Manifolds

Section Code 1950 : Metal.

Back To Directory Sections

#1905017

Range of 2, 3, 4 and 5-way manifold assemblies with nickel plated brass finishes. Incorporating a screw down isolating valve on each port. Also supplied with 15mm Eurocone compression olive connectors. Maximum working pressure 10.0 bar. Maximum operating temperature 95°C

Section:
1950 Manifolds
Section Subtitle:
Metal.
WRAS Approval Number:
1905017
Expiry date:
31/05/2024
Size:
¾” BSP (M or F) and supplied with 15mm compression outlets.
Marking:
IVAR on operating member.
Installation Requirements:
R001
Model:
506800N EASY-LOCK 2 Way Angled ¾” x Eurok Modular Manifold with Isolating Valves 506801N EASY-LOCK 3 Way Angled ¾” x Eurok Modular Manifold with Isolating Valves 506802N EASY-LOCK 4 Way Angled ¾” x Eurok Modular Manifold with Isolating Valves 506830N EASY-LOCK 5 Way Angled ¾” x Eurok Modular Manifold with Isolating Valves All models are made to the same construction and to be connected using 500025 Eurocone 15mm Copper Fittings.
Manufacturer:
IVAR S.p.A.
Company Name
IVAR S.p.A.
Address
Via IV Novembre, 181. 25080 Prevalle (BS)
Country
Italy
Phone
+39 030 680028

View All Listings by this Company

Print This Approval


#1907328

Range of 2, 3 and 4 port manifold assemblies with brass bodies. Maximum working pressure 16.0 bar. Maximum operating temperature 95°C

Section:
1950 Manifolds
Section Subtitle:
Metal.
WRAS Approval Number:
1907328
Expiry date:
31/07/2024
Size:
See model
Marking:
‘S’, PW and size on body. Size, IS/EN1254/2 and Irish Instantor (brand of Sanbra Fyffe) on nut.
Installation Requirements:
R001
Model:
771871PW – ¾” x ½” (2 port) 771872PW – 1” x ½” (2 port) 771874PW – ¾” x ½” (3 port) 771875PW – 1” x ½” (3 port) 771877PW – ¾” x ½” (4 port) 771878PW – 1” x ½” (4 port) Models added August 2022 771879PW - 1" x 1" (2 port) 771896PW - 1" x 1" (3 port) 771897PW - 1" x 1" (4port)
Factor:
Sanbra Fyffe Ltd.
Company Name
Sanbra Fyffe Ltd.
Address
Conex Works, Santry Avenue, Dublin
Postcode
D09 K160
Country
Ireland
Phone
353 1 842 6255
General Email
sales@sanbra.ie

View All Listings by this Company

Print This Approval


#2012006

Range of 2, 3 and 4 port manifold assemblies with either DRZ brass or brushed chrome plated brass bodies incorporating screw down isolation valves with dome type operating members. Maximum working pressure 10.0 Bar Maximum operating temperature 85.0°C

Section:
1950 Manifolds
Section Subtitle:
Metal.
WRAS Approval Number:
2012006
Expiry date:
31/12/2025
Size:
2 Port: 3825.34 (¾” BSP (M) X ¾“ BSP (F)) 3825.1 (1” BSP (M) X 1” BSP (F)) 3834.1 (1” BSP (M) X 1” BSP (F)) 3834.34(¾” BSP (M) X ¾“ BSP (F)) 3 Port: 3850.34 (¾” BSP (M) X ¾” BSP (F)) 3850.1 (1” BSP (M) X 1” BSP (F)) 3835.34 (¾” BSP (M) X ¾” BSP (F)) 3835.1 (1” BSP (M) X 1” BSP (F)) 4 Port: 3856.34 (¾” BSP (M) X ¾” BSP (F)) 3856.1 (1” BSP (M) X 1” BSP (F)) 3837.34 (¾” BSP (M) X ¾” BSP (F)) 3837.1 (1” BSP (M) X 1” BSP (F))
Marking:
FAR, size and made in Italy on body. CR on body (models 3834.1, 3834.34, 3835.34, 3835.1, 3837.37 & 3837.1).
Installation Requirements:
R001
Model:
2 Port: 3825.34 3825.1 3834.1 3834.34 3 Port: 3850.34 3850.1 3835.34 3835.1 4 Port: 3856.34 3856.1 3837.34 3837.1
Manufacturer:
FAR Rubinetterie S.p.A.
Company Name
FAR Rubinetterie S.p.A.
Address
Via Morena 20, 28024, Gozzano (NO)

View All Listings by this Company

Print This Approval


#2101339

Range of 2, 3 and 4 port manifold assemblies with brass bodies (brushed chrome finish). The products are supplied with isolation valves. Maximum working pressure 10.0 bar. Maximum operating temperature 85°C.

