working pressure 5.0 bar. Maximum operating temperature 60°C.
Single hole, single outlet (swivel) combination tap assembly with brass body (chromium plated), incorporating a ceramic cartridge headworks and single lever operating member. The outlet incorporates a plastic aerator. One inlet hose incorporates an approved check valve cartridge, however, the complete product has not been fully tested to demonstrate it provides backflow protection. Maximum working pressure 5.0 bar. Maximum operating temperature 60°C.
Range of single hole, single outlet (swivel) combination tap assemblies (brass bodies, various finishes), incorporating a ceramic cartridge headwork with a single lever operating member and the spout outlet incorporates a plastic aerator. Maximum working pressure; 10 Bar Maximum operating temperature 60°C
Single hole, single outlet (swivel) combination tap assembly (chromium plated brass), incorporating a ceramic cartridge headwork with a single lever operating member. The spout outlet incorporates a plastic aerator. Maximum working pressure 5.5 bar. Maximum operating temperature 60°C.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| M 07119A-L25 | Chrome | G3/4(M) | 10 bar | 60 °C | AMG,WRAS | Body | No | 1/4 Turn ceramic disk | Metal Backnuts | Flow Straightener | |
| M 07119A-L25-B | Matt black | G3/4(M) | 10 bar | 60 °C | AMG,WRAS | Body | No | 1/4 Turn ceramic disk | Metal Backnuts | Flow Straightener | |
| M 08119A-L10 | Chrome | G3/4(M) | 10 bar | 60 °C | AMG,WRAS | Body | No | 1/4 Turn ceramic disk | Metal Backnuts | Flow Straightener | |
| M 08119A-L10-B | Matt black | G3/4(M) | 10 bar | 60 °C | AMG,WRAS | Body | No | 1/4 Turn ceramic disk | Metal Backnuts | Flow Straightener |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 504109 | chrome | G3/4 | 16 bar | 60 °C | KINEN | on body | No | 1/4 Turn ceramic disk | Metal Backnuts | Aerator | |
| 5594201 | chrome | G3/4 | 16 bar | 60 °C | KINEN | on body | No | 1/4 Turn ceramic disk | Metal Backnuts | Aerator | |
| 144201 | chrome | G3/4 | 16 bar | 60 °C | KINEN | on body | No | 1/4 Turn ceramic disk | Metal Backnuts | Aerator |
Range of two hole, single outlet (fixed) combination tap assemblies with brass bodies (various finishes) incorporating ceramic cartridge headworks with single lever operating members Spout outlets incorporate a plastic aerator. Maximum working pressure 5.0 bar. Maximum operating temperature 60°C.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| USH0228 | chrome | 3/4" x 1/2" offset unions | 10 bar | 60 °C | SONAS | on body | No | 1/4 Turn ceramic disk |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 1L446100MA | Tri-chrome | 3/4" BSP (M) | 10 bar | 65 °C | WIDE | Body | No | 1/4 Turn ceramic disk | Metal Backnuts | Aerator | Shower Hose, Handset, |
| 1L446100DH | Matt black | 3/4" BSP (M) | 10 bar | 65 °C | WIDE | Body | No | 1/4 Turn ceramic disk | Metal Backnuts | Aerator | Shower Hose, Handset, |
| 1L446100SA1 | Brushed gold | 3/4" BSP (M) | 10 bar | 65 °C | WIDE | Body | No | 1/4 Turn ceramic disk | Metal Backnuts | Aerator | Shower Hose, Handset, |
Range of wall mounted, two-hole, single outlet, fixed, combination tap assemblies (chrome plated brass bodies), incorporating quarter turn ceramic disc headworks with single lever operating members. The spout outlets incorporate plastic aerators. Products incorporate a hand shower and a manual diverter to shower outlet. Models incorporate approved check valve cartridges; however, the complete products have not been fully tested to demonstrate they provide backflow protection. Maximum working pressure: 6.0 Bar. Maximum operating temperature: 65°C.
Range of deck mounted, two-hole, single outlet, fixed, combination tap assemblies (chrome plated brass bodies), incorporating quarter turn ceramic disc headworks with single lever operating members. The spout outlets incorporate a plastic aerator, and manual diverter to shower outlet. Products supplied with shower hose and handset. Models incorporate approved check valve cartridges; however, the complete products have not been fully tested to demonstrate they provide backflow protection. Maximum working pressure: 6.0 Bar Maximum operating temperature: 65°C
Wall mounted, two hole, single outlet (fixed) combination tap assemblies (chromium plated brass), incorporating a quarter turn ceramic disc headwork with a dome type operating member. The temperature is controlled independently via a thermostatic cartridge incorporating a dome type operating member and a manual override button. Each inlet incorporates a combined NBR washer and stainless steel strainer, and an approved check valve cartridge, however, the complete product has not been fully tested to demonstrate it provides backflow protection. The spout outlet incorporates a self cancelling diverter to shower outlet and a plastic flow straightener. Maximum working pressure 10.0 bar.
Non-metallic materials and components comply with BS6920 at 65°C
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| K005* | Various | ½" captive nut | 5 bar | 65 °C | WINSDRUM | On Spout | No | Ceramic cartridge | Metal Backnuts | Aerator | Interconnecting Hoses, |
| K008* | Various | ½" captive nut | 10 bar | 65 °C | WINSDRUM | On body | No | 1/4 Turn ceramic disk | Metal Backnuts | Aerator |
* denotes finish and can be replaced by: C - Chrome RG - Rose Gold BTG - Brushed Titanium gold BZG - Brushed Zirconium gold BRG - Brushed Rose gold MW - Matte white BS - Brushed stainless BN - Brushed nickel PN - Polished nickel GM - Gunmetal B - Matte black TG - Titanium gold ZG - Zirconium gold BC - Black+chrome W - White CW - Chrome+white Q - Quartzite ZGC - Zirconium gold+chrome TGC - Titanium gold+chrome M - Medieval A - Antique bronze CP - Champagne BL - Brushed lead BP - Polished Black
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Wastes | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| HGLS20 | Various | 15mm | 6 bar | 65 °C | Logo | on spout | No | Plastic Backnuts | Aerator | Click Type | Flow Regulator Fitted, Interconnecting Hoses, | |
| HGLS38 | Various | 15mm | 6 bar | 65 °C | Logo | on spout | No | Plastic Backnuts | Aerator | Click Type | Flow Regulator Fitted, Interconnecting Hoses, | |
| HGLS30 | Various | 15mm | 6 bar | 65 °C | Logo | on spout | No | Plastic Backnuts | Aerator | Click Type | Flow Regulator Fitted, Interconnecting Hoses, | |
| FLLS20 | Various | 15mm | 6 bar | 65 °C | Logo | on spout | No | Plastic Backnuts | Aerator | Click Type | Flow Regulator Fitted, Interconnecting Hoses, | |
| FLLS30 | Various | 15mm | 6 bar | 65 °C | Logo | on spout | No | Plastic Backnuts | Aerator | Click Type | Flow Regulator Fitted, Interconnecting Hoses, |
Range of three-hole, metal, single outlet (fixed) deck mounted, combination tap assemblies, (brass bodies - various finishes, see model), incorporating quarter turn ceramic disc headworks with lever or cross top operating members. The products are supplied with stainless steel braided PEX lined inter-connecting hoses. The spout outlet incorporates a plastic aerator. Maximum working pressure 10.0 bar. Maximum operating temperature 60°C.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 20.189.002 | Various | G 1/2" | 10 bar | 65 °C | Grohe | Spout | No | 1/4 Turn ceramic disk | Not Applicable | Aerator | |
| 20.193.002 | Various | G 1/2" | 10 bar | 65 °C | Grohe | Spout | No | 1/4 Turn ceramic disk | Not Applicable | Aerator |
Where xxx denotes finish, can be replaced by: 002 – Chrome DC2 – Supersteel DA2 – Warm sunset AL2 – Brushed hard graphite A02 – hard graphit DL2 – brushed warm sunset GN2 – brushed cool sunrise A02 – hard graphite MS2 – satin steel GL2 – cool sunrise MS2 – satin graphite
Range of chemical dosing equipment which incorporate self-closing valves and plastic bodies. The outlet of the injector incorporates a connection for injection of chemicals via venturi action and the inlets include stainless-steel strainers. Maximum operating pressure 9 bar. Maximum operating temperature 70°C.
Filling loop assembly consisting of an in-line isolation valve, an in-line double check valve assembly (suitable for back flow protection against fluid category 3) that incorporates an isolation valve and a stainless-steel braided EPDM lined hose. Maximum working pressure 10.0 bar. Maximum operating temperature 85°C.
Non-metallic materials and components comply with BS6920 at 85°C
Range of Socket weld, Click weld, Butt weld and Electro fusion fittings (see models), for use with ABN//INSTAL CT Faser RD Series 3.2 / SDR 7.4 & ABN//INSTAL CT Faser RD Series 5 / SDR 11 pipe. Maximum working pressure; (see models) Maximum operating temperature; (see models)
Range of brass compression fittings for use with copper pipes (manufactured to EN 1057). For above ground use only. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Flange fittings with TP2 copper bodies, for use with TP2 copper pipe to EN1057. Above ground use only. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of end feed copper fittings for use with copper pipes (manufactured to EN 1057). The 5043G series and 5002G series models incorporate an EPDM ‘O’-ring on the captive nut connection. For above and below ground use. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Dual flush, WC outlet valves. The valves are operated via a push button assembly for either full or reduced flush and incorporates an internal overflow. Cold water use only.
Electric instantaneous, vented, mains water heater. Maximum operating temperature 98°C.
Range of ultrasonic dry type water meters with brass bodies. Maximum working pressure 16.0 Bar. Maximum operating temperature 50.0°C.
