Water Regulations Approval Scheme Ltd

Tubes

Section Code 1860 : Plastic hoses.

WRAS Approval Number: #2001335

Range of stainless-steel interlock EPDM or PVC lined hose assemblies. Open outlet use only. Maximum operating temperature 85°C

Section:: 1860 Tubes
Description:: Plastic hoses.
Size:: ½” BSP (F) captive nut end connections
Marking:: NT (company logo), WRAS, year (YYYY) on sleeve
Installation Requirements:: R001 R040
Expiry date:: 31/01/2025
Model:: NT (stainless steel double lock)-x-xx-xx-xxx-xxx Where – X = inner hose: A – EPDM, B – PVC 1st xx = connector size 01 = G1/2” Hexagon nut 2nd xx = connector size 01 = G1/2” Conical nut 1st xxx = hose bore: 140 = DN14, 160 = DN16 2nd xxx = hose length; 50cm to 300cm

Approval Holder:: Xiamen Nuote Sanitary Ware Co. Ltd.

Company Name
Xiamen Nuote Sanitary Ware Co. Ltd.
Address
no 563 TONLONG SECOND ROAD TORCH HI TECH ZONE
Postcode
CHINA
Country
XIAMEN

View All Listings by this Company
Manufacturer:: Xiamen Nuote Sanitary Ware Co. Ltd.

Company Name
Xiamen Nuote Sanitary Ware Co. Ltd.
Address
no 563 TONLONG SECOND ROAD TORCH HI TECH ZONE
Postcode
CHINA
Country
XIAMEN

View All Listings by this Company

WRAS Approval Number: #2001359

“LUXOR SILICONE LINE” range of stainless steel braided silicone lined flexible hose assemblies with various end connections (see model), incorporating EPDM ‘O’-rings and washers. Maximum working pressure 10.0 bar.

Non-metallic materials and components comply with BS6920 at 70°C

Section:: 1860 Tubes
Description:: Plastic hoses.
Size:: Please refer to model.
Marking:: Lux, year of manufacture (YY), WRAS, DN, Temp (70°C) and PN on crimp connection.
Installation Requirements:: R001 R008
Expiry date:: 31/01/2025
Model:: Existing Model: Bore diameters: DN6, DN8 & DN13. End connections (one or both sides): Male: 3/8 BSP, 1/2 BSP, 1/2 BSP (H.N.), 1/2 BSP (D.B.), 1/2 BSP 32 mm (H.N.), 1/2 BSP swivel, 1/2 NPT (H.N.), 1/2 taper (H.N.), 3/4 BSP, M8 hexag. Short, M8 hexag. Medium, M8 cyl. Short, M8 cyl. Medium, M8 cyl. Long, M10, M10 hexag. Short, M10 hexag. Short (C.S.), M10 hexag. Medium, M10 hexag. Long, M10 (H.N.), M10 (P.1.), M11, M12, M12 hexag. Medium, M12 (P.1.), M12 (C.T.), M15 swivel. Female (captive nut): 3/8 BSP, 3/8 BSP w/gasket, 3/8 BSP (G.B.), 3/8 BSP 06,6mm (G.B.), 3/8 BSP w/gasket, 3/8 BSP w/O-ring, 1/2 BSP, 1/2 BSP w/gasket, 1/2 BSP w/O-ring (H.N.), 1/2 NPSM, 3/4 BSP, 3/4 BSP w/gasket, 3/4 BSP w/2 O-rings (H.N.), M12, M15. Female elbow (captive nut): 3/8 BSP, 3/8 BSP w/gasket, 3/8 BSP w/O-ring (G.B.), 3/8 BSP H29,5mm w/O-ring (G.B.), 1/2 BSP, 1/2 BSP w/gasket, 1/2 BSP w/O-ring (H.N.), 1/4 BSP, 3/4 BSP, 3/4 BSP w/gasket, 3/4 BSP w/2 O-rings (H.N.), M24x1,5 w/O-ring (A.T.). Plug-in: straight pipe Ø10 mm, straight pipe Ø10 mm w/recess, straight pipe Ø15 mm (A.T.), straight plug-in (A.T.), straight plug-in w/O-ring (A.T.), straight plug-in w/2 O-rings, straight plug-in w/O-ring (F.1.), elbow pipe w/2 O-rings (A.T.). Compression: Ø10mm - Ø15mm Models added April 2023: DN6 brass end connections 9/16” w/gasket (female) Length 300 e Length 500 mm DN8 brass end connections 9/16” w/gasket (female) Length 300 e Length 500 mm

Approval Holder:: LUXOR S.p.A.

