Section Code 2290 : Stop, gate, metal.
Back To Directory SectionsRange of non-rising gate valves with bronze bodies, brass wedges and PTFE gaskets. Having a handwheel or lock shield option depending on model. Maximum working pressure 16.0 bar. Maximum operating temperature 100°C.
Range of gate valves with bronze bodies and bronze discs, and PTFE seal. The valves operate via rising spindle headwork with hand wheel operating members. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
‘Series 54’ range of gate valves with blue epoxy coating ductile iron bodies and wedges and EPDM ‘O’-rings. The valves operate using a non-rising spindle headwork with hand wheel operating members. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves with DZR brass bodies and discs, and PTFE seal. The valves operate via a hand wheel. Maximum working pressure 16.0 bar. Maximum operating temperature 85C.
Range of gate valves with (blue epoxy coated) ductile iron bodies, incorporating EPDM O rings and wedges. The valves are operated via a non-rising spindle headwork and hand wheel. Maximum working pressure 25.0 bar. Maximum operating temperature 80ºC.
range of gate valves with brass bodies and brass wedges. The valves operate via a non-rising spindle headwork and hand wheel operating member. Maximum working pressure 20.0 Bar. Maximum operating temperature 85 °C.
Range of gate valves with bronze bodies and wedges incorporating PTFE seals and a non-rising stem. The valves are operated via handwheel mechanism. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of hand wheel operated or key operated gate valves with blue epoxy coated ductile iron bodies, EPDM ‘O’-rings and brass valve seats. Maximum working pressure 16.0bar. Maximum working temp 65°C.
Range of hand wheel operated or key operated gate valves with blue epoxy coated ductile iron bodies, ductile iron wedge encapsulated in EPDM and EPDM ‘O’-rings. Maximum working pressure 16.0bar. Maximum working temp 65°C.
Range of gate valves with blue epoxy coated cast iron bodies and EPDM coated cast iron wedges. The valves operate via non-rising spindle headwork. Maximum working pressure 10.0 bar and 16.0 bar (dependent on flange drilling pattern). Maximum operating temperature 85°C.
Range of gate valves with bronze bodies, brass bonnets, DZR stems and PTFE gland packing. The valves operate via a spindle headwork with hand wheel operating members. Maximum working pressure 25.0 bar. Maximum operating temperature 85°C.
Range of resilient seated gate valves with blue epoxy coated ductile iron bodies and bonnets and ductile iron wedges encapsulated in EPDM. The valve is operated via a non-rising spindle headwork. Maximum working pressure 16.0 bar. The maximum operating temperature 85°C
Range of gate valves (brass bodies) controlled via a handwheel with PTFE seals. Maximum working pressure 20.0 bar (L198 models), 16.0 bar (L197 & P474 models). Maximum operating temperature 99°C
Range of gate valves with ductile iron bodies (blue epoxy coated), EPDM rubber coated wedges and non-rising spindles with hand wheel operating members. Maximum working pressure 16.0 bar. Maximum operating temperature 80°C
Range of non-rising spindle gate valves with epoxy coated ductile iron body and wedge. Maximum working pressure 16.0 bar. Maximum operating temperature 80°C.
Range of Gate valves with ductile iron bodies (blue epoxy coated) with EPDM seals and wedge and non-rising spindle headwork operated via a hand wheel. Maximum working pressure 25 bar. Maximum operating temperature 80°C
Cim 50’ range of gate valves with a brass body and wedge, brass spindle, fibre/NBR gasket and PTFE stem gasket. The valves incorporate a non-rising stem with a hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 65°C.
Range of blue epoxy coated ductile iron gate valves incorporating an EPDM Wedge. The valves operate via a non-rising spindle headwork with hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of resilient seated gate valves with blue epoxy coated ductile iron bodies and bonnets and ductile iron wedges encapsulated in EPDM. The valve is operated via a non-rising spindle headwork. Maximum working pressure 16.0 bar. The maximum operating temperature 85°C
Range of non-rising spindle gate valves with epoxy coated ductile iron body and wedge. Maximum working pressure 16.0 bar. Maximum operating temperature 80°C.
Range of gate valves with either brass or DZR brass (GV20102DR prefix models) bodies with a brass wedge and PTFE packing. The valves operate via a non-rising spindle headworks that incorporates a wheel type operating member. Maximum working pressure 16.0 Bar. Maximum operating temperature 85°C.
Range of gate valves with blue epoxy coated ductile iron bodies, EPDM rubber coated ductile iron wedge. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 60°C.
Range of gate valves with brass bodies and brass wedges and PTFE seals. The valves operate via a non-rising spindle with hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valve with ductile iron bodies, wedge and bonnet (blue epoxy powder coated) and EPDM `O` rings and gaskets. Valves are operated via a non-rising spindle headwork. Maximum working pressure 16.0 bar. Maximum operating temperature 60°C.
Range of gate valves with bronze bodies and wedges and a PTFE packing ring. The valves are operated via a non-rising spindle with either a hand wheel operating member or are the Lockshield type. Maximum working pressure 16.0 bar, maximum operating temperature 85°C.
