Section Code 0490 : Single hole, metal, double outlet, swivel.
Back To Directory SectionsSingle hole, double outlet (swivel) combination tap assembly (chromium plated brass) incorporating non-rising spindle headwork with dome type operating members. The spout outlet incorporates a plastic flow straightener & inlets incorporate flow regulators. Maximum working pressure 5.0 bar. Maximum operating temperature 70°C.
Range of single hole, double outlet (swivel) combination taps assemblies (chromium plated brass or stainless steel finish), incorporating a ceramic disc headwork (dispensing boiling water) and a ceramic cartridge headwork (dispensing cold/hot/mixed water) both with single lever operating members. The spout outlets incorporate a plastic aerator. The products are supplied with an instantaneous water heater (4 or 8 litre) for providing boiling water (98°C), as well as an installation safety kit which includes a pressure reducing valve set at 3.0 bar, pressure relief valve set at 6.0 bar, tundish and an expansion vessel. Maximum working pressure 5.5 bar. Maximum operating temperature 98°C.
Range of single hole, double outlet (swivel) combination tap assemblies (chromium plated brass). The products incorporate quarter turn ceramic disc headworks with single lever operating members. The spout outlets incorporate a plastic flow straightener. Maximum operating pressure 5.0 bar. Maximum operating temperature 60°C.
Range of single hole, double outlet (swivel) combination tap assemblies (chromium plated brass), incorporating non-rising spindle headworks with dome type operating members. The spout outlet incorporates a plastic flow straightener. The ML1 model incorporates a plastic flow regulator on each inlet. Maximum working pressure 5.0 bar. Maximum operating temperature 70°C
Single hole, double outlet (swivel) combination tap assembly (chromium plated brass) incorporating quarter turn ceramic disc headwork with single lever operating members The spout outlets incorporate a plastic aerator. Maximum operating pressure 5.0 bar. Maximum operating temperature 70°C.
Single hole, double outlet (swivel) combination tap assembly (chromium plated brass). Incorporating quarter turn ceramic disc headworks and dome operating members. The spout outlet incorporates a plastic aerator. Maximum working pressure 5.0 bar and maximum operating temperature 70ºC.
Single hole, double outlet (swivel) combination tap assembly (chromium plated brass) incorporating quarter turn ceramic disc headwork with single lever operating members The spout outlets incorporate a plastic aerator. Maximum operating pressure 5.0 bar. Maximum operating temperature 70°C.
Range of single hole, dual outlet (swivel) combination tap assembly (chromium plated brass) supplied with an undersink unit supplying water at 98°C. The tap assembly incorporates quarter ceramic disc headworks and single lever operating members. The spout outlet incorporates a plastic aerator. The undersink water unit is supplied with an installation kit, consisting of a pressure reducing valve (set at 6.0 bar), an expansion vessel and manifold incorporating an isolation valve (single lever operated) and single check valve cartridge (suitable for backflow prevention against Fluid Category 2). Maximum working pressure 6.0 bar. Maximum operating temperature 98°C.
Single hole, single outlet (swivel) combination tap assembly (chromium plated brass) incorporating quarter ceramic disc headwork with single lever operating members. The spout outlet incorporates a plastic aerator. Maximum working pressure 6.0 bar. Maximum operating temperature 98°C.
Single hole, double outlet (swivel) combination tap assembly (chromium plated brass). Incorporating quarter turn ceramic disc headworks and lever operating members. Maximum working pressure 6.0 bar. Maximum operating temperature 85°C.
Single hole, single outlet (swivel) combination tap assembly (chromium plated brass) incorporating a rising spindle headwork and single lever operating member. The spout outlet incorporates a plastic aerator. A second outlet option is present in this product which can be used to accommodate a spout or plugged. No flow control is present for this optional outlet. Maximum working pressure 10.0 bar. Maximum operating temperature 65°C.
