Water Regulations Approval Scheme Ltd

Fittings and Pipe - Compatible Systems

Section Code 1100 : Unless specified in the individual approval, the products within this section are not suitable for below ground use

Back To Directory Sections

WRAS Approval Number: #1907002

Range of stainless-steel crimp fittings with EPDM ‘O’ rings for use with stainless steel pipes. Fittings between 15mm & 168mm are for use with 316 stainless steel pipe. Fittings between 15mm & 54mm are for use with 444 stainless steel pipe. Fittings between 76mm & 168mm are for use with 304 stainless steel pipe. For above ground use only. Maximum working pressure 16.0 bar. Maximum operating temperature 99°C

Section:: 1100 Fittings and Pipe - Compatible Systems
Section Subtitle:: Unless specified in the individual approval, the products within this section are not suitable for below ground use
WRAS Approval Number:: 1907002
Expiry date:: 31/07/2024
Size:: 15mm, 22mm, 54mm, 76mm, 168mm
Marking:: Xpress & size on body
Installation Requirements:: R001
Model:: VSH Xpress range of fittings
Factor:: Aalberts Integrated Piping Systems BV

Company Name
Aalberts Integrated Piping Systems BV
Address
OUDE AMERSFOORTSEWEG 99 1212 AA HILVERSUM PO BOX 498
Country
Netherlands

View All Listings by this Company

WRAS Approval Number: #1907060

ABN range of Socket fusion (20-125mm), Electrofusion (75-125mm), Elecpipe (Clickweld) (75-125mm) and Buttweld (160-200mm) plastic fittings for use with ABN//INSTAL CT Faser RD Series 3.2/SDR 7.4 multi-layer pipe (20-32mm) and Series 5/SDR 11 multi-layer pipe (40-200mm). Sizes 20mm to 32mm have a maximum working pressure of 31.7 bar @cold water use only and 8.1 bar@80°C. Sizes 40mm to 200mm have a maximum working pressure of 20.3 bar @cold water use only and 8.1 bar@80°C