Section:
1950 Manifolds
Section Subtitle:
Metal.
WRAS Approval Number:
2101339
Expiry date:
31/01/2026
Note:
1002273 UNI-X end plugs are not considered approved in their own right.
Size:
¾” BSP (M) x ¾” BSP (F).
Marking:
Uponor on operating valve.
Installation Requirements:
R001
Model:
1002280 - 2 port manifold. 1002281 - 3 port manifold. 1002282 - 4 port manifold. 1002273 UNI-X end plug (optional) which must be used in conjunction with the above manifolds. 1020248 SPI UNI-C valve insert, which is included with the manifolds, or available as a spare part. Models added June 2021: 1” BSP (M) x 1” BSP (F), with ¾” BSP (M) on valve outlets.
Factor:
Uponor GmbH
Company Name
Uponor GmbH
Address
Industriestraße 56, 97437 Hassfurt
Country
Germany
Phone
0034916853600

View All Listings by this Company
Manufacturer:
Te-sa S.r.l
Company Name
Te-sa S.r.l

View All Listings by this Company

Print This Approval


#2111332

Range of two, three, four and five-way manifold assemblies incorporating brass bodies (brushed chrome finish) and EPDM ‘O’-rings. The products are supplied with isolation valves. Maximum working pressure 10.0 bar. Maximum operating temperature 95°C.

Section:
1950 Manifolds
Section Subtitle:
Metal.
WRAS Approval Number:
2111332
Expiry date:
30/11/2026
Size:
¾” BSP (M) x ¾” BSP (F).
Marking:
Ivar on operating member. Made in Italy and size body
Installation Requirements:
R001 R120
Model:
2-way manifold: 507362N 507800N 3-way manifold: 507363N 507801N 4-way manifold: 507364N 507802N 5-way manifold: 507365N 507830N
Manufacturer:
IVAR S.p.A.
Company Name
IVAR S.p.A.
Address
Via IV Novembre, 181. 25080 Prevalle (BS)
Country
Italy
Phone
+39 030 680028

View All Listings by this Company

Print This Approval


#2201314

Range of 2, 3 or 4 way manifolds with a brass body. Maximum working pressure 10.0 bar. Maximum operating temperature 60°C.

Section:
1950 Manifolds
Section Subtitle:
Metal.
WRAS Approval Number:
2201314
Expiry date:
31/01/2027
Size:
¾” BSP (F) x ¾” BSP (M) inlets. ½” BSP (M) outlet
Marking:
Giacomini logo and size on body. Giacomini logo on cap.
Installation Requirements:
R001 R120
Model:
R585CY062 – 2 port R585CY063 – 3 port R585CY064 – 4 port
Manufacturer:
Giacomini S.p.A.
Company Name
Giacomini S.p.A.
Address
Via per Alzo, 39 28017 San Maurizio d'Opaglio (Novara)
Country
Italy
Phone
+39 0322 923 111

View All Listings by this Company

Print This Approval


#2207314

Range of wholesome-water nickel plated brass manifolds for use with ‘Emmeti Gerpex RA’ Pexb/Al/Pexb Multilayer pipe and ‘Emmeti Alpert’ PERT/AL/PERT Multilayer Pipe. Maximum working pressure 10.0 bar. Maximum operating temperature 95°C. Range of closed circuit use nickel plated brass manifolds for use with ‘JG Speedfit Layflat Polybutylene Barrier Pipe (models 10BPB & 15BPB)’. Maximum working pressure 3.0 bar. Maximum operating temperature 92°C.

