Section Code 1465 : Combination boilers and Water Jacketed Tube heaters. Low volume water content. Heat retained in water heaters will cause expansion of water after closure of draw-off taps and valves. Provision for expansion of water must be made to accommodate excess pressure within the system. Particular care is required where check valves are positioned, or loose jumper valves are thought to be upstream of the heater.
Back To Directory SectionsRange of wall mounted, gas fired, combination boiler providing domestic hot water via a plate heat exchanger and a pressurised central heating system. The product includes a pressure relief valve (set at 3.0 bar). Maximum working pressure of the secondary circuit is 7.0 bar, whilst for the primary circuit is 2.5 bar. Maximum operating temperature of the secondary circuit is 60°C.
Range of wall mounted combination boilers providing domestic hot water via a heat exchanger and pressurised central heating system. Incorporating a pressure relief valve set at 3.0 bar and an expansion vessel. Maximum working pressure of 2.5 bar (primary) & 10.0 bar (secondary). Maximum operating temperature 70°C.
Range of gas fired boilers providing domestic hot water via a stainless-steel plate heat exchanger or heating depending on the application. Maximum working pressure 8.0 bar. Maximum operating temperature 90˚C.
Range of wall mounted gas fired condensing instantaneous water heaters. Maximum working pressure 10.0 bar. Maximum operating temperature 85°C.
Range of wall hung, gas-fired condensing combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system incorporating an expansion vessel and pressure relief valve set at 3.0 bar. The supplies to both domestic hot water and primary are controlled via spherical valves except the domestic hot water outlet. The primary circuit can be filled via a built in CAB device, verified by test (suitable for backflow protection against Fluid Category 3). Primary circuit: Maximum working pressure 2.5 bar. Maximum operating temperature 82°C. Secondary circuit: Maximum working pressure 10.0 bar. Maximum operating temperature 60°C.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. Incorporating a pressure relief valve set at 3.0 bar and expansion vessel. Maximum working pressure of 2.5 bar (primary) and 10.0 bar (secondary). Maximum operating temperature 65°C. Cold water supply only.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. Incorporating a pressure relief valve set at 3.0 bar and expansion vessel. Maximum working pressure of 2.5 bar (primary) and 10.0 bar (secondary). Maximum operating temperature 65°C. Cold water supply only.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. Incorporating a pressure relief valve set at 3.0 bar and expansion vessel. Maximum working pressure of 2.5 bar (primary) and 10.0 bar (secondary). Maximum operating temperature 65°C. Cold water supply only.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. Incorporating a pressure relief valve set at 3.0 bar and expansion vessel. Maximum working pressure of 2.5 bar (primary) and 10.0 bar (secondary). Maximum operating temperature 65°C. Cold water supply only.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. Incorporating a pressure relief valve set at 3.0 bar and expansion vessel. Maximum working pressure of 2.5 bar (primary) and 10.0 bar (secondary). Maximum operating temperature 65°C. Cold water supply only.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. Incorporating a pressure relief valve set at 3.0 bar and expansion vessel. Maximum working pressure of 2.5 bar (primary) and 10.0 bar (secondary). Maximum operating temperature 65°C. Cold water supply only.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. Incorporating a pressure relief valve set at 3.0 bar and expansion vessel. Maximum working pressure of 2.5 bar (primary) and 10.0 bar (secondary). Maximum operating temperature 65°C. Cold water supply only.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. Incorporating a pressure relief valve set at 3.0 bar and expansion vessel. Maximum working pressure of 2.5 bar (primary) and 10.0 bar (secondary). Maximum operating temperature 65°C. Cold water supply only.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. Incorporating a pressure relief valve set at 3.0 bar and expansion vessel. Maximum working pressure of 2.5 bar (primary) and 10.0 bar (secondary). Maximum operating temperature 65°C. Cold water supply only.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. Incorporating a pressure relief valve set at 3.0 bar and expansion vessel. Maximum working pressure of 2.5 bar (primary) and 10.0 bar (secondary). Maximum operating temperature 65°C. Cold water supply only.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. Incorporating a pressure relief valve set at 3.0 bar and expansion vessel. Maximum working pressure of 2.5 bar (primary) and 10.0 bar (secondary). Maximum operating temperature 65°C. Cold water supply only.