Range of gate valves with bronze bodies and wedges and a PTFE packing ring. The valves are operated via a non-rising spindle with either a hand wheel operating member or are the Lockshield type. Maximum working pressure 16.0 bar, maximum operating temperature 85°C.
Range of gate valves with ductile iron bodies (blue epoxy coated), brass sealing disc and hand wheel operating members. Maximum working pressures: 10.0 bar (DN350-DN500) and 25.0 bar (DN50-DN300) Maximum operating temperature 85°C
Range of gate valves with ductile iron bodies (blue epoxy coated), EPDM rubber coated wedges and hand wheel operating members. Maximum working pressure 16.0 bar. Maximum operating temperature 80°C
Range of gate valves with ductile iron bodies (blue epoxy coated), and EPDM coated wedge with hand wheel operating members. Maximum working pressure 16.0 bar. Maximum operating temperature 80°C
Range of gate valves with ductile iron bodies (blue epoxy coated), and EPDM coated wedge with hand wheel operating members. Maximum working pressure 16.0 bar. Maximum operating temperature 80°C
Gate valve with ductile iron body (blue epoxy coated) with non-rising spindle, EPDM seat and handwheel type operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves with blue epoxy coated ductile iron bodies and a ductile iron, EPDM coated wedge. Valves are operated via a non-rising spindle headwork with hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of hand wheel operated gate valves with blue epoxy coated ductile iron bodies and EPDM ‘O’-rings. Maximum working pressure 16.0 bar. Maximum operating temperature 80°C.
Range of gate valves with either brass or DZR brass bodies with a brass wedge and PTFE packing. The valves operate via a non-rising spindle headwork that incorporates a wheel type operating member. Maximum working pressure 16.0 Bar. Maximum operating temperature 85°C.
Range of gate valves with ductile iron bodies (blue epoxy coated), brass sealing disc and hand wheel operating members. Maximum working pressures: 10.0 bar (DN350-DN500) and 25.0 bar (DN50-DN300) Maximum operating temperature 85°C
Range of gate valves with blue epoxy coated ductile iron bodies, EPDM coated ductile iron wedge and EPDM seals. Maximum working pressure 16.0 bar. Maximum operating temperature 100°C.
Range of gate valves with ductile iron bodies (blue epoxy coated), EPDM coated wedge and EPDM o-rings. Maximum working pressure 10.0 bar and 16.0 bar. Maximum operating temperature 80°C
Range of resilient seated gate valves with blue epoxy coated ductile iron bodies and bonnets and ductile iron wedges encapsulated in EPDM. The valves are operated via a gear operated handwheel for sizes DN350 to 1200 and hand only for sizes DN40 to 300. Maximum working pressure 16.0 bar - DN40 – DN600, 10.0 bar DN700 – DN1200. maximum operating temperature 85°C.
Range of brass bodied gate valve with PTFE gaskets. Valves can either have a lockshield or hand wheel operated mechanism. 112120 series have bronze taper threaded ends and 112210 series have brass female threaded ends. Maximum working pressure 20.0 bar. Maximum operating temperature 60°C.
Range of gate valves having brass bodies and a PTFE gasket. The valves either have a handwheel or lockshield operating mechanism. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of blue epoxy coated ductile iron gate valves incorporating an EPDM Wedge. The valves operate via a non-rising spindle headwork with hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of blue epoxy coated ductile iron gate valves incorporating an EPDM Wedge. The valves operate via a non-rising spindle headwork with hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves with blue epoxy coated ductile iron bodies, EPDM coated ductile iron wedge and EPDM seals. Maximum working pressure 16.0 bar. Maximum operating temperature 100°C.
Range of gate valves with either brass or DZR brass (662468, 274331 & 662469 models) bodies with a brass wedge and PTFE packing. The valves operate via a non-rising spindle headworks that incorporates a wheel type operating member. Maximum working pressure 16.0 Bar. Maximum operating temperature 85°C.
Range of non-rising spindle gate valves with DZR brass bodies, with PTFE stem packing and gaskets. Operating members are either handwheel operated or lockshield. Maximum working pressure 20.0 bar. Maximum operating temperature 100°C.
Range of gate valves with blue epoxy coated ductile iron bodies, EPDM coated ductile iron wedge and EPDM seals. Maximum working pressure 16.0 bar. Maximum operating temperature 100°C.
Range of non-rising spindle gate valves with DZR brass bodies, with PTFE stem packing and gaskets. Operating members are either handwheel operated or lockshield. Maximum working pressure 20.0 bar. Maximum operating temperature 100°C.
Range of gate valves with DZR brass bodies with a brass wedge and PTFE packing. The valves operate via a non-rising spindle headworks that incorporates a wheel type operating member. Maximum working pressure 16.0 Bar. Maximum operating temperature 85°C.
Range of gate valves with DZR brass bodies and brass wedge. Valves are operated via a non-rising spindle headwork. Maximum operating pressure 20.0 Bar. Maximum operating temperature 100°C.