CM(E) range of electronically operated pumps available in stainless steel, (‘EN 1.4301/AISI304’ or ‘EN 1.4401 /AISI316’) and cast iron. The pumps are supplied with Sic-Sic mechanical shaft seals and FKM or EPDM seals. Maximum operating parameters: Cast iron models: Maximum working pressure 6.0 bar @ 90°C. Maximum working pressure 10.0 bar @ 40°C. Stainless steel models (not self-priming variants): Maximum working pressure 10.0 bar @ 99°C. Maximum working pressure 16.0 bar @ 90°C. Stainless steel self-priming models (CM(E) 1, 3 & 5 (AISI 304) only): Maximum working pressure 10.0 or 16.0 bar @ 60°C.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| FH SLRD01 C | chrome | 1/2" BSP (F) | 5.0 bar | 85 °C | Bristan | Body | No | Not Applicable | Not Applicable | Fixed Head, | |
| FH SLRD01 BB | Brushed Brass | 1/2" BSP (F) | 5.0 bar | 85 °C | Bristan | Body | No | Not Applicable | Not Applicable | Fixed Head, | |
| FH SLRD01 GM | Gun Metal | 1/2" BSP (F) | 5.0 bar | 85 °C | Bristan | Body | No | Not Applicable | Not Applicable | Fixed Head, | |
| FH SLRD02 C | chrome | 1/2" BSP (F) | 5.0 bar | 85 °C | Bristan | Body | No | Not Applicable | Not Applicable | Fixed Head, | |
| FH SLRD03 C | chrome | 1/2" BSP (F) | 5.0 bar | 85 °C | Bristan | Body | No | Not Applicable | Not Applicable | Fixed Head, | |
| 225788 | chrome | 1/2" BSP (F) | 5.0 bar | 85 °C | Bristan | Body | No | Not Applicable | Not Applicable | Fixed Head, | |
| RP3 FH SLRD01 C | chrome 3 | 1/2" BSP (F) | 5.0 bar | 85 °C | Bristan | Body | No | Not Applicable | Not Applicable | Fixed Head, | |
| FH TDRD01 C | chrome | 1/2" BSP (F) | 5.0 bar | 85 °C | Bristan | Nut | No | Not Applicable | Not Applicable | Fixed Head, | |
| FH TDRD02 C | chrome | 1/2" BSP (F) | 5.0 bar | 85 °C | Bristan | Nut | No | Not Applicable | Not Applicable | Fixed Head, | |
| FH TDRD02 G | Gold | 1/2" BSP (F) | 5.0 bar | 85 °C | Bristan | Nut | No | Not Applicable | Not Applicable | Fixed Head, | |
| FH TDRD03 C | chrome | 1/2" BSP (F) | 5.0 bar | 85 °C | Bristan | Nut | No | Not Applicable | Not Applicable | Fixed Head, |
Two Fixed Head's with different finish and size as below FH SLRD01 C / BB / GM - (Dia 200mm) FH SLRD02 C - (Dia 250mm) FH SLRD03 C - (Dia 300mm) 225788 - (Wickes selling code for FH SLRD03 C) RP3 FH SLRD01 C - (Dia 200mm, chrome 3) FH TDRD01 C - (Dia 157mm) FH TDRD01 C / G - (Dia 200mm) FH TDRD03 C - (Dia 300mm)
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| JD-WH51-8** | Various | BSP 1/2" (F) | Open outlet use only bar | 60 °C | Kind | Inlet connector | No | ||||
| JD-WH51-10** | Various | BSP 1/2" (F) | Open outlet use only bar | 60 °C | Kind | Inlet connector | No | ||||
| JD-WH51-12** | Various | BSP 1/2" (F) | Open outlet use only bar | 60 °C | Kind | Inlet connector | No | ||||
| JD-WH52-8** | Various | BSP 1/2" (F) | Open outlet use only bar | 60 °C | Kind | Inlet connector | No | ||||
| JD-WH52-10** | Various | BSP 1/2" (F) | Open outlet use only bar | 60 °C | Kind | Inlet connector | No | ||||
| JD-WH52-12** | Various | BSP 1/2" (F) | Open outlet use only bar | 60 °C | Kind | Inlet connector | No | ||||
| JD-WH03** | Various | BSP 1/2" (M) | Open outlet use only bar | 60 °C | Kind | Body | No | ||||
| JD-WH05** | Various | BSP 1/2" (M) | Open outlet use only bar | 60 °C | Kind | Body | No | ||||
| JD-HA61** | Various | BSP 1/2" (M) | Open outlet use only bar | 60 °C | Kind | Body | No | ||||
| JD-HA60** | Various | BSP 1/2" (M) | Open outlet use only bar | 60 °C | Kind | Body | No | ||||
| JD-HA55** | Various | BSP 1/2" (M) | Open outlet use only bar | 60 °C | Kind | Body | No | ||||
| JD-HA54** | Various | BSP 1/2" (M) | Open outlet use only bar | 60 °C | Kind | Body | No |
The suffixes of ** represents different types of finishes as follows: C: Chrome NS: Nickel brushed RP: Red powder coated TS: Zr gold brushed RS: Rose gold brushed GS: Gold brushed GM: Gun metal brushed B: Electroplated matte black W: White CB: Matte black and chrome CW: White and chrome TG: Zr gold plated RG: Rose gold plated G: Gold plated GP: Gun metal plated BS: Gun gray brushed
Range of shower handsets with ABS bodies (various finishes, see model). The spray outlet is either multifunction or single function depending on series. Open outlet use only. Maximum operating temperature 60°C.
Range of wall mounted or ceiling mounted shower arms with brass bodies (various finishes - see model). Maximum operating temperature 65°C.
Range of In-line Y patterned strainers with ductle iron bodies (blue epoxy powder coated) and stainless-steel mesh. Maximum working pressure: 16 Bar Maximum operating temperature: 85 °C
Range of in-line Y pattern strainers with bronze bodies, forged brass cap and stainless- steel screen. Threaded end connections to BS21 ISO7/1 r/c (BSP taper – JIS B0203) Maximum working pressure 25 bar. Maximum operating temperature 23˚C.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| FBA015 | Bronze | 1/2" BSP (M) | 16 bar | 85 °C | Zhejiang Tasan Flow Tech logo, C84400, size, arrow, Date of manufacture(WWYY), WRAS | Body | No | Rising spindle | Not Applicable | Not Applicable | |
| FBA020 | Bronze | 3/4" BSP (M) | 16 bar | 85 °C | Zhejiang Tasan Flow Tech logo, C84400, size, arrow, Date of manufacture(WWYY), WRAS | Body | No | Rising spindle | Not Applicable | Not Applicable |
Range of drain taps with a brass body (some models chrome plated) and rising spindle headwork. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SD2001 | 1/2" BSP (M) | 16 bar | 85 °C | SD and size | Body | No | |||||
| SD2001 | 3/4" BSP (M) | 16 bar | 85 °C | SD and size | Body | No |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| VAL2 HNK FL5 C CD | Chrome | 1/2" BSP (M) | 5 bar | 60 °C | Bristan | Operating member | No | 1/4 Turn ceramic disk | Metal Backnuts | Flow Straightener | Flow Regulator Fitted, |
| TAP1103 | Chrome | 1/2" BSP (M) | 5 bar | 60 °C | Bristan | Operating member | No | 1/4 Turn ceramic disk | Metal Backnuts | Flow Straightener | Flow Regulator Fitted, |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| M3401 X XXX | VARIOUS | 1/2” BSP | 10.0 bar | 65 °C | PPI | REAR OF BODY | No | 1/2 Turn ceramic disk | Metal Backnuts | Aerator & Flow Straightener | Flow Regulator Fitted, |
X XXX Denotes the following: First X: Different handle option and the second, third & fourth XXX for different finishes: Handles: A – Single lever type Chrome – No suffix, brushed brass – BGP, PVD Gold – PVD, Brushed Nickel – BN1, Gun Metal – GMG, Matt Black – MBK, Matt White – MWH, Stainless Steel – SS1, Black Chrome – BCP, Titanium – TIB and Antique Bronze – AB1
Range of pillar taps (chrome plated brass bodies) incorporating quarter turn ceramic disc headworks with single lever operating members and flow regulator in the inlet (1/2” only). The spout outlets incorporate a plastic flow straightener. The product is supplied with metal back nuts. Maximum working pressure: 10.0 Bar Maximum operating temperature: 85°C
Deck mounted pillar tap (chrome plated brass body) incorporating quarter turn ceramic disc headwork with a dome type operating member. The spout outlet incorporates a plastic aerator. Maximum working pressure 10.0 Bar Maximum operating temperature 60.0°C
Range of shower hoses, multi-layered hose (various external finishes) with PVC inner liner, brass end connections. Open outlet use only. Maximum operating temperature 60°C.
Range of chromium plated stainless steel or brass interlocked shower hoses with an optional PVC outer layer. Incorporating either a PVC or TPE inner hose and EPDM gaskets. Maximum operating temperature 60°C.
Range of Stainless-Steel braided EPDM lined flexible hose assemblies with various end connections. For use with copper pipe manufactured to EN1057 Maximum working pressure; 16 Bar Maximum operating temperature; 85°C
Range of stainless-steel braided EPDM lined flexible hose assemblies with a variety of end connections. Some models incorporate push-fit isolation valves. Compression connection to be used with DM LLDPE pipes or PEX barrier pipe manufactured to BS7291-3. Maximum working pressure and maximum operating temperature 12 bar @cold water use only & 7 bar @ 65°C.
Range of flexible corrugated stainless-steel tubing with white plastic covering. Compression connections are for use with copper pipe (manufactured to EN 1057). Captive nut end connections incorporate an EPDM gasket. 2BACa0504 prefix models incorporate a servicing valve (chromium plated brass body with brass ball) on the compression end connection. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Air source heat pump with a temperature and pressure relief valve (7.0 Bar) factory fitted. Maximum working pressure 5.5 bar. Maximum operating temperature 70°C.
Range of domestic stainless steel or coated carbon steel indirect unvented hot water storage cylinders and buffer tanks, incorporating a stainless-steel coil for connection to a heat pump circuit. The secondary circuit is factory fitted with a temperature and pressure relief valve (7.0 Bar @90°C) and an immersion heater. Maximum working pressures: Water storage tanks (ECO-ZR200S and EG-200CAIO): 5.5 bar. Buffer tank (ECO-ZR60 and ECO-ZR60S): 7.0 bar. Maximum operating temperature 70°C. The ECO-ZR60 and ECO-ZR60S models are to be used in a primary circuit only.
Range of automatic air release valves with blue epoxy coated cast iron bodies and plastic floats. Maximum working pressure 10.0 Bar 16.0 Bar, 25.0 Bar (see models) Maximum operating temperature 60.0°C
Series of wall mounted, thermostatic mixer valve with brass bodies, diverter headwork that controls flow between one, two or three outlets (see model) with various type of operating member. The temperature is controlled independently via a thermostatic cartridge operating member with a manual override button. Inlets incorporate a stainless-steel strainer and approved check valve cartridges, however, the complete product has not been fully tested to demonstrate it provides backflow protection. Maximum working pressure 5.0 bar.
Non-metallic materials and components comply with BS6920 at 55°C
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 814109 | chrome | 3/4” | 5 bar | 65 °C | KINEN | on body | No | 1/4 Turn ceramic disk | Shower Hose, Handset, Riser Rail, | ||
| 814111 | chrome | 3/4” | 5 bar | 65 °C | KINEN | on body | No | 1/4 Turn ceramic disk | Shower Hose, Handset, Riser Rail, |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| AQDL1 | Chrome | 15mm compression | 10 bar | 65 °C | AQUALISA | Valve body | No | 1/4 Turn ceramic disk | Not Applicable | Not Applicable | Shower Hose, Handset, |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 938HP | Chrome | 15mm Compression | 5 bar | 70 °C | AQUALISA | shower valve | No | Single sequential | Not Applicable | Shower Hose, Handset, |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 958HP | Chrome | 15mm compression | 10 bar | 65 °C | AQUALISA | Valve Body | No | 1/4 Turn ceramic disk | Not Applicable | Not Applicable | Shower Hose, Handset, |
Range of T type thermostatic blending valves with (brass bodies - chrome plated finishes). The inlets incorporate a stainless-steel strainer. ISO models incorporate a servicing valve on each inlet. For use with copper pipe (BS EN 1057). Maximum working pressure 10.0 bar. Maximum operating temperature 85°C.
Range of wall mounted thermostatic shower valves, (brass bodies - various finishes), incorporating a thermostatic cartridge controlling the temperature. Supplied with either single lever or cross top operating members depending on model and with a manual override button. The inlets incorporate stainless steel strainers and approved check valve cartridges, however, the complete product has not been fully tested to demonstrate it provides backflow protection. Maximum working pressure 5.0 bar. Maximum operating temperature 85ºC.