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. Incorporating a pressure relief valve set at 3.0 bar and expansion vessel. Maximum working pressure of 2.5 bar (primary) and 10.0 bar (secondary). Maximum operating temperature 65°C. Cold water supply only.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. Incorporating a pressure relief valve set at 3.0 bar and expansion vessel. Maximum working pressure of 2.5 bar (primary) and 10.0 bar (secondary). Maximum operating temperature 65°C. Cold water supply only.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. Incorporating a pressure relief valve set at 3.0 bar and expansion vessel. Maximum working pressure of 2.5 bar (primary) and 10.0 bar (secondary). Maximum operating temperature 65°C. Cold water supply only.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. Incorporating a pressure relief valve set at 3.0 bar and expansion vessel. Maximum working pressure of 2.5 bar (primary) and 10.0 bar (secondary). Maximum operating temperature 65°C. Cold water supply only.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. Incorporating a pressure relief valve set at 3.0 bar and expansion vessel. Maximum working pressure of 2.5 bar (primary) and 10.0 bar (secondary). Maximum operating temperature 65°C. Cold water supply only.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. Incorporating a pressure relief valve set at 3.0 bar and expansion vessel. Maximum working pressure of 2.5 bar (primary) and 10.0 bar (secondary). Maximum operating temperature 65°C. Cold water supply only.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. Incorporating a pressure relief valve set at 3.0 bar and expansion vessel. Maximum working pressure of 2.5 bar (primary) and 10.0 bar (secondary). Maximum operating temperature 65°C. Cold water supply only.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. Incorporating a pressure relief valve set at 3.0 bar and expansion vessel. Maximum working pressure of 2.5 bar (primary) and 10.0 bar (secondary). Maximum operating temperature 65°C. Cold water supply only.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. Incorporating a pressure relief valve set at 3.0 bar and expansion vessel. Maximum working pressure of 2.5 bar (primary) and 10.0 bar (secondary). Maximum operating temperature 65°C. Cold water supply only.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. Incorporating a pressure relief valve set at 3.0 bar and expansion vessel. Maximum working pressure of 2.5 bar (primary) and 10.0 bar (secondary). Maximum operating temperature 65°C. Cold water supply only.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. Incorporating a pressure relief valve set at 3.0 bar and expansion vessel. Maximum working pressure of 2.5 bar (primary) and 10.0 bar (secondary). Maximum operating temperature 65°C. Cold water supply only.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. Incorporating a pressure relief valve set at 3.0 bar and expansion vessel. Maximum working pressure of 2.5 bar (primary) and 10.0 bar (secondary). Maximum operating temperature 65°C. Cold water supply only.
EMAS range of combination boilers with instant hot water and central heating system with a stainless-steel plate heat exchanger. Hot water is produced via heat from a centralised heating system (not supplied). The unit incorporates a pressure relief valve set at 3.0 bar and an expansion vessel on the central heating circuit. The inlet and outlet of the primary and secondary circuits fitted with isolation valves. Maximum working pressure: primary circuit 2.5 bar & secondary circuit 10.0 bar. Maximum operating temperature: primary circuit 70˚C & secondary circuit 50˚C.
Range of wall mounted gas fired combination boilers providing domestic hot water and pressurised central heating via a plate heat exchanger. Maximum working pressure 3.0 bar (primary) and 8.0 bar (secondary). Maximum operating temperature 90°C. Cold water supply only
Range of gas fired instantaneous condensing domestic hot water heaters with integral storage tank. Having a stainless-steel coil and built in circulating pump. Maximum working pressure 11.0 bar. Maximum operating temperature 80°C
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. Incorporating a pressure relief valve set at 3.0 bar and expansion vessel. Maximum working pressure of 2.5 bar (primary) and 10.0 bar (secondary). Maximum operating temperature 65°C. Cold water supply only.
Range of wall mounted, gas fired combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. The primary circuit incorporates an expansion vessel and a pressure relief valve set at 3.0 bar. The secondary circuit incorporates a strainer and plastic flow regulator. The boilers are supplied with straight spherical valves. Maximum working pressure of primary circuit is 2.5 bar and of secondary circuit is 10.0 bar. Maximum operating temperature of primary circuit is 85°C and of secondary circuit is 60°C.