Company Name
LUXOR S.p.A.
Address
Via Madonnina, 94 Montichiari (BS)
Postcode
25018
Country
Italy
Phone
+39 030 9961161
General Email
marco.cauzzi@luxor.it

View All Listings by this Company
Manufacturer:: LUXOR S.p.A.

Company Name
LUXOR S.p.A.
Address
Via Madonnina, 94 Montichiari (BS)
Postcode
25018
Country
Italy
Phone
+39 030 9961161
General Email
marco.cauzzi@luxor.it

View All Listings by this Company

WRAS Approval Number: #2004004

Range of stainless steel or nylon braided PEX lined flexible hose assemblies with EPDM washers or ‘O’-rings and a variety of end connections. Maximum working pressure 10.0 bar. Maximum operating temperature 65°C.

Section:: 1860 Tubes
Description:: Plastic hoses.
Size:: See model.
Marking:: Solex, WRAS and date of manufacture (MMYY) on ferrule.
Installation Requirements:: R001 R008
Expiry date:: 30/04/2025
Model:: H16X0005s-01: ½” BSP Captive nut x M8*1 (Bore sizes: DN6, DN7). H16X0005s-02: ½” BSP Captive nut x M10*1 (Bore sizes: DN7, DN8). H16X0005s-03: ⅜” BSP Captive nut x M8*1 (Bore sizes: DN6, DN7). H16X0005s-04: ⅜” BSP Captive nut x M10*1 (Bore sizes: DN6, DN7). H16X0005s-05: ½” BSP Captive nut x ½” BSP Captive nut (Bore sizes: DN6, DN7, DN8). H16X0005s-06: M8*1 x M16*1 (Bore size: DN6).

Approval Holder:: Xiamen Solex High-Tech Industries Co., Ltd

Company Name
Xiamen Solex High-Tech Industries Co., Ltd
Address
No. 298 Yangguang Road West, Haicang District, Xiamen, 361022
Country
China
General Email
brian_lin@mysolex.com

View All Listings by this Company
Manufacturer:: Xiamen Solex High-Tech Industries Co., Ltd

Company Name
Xiamen Solex High-Tech Industries Co., Ltd
Address
No. 298 Yangguang Road West, Haicang District, Xiamen, 361022
Country
China
General Email
brian_lin@mysolex.com

View All Listings by this Company

WRAS Approval Number: #2006327

Range of shower hoses incorporating a PVC inner liner with corrugated metal outer casing, EPDM washers and stainless steel strainer. Maximum operating temperature 60°C.

Section:: 1860 Tubes
Description:: Plastic hoses.
Open outlet use only.
Size:: ½” BSP (F) captive nut
Marking:: DTC15 (brand of Methven), WRAS and date of manufacture (YY) on ferrule.
Installation Requirements:: R001 R040
Expiry date:: 30/06/2025
Model:: HOS1.75CPS02 D50010011

Approval Holder:: Methven UK Limited

Company Name
Methven UK Limited
Address
3-3A Stone Cross Court Yew Tree Way Golborne Warrington
Postcode
WA3 3JE
Country
United Kingdom
Phone
0800 195 1602
General Email
raluca.olariu@uk.methven.com

View All Listings by this Company

WRAS Approval Number: #2007058

Range of interlocked, chrome plated, stainless-steel shower hoses incorporating EPDM washers and a polyethylene liner. Maximum operating temperature 70°C.

Section:: 1860 Tubes
Description:: Plastic hoses.
Open outlet use only.
Size:: ½” BSP (F) captive nut.
Marking:: Neoperl, date of manufacture (YYYY/MM) and 21 on crimped connector.
Installation Requirements:: R001
Expiry date:: 31/07/2025
Model:: Chromalux Agraff CRG Hose (G1/2 conicals) - part code: 39.56CD.EFG.HI Chromalux Agraff CRG Hose (G1/2 conical, G1/2 knurled) - part code: 39.56CD.EFG.HI

Product Images

Approval Holder:: Neoperl GmbH

Company Name
Neoperl GmbH
Address
Klosterrunstrasse 9-11, Müllheim
Postcode
D-79379
Country
Germany
Phone
+49 7631 188 374
General Email
DE.Approvals@neoperl.com

View All Listings by this Company
Manufacturer:: Neoflex (Xinhui) Limited

Company Name
Neoflex (Xinhui) Limited
Address
No. 3 Yanan Industrial Zone, Yamen Town, Xinhui District, 529149, Jiangmen, Guangdong Province
Country
China
General Email

View All Listings by this Company

WRAS Approval Number: #2007327

Range of flexible hoses assemblies incorporating a braided outer with TPSiV liner and various brass end connections. Incorporating NBR or EPDM washers and ‘O’-rings. Maximum operating temperature 85°C.