‘Z123’ range of gate valves with either brass or DZR brass (from October 2023) bodies and PTFE washers. Valves are operated via a non-rising spindle headwork. Maximum operating pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of gate valves incorporating either rising or non-rising spindle headworks and PTFE gaskets. The products are available as follows: Brass body, brass wedge and handwheel (132 prefix models). Bronze body, bronze wedge and handwheel (133 prefix models) or lockshield operating member (136 prefix models). Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves with bronze bodies with metal seats. The valves operate via a non-rising spindle headworks that incorporate a wheel type operating member or lock shield type (see models) Maximum working pressure 20.0 bar. Maximum operating temperature 85°C
Range of gate valves with bronze bodies, bronze wedge and PTFE gaskets. The valves operate via a hand wheel. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves FIG. 100 and FIG. 100LK with bronze bodies and bronze wedges. The valves operate via non-rising spindle head work with hand wheel or lock shield operating members. Maximum working pressure 20.0 bar. Maximum operating temperature 100°C
Range of resilient seated gate valves with blue epoxy coated ductile iron bodies and bonnets and ductile iron wedges encapsulated in EPDM. The valves are operated via a gear operated handwheel for sizes DN350 to 1200 and hand only for sizes DN40 to 300. Maximum working pressure 16.0 bar - DN40 – DN600, 10.0 bar DN700 – DN1200. maximum operating temperature 85°C.
Range of gate valves incorporating either rising or non-rising spindle headworks and PTFE gaskets. The products are available as follows: Brass body, brass wedge and handwheel (ART325 RS models). Bronze body, bronze wedge and handwheel (ART330 HW models) or lockshield operating member (ART330 LS models). Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves with bronze bodies with metal seats. The valves operate via a non-rising spindle headworks that incorporate a wheel type operating member or lock shield type (see models) Maximum working pressure 20.0 bar. Maximum operating temperature 85°C
Range of gate valves with blue epoxy coated ductile iron bodies, EPDM coated ductile iron wedges. The valves operate via a non-rising spindle headwork with hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves (gunmetal) with gunmetal bronze wedges, brass spindle and PTFE seals. Maximum working pressure 20.0 bar. Maximum operating temperature 100°C.
Range of gate valves incorporating bronze bodies and wedges with PTFE seals. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating bronze bodies and wedges with PTFE seals. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating brass bodies and wedge with PTFE seals. The valves operate via a non-rising spindle headwork that incorporates a wheel type operating member. Maximum working pressure 20.0 Bar. Maximum operating temperature 85°C.
Range of hand wheel operated or key operated gate valves with blue epoxy coated ductile iron bodies, ductile iron wedge encapsulated in EPDM and EPDM ‘O’-rings. Maximum working pressure 16.0bar. Maximum working temp 65°C.
Range of gate valves incorporating bronze bodies and wedges with PTFE seals. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves with blue epoxy coated ductile iron bodies, EPDM coated ductile iron wedges. The valves operate via a non-rising spindle headwork with hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of hand wheel operated gate valves with bronze bodies, bronze wedges, non rising spindles and graphite gaskets. Maximum working pressure 25.0 bar. Maximum operating temperature 100°C.
Range of gate valves incorporating bronze bodies and wedges with PTFE seals. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating bronze bodies and wedges with PTFE seals. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves with blue epoxy coated ductile iron bodies, EPDM coated ductile iron wedges. The valves operate via a non-rising spindle headwork with hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating bronze bodies and wedges with PTFE seals. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating bronze bodies and wedges with PTFE seals. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating bronze bodies and wedges with PTFE seals. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating bronze bodies and wedges with PTFE seals. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating bronze bodies and wedges with PTFE seals. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves with blue epoxy coated ductile iron bodies, EPDM coated ductile iron wedges. The valves operate via a non-rising spindle headwork with hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves with bronze bodies and wedge with PTFE packing. The valves operate via a non-rising spindle headworks that incorporates a hand wheel type operating member. Maximum working pressure 25.0 Bar. Maximum operating temperature 85°C.
Range of gate valves incorporating a blue epoxy coated ductile iron body. EPDM coated ductile iron wedges and a non-rising spindle headwork. Maximum working pressure 16.0 bar. Maximum operating temperature 45°C.
Range of gate valves incorporating bronze bodies and wedges with PTFE seals. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating bronze bodies and wedges with PTFE seals. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating bronze bodies and wedges with PTFE seals. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of DZR brass gate valves incorporating brass wedges. The Fig 30 range incorporates hand wheel operating members. The Fig 30LS range incorporates a lock shield operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating bronze bodies, wedges and PTFE seals. The valves are operated via a non-rising spindle with a hand wheel operating member. For use with copper pipe manufactured to EN1057. Maximum working pressure 16.0 bar. Maximum operating temperature 100°C.
Range of gate valves incorporating cast iron bodies (blue epoxy coated), EPDM rubber coated wedges and non-rising spindles with hand wheel operating member. Maximum working pressure 10.0 bar (Z45X-10Q model). Maximum working pressure 16.0 bar (Z45X-16Q models). Maximum operating temperature 80°C.