Range of single hole, double outlet (swivel) combination tap assemblies (chromium plated brass or brushed steel finish) incorporating quarter turn ceramic disk headworks with single lever operating members. The spout outlet incorporates a plastic aerator and flow regulator. Maximum working pressure 5.0 Bar. Maximum operating temperature 60°C
Single hole, double outlet (swivel) combination tap assembly (chromium plated brass) incorporating quarter turn ceramic disc headworks with single lever operating members. Maximum working pressure 6.0 bar. Maximum operating temperature 85°C.
Range of single hole, single outlet fixed combination tap assemblies (chromium plated brass) with temperature controlled independently via a thermostatic cartridge (with dome type operating member) and flow controlled via a ceramic cartridge headwork (with single lever operating members). Water can be supplied either from the hot water mains (standard side of tap) or boiling water via the boiler unit. The boiler unit is fed via a cold water filter incorporating an line expansion vessel and control assembly consisting of a inlet control groups with DZR brass bodies incorporating a pre-set pressure reducing valve (3.0 bar), a pre-set pressure relief (6.0 bar) and a single check valve assembly (suitable for backflow prevention against fluid category 2.The spout outlet incorporates a plastic aerator. Maximum working pressure 8.0 bar. Maximum operating temperature 100°C boiling water circuit, 60°C standard outlet side.
Single hole, double outlet (swivel) combination tap assembly (chromium plated brass and ‘supersteel’ finish brass), incorporating a ceramic cartridge headwork with a single lever operating member. The tap also incorporates a quarter ceramic disc self-closing headwork with a single lever operating member, which is intended to be supplied by an instantaneous water heater (not included)to dispense near boiling water. The spout outlet incorporates a plastic aerator. Maximum working pressure 10.0 bar. Maximum operating temperature 60°C (Hot and cold supplies). Maximum operating temperature 99°C (instantaneous water circuit/supply only).
Single hole, single outlet (swivel) combination tap assembly (various finishes) incorporating ceramic cartridge headwork, single lever operating member and spring loaded pull down hand spray with manually operated trigger mechanism. The product also incorporates a second swivel spout which incorporates its own ¼ turn ceramic disc headwork to control the flow with a single lever operating member and a plastic aerator. Maximum working pressure 5.0 bar. Maximum operating temperature 60°C.
Range of single hole, double outlet (swivel) combination tap assembly (chromium plated brass), incorporating ceramic cartridge headworks and single lever operating members. The tap body incorporates an additional quarter turn ceramic disc headwork that controls the flow of an optional third inlet supply. The spout outlet incorporates a plastic aerator. The product is supplied with a brass connecting tee-piece for use as part of the additional supply. The inlet hoses incorporate stainless steel strainers. Maximum operating pressure 5.0 bar. Maximum operating temperature 60°C.
Single hole, single outlet (swivel) combination tap assembly (various finishes) incorporating ceramic cartridge headwork, single lever operating member and spring loaded pull down hand spray with manually operated trigger mechanism. The product also incorporates a second swivel spout which incorporates its own ¼ turn ceramic disc headwork to control the flow with a single lever operating member and a plastic aerator. Maximum working pressure 5.0 bar. Maximum operating temperature 60°C.
Single hole, double outlet (swivel) combination tap assembly (brass body in various finishes) incorporating a ceramic cartridge headwork with single lever operating member. Electronic controls allow the tap to dispense ambient, boiling, chilled or sparkling water from undercounter units which are not included as part of this approval. Maximum working pressure 7.0 bar. Maximum operating temperature 65°C (manual control side - ceramic cartridge) & 100°C (electronic control side).
Single hole, double outlet (swivel) combination tap assembly (chromium plated brass). Incorporating quarter turn ceramic disc headworks and dome operating members. The spout outlet incorporates a plastic aerator. Maximum working pressure 5.0 bar and maximum operating temperature 70ºC.