Wall mounted, bar type thermostatic blending valves (chromium plated brass) incorporating a quarter turn ceramic disc headwork, controlling and diverting the flow between overhead shower and handset, with dome type operating member. The temperature is controlled independently via a thermostatic cartridge with a dome type operating member which incorporates a manual override button. Both inlets incorporate stainless steel strainer and approved check valve cartridges, however, the complete products have not been fully tested to demonstrate that they provide backflow protection Maximum working pressure 10.0 bar. Non-metallic materials and components comply with BS6920 at 85°C
Non-metallic materials and components comply with BS6920 at 85°C
Range of wall mounted thermostatic shower valves with brass bodies and trim set (various finishes - see model). Flow is controlled by a quarter turn ceramic disc headwork with various operating members. Temperature is controlled independently via a thermostatic cartridge with various operating members. The inlets incorporate an approved check valve cartridge, however, the complete product has not been fully tested to demonstrate it provides backflow protection. The product is supplied with a shower hose and handset. Maximum working pressure 5.0 bar. Maximum operating temperature 60°C.
Range of butterfly valves with blue epoxy coated bodies. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of butterfly valves incorporating blue epoxy coated ductile iron bodies and discs. Maximum working pressure 16.0 Bar. Maximum operating temperature 85.0°C
Range of butterfly valves with blue epoxy coated ductile iron bodies and discs. Maximum working pressure 16.0bar. Maximum operating temperature 85°C.
Range of in-line pilot operated control valves with blue epoxy coated ductile iron bodies, incorporating a solenoid valve. Maximum working pressure 12.0 Bar Maximum operating temperature 60.0°C
Range of brass bodied concealed flow control vales with trim sets in various finishes (see model), incorporating a quarter turn ceramic disc headwork with various operating members. Maximum working pressure 5.0 bar. Maximum operating temperature 85°C.
Range of dual plate non-return valves with blue epoxy coated ductile iron bodies, stainless steel discs and an EPDM seat. Maximum working pressure 16.0 bar. Maximum operating temperature 99°C.
Range of spring-loaded resilient trim, non-return valves with blue epoxy coated ductile iron bodies, stainless steel discs, PTFE stem gaskets and EPDM seat. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of dual plate non-return valves with blue epoxy coated ductile iron bodies, stainless steel discs and an EPDM seat. Maximum working pressure 16.0 bar. Maximum operating temperature 99°C.
Range of dual plate non-return valves with blue epoxy coated ductile iron bodies, stainless steel discs and an EPDM seat. Maximum working pressure 16.0 bar. Maximum operating temperature 99°C.
‘GNVP’ range of non-return valves with a white plastic housing. The product incorporates two test/drainage plugs. Maximum working pressure 16.0 bar. Maximum operating temperature 60°C.
Range of in-line pressure reducing valves with either chromium plated DZR brass bodies, with manually adjustable outlet pressure ranges between 2.8bar to 3.2bar. Compression connections to be used with copper pipe EN1057 only. Maximum working inlet pressure: 16.0 bar. Maximum operating temperature: 85°C.
Range of pressure reducing valves, manually adjustable outlet pressure from 0.5 bar - 6.5 bar, with DZR brass bodies and inspection ports on both the inlets and outlets. The valves incorporate plastic strainers. Maximum working pressure 25 bar. Maximum operating temperature 85˚C.
Range of pilot operated, adjustable, pressure reducing control valves with blue epoxy coated ductile iron bodies. The valves are supplied with a pilot valve, three spherical valves and a needle valve. Maximum supply pressure 16.0 bar. Outlet pressure setting is adjustable in the range of 2.0 – 12.0 bar. Maximum operating temperature 80°C. Above ground use only.
Range of pilot operated pressure reducing control valves (ranges of 0.7 to 7.0 bar or 1.5 to 15.0 bar) with ductile iron bodies (blue epoxy coating). Maximum working pressure: 16 Bar. Cold water use only.
Range of adjustable, pilot operated pressure reducing control valves with ductile iron bodies (blue epoxy coated) EPDM diaphragms, stainless steel tubing, isolation valves and needle valves. The product also incorporates both upstream and downstream pressure gauges. Maximum working pressure 10 Bar Maximum operating temperature 85°C Maximum outlet pressure 2 – 8bar
Range of pilot operated pressure reducing control valves with ductile iron bodies (blue polyester or epoxy coating) or stainless-steel bodies. Maximum working pressure 16 Bar (PR models) 12 Bar (PR-SC models) Maximum operating temperature 60°C Pressure ranges 0.35 bar-3.5 bar, 0.7 bar-5.5 bar, 1.38 bar-13.8, 6.9 bar-16 bar.
Range of pressure relief valves (pre-set at 3.0 bar), with plastic bodies. Maximum working pressure 10.0 bar. Maximum operating temperature 100°C.
Pressure relief valve with a brass body. Pre-set at 2.5 bar relief pressure. Maximum operating temperature 110°C.
Solenoid valve with a brass body, EPDM diaphragm and ‘O’-rings. Maximum operating pressure 10.0 bar. Cold water use only.
Range of spherical valves nickel plated brass body with chrome plated brass ball and operated via lever, butterfly type handle or screwdriver slot. For use with copper pipe (manufactured to EN1057). Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
In-line spherical valve incorporating a chrome plated brass body and ball. Compression end to be used with copper pipe EN1057. Maximum working pressure 16.0 Bar Maximum operating temperature 85.0°C
Spherical ball valve (screwdriver operated) incorporating a chromium plated brass body and ball. For use with BS EN 1057 copper pipe Maximum working pressure 16 Bar Maximum operating temperature 85°C
Range of spherical valves with various means of operation some via handle some with actuators, see models, comprising of a bronze valve body, spindle and ball valve, and EPDM O rings Maximum working pressure 16 bar Maximum operating temperature 90˚C.
Range of angled (S0273 and S0274 suffix models only) or in-line spherical valves with a nickel plated brass body, chromium plated brass ball and PTFE or EPDM seats. The products are either screwdriver operated or supplied with a T-handle (S0233BH-1 and S0233BH-2 models only). Compression ends are for use with copper pipes (manufactured to EN1057). Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Push fit in-line spherical valve with plastic body, for use with PE-X pipe (manufactured to BS7291-3), PB pipe (manufactured to BS7291-2) and copper pipe (manufactured to BS EN1057). Maximum working pressure/temperature: 12.0 Bar (cold water) and 7.0 Bar at 65°C.
Range of gate valves with brass bodies, brass wedge and PTFE gaskets. The valves incorporate a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves with ductile iron bodies (blue epoxy coated), EPDM coated wedge and EPDM O - rings. Maximum working pressure – 10.0 bar (DN900 and DN1000 only) and 16.0 bar (DN350 – DN800). Maximum operating temperature - 85°C
Range of gate valves with bronze bodies, bronze wedge and PTFE gaskets. The valves incorporate a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves with a non-rising spindle and a handwheel operating member. DZR brass body and a brass wedge. For use with copper pipe (manufactured to EN1057). Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves with blue epoxy coated ductile iron bodies, EPDM wedge and a non-rising spindle. Maximum working pressure 16.0. Maximum operating temperature 85°C.
Range of gate valves with blue epoxy coated ductile iron bodies, EPDM coated ductile iron wedge and EPDM seals. Valves are operated via a non-rising spindle headwork. With lever or gear operating member. Maximum working pressure 16.0 Bar Maximum operating temperature 100.0°C
Range of gate valves with blue epoxy coated ductile iron bodies, EPDM coated ductile iron wedge and EPDM seals. Valves are operated via a non-rising spindle headwork. Maximum working pressure 16.0 Bar Maximum operating temperature 100.0°C
Range of gate valves with bronze bodies, brass bonnets and DZR brass stems . The valves operate via a spindle headwork with hand wheel operation. Threaded end connections to BS21 ISO 7 /1 r/c (BSP Taper - JIS B0203). Maximum working pressure 25.0 bar. Maximum operating temperature 23oC.
Range of inlet control valves with DZR brass bodies. The valves consist of an adjustable pressure reducing valve set at 3.0 bar, pressure relief valve set at either 4.5, 6.0 or 8.0 bar. The valves also incorporate an approved check valve cartridge, verified by test (suitable for backflow protection against Fluid Category 2). For use with copper pipe to BS EN 1057. Maximum working pressure 16.0 Bar. Maximum operating temperature 65°C.
Range of double regulating valves incorporating bronze bodies, brass disc face (½” - ¾” models) or PTFE (1” - 2” models), PTFE plate and NBR ‘O’-rings. Maximum working pressure 25.0 bar. Maximum operating temperature 100°C.
Range of bedpan washers and macerators with flow controlled by solenoid valve and discharged via a type AB air gap (verified by test - suitable for backflow protection against fluid cat 5). Maximum working pressure 6 Bar Maximum operating temperature 60°C
‘Caleffi Ecal’ electrolytic anti-scale device with a stainless-steel filter and magnet, comprising of an in-line DZR brass body and a plastic housing. Maximum working pressure 16.0 bar. Maximum operating temperature 40°C.
Range of UV disinfection units with stainless steel bodies and quartz tubes. Maximum working pressure 10.0 bar. Cold water use only.
Range of UV disinfection units with stainless steel bodies and quartz tube. Maximum working pressure 8.0 bar. Cold water use only.
Range of floor standing or wall mounted water dispensers which dispenses ambient and/or chilled water. Flow is controlled via self-closing headwork and products have either tap with lever operating members, a tap with floor pedal (floor standing models only), a bubbler with push button or a bubbler with floor pedal (floor standing models only). Maximum working pressure 6.0 bar. Cold water use only.
Range of commercial, salt regenerated, electronically controlled ion exchange water softeners. Maximum working pressure 7.0 bar. Cold water use only.
Non-metallic materials and components comply with BS6920 at Cold water use only°C
Electronically controlled, commercial ion exchange water softeners. Maximum working pressure 7.0 bar. Cold water use only
'Iupital F10-02 nat, Iupital F20-03 nat & Iupital FG2025 nat (natural, appear white)'. 'Iupital F10-02 E9000 black & Iupital F20-03 E9001 black (black coloured)'. Injection moulded acetal materials. For use with water up to 85°C.
'9001 Black High Chlorinated Polyethylene Anticorrosive Coating'. Factory applied, black coloured epoxy coating. Apply as per manufacturer's TDS/IFU 'number: 001', 'First Edition', revision date 'March 20, 2025'. Cure for 60 minutes@23°C. For use with water up to 23°C. This material is only approved for the curing conditions that appear on the approval. If the cure conditions are varied from those specified on the approval then the material is not covered by the scope of the approval.
'BSS-LM'. Factory applied, white coloured epoxy coating. Apply as per manufacturer's User Instructions 'File no. BSS-LM-D0001', 'Date: 9.20.2025'. Cure for 10 minutes@190°C. For use with water up to 65°C. This material is only approved for the curing conditions that appear on the approval. If the cure conditions are varied from those specified on the approval then the material is not covered by the scope of the approval.
'Epilux 610 T Primer for use with Epilux 155 SF Topcoat'. Factory applied, white coloured (once applied) two-part epoxy coating. The topcoat can also be used alone, without the primer. 'Epilux 610 T Primer’ comprises of a base & hardener to be mixed in a 3:1 volume ratio and then applied as per manufacturer's TDS 'Ver.1 Aug 25'. Cure for 16 hours@25°C – 28°C, 60%±10% RH. 'Epilux 155 SF Topcoat' comprises of a base & hardener to be mixed in a 4:1 volume ratio and then applied as manufacturer's TDS 'Ver 1 Aug 25'. Cure for 7 days@25°C – 28°C, 60%±10% RH. For use with water up to 60°C. This material is only approved for the RH, mixing & curing conditions that appear on the approval. If the RH, mix and/or cure conditions are varied from those specified on the approval then the material is not covered by the scope of the approval.