Range of gate valves incorporating DZR brass bodies and wedges, non-rising spindles and handwheel operating members. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating ductile iron epoxy coted bodies and with EPDM ‘O’-ring seals and discs. The valves are operated via a non-rising spindle with a hand wheel operating member Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating ductile iron epoxy coted bodies and with EPDM ‘O’-ring seals and discs. The valves are operated via a non-rising spindle with a hand wheel operating member Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating bronze bodies and wedges with PTFE seals. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of non-rising gate valves with blue epoxy coated ductile iron body and EPDM rubber coated wedge. Maximum working pressure 16.0 bar. Maximum operating temperature 80°C
Range of gate valves with blue epoxy coated ductile iron bodies, a ductile iron wedge encapsulated in EPDM rubber, PTFE seals and EPDM gaskets and ‘O’-rings. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 80°C.
Range of gate valves with brass bodies, brass wedges and PTFE packing glands. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 65°C.
Range of gate valves with blue epoxy resin coated cast iron (DN65-80) or ductile iron (DN100-200) bodies, EPDM coated ductile iron wedge and EPDM gaskets. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 16.0 bar. Cold water use only.
Range of gate valves incorporating ductile iron epoxy coted bodies and with EPDM ‘O’-ring seals and discs. The valves are operated via a non-rising spindle with a hand wheel operating member Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves with blue epoxy coated cast iron bodies, cast iron disc encapsulated in EPDM, stainless steel shaft and EPDM gaskets. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves with brass bodies, brass wedges and PTFE seals. The valves are operated via a non-rising spindle with a hand wheel operating member. To be used with copper pipe manufactured to EN1057. Maximum working pressure 16.0 bar. Maximum operating temperature 99°C.
Range of gate valves incorporating brass bodies and wedges with EPDM ‘O’-rings and a non-rising spindle with a hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating ductile iron epoxy coted bodies and with EPDM ‘O’-ring seals and discs. The valves are operated via a non-rising spindle with a hand wheel operating member Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves with blue epoxy coated ductile iron bodies and EPDM coated ductile iron wedges. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of handwheel operated gate valves incorporating blue epoxy coated ductile iron bodies, EPDM coated ductile iron disc and EPDM seals. Maximum working pressure 10.0 bar. Maximum operating temperature 80°C
Range of gate valves with either brass or DZR brass (from November 2023) bodies and PTFE washers. Maximum operating pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves with blue epoxy coated ductile iron bodies and EPDM coated ductile iron wedges. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating brass bodies and wedge with PTFE seals. The valves operate via a non-rising spindle headwork that incorporates a wheel type operating member. Maximum working pressure 20.0 Bar. Maximum operating temperature 85°C.
Range of gate valves with brass bodies and PTFE Washers. Valves are operated via a non-rising spindle headwork. Maximum operating pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves with blue epoxy coated ductile iron bodies and EPDM coated ductile iron wedges. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of 115 gate valves with blue epoxy coated ductile iron bodies and EPDM coated ductile iron wedges. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating bronze bodies, wedges and a non-rising stem. Maximum working pressure 20.0 bar. Maximum operating temperature 85ºC.
Range of gate valves with blue epoxy coated ductile iron bodies and EPDM coated ductile iron wedges. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of non-rising spindle gate valves with DZR brass bodies, with PTFE stem packing and gaskets. Operating members are handwheel operated. Maximum working pressure 20.0 bar. Maximum operating temperature 100°C.
Range of gate valves incorporating either rising or non-rising spindle headworks and PTFE gaskets with Bronze body, bronze wedge and handwheel. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating bronze bodies and wedges. The valves operate via a non-rising spindle headwork with lock shield or hand wheel operating members. Maximum working pressure 20.0 bar. Maximum operating temperature 85ºC.
Range of gate valves incorporating brass bodies, NBR, PTFE and fibre seals. For use with copper pipe (EN 1057) Maximum working pressure 16.0 bar. Maximum working temperature 85°C.
Range of gate valves incorporating brass bodies, brass wedge, PTFE and NBR washers and operated via a non-rising spindle headwork. Maximum operating pressure 10.0 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating bronze bodies and wedges with PTFE seals. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating bronze bodies and wedges with PTFE seals. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating bronze bodies and wedges with PTFE seals. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating brass bodies, brass wedge, PTFE and NBR washers and operated via a non-rising spindle headwork. Maximum operating pressure 10.0 bar. Maximum operating temperature 85°C.
Range of gate valves with bronze bodies and PTFE seals. The valves incorporate a non-rising stem and hand-wheel or lock shield operating members (see models). Maximum working pressure 20.0 bar. Maximum operating temperature 100ºC.
Range of gate valves with a DZR brass body and disc, and PTFE washers. The products are operated by a non-rising spindle headwork with a hand wheel operating member. For use with copper pipe manufactured to EN1057. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves with blue epoxy coated ductile iron bodies and EPDM coated ductile iron wedges. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves with ductile iron bodies (blue epoxy coated), EPDM rubber coated wedges and hand wheel operating members. Maximum working pressure 16.0 bar. Maximum operating temperature 80°C
Range of gate valves with ductile iron bodies (blue epoxy coated), EPDM rubber coated wedges and hand wheel operating members. Maximum working pressure 16.0 bar. Maximum operating temperature 80°C
Range of lock shield or handwheel operated gate valves with brass bodies, gate & PTFE seals, for use with copper tube manufactured to EN1057. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating blue epoxy coated ductile iron body and EPDM coated wedge. The valves operate via a non-rising spindle headwork with hand wheel operating member. Maximum working pressure 17.24 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating blue epoxy coated ductile iron bodies and EPDM coated ductile iron wedges. The valves are operated via a non-rising spindle with a hand wheel operating member or key and bar operating members (see model). Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of gate valves incorporating bronze bodies and wedges. The valves operate via a non-rising spindle headwork with lock shield or hand wheel operating members. Maximum working pressure 20.0 bar. Maximum operating temperature 85ºC.