Electronically controlled Heat interface units (HIU) with twin stainless-steel plate heat exchangers providing space heating and instantaneous hot water. The cold inlet supply to the plate heat exchanger incorporates an isolation valve, in line single check valve assembly, (suitable for backflow protection against Fluid Category 2) and and water hammer arrestor. The space heating circuit incorporates an expansion vessel and a pressure relief valve (set at 3.0 bar). The product is supplied with a filling loop comprising of an in-line double check valve assembly (suitable for backflow protection against Fluid Category 3), which incorporates an isolation valve, a stainless-steel braided EPDM lined flexible hose assembly. The inlet and outlet of all circuits incorporates a lever operated spherical valves with brass bodies. Maximum working pressures and operating temperatures: Primary: 16.0 bar and 90˚C. Domestic hot water (DHW): 10.0 bar and 60˚C. Secondary (space heating): 2.5 bar and 90˚C.
Range of wall mounted combination boilers providing domestic hot water via a heat exchanger and pressurised central heating system.Incorporating a pressure relief valve set at 3.0 bar and an expansion vessel. Maximum working pressure of 2.5 bar (primary) & 7.0 bar (secondary). Cold supply only. Maximum operating temperature 60°C.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system, incorporating a pressure relief valve set at 3.0 bar and expansion vessel. The domestic cold water inlet incorporate a ½” BSP(M) brass body spherical valve. Maximum working pressure of 2.5 bar (primary) and 10.0 bar (secondary). Maximum operating outlet temperature (DHW) 85°C. Maximum inlet temperature (DHW) 60°C
Viessmann range of combination boilers with instant hot water and central heating system with a plate heat exchanger. The unit incorporates a pressure relief valve set at 3.0 bar and an expansion vessel on the central heating circuit. The secondary circuit (DHW) consists of a flow restrictor and a copper filling loop. Maximum working pressure 2.5 bar (primary) and 10.0 bar (secondary). Maximum operating temperature 85°C
GLOWWORM range of combination boilers with instant hot water, and central heating system with a stainless steel plate heat exchanger. The unit incorporates a pressure relief valve set at 3.0 bar and an expansion vessel on the central heating circuit. The secondary circuit (DHW) consists of a strainer. Maximum working pressure: Heating Circuit 3.0 bar. Domestic Hot Water Circuit 10.0 bar Maximum working temperature: Heating Circuit 75˚C. Domestic Hot Water Circuit 55˚C
PREMIX range of combination boilers with instant hot water and central heating system with a stainless-steel plate heat exchanger. Hot water is produced via heat from a centralised heating system (not supplied). The unit incorporates a pressure relief valve set at 3.0 bar and an expansion vessel on the central heating circuit. The inlet and outlet of the primary and secondary circuits fitted with isolation valves. Maximum working pressure: primary circuit 2.5 bar & secondary circuit 10.0 bar. Maximum operating temperature: primary circuit 70˚C & secondary circuit 50˚C.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. Incorporating a pressure relief valve set at 3.0 bar and expansion vessel. Maximum working pressure of 2.5 bar (primary) and 10.0 bar (secondary). Maximum operating temperature 65°C. Cold water supply only.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. Incorporating a pressure relief valve set at 3.0 bar and expansion vessel. Maximum working pressure of 2.5 bar (primary) and 10.0 bar (secondary). Maximum operating temperature 65°C. Cold water supply only.
SV Range of wall mounted gas fired condensing instantaneous water heaters. Maximum working pressure 10.0 bar. Maximum operating temperature 85°C.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. The primary circuit incorporates a pressure relief valve set at 3.0 bar and an expansion vessel. The products are supplied with a temporary filling loop which incorporates a combined isolation valve and double check valve assembly (suitable for backflow protection against Fluid Category 3), stainless steel braided EPDM lined flexible hose assembly and an isolation valve. The secondary circuit (DHW) incorporates a plastic flow restrictor The primary circuit incorporates isolation valves on the flow and return. Maximum working pressure of secondary circuit is 6.0 bar. Maximum working pressure of primary circuit is 2.5 bar. Maximum operating temperature 60°C. Cold water supply only.