Section:: 1860 Tubes
Description:: Plastic hoses.
Open outlet use only.
Size:: See model.
Marking:: FQR , date of manufacture (YY), nominal diameter & WRAS on ferrule.
Installation Requirements:: R001
Expiry date:: 31/07/2025
Model:: P6K, P6KL, P6KZ - DN6 available with the following end connection options: 8X1, 10x1, 12X1, 15x1, 14x1, F1/2, F15X1, F14X1, M3/8, F3/8 conical, F1/2 conical & T8. P9K, P9KL, P9KZ - DN8 available with the following end connection options: 10x1, 12X1, 15x1, 14x1, F1/2, F15X1, F14X1, M3/8, F3/8 conical, F1/2 conical & T8.

Product Images

Approval Holder:: F.Q.R. Frattini S.R.L.

Company Name
F.Q.R. Frattini S.R.L.
Address
Via Per Borgomanero 71 Briga Novarese (No)
Postcode
28010
Country
Italy
Phone
+39 0322 94100
General Email
fqr3@fqrfrattini.com

View All Listings by this Company
Manufacturer:: F.Q.R. Frattini S.R.L.

Company Name
F.Q.R. Frattini S.R.L.
Address
Via Per Borgomanero 71 Briga Novarese (No)
Postcode
28010
Country
Italy
Phone
+39 0322 94100
General Email
fqr3@fqrfrattini.com

View All Listings by this Company

WRAS Approval Number: #2006355

Range of braided (stainless steel or stainless steel braided plus black nylon wire or nylon) PEX lined flexible hose assemblies with various end connections and lengths (see model section). Connections 35, 36, 37, 38, 39, 40, 41 and 42 noted within the model section are for use with copper tube manufactured to BS2871 or PPR pipe manufactured to BS 15874. Maximum working pressure 10.0 bar. Maximum operating temperature 60°C.

Section:: 1860 Tubes
Description:: Plastic hoses.
Size:: See model.
Marking:: Jianglin, WRAS & year of manufacture (YYYY) on ferrule.
Installation Requirements:: R001 R008
Expiry date:: 30/06/2025
Model:: JL – A*B – XX – D – 2 - XXX Where model = JL – Connection A * Connection B – DN – Outer braided material – Inner tube material – Length JL = abbreviation of manufacturer’s company name Jianglin. A*B = Connection A and Connection B (from 01 to 42): Connections 01 and 02 only applicable for DN6 bore hoses only. Connections 03, 19, 26, and 29 applicable for DN6 and DN8 bore hoses only. Connections 05, 06, 20, 21, 22, 23, 30, 35, 36, 39 and 40 applicable for DN6, DN8 and DN10 bore hoses only. Connections 04, 07, 08, 09, 10, 11, 12, 24, 31, 33, 37 and 41 applicable for DN6, DN8, DN10 and DN13 bore hoses only. Connections 13, 14 and 15 applicable for DN8, DN10, DN13 Connections 25 and 27 applicable for DN8, DN10 and DN13 bore hoses only. Connections 16, 17, 18 and 28 applicable for DN10, DN13 bore hoses only. Connections 32, 34, 38 and 42 apply to all bore hoses. 01 = F1/4, 02 = F1/4 elbow, 03 = M1/4, 19 = M8*(12-110) with single ‘O’-ring or double ‘O’-ring, 26 = F15, 29 = 10mm compression, 05 = F3/8 knurling nut, 06 = F3/8 insert without nut, 20 = M10*(12-110) with single ‘O’-ring or double ‘O’-ring, 21 = M11*(12-110) with single ‘O’-ring or double ‘O’-ring, 22 = M12*(12-110) with single ‘O’-ring or double ‘O’-ring, 23 = M14*(12-110) with single ‘O’-ring or double ‘O’-ring, 30 = 12mm compression fitting, 35 = 10mm pushfit, 36 = 12mm pushfit, 39 = 10mm pushfit isolation valve, 40 = 12mm pushfit isolation valve, 04 = F3/8, 07 = F3/8 elbow, 08 = M3/8, 09 = F1/2, 10 = F1/2 wing nut, 11 = F1/2 elbow, 12 = M1/2, 24 = M15*(12-110) with single ‘O’-ring or double ‘O’-ring, 31 = 15mm compression fitting, 33 = 15mm isolation valve, 37 = 15mm pushfit, 41 = 15mm pushfit isolation valve, 13 = F3/4, 14 = F3/4 elbow, 15 = M3/4, 16 = F1, 17 = F1 elbow, 18 = M1 28 = 22mm smooth tube, 25 = M16*(12-110) with single ‘O’-ring or double ‘O’-ring, 27 = 15mm smooth tube, 32 = 22mm compression fitting, 34 = 22mm isolation valve, 38 = 22mm pushfit, 42 = 22mm pushfit isolation valve. XX = DN (Dimension from 06 to 19): DN6 = 06, DN8 = 08, DN10 = 10, DN13 = 13. D = Outer braided material: SS = stainless steel wire, SN = stainless steel wire plus black nylon wire, N = Nylon Braided. Inner tube material: 2 = PEX. XXX = Length (15cm to 200cm): 015 = 15cm … 0200 = 200cm For example: JL-09*20-08-SS-2-045 would be for F1/2 x M10, DN8, stainless steel braided, PEX inner tube, 45cm long.