Section:
1950 Manifolds
Section Subtitle:
Metal.
WRAS Approval Number:
2207314
Expiry date:
31/07/2027
Note:
R200 (closed circuit use only) applies to the manifolds and RWC Topsan, Topway, Multiplex and Modular pipes.
Size:
Please refer to model.
Marking:
Emmeti or Emmeti Logo on manifold body. Emmeti and date (WWYY) on nut
Installation Requirements:
R001 R200
Model:
01282050 FJ301282050I0020 3/4" 2-WAY TOPSAN 24X19 01282052 FJ301282052I0020 3/4" 3-WAY TOPSAN 24X19 01282054 FJ301282054I0020 3/4" 4-WAY TOPSAN 24X19 01282056 FJ301282056I0020 3/4" 5-WAY TOPSAN 24X19 01282058 FJ301282058I0020 3/4" 6-WAY TOPSAN 24X19 01282060 FJ301282060I0020 3/4" 7-WAY TOPSAN 24X19 01282062 FJ301282062I0020 3/4" 8-WAY TOPSAN 24X19 01282064 FJ301282064I0020 3/4" 9-WAY TOPSAN 24X19 01282066 FJ301282066I0020 3/4" 10-WAY TOPSAN 24X19 01282068 FJ301282068I0020 3/4" 11-WAY TOPSAN 24X19 01282070 FJ301282070I0020 3/4" 12-WAY TOPSAN 24X19 01282084 FJ301282084I0020 1" 4-WAY TOPSAN 01282086 FJ301282086I0020 1" 5-WAY TOPSAN 01282088 FJ301282088I0020 1" 6-WAY TOPSAN 01293260 FF801293260I0040 3/4" 2-WAY TOPWAY SINGLE BAR 36MM 01293262 FF801293262I0040 3/4" 3-WAY TOPWAY SINGLE BAR 36MM 01293264 FF801293264I0040 3/4" 4-WAY TOPWAY SINGLE BAR 36MM 01293266 FF801293266I0040 3/4" 5-WAY TOPWAY SINGLE BAR 36MM 01293268 FF801293268I0040 3/4" 6-WAY TOPWAY SINGLE BAR 36MM 01293270 FF801293270I0040 3/4" 7-WAY TOPWAY SINGLE BAR 36MM 01293272 FF801293272I0040 3/4" 8-WAY TOPWAY SINGLE BAR 36MM 01293274 FF801293274I0040 3/4" 9-WAY TOPWAY SINGLE BAR 36MM 01293276 FF801293276I0040 3/4" 10-WAY TOPWAY SINGLE BAR 36MM 01293278 FF801293278I0040 3/4" 11-WAY TOPWAY SINGLE BAR 36MM 01293280 FF801293280I0040 3/4" 12-WAY TOPWAY SINGLE BAR 36MM 01293290 FF801293290I0040 3/4" 2-WAY TOPWAY SINGLE BAR 50MM 01293292 FF801293292I0040 3/4" 3-WAY TOPWAY SINGLE BAR 50MM 01293294 FF801293294I0040 3/4" 4-WAY TOPWAY SINGLE BAR 50MM 01293296 FF801293296I0040 3/4" 5-WAY TOPWAY SINGLE BAR 50MM 01293298 FF801293298I0040 3/4" 6-WAY TOPWAY SINGLE BAR 50MM 01293300 FF801293292I0040 3/4" 7-WAY TOPWAY SINGLE BAR 50MM 01293302 FF801293302I0040 3/4" 8-WAY TOPWAY SINGLE BAR 50MM 01293304 FF801293304I0040 3/4" 9-WAY TOPWAY SINGLE BAR 50MM 01293306 FF801293306I0040 3/4" 10-WAY TOPWAY SINGLE BAR 50MM 01293308 FF801293308I0040 3/4" 11-WAY TOPWAY SINGLE BAR 50MM 01293310 FF801293310I0040 3/4" 12-WAY TOPWAY SINGLE BAR 50MM 01293830 FF801293830I0040 1" 2-WAY TOPWAY SINGLE BAR 01293832 FF801293832I0040 1" 3-WAY TOPWAY SINGLE BAR 01293834 FF801293834I0040 1" 4-WAY TOPWAY SINGLE BAR 01293836 FF801293836I0040 1" 5-WAY TOPWAY SINGLE BAR 01293838 FF801293838I0040 1" 6-WAY TOPWAY SINGLE BAR 01293840 FF801293840I0040 1" 7-WAY TOPWAY SINGLE BAR 01293842 FF801293842I0040 1" 8-WAY TOPWAY SINGLE BAR 01293844 FF801293844I0040 1" 9-WAY TOPWAY SINGLE BAR 01293846 FF801293846I0040 1" 10-WAY TOPWAY SINGLE BAR 01293848 FF801293848I0040 