Electronically controlled heat interface units (HIU) with twin stainless-steel plate heat exchangers providing space heating and instantaneous hot water. The cold inlet supply to the plate heat exchanger incorporates an isolation valve, in line single check valve assembly, (suitable for backflow protection against Fluid Category 2) and a water hammer arrestor. The space heating circuit incorporates an expansion vessel and a pressure relief valve (set at 3.0 bar). The product is supplied with a filling loop comprising of an in-line double check valve assembly (suitable for backflow protection against Fluid Category 3), which incorporates an isolation valve, a stainless-steel braided EPDM lined flexible hose assembly and an isolation valve. The inlet and outlet of all circuits incorporates lever operated spherical valves with brass bodies. Maximum working pressures and operating temperatures: Primary: 16.0 bar and 90˚C. Domestic hot water (DHW): 10.0 bar and 60˚C. Secondary (space heating): 2.5 bar and 90˚C.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. Incorporating a pressure relief valve and expansion vessel. Primary circuit has a maximum working pressure of 3.5 bar and operating temperature of 85°C. Secondary circuit has a maximum working pressure of 10.0 bar and operating temperature of 60°C.
RINNAI range of wall mounted combination boilers.The unit incorporates a stainless-steel plate heat exchanger pressure relief valve set at 3.0 bar and an expansion vessel on the primary circuit. Maximum working pressure of primary circuit is 2.5 bar and secondary circuit is 10.0 bar. Maximum operating temperature 60˚C.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system, incorporating a pressure relief valve set at 3.0 bar and expansion vessel on the primary circuit. The inlet of the replenishing valve between the primary and secondary circuits incorporate a plastic strainer. Maximum working pressure 2.5 bar (primary) and 6.0 bar (secondary). Maximum operating temperature 85˚C.
LCB700 range of internal and external oil-fired condensing combination boilers providing domestic hot water and pressurised central heating via a plate heat exchanger. The products are supplied with a temporary filling loop which incorporates a combined isolation valve and double check valve assembly (suitable for backflow protection against Fluid Category 3), stainless steel braided EPDM lined flexible hose assembly and an isolation valve. The primary (space heating) circuit incorporates an expansion vessel and a pressure relief valve (set at 3.0 bar). Operating parameters: Primary (space heating) circuit: Maximum working pressure 2.5 Bar. Maximum operating temperature 105°C. Secondary (DHW) circuit: Maximum working pressure 10.0 Bar. Maximum operating temperature 85°C.
Range of heat interface units (HIU) with either twin or single stainless steel copper brazed plate heat exchangers (depending on model) providing heating and hot water (twin unit) hot water only, or heating only. The hot water is generated via a plate heat exchanger. The primary (space heating) circuit incorporates an expansion vessel and a pressure relief valve (set at 3.0 bar). The product incorporates a CAb backflow prevention device (suitable for backflow protection against Fluid Category 3) for filling the heating circuit. The inlet and outlet of all circuits incorporate a lever operated spherical valve. Maximum working pressures and operating temperatures: Primary (district heating): 10.0 bar and 85˚C. Domestic hot water (DHW): 10.0 bar and 60˚C. Secondary (space heating): 2.5 bar and 80˚C.
Ranges of wall hung, gas-fired condensing combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system incorporating an expansion vessel and pressure relief valve set at 3.0 bar. The supplies to both domestic hot water and primary are controlled via spherical valves. Products are supplied with a rigid filling loop or keyless filling link. Maximum working pressure of the primary circuit is 2.5 bar & maximum supply pressure of the secondary circuit is 8.0 bar. Cold water supply only. Maximum operating temperature 95°C.
Range of wall hung, gas-fired condensing combination boilers providing domestic hot water via a plate heat exchanger. The pressurised central heating system incorporates an expansion vessel and pressure relief valve set at 3.0 bar. The supplies to both domestic hot water and primary are controlled via spherical valves. The primary circuit has a maximum working pressure of 2.5 bar. The secondary circuit has maximum working pressure of 10.0 bar. Maximum supply temperature is 60°C. Maximum operating temperature of secondary circuit is 85°C.
Range of floor standing gas fired combination boilers providing domestic hot water via a stainless-steel plate heat exchanger. Unit is supplied with a safety relief valve (8.0 bar). Maximum working pressure 7.5 bar. Maximum operating temperature 85°C.