Range of single hole, double outlet (swivel) combination tap assemblies (chromium plated brass) incorporating a ceramic cartridge headwork with a single lever operating member. The taps also incorporate a self-closing headwork with a single lever operating member which is intended to be supplied by an instantaneous water heater (not included on this approval) to dispense near boiling water. The spout outlet incorporates a plastic aerator. Maximum working pressure 5.5 bar. Maximum operating temperature 98°C
Range of single hole, double outlet (swivel) combination tap assemblies (chromium plated brass), incorporating a quarter turn ceramic disc headworks on the left-hand side controlling the hot water flow, and a manual diverter on the right-hand side controlling the cold water flow (forward) or filtered water (backward) all with single lever operating members. The near boiling water flow is activated via a magnetic key fob being placed on the rear of the tap body (boiler unit not supplied). The spout outlet incorporates a plastic aerator. The hot and cold inlet hoses incorporate an approved check valve cartridge(s), however, the complete product has not been fully tested to demonstrate it provides backflow protection. The product is supplied with optional ⅜” BSP (M) x ½” BSP (F) adaptors for the hot and cold inlet hoses. Maximum working pressure 5.0 bar. Maximum operating temperature 60°C for mixed (ambient hot and cold + filtered water), 98°C for near boiling water outlet.
Range of single hole, metal double outlet (swivel) combination tap assemblies (chromium plated brass) incorporating ceramic cartridge headwork and a single lever type operating member controlling the mixed supply. Electronic controls allow the tap to dispense ambient and hot from under counter units which are not included as part of this approval. Spout outlets incorporate a plastic aerator and inlets incorporate stainless steel strainers. Maximum working pressure 6.0 bar. Maximum operating temperature 60°C. From April 2020 the taps have a maximum operating temperature of 99°C.
Range of single hole, double outlet (swivel) combination tap assemblies (chromium plated brass), incorporating a quarter turn ceramic disc headwork controlling the hot water volume and a half turn ceramic disc headwork both controlling and diverting the supply between a mains cold inlet and alternative third supply - all using single lever operating members. The spout outlet incorporates a plastic aerator. Maximum working pressure 5.0 bar. Maximum operating temperature 60°C.
Range of single hole, double outlet (swivel) combination tap assemblies (chromium plated brass), incorporating ceramic cartridge headworks and single lever operating members controlling the cold water. Tap also has a quarter turn ceramic disc headwork using a dome type operating member incorporating a manual override button that is intended to control the flow of a boiling water supply (unit not supplied). The spout outlet incorporates a plastic flow straightener. Maximum working pressure 5.0 bar. Maximum operating temperature cold water circuit 60°C Maximum operating temperature hot water circuit 90°C
Range of single hole, double outlet (swivel) combination tap assemblies (chromium plated brass), incorporating quarter turn ceramic disc headwork controlling the hot supply and a half turn ceramic disc headwork that controls and diverts the cold supply and an alternative inlet supply, both using single lever operating members. The spout outlet incorporates a plastic aerator. Maximum working pressure 5.0 bar. Maximum operating temperature 60°C.
Single hole, double outlet (swivel) combination tap assembly (chromium plated brass), incorporating quarter turn ceramic disk headworks with single lever operating members. The spout outlet incorporates a plastic flow straightener. Maximum working pressure 5.0 bar. Maximum operating temperature 60°C.
Range of single hole, double outlet (swivel) combination tap assemblies (chromium plated brass) incorporating ¼ turn ceramic disc headworks with single lever operating members. The spout outlet incorporates a plastic flow straightener. Maximum working pressure 10.0 Bar. Maximum operating temperature 70°C.
Range of single hole, single outlet (swivel) combination tap assemblies (chromium plated brass), incorporating non-rising spindle heads with dome type operating members. The spout outlet incorporates a plastic flow straightener. Maximum working pressure 5.0 bar. Maximum operating temperature 65°C.
Single hole, single outlet (swivel) combination tap assembly (chromium plated brass), incorporating non-rising spindle headworks with dome type operating members. The spout outlet incorporates a plastic flow straightener. Maximum working pressure 10.0 bar. Maximum operating temperature 65°C
Range of single hole, double outlet (swivel) combination tap assemblies (chromium plated brass) with a non-rising spindle headwork operated by either dome (M0113CP) or cross top (M0113F & M06130) operating members. The spout outlet incorporates a plastic flow straightener. Maximum working pressure 10.0 bar. Maximum operating temperature 70°C
Single hole, double outlet (swivel) combination tap assemblies (chromium plated brass), incorporating non rising spindle headworks with dome type operating members. Maximum working pressure 7.0 bar. Maximum operating temperature 65°C.