Approval Holder:: Yuhuan Jianglin Plumbing Hose & Parts Inc.

Company Name
Yuhuan Jianglin Plumbing Hose & Parts Inc.
Address
2 Jindifu Road Yuhuan Economic Development Zone Yuhuan
Postcode
317600
Country
China
Phone
86-576-89901684
General Email
coo@cnjianglin.com

View All Listings by this Company
Manufacturer:: Yuhuan Jianglin Plumbing Hose & Parts Inc.

Company Name
Yuhuan Jianglin Plumbing Hose & Parts Inc.
Address
2 Jindifu Road Yuhuan Economic Development Zone Yuhuan
Postcode
317600
Country
China
Phone
86-576-89901684
General Email
coo@cnjianglin.com

View All Listings by this Company

WRAS Approval Number: #2003378

Range of PVC outer and inner lined flexible shower hoses with polyester braiding between the layers, plastic end connections and NBR washers. Maximum operating temperature 65°C.

Section:: 1860 Tubes
Description:: Plastic hoses.
Open outlet use only.
Size:: ½” BSP (F)
Marking:: Delmei, WRAS and date of manufacture (YYYY/MM/DD) on end connector.
Installation Requirements:: R001
Expiry date:: 31/03/2025
Model:: 2DH3111-00-012-000 (red connectors). 2DH3111-01-012-000 (yellow connectors). 2DH3111-02-012-000 (blue connectors). 2DH3111-03-012-000 (green connectors).

Approval Holder:: Xiamen Delmei Sanitary Ware Co Ltd

Company Name
Xiamen Delmei Sanitary Ware Co Ltd
Address
No. 700-702, Caotang Rd, Tong'an District, Xiamen China 361100

View All Listings by this Company
Manufacturer:: Xiamen Delmei Sanitary Ware Co Ltd

Company Name
Xiamen Delmei Sanitary Ware Co Ltd
Address
No. 700-702, Caotang Rd, Tong'an District, Xiamen China 361100

View All Listings by this Company

WRAS Approval Number: #2007067

Range of stainless steel braided, white (translucent) polyethylene lined (CPWX models) or white elastomeric thermoplastic (TPSiV) lined (SPWX models) flexible hose assemblies. Hoses are available with a variety of end connections (see model), either brass or nickel plated brass (SPWX/CPWX10 models). Maximum working pressures 10.0 bar. Maximum operating temperature 90°C.