‘SIKAFLOOR 150 & SIKALASTIC-836 DW’. Factory applied, off-white coloured (once mixed and applied), two-part epoxy primer for use with two-part polyurea coating. Mix parts A & B of SIKAFLOOR 150 in a 100:50 weight ratio and apply as per manufacturer’s PDS ‘October 2023, Version 11.0’. Cure for 4 hours@25°C. Mix parts A & B of SIKALASTIC-836 DW in a 100:100 volume ratio and apply as per manufacturer’s PDS ‘July 2022, Version 04.0’. Cure for 24 hours@25°C. For use with water up to 60°C. This material is only approved for the mixing & curing conditions that appear on the approval. If the mix and/or cure conditions are varied from those specified on the approval then the material is not covered by the scope of the approval.
‘EPACRETE EPAPOX 25 & EPAPROOF FPCS WFC’. Factory applied, off-white coloured (once mixed and applied), two-part epoxy primer for use with two-part polyurea coating. Mix parts A & B of EPACRETE EPAPOX 25 in a 100:50 weight ratio and apply as per manufacturers TDS 01.140317. Cure for 4 hours@25°C. Mix parts A & B of EPAPROOF FPCS WFC in a 100:100 volume ratio and apply as per manufacturers TDS rev 01-2023. Cure for 24 hours@25°C. For use with water up to 60°C. This material is only approved for the mixing & curing conditions that appear on the approval. If the mix and/or cure conditions are varied from those specified on the approval then the material is not covered by the scope of the approval.
'Polyglass VEF'. Factory applied, two-part, off-white coloured, vinyl ester coating. Mix parts A & B in a 98:2 mass ratio and apply as per manufacturer's instructions '2/23' last reviewed July 2020. Cure for 7 days@21°C. For use with water up to 23°C. This material is only approved for the mixing & curing conditions that appear on the approval. If the mix and/or cure conditions are varied from those specified on the approval then the material is not covered by the scope of the approval.
'AFIL BLUE Tank Panel'. Beige coloured GRP tank panel manufactured by continuous winding. For use with water up to 60°C.
'VPL500T/VPL500B VIP Seal Lubricant'. White coloured (opaque), water based lubricant. For use with water up to 23°C.
Natural (appear white), black or grey, injection moulded, glass fibre reinforced nylon materials. Grivory HT1V-3 FWA natural and black 9225. Grivory HT1V-4 FWA natural and black 9225. Grivory HT1V-4 FWA grey 9489. Grivory HT1V-4 FWA grey-blue 4637. Grivory HT1V-5 FWA natural and black 9225. Grivory HT1V-5 FWA grey L1366.3 & Grivory HT1V-5 FWA grey 9616. Grivory HT1V-5 FWA grey L16760.2. Grivory HT1V-6 FWA natural and black 9225. For use with water up to 85°C.
'RADILON® DT RV300RKC2 106 NT to RADILON® DT RV500RKC2 106 NT and RADILON® DT RV300RKC2 306 BK to RADILON® DT RV500RKC2 306 BK'. Natural (appears off-white in colour) or black, injection moulded glass fibre filled PA6.12 materials. For use with water up to 85°C.
'Tritan™ TX1501HF'. Clear, injection moulded copolyester (PCTM) material. For use with water up to 85°C.
'Tritan™ TX1001'. Clear, injection moulded copolyester (PCTM) material. For use with water up to 85°C.
'Tritan™HM1060'. Clear (translucent), injection moulded copolyester material. For use with water up to 85°C.
'Tritan™ TX2001'. Clear, injection moulded copolyester (PCTM) material. For use with water up to 85°C.
'Radius Systems PE100 Black Spigot Fittings'. Black coloured, injection moulded PE100 spigot fittings. For use with water up to 23°C.
'B1-4773' Lip Seals and 'O' rings. Black coloured, EPDM components with shore hardness of 70. Compression moulded Lip Seals have an in-radius size of 2.7mm. Compression moulded ‘O’ rings have an in-radius size of 1.5mm. Injection moulded ‘O’ rings have an in-radius size of 1.0mm. For use with water up to 85°C.
'E7581'. Black coloured, injection moulded EPDM rubber material. Shore hardness 70. Tested in-radius size 1.0mm. For use with water up to 85°C.
'ECL/EP/50 & ECL/EP/80'. Black coloured, compression moulded EPDM materials. Shore hardness between 50 & 80. Tested in-radius size 1.0mm. For use with water up to 85°C.
'E7131'. Black coloured, injection moulded EPDM rubber material. Shore hardness 70. Tested in-radius size 1.0mm. For use with water up to 85°C.
'7571E'. Black coloured, injection moulded EPDM material. Shore hardness 55. Tested in-radius size 1.0mm. For use with water up to 23°C.
'VEV1'. Black coloured, compression moulded FKM seal. Shore hardness 70 A. Tested in-radius size 4.45mm. For use with water up to 23°C.
'FKM 70 514404'. Black coloured, compression moulded FKM 'O' ring. Shore hardness 70. Tested in-radius size 5.0mm. For use with water up to 85°C.
72401, 72501, 73401, 73501, 74401, 74501, 75401, 75501, 76401, 76501, 77401, 77501, 78401, 78501, 79401 & 79501. Range of press moulded, solid silicone rubber materials which are blue or red coloured. Shore hardness between 20 & 90. Tested in-radius size 1.0mm. for use with water up to 85°C.
'Weld-On 719 Gray PVC Solvent Cement'. Grey coloured solvent cement. Apply as per manufacturer's data sheet '719-05-2024'. Cure for 8 hours at 5°C. For use with water up to 23°C. This material is only approved for the curing conditions that appear on the approval. If the cure conditions are varied from those specified on the approval then the material is not covered by the scope of the approval.
'Weld-On 795 Blue PVC Cement'. Blue coloured solvent cement. Apply as per manufacturer's data sheet '795-05-2024'. Cure for 4 hours at 5°C. For use with water up to 23°C. This material is only approved for the curing conditions that appear on the approval. If the cure conditions are varied from those specified on the approval then the material is not covered by the scope of the approval.
'Weld-On 705 ECO Gray PVC Solvent Cement'. Grey coloured solvent cement. Apply as per manufacturer's data sheet '705 ECO-09-2024'. Cure for 12 hours at 5°C. For use with water up to 23°C. This material is only approved for the curing conditions that appear on the approval. If the cure conditions are varied from those specified on the approval then the material is not covered by the scope of the approval.
Range of deck mounted single hole, single outlet (fixed) electronically controlled combination tap assemblies (stainless steel spout, available in Satin, Stainless-Steel, Black, Brass, Bronze, Copper, and Chrome finishes). Flow is controlled by a solenoid valve activated by via an infra-red sensor which incorporates a stainless steel filter at its inlet. The spout outlet incorporates a plastic aerator. Maximum working pressure 10.0 bar. Maximum operating temperature 60˚C.
Range of wall mounted single hole, single outlet (fixed) electronically controlled combination tap assemblies (stainless steel spout, available in Satin, Stainless-Steel, Black, Brass, Bronze, Copper, and Chrome finishes). Flow is controlled by a solenoid valve activated by via an infra-red sensor which incorporates a stainless steel filter at its inlet. The spout outlet incorporates a plastic aerator. Maximum working pressure 10.0 bar. Maximum operating temperature 60˚C.
Bottom entry BS1212-4 (2016) compact type float operated inlet valve for WC flushing cisterns with a plastic body and a plastic flow regulator at the inlet. Maximum working pressure 10.0 Bar Cold water use only
Range of combined bath filler, waste and overflow assemblies. Maximum operating temperature 60°C.
Combined bath filler, waste and overflow with a brass body and metal trim (various finishes). The outlet incorporates an approved single check valve cartridge, however, the complete product has not been fully tested to demonstrate it provides backflow protection. The product is supplied with a click type waste (not verified by test). Maximum operating temperature 85°C.
Range of shower sets with shower hose, handset and riser rail. Open outlet use only. Maximum operating temperature 65 °C.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 814110 | chrome | 3/4" | 5 bar | 65 °C | KINEN | on body | No | Ceramic cartridge | Shower Hose, Handset, Fixed Head, | ||
| 814112 | 814112 | 3/4" | 5 bar | 65 °C | KINEN | on body | No | Ceramic cartridge | Shower Hose, Handset, Fixed Head, |
In-line non-verifiable double check valve assembly with integral lever operated spherical valve, consisting of two spring loaded resilient trim check valve cartridges housed within a DZR brass body, verified by test (suitable for backflow protection against Fluid Category 3). For use with copper pipe (manufactured to BS EN 1057). Maximum working pressure 16.0 bar. Maximum operating temperature 65°C.
Range of near boiling water dispensers comprising of an install rail, under-counter boiler unit with a stainless steel tank and a countertop outlet (font). The install rail incorporates a water block, a double check valve assembly (suitable for backflow protection against fluid category 3) with an integral lever operated isolation valve and an adjustable pressure reducing valve (outlet pressure range 3.0 to 3.5 bar). The flow is controlled via a solenoid valve which is activated by a touch method at the outlet. The commercial model outlets (fonts) incorporate a safety button. The solenoid valve incorporates a plastic flow regulator. The countertop outlet (font) incorporates a plastic aerator. All models incorporate a separate vent outlet within the tap spout for the near-boiling water circuit. Maximum supply pressure to the install rail 16.0 bar. Maximum operating temperature 98°C. Cold supply only.
Range of quarter turn ceramic disc headwork assemblies with brass bodies, NBR ‘O’-rings and silicone gaskets. For insertion into specifically dimensioned tap assemblies. Maximum working pressure 10 Bar Maximum operating temperature 85°C.
Range of ceramic cartridge headworks with NBR rubber ‘O’-rings and silicone seals. For insertion into specifically dimensioned tap assemblies. Maximum working pressure 10 Bar Maximum operating temperature 85°C.
Range of ceramic cartridge headworks with EPDM seals. For insertion into specifically dimensioned tap assemblies. Maximum working pressure 10 Bar, Maximum operating temperature 85°C.
Range of ceramic cartridge headworks incorporating a plastic body to be housed in specifically dimensioned bodies. Maximum working pressure 12.0 bar. Maximum operating temperature 85°C.
Quarter turn ceramic disc headwork incorporating a brass body, EPDM and NBR ‘O’-rings and a silicone gasket. Maximum working pressure 10.0 bar. Maximum operating temperature 85°C.