Single hole double outlet (swivel) combination tap assembly (white coated brass) incorporating non-rising spindle headworks using dome type operating members. Maximum working pressure 7.0 bar. Maximum operating temperature 65°C.
Range of single hole, double outlet (swivel) combination tap assemblies (chromium plated brass) with a non-rising spindle headwork operated by dome operating members. The spout outlet incorporates a plastic flow straightener. Maximum working pressure 10.0 bar. Maximum operating temperature 70°C
Single hole, double outlet (swivel) combination tap assemblies (chromium plated brass), incorporating non rising spindle headworks with dome type operating members. Maximum working pressure 7.0 bar. Maximum operating temperature 65°C.
Range of single hole, double outlet (swivel) combination tap assemblies (chromium plated or white painted brass), incorporating quarter turn ceramic disc headworks and single lever type operating members. Outlets incorporates a plastic flow straightener. Maximum operating pressure 10.0 bar. Maximum operating temperature 70°C.
Range of single hole, double outlet (swivel) combination tap assemblies with brass bodies (various finishes) incorporating a quarter turn ceramic disc headwork and single lever operating members. The spout outlet incorporates a plastic flow straightener. Maximum working pressure 10.0 bar. Maximum operaring temperature 60°C.
Range of single hole, double outlet (swivel) combination tap assemblies (chromium plated brass) with a non-rising spindle headwork operated by either dome operating members. The spout outlet incorporates a plastic flow straightener. Maximum working pressure 10.0 bar. Maximum operating temperature 70°C
Range of single hole, double outlet (swivel) combination tap assemblies (chromium plated brass) incorporating a ceramic cartridge headwork with a single lever operating member. The taps also incorporate a self-closing headwork with a single lever operating member which is intended to be supplied by an instantaneous water heater (not included on this approval) to dispense near boiling water. The spout outlet incorporates a plastic aerator. Maximum working pressure 5.5 bar. Maximum operating temperature 98°C
Range of single hole, double outlet (swivel) combination tap assemblies with brass bodies (various finishes). Incorporating a non-rising spindle headwork with a dome type operating members. Maximum working pressure 10.0 bar. Maximum operating temperature 65°C.
Range of single hole, double outlet (swivel) combination tap assemblies (chromium plated brass). All models can be specified with either a non rising spindle headwork or a quarter turn ceramic disc headwork with dome (Tevere), cross top (Monaco) or single lever (Miura) operating members. The spout outlet incorporates a plastic flow straightener. Maximum working pressure 10.0 bar. Maximum operating temperature 65°C.
Range of single hole, double outlet (swivel) combination tap assemblies (chromium plated brass), incorporating a quarter turn ceramic disc headwork controlling the hot water volume and a half turn ceramic disc headwork both controlling and diverting the supply between a mains cold inlet and alternative third supply - all using single lever operating members. The spout outlet incorporates a plastic aerator. Maximum working pressure 5.0 bar. Maximum operating temperature 60°C.
Single hole, double outlet (swivel) combination tap assembly (chromium plated brass) incorporating quarter turn ceramic disc headwork with single lever operating members The spout outlets incorporate a plastic aerator. Maximum operating pressure 5.0 bar. Maximum operating temperature 70°C.
Range of single hole, double outlet (swivel) combination tap assemblies (chromium plated brass), incorporating a ceramic cartridge headwork with a single lever operating member. The cold water inlet hose Incorporates approved check valve cartridge(s), however, the complete product has not been fully tested to demonstrate it provides backflow protection The spout outlet incorporates a plastic aerator. Maximum working pressure 5.5 bar. Maximum operating temperature 85°C.