Section:: 1860 Tubes
Description:: Plastic hoses.
The SPWX/CPWX08 hoses with MB10 ends are intended for a 10mm compression outlet connection, but no nut and olive are supplied.
Size:: See model
Marking:: HG (brand of Hydrogomma), WRAS and year of manufacture (YYYY) on crimped connector.
Installation Requirements:: R001 R008
Expiry date:: 31/07/2025
Model:: SPWX/CPWX06 hoses: ⅜” captive nut (F38). SPWX/CPWX08 hoses: 10mm compression - MB10 (B10). ⅜” BSP (M) (M38). ⅜” captive nut (F38). ½” BSP (M) (M12). ½” captive nut (F12). ¾” BSP (M) (M34). ¾” captive nut (F34). SPWX/CPWX10 hoses: ⅜” BSP (M) (M38). ⅜” captive nut (F38). ½” BSP (M) (M12). ½” captive nut (F12). SPWX/CPWX13 hoses: ½” BSP (M) (M12). ½” captive nut (F12). ¾” BSP (M) (M34). ¾” captive nut (F34). The reference in the brackets at the end of each size is the corresponding fitting code used in the model key code structure. Model key code: Range name-hose diameter-fitting 1-dimension-fitting 2-dimension-hose length. Where: Range name = SPWX or CPWX Diameter = DN size of hose - 06, 08, 10, 13. Fitting 1-dimension = See size section for codes. Fitting 2-dimension = See size section for codes. Hose length = 3-digit length in cm, e.g. 050 = 50cm long. Example code: SPWX08M38F12050 SPWX range hose, DN 8 hose diameter, ⅜” BSP (M) x ⅜” captive nut, 50cm long.

Product Images

Approval Holder:: Hydrogomma Spa

Company Name
Hydrogomma Spa
Address
Via Delle Industrie 2/4 20884 Sulbiate Milano
Country
Italy

View All Listings by this Company
Manufacturer:: Hydrogomma Spa

Company Name
Hydrogomma Spa
Address
Via Delle Industrie 2/4 20884 Sulbiate Milano
Country
Italy

View All Listings by this Company

WRAS Approval Number: #2007039

Range of PET (Polyethylene terephthalate) braided flexible hoses incorporating HDPE liner and EPDM ‘O’-rings. Maximum working pressure 5.0 bar. Maximum operating temperature 85°C Models added in January 2022: Maximum operating temperature 70°C.

Section:: 1860 Tubes
Description:: Plastic hoses.
Size:: See model
Marking:: TUCAI and product information on ferrule. The production information is in the following format: NT or TB/XX/WRAS/DNYY. NT or TB denotes site of manufacture. XX denotes year of manufacture (YY). WRAS denotes WRAS Approval. DNYY denotes bore diameter and is replaced with DN7 or DN8.
Installation Requirements:: R001
Expiry date:: 31/07/2025
Model:: Pull Out Twist Mini range: DN7 bore diameter with end connections: H1/2 conical, H1/2 ET, H1/2 UJ, H⅜ UJ, H⅜ captive nut, H1/2 captive nut, H11X1 captive nut, M15X1, M10X1, M8X1, M12X1, M14X1, M15X1 with O-ring, LISO 10, LISO 8, CLIP 10, CLIP 11, G⅜ BSP. Pull Out Twist range: DN8 bore diameter with end connections: H1/2 conical, H1/2 ET, H1/2 UJ, H⅜ UJ, H⅜ captive nut, H1/2 captive nut, M15X1, M10X1, M8X1, M12X1, M14X1, M15X1 with O-ring, LISO 10, LISO 8, CLIP 11, CLIP 15, G⅜ BSP. Models added in January 2022: Pullout Twist Mini Range (braiding ACB): DN7 bore diameter with end connections: M16x1, M22x1, 1/2-18UNS, 11/16-16 UNS. Pullout Twist Range (braiding ACB): DN8 bore diameter with end connections H11x1 Captive nut, CLIP 10, M16x1, M18x1.5, M22x1, CLIP 14, 1/2-18UNS, 11/16-16 UNS.

Product Images

Approval Holder:: Tucai SA

Company Name
Tucai SA
Address
Llobateras 10-12, Poligomo Industrial Santiga, 08210 Barbera Del Valles (Barcelona)
Country
Spain
Phone
+34 93 718 9562

View All Listings by this Company
Manufacturer:: Ningbo Tucai Flexible Pipe Co., Ltd. & TUCAI BULGARIA, Spdl. Ltd.

Company Name
Ningbo Tucai Flexible Pipe Co., Ltd. & TUCAI BULGARIA, Spdl. Ltd.
Address
Ningbo Tucai Flexible Pipe Co., Ltd. : No. 1 Beixing Road, Mazhu Town Yuyao, Zheijiang, 31450 (China) TUCAI BULGARIA, Spdl. Ltd.: 7538 Aydemir Village, 39 Chernozem Street, Silistra Region (Bulgarie)

View All Listings by this Company