Section:: 1100 Fittings and Pipe - Compatible Systems
Section Subtitle:: Unless specified in the individual approval, the products within this section are not suitable for below ground use
WRAS Approval Number:: 1907060
Expiry date:: 31/07/2024
Size:: see model
Marking:: ABN, size, material, series, date of manufacture (DD/MM/YYYY), and DIN8078-2008-09 on the pipe. ABN and size on the fittings body
Installation Requirements:: R001
Model:: ABN//INSTAL CT Faser RD Series 3 pipe 3m: 20mm (D0CTF32020000), 25mm (D0CTF32025000), 32mm (D0CTF32032000). ABN//INSTAL CT Faser RD Series 5 pipe 3m: 40mm (D0CTF50040000), 50mm (D0CTF50050000), 63mm (D0CTF50063000), 75mm (D0CTF50075000), 90mm (D0CTF50090000), 110mm (D0CTF50110000). ABN//INSTAL CT Faser RD Series 5 pipe 5.8m: 125mm (D0CTF50125000), 160mm (D0CTF50160000), 200mm (D0CTF50200000). ABN//INSTAL CT Faser RD Series 5 socketed pipe 3m: 40mm (D0CTF50040M00), 50mm (D0CTF50050M00), 63mm (D0CTF50063M00), 75mm (D0CTF50075M00), 90mm (D0CTF50090M00), 110mm (D0CTF50110M00). ABN//INSTAL CT Faser RD 125mm Series 5 socketed pipe 5.8m: 125mm (D0CTF50125M00). ABN Welding Socket: 20mm (D1M0200000000), 25mm (D1M0250000000), 32mm (D1M0320000000), 40mm (D1M0400000000), 50mm (D1M0500000000), 63mm (D1M0630000000), 75mm (D1M0750000000), 90mm (D1M0900000000), 110mm (D1M1100000000), 125mm (D1M1250000000). ABN 90° equal tee: 20mm (D1T0200000000), 25mm (D1T0250000000), 32mm (D1T0320000000), 40mm (D1T0400000000), 50mm (D1T0500000000), 63mm (D1T0630000000), 75mm (D1T0750000000), 90mm (D1T0900000000), 110mm (D1T1100000000), 125mm (D1T1250000000). ABN 90° unequal tee: 25x20x20mm (D1TR025020020), 25x20x25mm (D1TR025020025), 32x25x25mm (D1TR032025025), 32x20x32mm (D1TR032020032), 32x25x32mm (D1TR032025032), 40x20x40mm (D1TR040020040), 40x25x40mm (D1TR040025040), 40x32x40mm (D1TR040032040), 50x25x50mm (D1TR050025050), 50x32x50mm (D1TR050032050), 50x40x50mm (D1TR050040050), 63x25x63mm (D1TR063025063), 63x32x63mm (D1TR063032063), 63x40x63mm (D1TR063040063), 63x50x63mm (D1TR063050063), 75x50x75mm (D1TR075050075), 75x63x75mm (D1TR075063075), 90x63x90mm (D1TR090063090), 90x75x90mm (D1TR090075090), 110x63x110mm (D1TR110063110), 110x75x110mm (D1TR110075110), 110x90x110mm (D1TR110090110). ABN 90° elbow: 20mm (D1C0200900000), 25mm (D1C0250900000), 32mm (D1C0320900000), 40mm (D1C0400900000), 50mm (D1C0500900000), 63mm (D1C0630900000), 75mm (D1C0750900000), 90mm (D1C0900900000), 110mm (D1C1100900000), 125mm (D1C1250900000). ABN 45° elbow: 20mm (D1C0200450000), 25mm (D1C0250450000), 32mm (D1C0320450000), 40mm (D1C0400450000), 50mm (D1C0500450000), 63mm (D1C0630450000), 75mm (D1C0750450000), 90mm (D1C0900450000), 110mm (D1C1100450000), 125mm (D1C1250450000). ABN welding reducer: 25x20mm (D1R0250200000), 32x20mm (D1R0320200000), 32x25mm (D1R0320250000), 40x25mm (D1R0400250000), 40x32mm (D1R0400320000), 50x32mm (D1R0500320000), 50x40mm (D1R0500400000), 63x25mm (D1R0630250000), 63x32mm (D1R0630320000), 63x40mm (D1R0630400000), 63x50mm (D1R0630500000), 75x32mm (D1R0750320000), 75x40mm (D1R0750400000), 75x50mm (D1R0750500000), 75x63mm (D1R0750630000), 90x63mm (D1R0900630000), 90x75mm (D1R0900750000), 110x63mm (D1R1100630000), 110x75mm (D1R1100750000), 110x90mm (D1R1100900000), 125x110mm (D1R1251100000). ABN end cap: 20mm (D1TA020000000), 25mm (D1TA025000000), 32mm (D1TA032000000), 40mm (D1TA040000000), 