Range of gate valves with blue epoxy coated ductile iron bodies, incorporating an NBR wedge and non-rising spindle with hand wheel operating member. Maximum working pressure 16.0 bar. Cold water use only.
Gate valve with an blue epoxy coated cast iron body, EPDM packing and seal. The valve operates via a hand wheel. Maximum working pressure 16.0 bar. Cold water use only.
Range of gate valves incorporating bronze bodies and wedges. The valves operate via a non-rising spindle headwork with lock shield or hand wheel operating members. Maximum working pressure 20.0 bar. Maximum operating temperature 85ºC.
Range of gate valves incorporating blue epoxy coated ductile iron body and EPDM coated wedge. The valves operate via a non-rising spindle headwork with hand wheel operating member. Maximum working pressure 17.24 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating a blue epoxy coated cast iron body, EPDM gate and seals and a non-rising stem with a handwheel operating member Maximum working pressure 16.0 bar, Maximum operating temperature 85ºC.
SFGV Range of gate valves with ductile iron bodies (blue epoxy coated) and EPDM rubber coated wedges. Maximum working pressure 16.0 bar. Maximum operating temperature 60°C
Range of gate valves with blue coloured epoxy coated ductile iron body and EPDM coated wedge. The valves operate via a non-rising spindle headwork with hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 80°C.
Range of gate valves incorporating bronze bodies and wedges. The valves operate via a non-rising spindle headwork with lock shield or hand wheel operating members. Maximum working pressure 20.0 bar. Maximum operating temperature 85ºC.
Range of resilient seated gate valves with blue epoxy coated ductile iron bodies, and an EPDM wedge, gasket and ‘O’-ring. The 3233 model has a rising spindle, the 3243 model has a non-rising spindle, both have a handwheel operating member. Maximum working pressure 25.0 bar. Maximum operating temperature 85°C.
Range of gate valves with blue epoxy coated ductile iron bodies, incorporating an EDPM wedge and non-rising spindle with hand wheel operating member. Maximum working pressure 10.0 bar. Maximum working temperature 65°C
Range of gate valves with a non-rising spindle and a handwheel operating member. The 8510 suffix models have a brass body and brass wedge, the 8511 suffix models have a DZR brass body and a brass wedge. For use with copper pipe (manufactured to EN1057). Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves with blue epoxy powder coated, ductile iron wedge and bodies. Maximum working pressure 16.0 bar. Maximum operating temperature 70°C
Range of gate valves with brass bodies and wedge with either a lockshield or non-rising spindle operating member for use with copper pipe (manufactured to EN 1057). Maximum working pressure 16.0 bar. Maximum operating temperature 100°C.
Range of resilient seated gate valves with blue epoxy coated ductile iron bodies, and an EPDM wedge, gasket and ‘O’-ring. The MV40-AAAAXY (model has a rising spindle, the MV40-AAAAX model has a non-rising spindle, both have a handwheel operating member. Maximum working pressure 25.0 bar. Maximum operating temperature 85°C.
Range of resilient seated gate valves with blue epoxy coated ductile iron bodies, and an EPDM wedge, gasket and ‘O’-ring. with a a non-rising spindle, both have a handwheel operating member. Maximum working pressure 25.0 bar. Maximum operating temperature 85°C.
Range of gate valves with a non-rising spindle and a handwheel operating member with a brass body and brass wedge. For use with copper pipe (manufactured to EN1057). Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of resilient seated gate valves with blue epoxy coated ductile iron bodies, and an EPDM wedge, gasket and ‘O’-ring. The RVRX model has a rising spindle, the RVHX model has a non-rising spindle, both have a handwheel operating member. Maximum working pressure 25.0 bar. Maximum operating temperature 85°C.
Resilient seated gate valves with blue epoxy coated ductile iron bodies, and an EPDM wedge, gasket and ‘O’-ring. With a non-rising spindle, and handwheel operating member. Maximum working pressure 25.0 bar. Maximum operating temperature 85°C.
Range of hand wheel operated or key operated gate valves with blue epoxy coated ductile iron bodies, ductile iron wedge encapsulated in EPDM and EPDM ‘O’-rings. Maximum working pressure 16.0bar. Maximum working temp 65°C.
Range of lock shield or handwheel operated gate valves with brass bodies, gate & PTFE seals, for use with copper tube manufactured to EN1057. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of resilient seated gate valves with blue epoxy coated ductile iron bodies, and an EPDM wedge, gasket and ‘O’-ring. The V23AR16 & F23AR25 models have a rising spindle, the V23A16 & F23A25 models have a non-rising spindle, both have a handwheel operating member. Maximum working pressure 25.0 bar. Maximum operating temperature 85°C.