Range of wall hung, gas-fired condensing combination boilers providing domestic hot water via a plate heat exchanger and pressure relief valve set at 3.0 bar. The supplies to both primary hot water and secondary are controlled via spherical valves. The boilers incorporate a filling loop assembly which incorporates a double check valve assembly (suitable for backflow protection against Fluid Category 3). Primary circuit: Maximum working pressure 2.5 bar. Maximum operating temperature 82°C. Secondary circuit: Maximum working pressure 10.0 bar. Maximum operating temperature 60°C
Range of floor standing gas fired combination boilers providing domestic hot water via a stainless-steel plate heat exchanger. Unit is supplied with a safety relief valve (8.0 bar). Maximum working pressure 7.5 bar. Maximum operating temperature 85°C.
Range of gas fired condensing combination boilers providing domestic hot water via a plate heat exchanger. The cold inlet incorporates an angled spherical valve with a brass body, chromium plated brass ball and a lever operating member. The primary circuit incorporates an expansion vessel, isolation valves on flow and return, drain valve and a pressure relief valve set at 3.0 bar. Maximum working pressure of the primary circuit is 2.5 bar. Maximum working pressure of the secondary circuit is 10.0 bar. Maximum operating temperature for the secondary circuit is 55˚C. Cold supply only.
Greenstar Heatslave II range of floor standing oil-fired condensing combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system, which incorporates an expansion vessel and pressure relief valve set at 3.0 bar. The cold water inlet incorporates a screwdriver operated spherical valve followed by a plastic flow regulator inserted within the pipework. Maximum working pressure: Primary circuit 2.5 bar. Secondary circuit 10.0 bar. Maximum operating temperature 82°C.
Greenstar range of indirect heat interface units providing heating and instantaneous hot water. The heating system incorporates an expansion vessel. The products are sold with or without a prefix kit (see model), which comprises of a mounting bracket that includes spherical valves for all circuits and a pressure relief valve (set at 3.0 bar). Maximum working pressure district heating 10.0 bar. Maximum working pressure space heating 2.5 bar. Maximum working pressure secondary hot water 10.0 bar. Maximum operating temperature 90°C.
Range of wall mounted, gas-fired, condensing combination boilers providing domestic hot water via a plate heat exchanger. The pressurised central heating system incorporates an expansion vessel and a pressure relief valve set at 3.0 bar. The inlets to the domestic hot water and primary circuits each have a screwdriver operated angled spherical valve. Both include a ½” BSP (M) connection for a filling link. The Greenstar CDi models only are supplied with an integral charging link (CAB device) verified by test (suitable for backflow protection against Fluid Category 3). Maximum working pressure of the primary circuit is 2.5 bar. Maximum working pressure of the secondary circuit is 10.0 bar. Maximum operating temperature of primary circuit is 82°C. Maximum operating temperature of secondary circuit is 60°C.
Range of electric combination boilers providing heating and instantaneous hot water. The heating system incorporates an expansion vessel and pressure relief valve (set at 3.0 bar). The DHW inlet and outlet incorporate spherical servicing valves. Fittited with a CAB device keyless filling link, verifired by test, suitable for category 3 backlfow protection. Maximum working pressure on central heating circuit 2.5 bar & Domestic Hot Water 10bar. Maximum operating temperature 80°C
Range of wall hung, gas fired, combination boilers providing domestic hot water via a plate heat exchanger. The primary circuit incorporates an integral expansion vessel and a pressure relief valve set at 3.0 bar. The product is supplied with a rigid pipe filling loop, followed by a separate isolation valve. The filling loop pipe attaches to the cold water inlet valve which incorporates a double check valve assembly (verified by test, suitable for backflow protection against Fluid Category 3) on the branch to the filling loop. The primary circuit includes an isolation valve on the flow and return and is also supplied with two loose 22mm compression isolation valves and a filter. Maximum working pressure of the primary circuit is 2.5 bar and the maximum supply pressure to the secondary circuit is 10.0 bar. Max operating temperature 65°C.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. The primary circuit incorporates a pressure relief valve set at 3.0 bar and an expansion vessel. The products are supplied with a temporary filling loop which incorporates a combined isolation valve and double check valve assembly (suitable for backflow protection against Fluid Category 3), stainless steel braided EPDM lined flexible hose assembly and an isolation valve. The secondary circuit (DHW) incorporates a plastic flow restrictor The primary circuit incorporates isolation valves on the flow and return. Maximum working pressure of secondary circuit is 6.0 bar. Maximum working pressure of primary circuit is 2.5 bar. Maximum operating temperature 60°C. Cold water supply only.