1" 11-WAY TOPWAY SINGLE BAR 01293850 FF801293850I0040 1" 12-WAY TOPWAY SINGLE BAR 01294634 FF801294634I0020 1 1/4" 4-WAY TOPWAY SINGLE BAR 01294636 FF801294636I0020 1 1/4" 5-WAY TOPWAY SINGLE BAR 01294638 FF801294638I0020 1 1/4” 6 – WAYS TOPWAY SINGLE BAR 01294640 FF801294640I0020 1 1/4” 7 – WAYS TOPWAY SINGLE BAR 01294642 FF801294642I0020 1 1/4” 8 – WAYS TOPWAY SINGLE BAR 01294644 FF801294644I0020 1 1/4” 9 – WAYS TOPWAY SINGLE BAR 01294646 FF801294646I0020 1 1/4” 10 – WAYS TOPWAY SINGLE BAR 01294648 FF801294640I0020 1 1/4” 11 – WAYS TOPWAY SINGLE BAR 01294650 FF801294650I0020 1 1/4” 12 – WAYS TOPWAY SINGLE BAR 01307260 FJ201307260I0120 3/4" 2-WAY MULTIPLEX MANIFOLD 01307265 FJ201307265I0120 3/4" 3-WAY MULTIPLEX MANIFOLD 01307270 FJ201307270I0120 3/4" 4-WAY MULTIPLEX MANIFOLD 01307280 FJ201307280I0080 1" 2-WAY MULTIPLEX MANIFOLD 01307285 FJ201307285I0060 1" 3-WAY MULTIPLEX MANIFOLD 01307290 FJ201307290I0040 1" 4-WAY MULTIPLEX MANIFOLD 01303150 FEE01303150I0100 3/4" 2-WAY Modular simple manifold 01303152 FEE01303152I0100 3/4" 3-WAY Modular simple manifold 01303154 FEE01303154I0100 3/4" 4-WAY Modular simple manifold 01303160 FEE01303160I0100 1" 2-WAY Modular simple manifold 01303162 FEE01303162I0100 1" 3-WAY Modular simple manifold 01303164 FEE01303164I0100 1" 4-WAY Modular simple manifold 28106000 FXB28106000I0A00 DN16X2 Pexb/Al/Pexb pipe coil 100m 28106010 FXB28106010I0AE0 DN16X2 Pexb/Al/Pexb pipe coil 200m 28106050 FXB28106050I0AN0 DN16X2 Pexb/Al/Pexb pipe coil 500m 28108010 FXB28108010I0960 DN16X2 Pexb/Al/Pexb pipe bar 4m 28106004 FXB28106004I0A00 DN20X2 Pexb/Al/Pexb pipe coil 100m 28106002 FXB28106002I0AE0 DN20X2 Pexb/Al/Pexb pipe coil 200m 28108014 FXB28108014I0960 DN20X2 Pexb/Al/Pexb pipe bar 4m 28106006 FXB28106006I0500 DN26x3 Pexb/Al/Pexb pipe coil 50m 28108016 FXB28108016I0400 DN26x3 Pexb/Al/Pexb pipe bar 4m 28107002 FRB28107002I0A00 DN16X2 Pert/Al/Pert pipe coil 100m 28107055 FRB28107055I0A00 DN16X2 Pert/Al/Pert pipe coil 100m random numbering 28107000 FRB28107000I0AE0 DN16X2 Pert/Al/Pert pipe coil 200m 28107004 FRB28107004I0AN0 DN16X2 Pert/Al/Pert pipe coil 500m 28107016 FRB28107016I0A00 DN20X2 Pert/Al/Pert pipe coil 100m 28107018 FRB28107018I0AF0 DN20X2 Pert/Al/Pert pipe coil 240m 10BPB-25C 10MM POLYBUTYLENE BARRIER PIPE 25M COIL 10BPB-50C 10MM POLYBUTYLENE BARRIER PIPE 50M COIL 10BPB-100C 10MM POLYBUTYLENE BARRIER PIPE 100M COIL 15BPB-25C 15MM POLYBUTYLENE BARRIER PIPE 25M COIL 15BPB-50C 15MM POLYBUTYLENE BARRIER PIPE 50M COIL 15BPB-85C 15MM POLYBUTYLENE BARRIER PIPE 85M COIL 10BPB-100C 15MM POLYBUTYLENE BARRIER PIPE 100M COIL 10BPB-120C 15MM POLYBUTYLENE BARRIER PIPE 120M COIL 10BPB-150C 15MM POLYBUTYLENE BARRIER PIPE 150M COIL 10BPB-300C 15MM POLYBUTYLENE BARRIER PIPE 300M COIL
Factor:
Emmeti Spa
Company Name
Emmeti Spa
Address
Via Brigata Osappo 166, 33074 Vigonovo frazione di Fontanafredda (PN)
Country
Italy