Range of resilient seated gate valves with blue epoxy coated ductile iron bodies, and an EPDM wedge, gasket and ‘O’-ring. The BV204W model has a rising spindle, the BV203W model has a non-rising spindle, both have a handwheel operating member. Maximum working pressure 25.0 bar. Maximum operating temperature 85°C.
Range of resilient seated gate valves with blue epoxy coated ductile iron bodies, and an EPDM wedge, gasket and ‘O’-ring. The FGAXXXNYYRB231 model has a rising spindle, the FGAXXXNYYNB231 model has a non-rising spindle, both have a handwheel operating member. Maximum working pressure 25.0 bar. Maximum operating temperature 85°C.
Range of non-rising spindle gate valves with epoxy coated ductile iron body and wedge. Maximum working pressure 16.0 bar. Maximum operating temperature 80°C.
Range of gate valves with a non-rising spindle and a handwheel operating member. The 960985, 960986 & 960987 suffix models have a brass body and brass wedge, the 850066, 850070 & 850071 suffix models have a DZR brass body and a brass wedge. For use with copper pipe (manufactured to EN1057). Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating blue epoxy coated ductile iron body and EPDM coated wedge. The valves operate via a non-rising spindle headwork with hand wheel operating member. Maximum working pressure 17.24 bar. Maximum operating temperature 85°C.
Range of gate valves with brass bodies, brass wedges and PTFE seals. The valves are operated via a non-rising spindle with a hand wheel operating member. To be used with copper pipe manufactured to EN1057. Maximum working pressure 16.0 bar. Maximum operating temperature 99°C.
Range of gate valves with a non-rising spindle with a handwheel operating member or lockshield connection. All models have brass or DZR brass body and brass wedge. For use with copper pipe (manufactured to EN1057). Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
AVK Series 21 range of gate valves with blue epoxy coated ductile iron bodies, ductile iron wedge encapsulated in EPDM, EPDM ‘O’-rings and non-rising spindles. Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 50°C
Range of gate valves incorporating ductile iron epoxy coted bodies and with EPDM ‘O’-ring seals and discs. The valves are operated via a non-rising spindle with a hand wheel operating member Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves with blue epoxy coated ductile iron bodies, non-rising spindles with handwheel operating member and a ductile iron wedge encapsulated in EPDM. Maximum working pressure 16.0 bar. Cold water use only.
Range of gate valves with ductile iron bodies (blue epoxy coated), EPDM coated wedge and EPDM o-rings. Maximum working pressure 10.0 bar and 16.0 bar. Maximum operating temperature 80°C
Range of gate valves with blue epoxy coated ductile iron bodies, ductile iron wedge encapsulated in EPDM, EPDM gasket and NBR O rings. The valves incorporate a non-rising spindle headwork. Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 80°C
Range of gate valves incorporating blue epoxy coated ductile iron body and EPDM gasket. Maximum working pressure 16 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of gate valves incorporating bronze body with bronze wedge with non-rising spindle headwork, handwheel and PTFE gaskets. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves with blue epoxy coated ductile iron bodies, ductile iron wedge encapsulated in EPDM, EPDM gasket and NBR O rings. The valves incorporate a non-rising spindle headwork. Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 80°C
Range of gate valves with a non-rising spindle with a handwheel operating member or lockshield connection. All models have brass body and brass wedge. For use with copper pipe (manufactured to EN1057). Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of gate valves with blue epoxy coated ductile iron bodies, ductile iron wedge encapsulated in EPDM and EPDM gaskets. The valves are operated via a non-rising spindle headwork with a hand wheel operating member. Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of gate valves with bronze bodies, bronze wedge, PTFE stem packing and non-rising spindles. Maximum working pressure 20.0 bar. Maximum operating temperature 100°C.
Range of gate valves incorporating bronze bodies and wedges with PTFE seals. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
‘SD - 9102’ range of gate valves with brass bodies and PTFE Washers. Valves are operated via a non-rising spindle headwork. Maximum operating pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves with epoxy coated ductile iron body and wedge. Maximum working pressure 16.0 bar. Maximum operating temperature 80°C.
Range of gate valves with ductile iron bodies (blue epoxy coated), EPDM coated wedge and EPDM o-rings. Maximum working pressure 10.0 bar and 16.0 bar. Maximum operating temperature 80°C
Range of resilient seated gate valves with ductile iron bodies and bonnets (blue epoxy powder coated) with a ductile iron wedge encapsulated in EPDM. The valves operate via a non-rising spindle headwork with hand wheel operating member. Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of gate valves incorporating blue epoxy coated ductile iron body and EPDM gasket. Maximum working pressure 16 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of resilient seated gate valves with cast iron bodies (blue epoxy coated), EPDM coated cast iron wedges and a handwheel operating member. Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of gate valves incorporating blue epoxy coated ductile iron body and EPDM gasket. Maximum working pressure 16 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of gate valves incorporating blue epoxy coated ductile iron body and EPDM gasket. Maximum working pressure 16 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of non-rising spindle gate valves with epoxy coated ductile iron body and wedge. Maximum working pressure 16.0 bar. Maximum operating temperature 80°C.
Range of non-rising spindle gate valves with epoxy coated ductile iron body and wedge. Maximum working pressure 16.0 bar. Maximum operating temperature 80°C.