Single hole, single outlet, fixed combination tap assemblies (brass bodies - various finishes), incorporating a ceramic cartridge headwork with a single lever operating member. The spout outlet incorporates a plastic flow straightener and an optional flow regulator. Maximum working pressure 10.0 Bar. Maximum operating temperature 85°C.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 501102 | Chrome | 1/2" BSP | 5 bar | 60 °C | KINEN | on handle | No | Ceramic cartridge | C-plate | Aerator | |
| 501101 | Chrome | 1/2" BSP | 5 bar | 60 °C | KINEN | on handle | No | Ceramic cartridge | C-plate | Aerator | |
| 5591103 | Chrome | 1/2" BSP | 12 bar | 60 °C | KINEN | on handle | No | Ceramic cartridge | C-plate | Aerator | |
| 5591101 | Chrome | 1/2" BSP | 12 bar | 60 °C | KINEN | on handle | No | Ceramic cartridge | C-plate | Aerator | |
| 5591104 | Chrome | 1/2" BSP | 12 bar | 60 °C | KINEN | on handle | No | Ceramic cartridge | C-plate | Aerator | |
| 141102 | Chrome | 1/2" BSP | 12 bar | 60 °C | KINEN | on handle | No | Ceramic cartridge | C-plate | Aerator | |
| 141101 | Chrome | 1/2" BSP | 12 bar | 60 °C | KINEN | on handle | No | Ceramic cartridge | C-plate | Aerator | |
| 141104 | Chrome | 1/2" BSP | 12 bar | 60 °C | KINEN | on handle | No | Ceramic cartridge | C-plate | Aerator |
Range of floor mounted, single hole, single outlet fixed combination tap assembly (various finishes), incorporating a ceramic cartridge headwork with a single lever operating member and a self-cancelling diverter to shower outlet. The outlet to the shower incorporates an approved check valve cartridge, however the complete product has not been fully tested to demonstrate it provides backflow protection. The spout outlet incorporates an aerator. These products are not supplied with shower handset and hose. Maximum working pressure 16.0 bar. Maximum operating temperature 60°C.
Single hole, single outlet (swivel) combination tap assembly with brass body (chromium plated), incorporating a ceramic cartridge headworks and single lever operating member. The outlet incorporates a plastic aerator. Maximum working pressure 5.0 bar. Maximum operating temperature 60°C.
Single hole, single outlet (swivel) combination tap assemblies, chrome finish(chromium plated brass), with a non-rising spindle and cross-top operating member(models 49944 & 88081) or ceramic disc headwork with lever type operating members(model 26251). The spout outlets incorporate a metal strainer and either a plastic aerator or alternative flow straightener. Maximum working pressure 10.0 bar. Maximum operating temperature 70°C.
Single hole, single outlet (swivel) combination tap assembly with brass body (chromium plated), incorporating a ceramic cartridge headworks and single lever operating member. The outlet incorporates a plastic aerator. Maximum working pressure 5.0 bar. Maximum operating temperature 60°C.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 247031 X XXX | VARIOUS | 1/2" BSP | 10.0 bar | 65 °C | PPI | BODY | No | 1/2 Turn ceramic disk | C-plate | Aerator & Flow Straightener | |
| 247032 X XXX | VARIOUS | 1/2" BSP | 10.0 bar | 65 °C | PPI | BODY | No | 1/2 Turn ceramic disk | C-plate | Aerator & Flow Straightener | |
| 247033 X XXX | VARIOUS | 1/2" BSP | 10.0 bar | 65 °C | PPI | BODY | No | 1/2 Turn ceramic disk | C-plate | Aerator & Flow Straightener |
X XXX Denotes the following: First X: Different handle option and the second, third & fourth XXX for different finishes: Handles: A – Lever or Dome type Chrome – No suffix, brushed brass – BGP, PVD Gold – PVD, Brushed Nickel – BN1, Gun Metal – GMG, Matt Black – MBK, Matt White – MWH, Stainless Steel – SS1, Black Chrome – BCP, Titanium – TIB and Antique Bronze – AB1
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 526402 | Chrome (CHR) | 3/8" | 10 bar | 70 °C | BLANCO | body | Yes | Ceramic cartridge | Not Applicable | Aerator | |
| 526407 | ANT/CHR | 3/8" | 10 bar | 70 °C | BLANCO | body | Yes | Ceramic cartridge | Not Applicable | Aerator | |
| 526415 | BLA/CHR | 3/8" | 10 bar | 70 °C | BLANCO | body | Yes | Ceramic cartridge | Not Applicable | Aerator | |
| 526408 | SGW/CHR | 3/8" | 10 bar | 70 °C | BLANCO | body | Yes | Ceramic cartridge | Not Applicable | Aerator | |
| 526981 | VGR/CHR | 3/8" | 10 bar | 70 °C | BLANCO | body | Yes | Ceramic cartridge | Not Applicable | Aerator | |
| 526980 | SOW/CHR | 3/8" | 10 bar | 70 °C | BLANCO | body | Yes | Ceramic cartridge | Not Applicable | Aerator |
All surface finishes are not in contact with drinking water. The product structure (schedule of materials) of all versions are identical. Surface finish / color explanation: CHR - Chrome ANT - Anthracite BLA - Black Matt SGW - Silgranite White VGR - Volcano Grey SOW - Soft White
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 1L449200DH | Matt black | 1/2" BSP (F) | 10 bar | 65 °C | WIDE | Body | No | Ceramic cartridge | Not Applicable | Aerator | Shower Hose, Handset, |
| 1L449200MA | Tri-chrome | 1/2" BSP (F) | 10 bar | 65 °C | WIDE | Body | No | Ceramic cartridge | Not Applicable | Aerator | Shower Hose, Handset, |
| 1L449200SA1 | Brushed gold | 1/2" BSP (F) | 10 bar | 65 °C | WIDE | Body | No | Ceramic cartridge | Not Applicable | Aerator | Shower Hose, Handset, |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 141701 | chrome | 1/2" BSP | 10 bar | 60 °C | KINEN | on body | No | Ceramic cartridge | Aerator |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 503109 | shower set | G3/4 | 10 bar | 60 °C | KINEN | on body | Yes | Metal Backnuts | Shower Hose, Handset, | ||
| 5593201 | shower set | G3/4 | 10 bar | 60 °C | KINEN | on body | Yes | Metal Backnuts | Shower Hose, Handset, | ||
| 143201 | shower set | G3/4 | 10 bar | 60 °C | KINEN | on body | Yes | Metal Backnuts | Shower Hose, Handset, |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| J THBSMVO C | Chrome | G 3/4" (M) | 10 bar | 60 °C | Bristan | Handle | No | 1/4 Turn ceramic disk | Metal Backnuts | Not Applicable | Flow Regulator Fitted, |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| JD-L201** | Various | BSP 1/2" (M) | Open outlet use only bar | 60 °C | Kind | Spout | No | Not applicable | Not Applicable | Aerator | |
| JD-200** | Various | BSP 1/2" (M) | Open outlet use only bar | 60 °C | Kind | Spout | No | Not applicable | Not Applicable | Aerator | |
| SJS-L202** | Various | BSP 1/2" (M) | Open outlet use only bar | 60 °C | Kind | Spout | No | Not applicable | Not Applicable | Aerator |
** represents different types of finishes as follows: C: Chrome NS: Nickel brushed RP: Red powder coated TS: Zr gold brushed RS: Rose gold brushed GS: Gold brushed GM: Gun metal brushed B: Electroplated matte black W: White CB: Matte black and chrome CW: White and chrome TG: Zr gold plated RG: Rose gold plated G: Gold plated GP: Gun metal plated BS: Gun gray brushed
Range of stainless steel (SS304 or SS316L) press-fit fittings incorporating EPDM ‘O’-rings for use with *‐KJ600304 and *-KJ600316 stainless steel pipes. The "KJ6278" prefix models also incorporates an EPDM gasket on the union nut. Jointing is achieved via a crimping tool using a ‘M’ profile. For above and below ground use. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Uponor S-Press press fittings, Uni-X & Uni-C compression fittings for use with Uponor MLC pipe. Maximum working pressure 10.0 bar, maximum operating temperature 70°C.
Range of copper press fittings with EPDM seals for use with copper pipe (manufactured to EN1057). Jointing is achieved via a crimping tool using a ‘M’ profile. Maximum working pressure 16.0 bar. Maximum operating temperature 99°C.
‘Fastwarm’ range of U profile press fittings (nickel plated brass bodies) for use with ‘Fastwarm’ range of PERT/AL/PERT multi-layered pipes. Maximum working pressure 10.0 bar. Maximum operating temperature 95°C.
Range of copper capillary, lead free solder ring and threaded fittings for use with copper pipe (manufactured to EN 1057). Maximum working pressure 16.0 bar. Maximum operating temperature 99°C.
Range of ‘M’ profile copper press fittings with EPDM ‘O’-rings for use with copper pipes (manufactured to EN 1057). Jointing is achieved via a crimping tool using a ‘M’ profile. For above and below ground use. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
'Flomasta’ range of push-fit fittings with PEX-b, polysulphone or PPE bodies, supplied with polysulphone inserts. For use with PEX pipe (manufactured to BSEN 7291 part 3), PB (manufactured to BSEN 7291 part 2) and copper pipe (EN1057). Maximum working pressure/temperature: 12.5 Bar @ 20°C. As of October 2025: Maximum working pressure/temperature 3 Bar @ 92°C.
Range of polypropolene fittings for use with PE pipe (manufactured to EN 12201). Maximum working pressure 16 bar. Cold water use.
RWC range of polypropolene fittings for use with PE pipe (manufactured to EN 12201). Maximum working pressure 16 bar. Cold water use.
Range of brass press fittings with EPDM ‘O’-rings for use with PEX/AL/PEX multilayer pipe (manufactured to EN ISO 21003). Jointing is achieved via a crimping tool using either a ‘U’, ‘TH’ or ‘H’ profile. Maximum working pressure 10.0 bar. Cold water use only.
Range of plastic and DZR brass pushfit fittings for use with PE-x pipe (manufactured to BS7291-3), PB pipe (manufactured to BS7291-2) and copper pipes (manufactured to EN 1057). Maximum working pressure 10.0 bar, except tank connectors which are open outlet use only. Cold water use only.
'Flomasta' range of push-fit fittings with PEX-b, polysulphone or PPE bodies, supplied with polysulphone inserts. For use with PEX pipe (manufactured to BSEN 7291 part 3), PB (manufactured to BSEN 7291 part 2) and copper pipe (EN1057). Maximum working pressure/temperature: 12.5 Bar @ 20°C. As of October 2025: Maximum working pressure/temperature 3 Bar @ 92°C.
Range of end feed copper fittings for use with copper tube (manufactured to EN 1057). Maximum working pressure 16.0 bar. Maximum operating temperature 99°C.
‘BECO Y’ range of ultrasonic water meters with plastic bodies, plastic transducers and silicone ‘O’-rings. The inlet incorporates a plastic strainer. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of electromagnetic flow meters incorporating grey epoxy coated ductile iron bodies. Maximum working pressure 10.0 bar. Maximum operating temperature 100°C.
Range of brass bodied threaded fittings and a brass end feed fitting (C04069H00081A model only). The CL08069H192B4 model is chrome plated. The C04069H00081A model end feed fitting is for use with copper pipe (manufactured to EN 1057). The C04149H00191A model incorporates a plastic flow straightener. Maximum working pressure 10.0 bar, except for the C04149H00190A and C04149H00191A models which are open outlet use only. Maximum operating temperature 85°C.
Threaded adaptor (brass body) soldered with copper pipe and a range of thread extensions (chrome plated brass bodies). Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of threaded fittings with either brass or chrome plated brass bodies. Maximum working pressure 40 Bar Maximum operating temperature 85°C.