View All Listings by this Company

Print This Approval


#2301018

Range of 2, 3 and 4 port brushed chrome DZR brass manifolds incorporating a screw down isolation valve at each port and brass compression adaptors (MFIT100053). Pushfit outlets are for use with copper pipe (manufactured to EN1057), BPB pipe (manufactured to BS EN 7291-2:2010) and BPEX pipe (manufactured to BS EN 7291-3:2010). MANA500552, MANA500553 and MANA500554 models used in conjunction with the MFIT100053 brass compression adaptor on the outlets are for use with BPB pipe (manufactured to BS EN 7291-2:2010) and BPEX pipe (manufactured to BS EN 7291-3:2010). Maximum working pressure 10.0 bar at 82°C and 16.0 bar at 20°C.

Section:
1950 Manifolds
Section Subtitle:
Metal.
WRAS Approval Number:
2301018
Expiry date:
31/01/2028
Note:
The approval holder advises that this product must not be used on a central heating/primary circuit. The MFIT100053 brass compression adaptor is not approved in its own right.
Size:
See model.
Marking:
MANA prefix models: RWC on operating members, size and CR on body. JGMAN prefix models: John Guest (brand of Reliance Worldwide Corporation (UK) Ltd.) on operating members, size and CR on body.
Installation Requirements:
R001 R120
Model:
MANA500522 (2 Port Manifold): ¾” BSP (M) x 15mm push fit (2 Port Manifold). MANA500523 (3 Port Manifold): ¾” BSP (M) x 15mm push fit (3 Port Manifold). MANA500524 (4 Port Manifold): ¾” BSP (M) x 15mm push fit (4 Port Manifold). MANA500552 (2 Port Manifold): ¾” BSP (M) x ¾” BSP (M). MANA500553 (3 Port Manifold): ¾” BSP (M) x ¾” BSP (M). MANA500554 (4 Port Manifold): ¾” BSP (M) x ¾” BSP (M). JGMAN2 (2 Port Manifold): ¾” BSP (M) x 15mm push fit (2 Port Manifold). JGMAN3 (3 Port Manifold): ¾” BSP (M) x 15mm push fit (3 Port Manifold). JGMAN4 (4 Port Manifold): ¾” BSP (M) x 15mm push fit (4 Port Manifold). MFIT100053: EUROCONUS FITTING 15mm (brass compression adaptors), which must be used in conjunction with the MANA500552, MANA500553 and MANA500554 models.
Manufacturer:
Reliance Worldwide Corporation UK Ltd
Company Name
Reliance Worldwide Corporation UK Ltd
Address
Horton Road West Drayton Middlesex
Postcode
UB7 8JL

View All Listings by this Company

Print This Approval


#2306056

Range of 2 and 3 port manifold assemblies with brass bodies incorporating ‘Tectite Classic’ push-fit fittings for use with either copper pipe (manufactured to EN1057), PEX pipe (manufactured to BS7291-3:2010) or PB pipe (manufactured to BS7291-2). Maximum working temperature and pressure: Use with copper pipe: 16.0 bar @ 30°C, 10.0 bar @ 65°C & 6.0 bar @ 95°C. Use with PEX & Polybutylene: 12.0 bar @ 20°C, 6.0 bar @ 65°C & 3.0 bar @ 92°C.