Range of wall hung, gas fired, combination boilers providing domestic hot water via a plate heat exchanger. The primary circuit incorporates an integral expansion vessel and a pressure relief valve set at 3.0 bar. The product is supplied with a rigid pipe filling loop, followed by a separate isolation valve. The filling loop pipe attaches to the cold water inlet valve which incorporates a double check valve assembly (verified by test, suitable for backflow protection against Fluid Category 3) on the branch to the filling loop. The primary circuit includes an isolation valve on the flow and return and is also supplied with two loose 22mm compression isolation valves and a filter. Maximum working pressure of the primary circuit is 2.5 bar and the maximum supply pressure to the secondary circuit is 10.0 bar. Max operating temperature 65°C.
Range of wall hung, gas fired, combination boilers providing domestic hot water via a plate heat exchanger. The primary circuit incorporates an integral expansion vessel and a pressure relief valve set at 3.0 bar. The product is supplied with a rigid pipe filling loop, followed by a separate isolation valve. The filling loop pipe attaches to the cold water inlet valve which incorporates a double check valve assembly (verified by test, suitable for backflow protection against Fluid Category 3) on the branch to the filling loop. The primary circuit includes an isolation valve on the flow and return and is also supplied with two loose 22mm compression isolation valves and a filter. Maximum working pressure of the primary circuit is 2.5 bar and the maximum supply pressure to the secondary circuit is 10.0 bar. Max operating temperature 65°C.
Range of wall hung, gas fired, combination boilers providing domestic hot water via a plate heat exchanger. The primary circuit incorporates an integral expansion vessel and a pressure relief valve set at 3.0 bar. The product is supplied with a rigid pipe filling loop, followed by a separate isolation valve. The filling loop pipe attaches to the cold water inlet valve which incorporates a double check valve assembly (verified by test, suitable for backflow protection against Fluid Category 3) on the branch to the filling loop. The primary circuit includes an isolation valve on the flow and return and is also supplied with two loose 22mm compression isolation valves and a filter. Maximum working pressure of the primary circuit is 2.5 bar and the maximum supply pressure to the secondary circuit is 10.0 bar. Max operating temperature 65°C.
Range of wall mounted combination boilers providing domestic hot water via a plate heat exchanger and pressurised central heating system. The primary circuit incorporates a pressure relief valve set at 3.0 bar and an expansion vessel. The products are supplied with a temporary filling loop which incorporates a combined isolation valve and double check valve assembly (suitable for backflow protection against Fluid Category 3), stainless steel braided EPDM lined flexible hose assembly and an isolation valve. The secondary circuit (DHW) incorporates a stainless-steel strainer. The primary circuit incorporates isolation valves on the flow and return. Maximum working pressures: DHW: 10.0 Bar CH:2.5 Bar Maximum operating Temperatures: DHW: 65.0°C CH: 85.0°C
Range of wall mounted combination boilers providing domestic hot water via a heat exchanger and pressurised central heating system. The products can be supplied with a rigid or flexible filling loop or keyless filling link. The flexible and rigid filling loops incorporate a flexible hose or copper pipe, isolation valve, double check valve assembly (suitable for back flow protection against fluid category 3). The keyless filling link incorporates a CAB backflow prevention device (suitable for back flow protection against fluid category 3). The products also incorporate an expansion vessel and pressure relief valve set at 3.0 bar. Maximum working pressure of primary circuit 2.5 bar. Maximum operating temperature of primary circuit 85°C Maximum working pressure of secondary circuit 8.0 bar Maximum operating temperature of secondary circuit 60°C
‘SATK 32’ range of indirect heat interface units providing instantaneous hot water. Domestic hot water is provided via a plate heat exchanger and this circuit incorporates a flow detector, stainless-steel filter and water hammer arrestor. The primary/space heating circuit incorporates a pressure relief valve set at 2.5 bar and an expansion vessel. Maximum working pressure of the domestic hot water circuit is 10.0 bar. Maximum working pressure of the primary circuit is 16.0 bar. Maximum working pressure of the space heating circuit is 2.5 bar. Maximum operating temperature 90°C.
Non-metallic materials and components comply with BS6920 at 85°C