Range of DZR brass metering stations supplied with red and blue test points. Maximum working pressure 25.0 bar. Maximum operating temperature 85°C.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 26.409.000 | chrome | G 1/2" | Open Outlet bar | 65 °C | Grohe | Faceplate | No |
Range of in-line `Y`-patterned strainers with bronze bodies incorporating stainless steel mesh strainers and PTFE washers. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of in-line `Y`-patterned strainers with bronze bodies incorporating stainless steel mesh strainers and PTFE washers. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of Y-pattern strainers with DZR brass bodies and stainless steel strainers. The compression connection is for use with copper pipe to BS EN1057. Maximum working pressure 20 bar (BSP threaded models ½”-2”), 16.0 bar (compression models). Maximum operating temperature 85°C.
Range of in-line `Y`-patterned strainers with bronze bodies incorporating stainless steel mesh strainers and PTFE washers. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of `Y`-patterned strainers with either brass or DZR brass bodies, incorporating a stainless-steel mesh strainer. Maximum working pressure: 25.0 Bar (Models 36233, 36234, 36235, 36236, 36237 & 36238 ) or 16.0 Bar (Models 36230 & 36231 ) Maximum operating temperature 95°C. Strainers with compression connections are to be used with copper pipe manufacture to BS EN 1057. Strainers with M profile press-fit connections are to be used with copper pipe manufactured to BS EN 1057 & SS304 Stainless steel pipe manufactured to EN 10312.
Range of bib taps incorporating either brass or DZR brass bodies. The inlet and the outlet of the tap incorporates approved single check valve cartridges however, the complete product has not been fully tested to demonstrate it provides backflow protection. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Wall mounted hose union tap (DZR brass body) incorporating a non-rising spindle headwork with a butterfly handle operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of wall mounted hose union taps with brass bodies incorporating a rising spindle headwork with a T - handle operating member. Model HC-20252-15 incorporates a lockshield device at the base of the operating stem. The spout outlets incorporate a hose union connector. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
‘DG10E PF series’ of stainless steel braided EPDM lined flexible hose assemblies with EPDM ‘O’-rings or gaskets available with a variety of end connections. The DN10 bore 15mm push fit connection is also available with a screwdriver operated isolation valve. Push-fit connections are for use with copper pipes (manufactured to EN 1057) and PEX pipes (manufactured to BS 7291-3). Maximum working pressure 10.0 bar. Cold water use only.
‘FS4E Series’ 2 port, 3 port and 4 port nickel plated brass manifolds incorporating stop valves. The models include white operating members with either red, green or blue indices. Maximum working pressure 10.0 bar. Maximum operating temperature 95°C.
Range of air venting valves with blue epoxy coated ductile iron or plastic bodies with plastic floats. Maximum working pressure 16.0 Bar. Cold water use only.
Range of automatic air release valves with blue epoxy coated stainless steel bodies and plastic or stainless-steel floats. Maximum working pressure 16.0, 25.0 or 40.0 bar (See Models below). Cold water use only.
Range of air vent valves with brass (covered with blue polyester coated ductile iron body) or plastic bodies and plastic floats. Maximum working pressure 16.0 bar (DAV KA & DAV A models) or 25.0 bar (DAV MP models). Cold water use only.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| AQ75BAR1 | Chrome | 15mm compression | 10 bar | 65 °C | AQUALISA | Valve body | No | Non-rising spindle | Not Applicable | Shower Hose, Handset, | |
| TS75BAR1 | Chrome | 15mm compression | 10 bar | 65 °C | AQUALISA | Valve body | No | Non-rising spindle | Not Applicable | Shower Hose, Handset, |
AQ75BAR1 Packed Products. Waterway contents are: • 704308 (shower valve) • 704418 (shower handset) • ACY1008 (shower hose) TS75BAR1 Packed Products. Waterway contents are: • 704308 (shower valve) • 707540 (shower handset) • ACY1008 (shower hose)
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| AQRNDCV1 | Chrome | 5 bar | 65 °C | Aqualisa | shower valve | No | Ceramic cartridge | Not Applicable | Not Applicable | Shower Hose, Handset, |
AQRNDCV1 Packed Products. Waterway contents are: 705342 (shower valve) 704418 (shower handset) ACY1008 (shower hose) ACY1013 (wall outlet)
Range of thermostatic shower valves with a quarter turn ceramic disc headwork or a 2-way ceramic disc diverter headwork controlling the flow to 1,2 outlets with various operating members (see model). Temperature is controlled independently via a thermostatic cartridge with various operating members (see model) incorporating a manual override button. Both inlets incorporate a stainless-steel strainer and an approved check valve cartridge, however, the complete product has not been fully tested to demonstrate it provides backflow protection. Maximum working pressure 10 Bar Maximum operating temperature 65°C.
Wapp mounted thermostatically controlled chrome finish shower valves. Incorporating an approved check valve cartridge (however the complete assembly has not been tested to demonstrate it provides backflow protection). Maximum temperature 85 °C Maximum pressure 10 bar.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| * M980116 X XXX | VARIOUS | 15mm compression | 5.0 bar | 65 °C | PPI | Body | No | Ceramic cartridge | Not Applicable | Not Applicable | Shower Hose, Handset, Riser Rail, |
| * 803250 X XXX | VARIOUS | 15mm compression | 5.0 bar | 65 °C | PPI | Body & Faceplate | No | 1/4 Turn ceramic disk | Not Applicable | Not Applicable | Shower Hose, Handset, Riser Rail, |
| * 801528 X XXX | VARIOUS | ½”x ¾” BSP (M) offset unions or 15mm compression | 5.0 bar | 65 °C | PPI | Body | No | 1/4 Turn ceramic disk | Not Applicable | Not Applicable | Flow Regulator Fitted, Shower Hose, Handset, Riser Rail, |
| * 803251 X XXX | VARIOUS | 15mm compression | 5.0 bar | 65 °C | PPI | Faceplate | No | 1/4 Turn ceramic disk | Not Applicable | Not Applicable | Shower Hose, Handset, Fixed Head, Riser Rail, |
| * 801524 X XXX | VARIOUS | ½”x ¾” BSP (M) offset unions or 15mm compression | 5.0 bar | 65 °C | PPI | Body | No | 1/4 Turn ceramic disk | Not Applicable | Not Applicable | Flow Regulator Fitted, Shower Hose, Handset, Fixed Head, Riser Rail, |
| * 801525 X XXX | VARIOUS | ½”x ¾” BSP (M) offset unions or 15mm compression | 5.0 bar | 65 °C | PPI | Body | No | 1/4 Turn ceramic disk | Not Applicable | Not Applicable | Flow Regulator Fitted, Shower Hose, Handset, Fixed Head, Riser Rail, |
| * 800204 X XXX | VARIOUS | 15mm compression | 10.0 bar | 60 °C | PPI | Body | No | Single sequential | Metal Backnuts | Not Applicable | Flow Regulator Fitted, Shower Hose, Handset, Riser Rail, |
| * 804203 X XXX | VARIOUS | 15mm compression | 10.0 bar | 65 °C | PPI | Body | No | 1/4 Turn ceramic disk | Metal Backnuts | Not Applicable | Shower Hose, Handset, Riser Rail, |
| * 801508 X XXX | VARIOUS | ½”x ¾” BSP (M) offset unions or 15mm compression | 5.0 bar | 65 °C | PPI | Body | No | 1/4 Turn ceramic disk | Not Applicable | Not Applicable | Flow Regulator Fitted, Shower Hose, Handset, Riser Rail, |
| * 801509 X XXX | VARIOUS | ½”x ¾” BSP (M) offset unions or 15mm compression | 5.0 bar | 65 °C | PPI | Body | No | 1/4 Turn ceramic disk | Not Applicable | Not Applicable | Flow Regulator Fitted, Shower Hose, Handset, Riser Rail, |
| * 801510 X XXX | VARIOUS | ½”x ¾” BSP (M) offset unions or 15mm compression | 5.0 bar | 65 °C | PPI | Body | No | 1/4 Turn ceramic disk | Not Applicable | Not Applicable | Flow Regulator Fitted, Shower Hose, Handset, Riser Rail, |
The “*” is for a different Overhead Shower, Shower Hose or Shower Handset, which represent the letters A to Z X XXX Denotes the following: First X: Different handle The second, third & fourth XXX for different finishes: Chrome – No suffix, Brushed brass – BGP, PVD Gold – PVD, Brushed Nickel – BN1, Gun Metal – GMG, Matt Black – MBK, Matt White – MWH, Stainless Steel – SS1, Black Chrome – BCP, Titanium – TIB and Antique Bronze – AB1.
Range of double flanged butterfly valves with blue, lavender or bright blue epoxy coated ductile iron bodies, EPDM seats and either white or red epoxy coated ductile iron or stainless steel discs. The products are supplied with bare shaft without operating members. Maximum working pressure 16.0 bar. Maximum operating temperature 60°C.
Range of lugged butterfly valves incorporating black epoxy coated ductile iron bodies, EPDM seats and stainless-steel discs. The products are operated by: DN50~DN200: Lever or DRV lever operating members. DN50~DN600: Gearbox or DRV gearbox operating members, or bare shaft without operating members. Maximum working pressures: RBV020-H models: 16.0 bar, RBV-S/PN25 models: 25.0 bar Maximum operating temperature 85°C.
Range of butterfly valves with blue epoxy coated ductile iron bodies, stainless-steel discs and EPDM or PTFE seats (see models). Maximum working pressure 16.0 Bar or10.0 Bar (see models). Maximum operating temperature 85°C.
Range of butterfly valves incorporating blue epoxy coated ductile iron bodies and discs. Maximum working pressure 16.0 Bar. Maximum operating temperature 85.0°C
Range of butterfly valves with blue epoxy coated bodies. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of butterfly valves incorporating blue epoxy coated ductile iron bodies and discs. Maximum working pressure 16.0 Bar. Maximum operating temperature 85.0°C
Range of butterfly valves with blue epoxy coated ductile iron bodies and stainless-steel discs incorporating EPDM rubber seats. (DN40 - DN200) incorporate a lever type operating member and (DN250 – DN500) incorporates a hand wheel type operating member. Maximum working pressure - 16 Bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of wafer or lugged butterfly valves incorporating blue epoxy coated ductile iron bodies, EPDM seats and stainless-steel discs. The LTDX71X-16Q DN40-150 size models are lever operated; all other models and sizes are gear operated. Maximum working pressure 10.0 bar or 16.0 bar. Maximum operating temperature 100°C.
Range of lever operated butterfly valves with blue epoxy coated cast iron bodies, stainless steel discs and EPDM ‘O’ rings and seals. Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of butterfly valves with blue epoxy coated ductile iron bodies, stainless-steel discs and EPDM or PTFE seats (see models). Maximum working pressure 16.0 Bar or10.0 Bar (see models). Maximum operating temperature 85°C.
Range of 2-way ceramic disc diverters/headworks (2 on, 1 off) with a plastic body to be housed in specifically dimensioned bodies. Maximum working pressure 12.0 bar. Maximum operating temperature 85°C.
3-way ceramic disc diverter with a plastic body, NBR ‘O’-rings and silicone seals. For insertion into specifically dimensioned bores. Maximum working pressure 10.0 bar. Maximum operating temperature 85°C.
Range of adjustable, bronze in-line pressure reducing valves. Models 131201015, 131201020 & 131201025 and model 131201032 have inspection ports on the outlet only. Models 131201050 & 131201100 sizes have inspection ports on the inlet and outlet. The valves incorporate a stainless-steel strainer. Maximum inlet supply pressure 20.0 bar. Maximum outlet pressure 1.0 bar to 4.0 bar. Maximum operating temperature 70°C.