Non-metallic materials and components comply with BS6920 at See description °C

Section:
1950 Manifolds
Section Subtitle:
Metal.
WRAS Approval Number:
2306056
Expiry date:
30/06/2028
Size:
22mm stub, 22mm push-fit with 15mm push-fit ports.
Marking:
Tectite, CR & Size on body.
Installation Requirements:
R001
Model:
45943 (2 Port) & 45944 (3 Port).
Factor:
Aalberts Integrated Piping Systems Ltd.
Company Name
Aalberts Integrated Piping Systems Ltd.
Address
St. Catherines Avenue Doncaster South Yorkshire
Postcode
DN4 8DF
Country
United Kingdom
Phone
01302 560560

View All Listings by this Company
Manufacturer:
Aalberts Integrated Piping Systems Ltd.
Company Name
Aalberts Integrated Piping Systems Ltd.
Address
St. Catherines Avenue Doncaster South Yorkshire
Postcode
DN4 8DF
Country
United Kingdom
Phone
01302 560560

View All Listings by this Company

Print This Approval


#2307320

6300E7 series of nickel plated brass manifolds and 6300R8 series of chromium plated brass manifolds with two, three or four outlets, for use with copper pipe (manufactured to EN1057). The products incorporate a screw down isolation valve at each port. Maximum working pressure 6.0 bar. Maximum operating temperature 85°C.

Section:
1950 Manifolds
Section Subtitle:
Metal.
WRAS Approval Number:
2307320
Expiry date:
31/07/2028
Size:
¾” BSP (F) x ¾” BSP (M) or 1” BSP (M) x 1” BSP (F).
Marking:
General Fittings on body or cap indice.
Installation Requirements:
R001 R120
Model:
6300E7N0505B2A MANIFOLD EK BLU NK 3/4X3/4-T2 6300E7N0505B3A MANIFOLD EK BLU NK 3/4X3/4-T3 6300E7N0505B4A MANIFOLD EK BLU NK 3/4X3/4-T4 6300E7N0505R2A MANIFOLD EK RED NK 3/4X3/4-T2 6300E7N0505R3A MANIFOLD EK RED NK 3/4X3/4-T3 6300E7N0505R4A MANIFOLD EK RED NK 3/4X3/4-T4 6300E7N0505V2A MANIFOLD EK GREEN NK 3/4X3/4-T2 6300E7N0505V3A MANIFOLD EK GREEN NK 3/4X3/4-T3 6300E7N0505V4A MANIFOLD EK GREEN NK 3/4X3/4-T4 6300E7N1005B2A MANIFOLD EK BLU NK 1”X3/4-T2 6300E7N1005B3A MANIFOLD EK BLU NK 1”X3/4-T3 6300E7N1005B4A MANIFOLD EK BLU NK 1”X3/4-T4 6300E7N1005R2A MANIFOLD EK RED NK 1”X3/4-T2 6300E7N1005R3A MANIFOLD EK RED NK 1”X3/4-T3 6300E7N1005R4A MANIFOLD EK RED NK 1”X3/4-T4 6300E7N1005V2A MANIFOLD EK GREEN NK 1”X3/4-T2 6300E7N1005V3A MANIFOLD EK GREEN NK 1”X3/4-T3 6300E7N1005V4A MANIFOLD EK GREEN NK 1”X3/4-T4 6300R8C0505V2A MANIFOLD 90° EK GREEN NK 3/4X3/4-T2 6300R8C0505V3A MANIFOLD 90° EK GREEN NK 3/4X3/4-T3 6300R8C0505V4A MANIFOLD 90° EK GREEN NK 3/4X3/4-T4 6300R8C1005V2A MANIFOLD 90° EK GREEN NK 1”X3/4-T2 6300R8C1005V3A MANIFOLD 90° EK GREEN NK 1”X3/4-T3 6300R8C1005V4A MANIFOLD 90° EK GREEN NK 1”X3/4-T4
Manufacturer:
General Fittings S.p.A
Company Name
General Fittings S.p.A
Address
Via Golgi 73/75 25064 Gussago Brescia
Country
Italy
Phone
+39 0303739017

View All Listings by this Company

Print This Approval



Back To Directory Sections

Page 1 of 2