Range of gate valves with a non-rising spindle and a handwheel operating member with a brass body and brass wedge. Maximum working pressure 17.5 Bar Maximum operating temperature 93.0°C
Range of flanged ductile iron, blue epoxy coated gate valves with EPDM seats and hand wheel operating members. Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of gate valves with blue epoxy coated ductile iron bodies, incorporating ductile iron wedges encapsulated in EPDM. The valves are operated via a non-rising shaft with a hand wheel operating member. Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 80°C
Range of resilient seated gate valves with cast iron bodies (blue epoxy coated), EPDM coated cast iron wedges and a handwheel operating member. Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of resilient seated gate valves with cast iron bodies (blue epoxy coated), EPDM coated cast iron wedges and a handwheel operating member. Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of gate valves incorporating bronze bodies and wedges with PTFE seals. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves with blue epoxy coated ductile iron bodies, ductile iron disc encapsulated in EPDM. The valves incorporate a non-rising spindle headwork with a hand wheel operating member. Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 80°C
Range of non-rising spindle gate valves with DZR brass bodies, with PTFE stem packing and gaskets. Operating members are either handwheel operated or lockshield. Maximum working pressure 20.0 bar. Maximum operating temperature 100°C.
Range of gate valves incorporating either rising or non-rising spindle headworks and PTFE gaskets. The products are available as follows: Brass body, brass wedge and handwheel (GVBZR models). Bronze body, bronze wedge and handwheel (GVBZ models) or lockshield operating member (GVBZLS models). Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of flanged ductile iron, blue epoxy coated gate valves with EPDM seats and hand wheel operating members. Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of seated gate valves with blue epoxy coated ductile iron bodies, bonnets and ductile iron wedges encapsulated in EPDM. All models have a handwheel operating member. Maximum working pressure 16 bar. Maximum operating temperature 80 °C
Range of gate valves with blue epoxy coated ductile iron bodies and EPDM coated ductile iron wedges. The valves operate via non-rising spindle headwork. Maximum working pressure 10.0 bar and 16.0 bar (dependent on flange pressure rating). Maximum operating temperature 80°C.
Range of gate valves with blue epoxy coated ductile iron bodies and EPDM coated ductile iron wedges. The valves operate via non-rising spindle headwork. Maximum working pressure 16.0 bar and a maximum operating temperature 85°C.
Range of gate valves with a non-rising spindle with a handwheel operating member. All models have brass or DZR brass body and brass wedge. For use with copper pipe (manufactured to EN1057). Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of gate valves with blue epoxy coated ductile iron bodies, incorporating ductile iron wedges encapsulated in EPDM. The valves are operated via a non-rising shaft with a gear box operating member. Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 60°C
Range of gate valves with blue epoxy coated ductile iron bodies, incorporating ductile iron wedges encapsulated in EPDM. The valves are operated via a non-rising spindle with hand wheel operating member. Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 80°C
Range of gate valves incorporating a brass body and a brass disc. The valves operate via non-rising spindle headwork with a hand wheel operating member Maximum working pressure 16.0 bar.
Range of gates valve with ductile iron bodies (blue epoxy coating), EPDM seats and `O` rings. The valves are handwheel operated via a non-rising spindle. Maximum working pressure 16.0 bar. Maximum operating temperature 80°C.
Range of resilient seated gate valves with cast iron bodies (blue epoxy coated), EPDM coated cast iron wedges and a handwheel operating member. Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of seated gate valves with blue epoxy coated ductile iron bodies, bonnets and ductile iron wedges encapsulated in EPDM. All models have a handwheel operating member. Maximum working pressure 16 bar. Maximum operating temperature 80 °C
Range of gate valves with blue epoxy coated ductile iron bodies and EPDM coated ductile iron wedges. The valves operate via non-rising spindle headwork. Maximum working pressure 10.0 bar and 16.0 bar (dependent on flange pressure rating). Maximum operating temperature 80°C.
Range of gate valves with blue epoxy coated ductile iron bodies and EPDM coated ductile iron wedges. The valves operate via non-rising spindle headwork. Maximum working pressure 16.0 bar and a maximum operating temperature 85°C.
Range of flanged ductile iron, blue epoxy coated gate valves with EPDM seats and hand wheel operating members. Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of non-rising spindle gate valves with DZR brass bodies, with PTFE stem packing and gaskets. Operating members are either handwheel operated or lockshield. Maximum working pressure 16 bar. Maximum operating temperature 100°C.
Range of non-rising spindle gate valves with DZR brass bodies, with PTFE stem packing and gaskets. Operating members are either handwheel operated or lockshield. Maximum working pressure 16 bar. Maximum operating temperature 100°C.
Range of resilient seated gate valves with blue epoxy coated ductile iron bodies and bonnets and ductile iron wedges encapsulated in EPDM. The valve is operated via a non-rising spindle headwork. Maximum working pressure 16.0 bar. The maximum operating temperature 85°C
Range of gate valves with blue epoxy coated ductile iron bodies, EPDM coated ductile iron wedges, EPDM gasket and ‘O’-ring. The valves operate via non-rising spindle headwork with a hand wheel operating member. Maximum working pressures: DN50: 25.0 bar, DN65-DN600: 16.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of non-rising resilient stem seated gate valves with epoxy coated bodies and EPDM wedge. Maximum working pressure 16 bar. Cold water use only.