Range of screwdriver operated spherical valves incorporating brass bodies, brass balls (chrome plated) and EPDM ‘O’-rings. For use with copper pipe to (EN1057). Maximum working pressure 16 Bar Maximum operating temperature 85°C.
Spherical valves with chrome or nickel plated brass body, chrome plated ball, PTFE seats and FKM ‘O’-ring. The products are available with lever, lockable lever or tee handles. Maximum working pressure 40.0 bar. Maximum operating temperature 85°C.
Range of quarter turn, lever handle or butterfly operated spherical valves with nickel plated brass bodies, chrome plated brass balls and PTFE seals. For use with copper pipe BS EN 1057. Maximum working pressure 25.0 bar. Maximum operating temperature 85°C.
Range of screwdriver operated spherical valves incorporating brass bodies, brass ball, and EPDM ‘O’-rings. Compression connections are for use with copper pipe (manufactured to EN1057). Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Isolation valves with nickel plated brass bodies, chrome plated brass balls and EPDM O-rings. Compression connection to be used with copper pipe EN1057. Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of spherical valves incorporating (brass bodies - various finishes). Maximum working pressure 16.0 bar, 25.0 bar for model HC-A61055-15 Maximum operating temperature 85°C.
Range of electrically (A20 & A150 series) or battery (E20 & E22 series) operated motorised spherical valves incorporating brass or stainless-steel bodies, stainless steel balls and EPDM ‘O’-rings. Maximum working pressure 10.0 bar. Maximum operating temperature 90°C.
Range of plastic bodied inline, tee and angled spherical or servicing valves with EPDM ‘O’-rings. The products are either lever or screwdriver operated (see model). The products are for use with PE-X pipe (manufactured to BS 7291-3) and copper pipe (manufactured to EN 1057). Maximum working pressure 10.0 bar. Cold water use only.
Range of resilient seated gate valves with blue epoxy coated ductile iron bodies, bonnets and ductile iron wedges encapsulated in EPDM. The valves operate via a non-rising spindle headwork with hand wheel operating member. Maximum working pressure 10.0 or 16.0 bar. Maximum operating temperature 100°C.
Range of gate valves with blue epoxy coated ductile iron bodies and EPDM coated ductile iron wedges. The valves are operated via a non-rising spindle headwork with a hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 80°C.
Range of gate valves with brass bodies, for use with copper pipe (manufactured to EN1057). Incorporating a either a handwheel or lockshield operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating blue epoxy coated ductile iron bodies, EPDM coated wedges. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 16.0 Bar. Maximum operating temperature 85°C.
Range of gate valves with blue epoxy ductile iron bodies and a ductile iron wedge encapsulated in EPDM. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves with bronze bodies, bronze wedge and PTFE gaskets. The valves incorporate a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves with bronze bodies, bronze wedge and PTFE gaskets. The valves incorporate a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of Gate valves with ductile iron bodies (blue epoxy coated), EPDM rubber coated wedges, non-rising spindles with hand wheel operating members. Maximum working pressure 16.0 Bar Maximum operating temperature 85.0°C
Range of gate valves with bronze bodies, bronze wedge and PTFE gaskets. The valves incorporate a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves with bronze bodies, bronze wedge and PTFE gaskets. The valves incorporate a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves with a non-rising spindle with a handwheel operating member or lockshield connection. Brass body and brass wedge. For use with copper pipe (manufactured to EN1057). Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of gate valves with blue epoxy coated ductile iron bodies and disks, with EPDM O seats. The valves are operated via a non-rising spindle headwork and hand wheel. Maximum working pressure 16.0 Bar
Non-metallic materials and components comply with BS6920 at 85°C
Range of gate valves with bronze bodies, bronze wedge and PTFE gaskets. The valves incorporate a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating a blue epoxy coated cast iron body, EPDM gate and seals and a non-rising stem with a handwheel operating member Maximum working pressure 16.0 bar, Maximum operating temperature 85ºC.
Range of gate valves with a brass body and wedge. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves with bronze bodies, bronze wedge and PTFE gaskets. The valves incorporate a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves with bronze bodies, bronze wedge and PTFE gaskets. The valves incorporate a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves with bronze bodies, bronze wedge and PTFE gaskets. The valves incorporate a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating blue epoxy coated ductile iron bodies, EPDM coated wedges. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 16.0 Bar. Maximum operating temperature 85°C.
Range of gate valves with bronze bodies, bronze wedge and PTFE gaskets. The valves incorporate a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of hand wheel operated gate valves with blue epoxy coated ductile iron bodies, ductile iron wedge encapsulated in EPDM. Maximum working pressure 16.0 Bar. Maximum operating temperature 85.0°C
Range of stop valves with brass bodies (see models) with T-type operating members. The 15mm, 22mm and 28mm compression sizes are for use with copper pipe (manufactured to EN 1057). The 20mm and 25mm compression sizes are for use PE pipes (manufactured to EN 12201-2). Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of screw down stop valves with plastic bodies, NBR washers and ‘O’ rings. For use with polyethylene pipe (manufactured to EN 12201). For above and below ground use. Maximum working pressure 6 bar. Cold water use only.
Range of regulating balancing valves with blue epoxy coated ductile iron bodies incorporating EPDM gaskets and hand wheel operating member. Maximum working pressure 16.0 Bar. Maximum operating temperature 85°C.
Range of regulating balancing valves with blue epoxy coated ductile iron bodies incorporating EPDM gaskets and hand wheel operating member. Maximum working pressure 16.0 Bar. Maximum operating temperature 85°C.
'M90-44'. Red coloured, injection moulded POM material. For use with water up to 85°C.
'GM2025-01'. Factory applied, grey coloured sulphate resistant cement. Mix cement:sand:water in a 1.5:1:0.4 mass ratio. Cure for 8 hours@23°C. For use with water up to 65°C. This material is only approved for the mixing and curing conditions that appear on the approval. If the mixing and/or curing conditions are varied from those specified on the approval then the material is not covered by the scope of the approval.
'YS-01 Powder Coating'. Factory applied, blue coloured epoxy powder coating. Apply as per manufacturer's instruction document 'HJ-Q-SOP-05' dated 2020-1-10. Cure for 10 minutes@200°C. For use with water up to 85°C. This material is only approved for the curing conditions that appear on the approval. If the cure conditions are varied from those specified on the approval then the material is not covered by the scope of the approval.
'MC-PROOF 4200 AE'. Site applied, cream coloured (once mixed), two-component urethane based coating. Mix Part A (amber liquid) with Part B (amber liquid) in a volume ratio of 1:1 and apply as per manufacturer's TDS dated 07.10.2025. Cure for 24 hours@7°C. For use with water up to 60°C. This material is only approved for the mixing and curing conditions that appear on the approval. If the mix and/or cure conditions are varied from those specified on the approval then the material is not covered by the scope of the approval.
'MC-PROOF 4210 AE'. Site applied, grey coloured (once mixed), two-component polyol and prepolymer based coating. Mix Part A (grey liquid) with Part B (amber liquid) in a volume ratio of 1:1 and apply as per manufacturer's TDS '07.10.2025'. Cure for 24 hours@7°C. For use with water up to 60°C. This material is only approved for the mixing and curing conditions that appear on the approval. If the mix and/or cure conditions are varied from those specified on the approval then the material is not covered by the scope of the approval.
'Tesnit BA-50'. Green coloured NBR/fibre material manufactured by calendering. For use with water up to 85°C. For use only as a jointing/gasket material having been tested at reduced surface area to volume ratio.
'AQUAFLOW HDPE PE80 BLUE PIPE'. Extruded, single layered (blue coloured) or dual layered (black coloured inner layer & blue coloured outer layer) HDPE pipes. For use with water up to 23°C.
'JXPE100LP'. Blue coloured, extruded HDPE pipe. For use with water up to 23°C.
'PTFE Thread Seal Tape 201 (white), 202 (pink), 203 (yellow), 204 (blue) & 205 (grey)'. PTFE tapes, manufactured by extrusion, stretching and calendaring, available in a range of colours. For use with water up to 85°C.
'70 EP111p' Lip Seals and 'O' rings. Black coloured, EPDM components with shore hardness of 70. Compression moulded Lip Seals have an in-radius size of 2.7mm. Compression moulded ‘O’ rings have an in-radius size of 1.5mm. Injection moulded ‘O’ rings have an in-radius size of 1.0mm. For use with water up to 85°C.
'TIMO 5-70 Gaskets & ‘O’ rings'. Black coloured, injection moulded EPDM gaskets & ‘O’ rings. Shore hardness 70. Tested in-radius size between 0.50mm & 2.66mm. For use with water up to 85°C.
'E7053AA'. Black coloured, compression moulded EPDM 'O' rings. Shore hardness 70. Tested in-radius size between 0.35mm and 5.0mm. For use with water up to 85°C.
'JHSX-02'. Black coloured, compression moulded EPDM rubber material. Shore hardness 50. Tested in-radius size 1.05mm. For use with water up to 85°C.
'XX-01'. Black coloured, compression moulded EPDM rubber material. Shore hardness 50. Tested in-radius size 1.05mm. For use with water up to 85°C.
Range of combination tap assemblies with a single outlet and fixed spout incorporating a manual diverter to shower. With a ceramic disc headwork and the spout incorporates a flow straightener. Maximum temperature 65 °C Maximum pressure 5.0 bar
BS EN 14055: 2018 concealed WC cistern incorporating a side or bottom entry compact type float operated inlet valve providing a Type AG air gap with a pneumatic or cable operated drop valve capable of full flush volumes of up to 6 litres and reduced flush of up to 4 litres. The cistern can be operated by manual push button / push plate, (not supplied). Maximum working pressure 10.0 bar. Cold water use only.
Concealed WC dual flushing cistern with a side entry BS 1212-4 (2016) float operated inlet valve providing a Type AG air gap arrangement and a dual flush outlet valve. The flush volume is operated by a two-push button assembly for a 6 or 3 litre flush volume. The cistern is operated by a manual push button and incorporates a servicing valve and flexible hose on the inlet supply. Maximum working pressure – 10.0 bar, cold water use only.