50mm (D1TA050000000), 63mm (D1TA063000000), 75mm (D1TA075000000), 90mm (D1TA090000000), 110mm (D1TA110000000), 125mm (D1TA125000000). ABN cross-over section: 20mm (D1S0200200000), 25mm (D1S0250200000), 32mm (D1S0320200000). ABN stub flange adaptor: 40mm (D1P0400000000), 50mm (D1P0500000000), 63mm (D1P0630000000), 75mm (D1P0750000000), 90mm (D1P0900000000), 110mm (D1P1100000000), 125mm (D1P1250000000). ABN plastic backing ring: 40mm (D1BPPA0400320), 50mm (D1BPPA0500400), 63mm (D1BPPA0630500), 75mm (D1BPPA0750650), 90mm (D1BPPA0900800), 110mm (D1BPPA1101000), 125mm (D1BPPA1401250). ABN Back plate elbow 90°: 20mmx0.5" (D2CP020012000), 25mmx0.5" (D2CP025012000). ABN elbow 90° with female thread: 20mmx0.5" (D2CRH02001290), 25mmx0.5" (D2CRH02501290), 25mmx0.75" (D2CRH02503490), 32mmx0.75" (D2CRH03203490). ABN 32mm x 1'' elbow 90° with hexagonal female thread: 32mmx1" (D2CRH03200190). ABN elbow 90° with male thread: 20mmx0.5" (D2CRM02001290), 20mmx0.75" (D2CRM02003490), 25mmx0.75" (D2CRM02503490), 32mmx0.75" (D2CRM03203490). ABN 32mm x 1'' elbow 90° with hexagonal male thread: 32mmx1" (D2CRM03200190). ABN tee 90° with female thread: 20mmx0.5" (D2TRH02001200), 25mmx0.5" (D2TRH02501200), 25mmx0.75" (D2TRH02503400), 32mmx0.75" (D2TRH03203400). ABN 32mm x 1'' tee 90° with hexagonal female thread: 32mmx1" (D2TRHTE032001). ABN adaptor with female thread: 20mmx0.5" (D2ERH02001200), 25mmx0.5" (D2ERH02501200), 25mmx0.75" (D2ERH02503400), 32mmx0.75" (D2ERH03203400). ABN adaptor with hexagonal female thread: 32mmx1" (D2ERHTE032001), 40mmx1.25" (D2ERHTE040114), 50mmx1.5" (D2ERHTE050112), 63mmx2" (D2ERHTE063002), 75mmx2.5" (D2ERHTE075212), 90mmx3" (D2ERHTE090003), 110mmx4" (D2ERHTE110004). ABN adaptor with male thread: 20mmx0.5" (D2ERM02001200), 20mmx0.75" (D2ERM02003400), 25mmx0.5" (D2ERM02501200), 25mmx0.75" (D2ERM02503400), 32mmx0.75" (D2ERM03203400). ABN adaptor with hexagonal male thread: 32mmx1" (D2ERMTE032001), 40mmx1.25" (D2ERMTE040114), 50mmx1.5" (D2ERMTE050112), 63mmx2" (D2ERMTE063002), 75mmx2.5" (D2ERMTE075212), 90mmx3" (D2ERMTE090003), 110mmx4" (D2ERMTE110004). ABN electrofusion coupling: 20mm (D4ME020000000), 25mm (D4ME025000000), 32mm (D4ME032000000), 40mm (D4ME040000000), 50mm (D4ME050000000), 63mm (D4ME063000000), 75mm (D4ME075000000), 90mm (D4ME090000000), 110mm (D4ME110000000), 125mm (D4ME125000000), 160mm (D4ME160000000), 200mm (D4ME200000000). ABN weld in saddle: 50x20mm (D5IDM20050000), 63x20mm (D5IDM20063000), 75x20mm (D5IDM20075000), 90x20mm (D5IDM20090000), 110x20mm (D5IDM20110000), 125x20mm (D5IDM20125000), 160x20mm (D5IDM20160000), 200x20mm (D5IDM20200000), 50x25mm (D5IDM25050000), 63x25mm (D5IDM25063000), 75x25mm (D5IDM25075000), 90x25mm (D5IDM25090000), 110x25mm (D5IDM25110000), 125x25mm (D5IDM25125000), 160x25mm (D5IDM25160000), 200x25mm (D5IDM25200000), 50x32mm (D5IDM32050000), 63x32mm (D5IDM32063000), 75x32mm (D5IDM32075000), 90x32mm (D5IDM32090000), 110x32mm (D5IDM32110000), 125x32mm (D5IDM32125000), 160x32mm (D5IDM32160000), 200x32mm (D5IDM32200000), 90x40mm (D5IDM40900000), 110x40mm (D5IDM40110000), 125x40mm (D5IDM40125000), 160x40mm (D5IDM40160000), 200x40mm (D5IDM40200000), 90x50mm (D5IDM50900000), 110x50mm (D5IDM50110000), 125x50mm (D5IDM50125000), 160x50mm (D5IDM50160000), 200x50mm (D5IDM50200000), 110x63mm (D5IDM63110000), 125x63mm (D5IDM63125000), 160x63mm (D5IDM63160000), 