Range of gate valves incorporating blue epoxy coated ductile iron bodies ,EPDM gasket, EPDM wedge and a handwheel operating member. Maximum working pressure 25 bar. Maximum operating temperature 80°C
Range of cast iron gate valves with blue epoxy coating, EPDM coated disc, PTFE gasket and EPDM seals. The valves are operated via a non-rising spindle headwork with a hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves with bronze bodies, bronze wedge and PTFE washers. Maximum working pressure 20.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of non-rising spindle gate valves, brass bodies, incorporating PTFE stem packing and gaskets with handwheel operating members. Maximum working pressure 20.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of gate valves with blue epoxy coated ductile iron bodies, EPDM coated ductile iron wedge and EPDM seals. Maximum working pressure 16.0 bar. Maximum operating temperature 100°C.
Range of resilient seated gate valves with cast iron bodies (blue epoxy coated), EPDM coated cast iron wedges and a handwheel operating member. Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of gate valves with bronze bodies and bronze wedges. The valves operate via non-rising spindle head work with hand wheel or lock shield operating members. Maximum working pressure 20.0 bar. Maximum operating temperature 100°C
Range of resilient seated gate valves with cast iron bodies (blue epoxy coated), EPDM coated cast iron wedges and a handwheel operating member. Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of resilient seated gate valves with cast iron bodies (blue epoxy coated), EPDM coated cast iron wedges and a handwheel operating member. Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of gate valves with ductile iron bodies (green epoxy coated) and EPDM coated ductile iron wedge. Maximum working pressure – 16.0 Bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of flanged gate valves with blue epoxy coated ductile iron bodies and EPDM O-rings and disc. The valves are operated via a non-rising spindle headwork with a wheel type operating member. Maximum working pressure 16.0 Bar
Non-metallic materials and components comply with BS6920 at 80°C
Range of gate valves with blue epoxy coated ductile iron bodies and EPDM encapsulated wedge. The gate is operated via a hand wheel operating member. Maximum working pressure 16.0 Bar
Non-metallic materials and components comply with BS6920 at 85°C
Range of gate valves with blue epoxy coated cast iron bodies, incorporating cast iron wedges encapsulated in EPDM. Maximum working pressure - 16 Bar Maximum operating temperature – 23°C.
Double flanged, gate valve with blue epoxy coated ductile iron body and EPDM coated wedge and handwheel operating member. Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 71°C
Range of gate valves with (blue epoxy coated) iron ductile bodies. The valves operate via a hand wheel operating member. Maximum working pressure 16.0 Bar
Non-metallic materials and components comply with BS6920 at 65°C
Range of gate valves with blue epoxy coated ductile iron bodies, non-rising spindles with handwheel operating member and a ductile iron wedge encapsulated in EPDM. Maximum working pressure 16.0 bar. Cold water use only.
Range of cast iron gate valves with blue epoxy coating, EPDM coated disc, PTFE gasket and EPDM seals. The valves are operated via a non-rising spindle headwork with a hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of resilient seated gate valves with blue epoxy coated ductile iron bodies and bonnets and ductile iron wedges encapsulated in EPDM. The valves are operated via a gear operated handwheel for sizes DN350 to 1200 and hand only for sizes DN40 to 300. Maximum working pressure 16.0 bar - DN40 – DN600, 10.0 bar DN700 – DN1200. maximum operating temperature 85°C.
Range of resilient seated gate valves with cast iron bodies (blue epoxy coated), EPDM coated cast iron wedges and a handwheel operating member. Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of handwheel operated gate valves with brass bodies, gate & PTFE seals, for use with copper tube manufactured to EN1057. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves with blue epoxy coated ductile iron bodies and EPDM encapsulated wedge. The gate is operated via a hand wheel operating member. Maximum working pressure 16.0 Bar
Non-metallic materials and components comply with BS6920 at 85°C
Range of resilient seated gate valves with cast iron bodies (blue epoxy coated), EPDM coated cast iron wedges and a handwheel operating member. Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of resilient seated gate valves with blue epoxy coated ductile iron bodies and bonnets and ductile iron wedges encapsulated in EPDM. The valves are operated via a gear operated handwheel for sizes DN350 to 1200 and hand only for sizes DN40 to 300. Maximum working pressure 16.0 bar - DN40 – DN600, 10.0 bar DN700 – DN1200. maximum operating temperature 85°C.
Range of gate valves with blue epoxy coated ductile iron bodies, incorporating ductile iron wedges encapsulated in EPDM and hand wheel operating members. Maximum working pressure - 16 Bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of handwheel operated gate valves with brass bodies, gate & PTFE seals, for use with copper tube manufactured to EN1057. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of flanged gate valves with blue epoxy coated ductile iron bodies and EPDM O-rings and disc. The valves are operated via a non-rising spindle headwork with a wheel type operating member. Maximum working pressure 16.0 Bar
Non-metallic materials and components comply with BS6920 at 80°C
Range of gate valves with bronze bodies, bronze wedge and PTFE washers. Maximum working pressure 20.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of resilient seated gate valves with blue epoxy coated ductile iron bodies and bonnets and ductile iron wedges encapsulated in EPDM. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 80°C.
Page of