BS EN 14055: 2018 concealed WC cistern incorporating a side entry compact type float operated inlet valve providing a Type AB air gap with a pneumatic or cable operated drop valve capable of full flush volumes of up to 6 litres and reduced flush of up to 4 litres. The cistern can be operated by manual push button / push plate, (not supplied). Maximum working pressure 10.0 bar. Cold water use only.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Wastes | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 58 130 xx0 | Various | G 1/2" | open outlet bar | 65 °C | hansgrohe | on faceplate | Yes | Not applicable | Not Applicable | Open Outlet | Click Type | |
| 42 540 xx0 | Various | G 1/2" | open outlet bar | 65 °C | AXOR | on faceplate | Yes | Not applicable | Not Applicable | Open Outlet | Click Type | |
| 58 119 xx0 | Various | basic set 58152180 | open outlet bar | 65 °C | hansgrohe | on faceplate | Yes | Not applicable | Not Applicable | Open Outlet | Click Type | |
| 58 131 xx0 | VArious | basic set 58152180 | open outlet bar | 65 °C | hansgrohe | on faceplate | Yes | Not applicable | Not Applicable | Open Outlet | Click Type | |
| 58 152 180 | NA | G 1/2" | open outlet bar | 65 °C | hansgrohe | sticker only, marking will be on the finish set | Yes | Not applicable | Not Applicable | Open Outlet |
model 58131xx0 and 58119xx0 are identical in the water pathway, only difference is the cover plate design. model 58130xx0 and 42540xx0 are both composed of the finish set 58131xx0/58119xx0 and basic set 58152180, only difference is the marking on the faceplate 58130xx0= hansgrohe, 42540xx0= AXOR
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SH001* | Various | ½” BSP (F) conical nut x ½” BSP(F) conical nut | For open outlet use only bar | 85 °C | WINSDRUM | On conical nut | No | Not applicable | Not Applicable | Not Applicable | |
| SH002* | Various | ½” BSP (F) conical nut x M15x1 | For open outlet use only bar | 85 °C | WINSDRUM | On conical nut | No | Not applicable | Not Applicable | Not Applicable |
1) The products are interlock type 2) * denotes finish and can be replaced by: C - Chrome RG - Rose Gold BTG - Brushed Titanium gold BZG - Brushed Zirconium gold BRG - Brushed Rose gold MW - Matte white BS - Brushed stainless BN - Brushed nickel PN - Polished nickel GM - Gunmetal B - Matte black TG - Titanium gold ZG - Zirconium gold BC - Black+chrome W - White CW - Chrome+white Q - Quartzite ZGC - Zirconium gold+chrome TGC - Titanium gold+chrome M - Medieval A - Antique bronze CP - Champagne BL - Brushed lead BP - Polished Black
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 1L325604DH | Matt black | 15mm compression | 10 bar | 60 °C | WIDE | Body | No | 1/2 Turn Ceramic cartridge | Not Applicable | Not Applicable | Shower Hose, Handset, Fixed Head, Riser Rail, |
| 1L325604MA | Tri-chrome | 15mm compression | 10 bar | 60 °C | WIDE | Body | No | 1/2 Turn Ceramic cartridge | Not Applicable | Not Applicable | Shower Hose, Handset, Fixed Head, Riser Rail, |
| 1L325604SA1 | Brushed gold | 15mm compression | 10 bar | 60 °C | WIDE | Body | No | 1/2 Turn Ceramic cartridge | Not Applicable | Not Applicable | Shower Hose, Handset, Fixed Head, Riser Rail, |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 30 122 100 | NA | NA | 16 bar | 70 °C | HG | on the body | Yes | Ceramic cartridge | Not Applicable | Not Applicable | |
| 30 122 101 | NA | NA | 16 bar | 70 °C | HG | on the body | Yes | Ceramic cartridge | Not Applicable | Not Applicable | |
| 30 579 600 | NA | NA | 16 bar | 70 °C | HG | on the body | Yes | Ceramic cartridge | Not Applicable | Not Applicable | |
| 30 333 001 | NA | NA | 16 bar | 70 °C | HG | on the body | Yes | Ceramic cartridge | Not Applicable | Not Applicable | |
| 30 746 700 | NA | NA | 16 bar | 70 °C | HG | on the body | Yes | Ceramic cartridge | Not Applicable | Not Applicable | |
| 30 746 702 | NA | NA | 16 bar | 70 °C | HG | on the body | Yes | Ceramic cartridge | Not Applicable | Not Applicable |
30 122 100 - Diameter= 25,4mm 30 122 101 - Diameter= 25,4mm 30 333 001 - Diameter= 25,4mm 30 746 700 - Diameter= 25,4mm 30 746 702 - Diameter= 25,4mm 30 579 600 - Diameter= 25,4mm
Range of single hole, single outlet fixed combination tap assemblies (brass bodies – various finishes) incorporating ceramic cartridge headworks with single lever operating members. The spout outlets incorporate plastic aerators. Model (CH20x) is supplied with a lever operated pop-up waste (not verified by test). Maximum working pressure Bar Maximum operating temperature °C.
Floor mounted spout outlet, (brass body – various finishes) incorporating a plastic aerator. Maximum operating temperature 65°C.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| JD-SP501 ** | Various | BSP 1/2" (F) | Open outlet only bar | 60 °C | Kind | Spout | No | Not applicable | Aerator | ||
| SJS-SP205 ** | Various | BSP 1/2" (F) | Open outlet only bar | 60 °C | Kind | Decorative plate | No | Not applicable | Aerator |
** represents different types of finishes as follows: C: Chrome NS: Nickel brushed RP: Red powder coated TS: Zr gold brushed RS: Rose gold brushed GS: Gold brushed GM: Gun metal brushed B: Electroplated matte black W: White CB: Matte black and chrome CW: White and chrome TG: Zr gold plated RG: Rose gold plated G: Gold plated GP: Gun metal plated BS: Gun gray brushed
‘Union Range’ of wall mounted shower arms (brass bodies) and overhead showers (plastic bodies) both with various finishes (see models). Maximum operating temperature 85°C.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 13.20205.G15.CP03-8510 | Chromed | BSP 1/2" (M) | 16 bar | 85 °C | Company logo (V&G), WRAS, size, production date (MM-YY) | Body | No | ||||
| 13.20205.G15.CP5R-8510 | BSP 1/2" (M) | 16 bar | 85 °C | Company logo (V&G), WRAS, size, production date (MM-YY) | Body | No | |||||
| 13.20205.G15.CP5R-8511 | BSP 1/2" (M) | 16 bar | 85 °C | Company logo (V&G), WRAS, CR, size, production date (MM-YY) | Body | No | |||||
| 13.20205.G20.CP03-8510 | Chromed | BSP 3/4" (M) | 16 bar | 85 °C | Company logo (V&G), WRAS, size, production date (MM-YY) | Body | No | ||||
| 13.20205.G20.CP5R-8510 | BSP 3/4" (M) | 16 bar | 85 °C | Company logo (V&G), WRAS, size, production date (MM-YY) | Body | No | |||||
| 13.20205.G20.CP5R-8511 | BSP 3/4" (M) | 16 bar | 85 °C | Company logo (V&G), WRAS, CR, size, production date (MM-YY) | Body | No | |||||
| 13.20245.A15.CP5R-8510 | BSP 1/2" (M) | 16 bar | 85 °C | Company logo (V&G), WRAS, size, production date (MM-YY) | Body | No | |||||
| 13.20245.A20.CP5R-8510 | BSP 3/4" (M) | 16 bar | 85 °C | Company logo (V&G), WRAS, size, production date (MM-YY) | Body | No | |||||
| 13.20255.G15.CP03-8510 | Chromed | BSP 1/2" (M) | 16 bar | 85 °C | Company logo (V&G), WRAS, size, production date (MM-YY) | Body | No | ||||
| 13.20255.G15.CP5R-8510 | BSP 1/2" (M) | 16 bar | 85 °C | Company logo (V&G), WRAS, size, production date (MM-YY) | Body | No | |||||
| 13.20255.G15.CP5R-8511 | BSP 1/2" (M) | 16 bar | 85 °C | Company logo (V&G), WRAS, CR, size, production date (MM-YY) | Body | No | |||||
| 13.20275.G15.CP5R-8510 | BSP 1/2" (M) | 16 bar | 85 °C | Company logo (V&G), WRAS, size, production date (MM-YY) | Body | No | |||||
| 13.20305.G15.CP03-8510 | Chromed | BSP 1/2" (M) | 16 bar | 85 °C | Company logo (V&G), WRAS, size, production date (MM-YY) | Body | No | ||||
| 13.20305.G15.CP5R-8510 | BSP 1/2" (M) | 16 bar | 85 °C | Company logo (V&G), WRAS, size, production date (MM-YY) | Body | No | |||||
| 13.20305.G15.CP5R-8511 | BSP 1/2" (M) | 16 bar | 85 °C | Company logo (V&G), WRAS, CR, size, production date (MM-YY) | Body | No | |||||
| 13.20305.G20.CP03-8510 | Chromed | BSP 3/4" (M) | 16 bar | 85 °C | Company logo (V&G), WRAS, size, production date (MM-YY) | Body | No | ||||
| 13.20305.G20.CP5R-8510 | BSP 3/4" (M) | 16 bar | 85 °C | Company logo (V&G), WRAS, size, production date (MM-YY) | Body | No | |||||
| 13.20305.G20.CP5R-8511 | BSP 3/4" (M) | 16 bar | 85 °C | Company logo (V&G), WRAS, CR, size, production date (MM-YY) | Body | No | |||||
| 13.20365.G15.CP03-8510 | Chromed | BSP 1/2" (M) | 16 bar | 85 °C | Company logo (V&G), WRAS, size, production date (MM-YY) | Body | No | ||||
| 13.20365.G15.CP5R-8510 | BSP 1/2" (M) | 16 bar | 85 °C | Company logo (V&G), WRAS, size, production date (MM-YY) | Body | No | |||||
| 13.20365.G15.CP5R-8511 | BSP 1/2" (M) | 16 bar | 85 °C | Company logo (V&G), WRAS, CR, size, production date (MM-YY) | Body | No |
Wall mounted thermostatic bar shower mixer (matte black plated brass), incorporating a ceramic disc diverter headwork controlling the flow between shower handset and overhead shower with a dome type operating member and a thermostatic cartridge controlling the temperature with a dome type operating member that incorporates a manual override button. The inlets incorporate stainless-steel EPDM strainer washers and approved check valve cartridges; (however, the complete product has not been fully tested to demonstrate it provides backflow protection). The product is supplied with screwdriver operated isolation valves, an overhead shower incorporating an EPDM washer at the inlet, shower handset, shower hose incorporating an EPDM washer at the captive nut and a stainless-steel EPDM strainer washer in the conical nut & riser rail assembly. Maximum working pressure 10.0 bar.
Non-metallic materials and components comply with BS6920 at 60°C
Range of wall mounted concealed thermostatic shower valves (brass bodies) incorporating single, double and triple outlets. Models (GR-AZ 50 & GR-AZ 50G) incorporate quarter turn ceramic disc headworks, models (GR-AZ 51 & GR-AZ 51G) incorporate two-way diverter cartridges & model (GR-AZ 53) incorporates a quarter turn ceramic disc headwork and two-way diverter valve. All models incorporate thermostatic mixing cartridges and approved check valve cartridges, however, the complete product has not been fully tested to demonstrate it provides backflow protection. Maximum working pressure Bar Maximum operating temperature °C.
Spherical valves with chrome or nickel plated brass body, chrome plated ball, PTFE seats and FKM ‘O’-ring. The products are available with lever, lockable lever or tee handles. Maximum working pressure 40.0 bar. Maximum operating temperature 85°C.
'RADILON® DT RV300RKC2 205 WT'. White coloured, injection moulded, glass filled Polyamide 612 material. For use with water up to 85°C.
'SAB A16 Compression Fittings'. Black coloured, compression fitting bodies, injection moulded from polypropylene (PP-B). For use with water up to 60°C.
'JSP/SF-02'. Black coloured, compression moulded EPDM rubber material. Shore hardness 50. Tested in-radius size 1.05mm. For use with water up to 85°C.
'WEICONLOCK AN 306-20'. Green coloured anaerobic adhesive. For use with water up to 85°C. This product is to be applied and cured in strict accordance with the manufacturer's instructions
Page 12 of 12
We use cookies to give you the best possible experience with WRAS. Some are essential to provide website functions and ensure the website is secure. We also use cookies to help us understand how people use the site and to make improvements. Click "Accept All" to enable recommended settings or click "Manage cookies" to adjust your settings. For more details, see our Cookie Policy.