200x63mm (D5IDM63200000). ABN 160mm series 5 90° Butt - weld elbow: 160mm (D5CIS51600900). ABN 160mm series 5 45° Butt - weld elbow: 160mm (D5CIS51600450). ABN 160mm series 5 90° Butt - weld tee: 160mm (D5TIS51600000). ABN 160x110mm series 5 Butt - weld reducer: 160x110mm (D5RIS51601100). ABN 160mm series 5 Butt - weld stub flange adaptor: 160mm (D5PIS51600000). ABN 160mm series 5 Butt - weld end cap: 160mm (D5TAIS5160000). ABN series 5 90° elbow: 160mm (D5CS516009000), 200mm (D5CS520009000). ABN series 5 45° elbow: 160mm (D5CS516004500), 200mm (D5CS520004500). ABN series 5 90° equal tee: 160mm (D5TS516000000), 200mm (D5TS520000000). ABN series 5 90° unequal tee: 160x110mm (D5TRS51601100), 200x110mm (D5TRS52001100), 200x125mm (D5TRS52001250), 200x160mm (D5TRS52001600). ABN series 5 end cap: 160mm (D5TAS16000000), 200mm (D5TAS52000000). ABN series 5 segmented reducer: 160x110mm (D5RS516011000), 160x125mm (D5RS516012500), 200x110mm (D5RS520011000), 200x125mm (D5RS520012500), 200x160mm (D5RS52001600). ABN series 5 stub flange adaptor: 160mm (D5PS516000000), 200mm (D5PS520000000). ABN Series 5 socketed elecpipe pipe: 75mmx5.8m (DE0CTF5007500), 90mmx5.8m (DE0CTF5009000), 110mmx5.8m (DE0CTF5011000), 125mmx5.8m (DE0CTF5012500), 75mmx0.5m (DE1CAME507505), 90mmx0.5m (DE1CAME509005), 110mmx0.5m (DE1CAME511005), 125mmx0.5m (DE1CAME512505), 75mmx1m (DE1CAME507500), 90mmx1m (DE1CAME509000), 110mmx1m (DE1CAME511000), 125mmx1m (DE1CAME512500). ABN Series 5 elecpipe pipe 0.5m: 75mmx0.5m (DE1CAEE507505), 90mmx0.5m (DE1CAEE509005), 110mmx0.5m (DE1CAEE511005), 125mmx0.5m (DE1CAEE512505), 75mmx1m (DE1CAEE507500), 90mmx1m (DE1CAEE509000), 110mmx1m (DE1CAEE511000), 125mmx1m (DE1CAEE512500). ABN elecpipe socket connector: 75mm (DE1COS0750000), 90mm (DE1COS0900000), 110mm (DE1COS1100000), 125mm (DE1COS1250000). ABN elecpipe double spigot connector: 75mm (DE1MA07500000), 90mm (DE1MA09000000), 110mm (DE1MA11000000), 125mm (DE1MA12500000). ABN elecpipe socket to socket fusion: 75mm (DE1MS07500000), 90mm (DE1MS09000000), 110mm (DE1MS11000000), 125mm (DE1MS12500000). ABN elecpipe socket coupling: 75mm (DE1M075000000), 90mm (DE1M090000000), 110mm (DE1M110000000), 125mm (DE1M125000000). ABN elecpipe reducer: 90x75mm (DE1RMH0900750), 110x75mm (DE1RMH1100750), 110x90mm (DE1RMH1100900), 125x110mm (DE1RMH1250110). ABN elecpipe to socket fusion reducer: 75x32mm (DE1RMSH075032), 75x40mm (DE1RMSH075040), 75x50mm (DE1RMSH075050), 75x63mm (DE1RMSH075063), 90x63mm (DE1RMSH090063), 90x75mm (DE1RMSH090075), 110x63mm (DE1RMSH110063), 110x75mm (DE1RMSH110075), 110x90mm (DE1RMSH110090), 125x110mm (DE1RMSH125110). ABN 90° elecpipe elbow: 75mm (DE1C075090000), 90mm (DE1C090090000), 110mm (DE1C110090000), 125mm (DE1C125090000). ABN 45° elecpipe elbow: 75mm (DE1C075045000), 90mm (DE1C090045000), 110mm (DE1C110045000), 125mm (DE1C125045000). ABN 90° elecpipe to socket fusion elbow: 75mm (DE1CS07509000), 90mm (DE1CS09009000), 110mm (DE1CS11009000), 125mm (DE1CS12509000). ABN 45° elecpipe to socket fusion elbow: 75mm (DE1CS07504500), 90mm (DE1CS09004500), 110mm (DE1CS11045000), 125mm (DE1CS12504500). ABN elecpipe 90° equal tee: 75mm (DE1T075000000), 90mm (DE1T090000000), 110mm (DE1T110000000), 125mm (DE1T125000000). ABN elecpipe-socket-elecpipe 90° equal tee: 75mm (DE1TS07500000), 90mm (DE1TS09000000), 110mm (DE1TS11000000), 125mm (DE1TS12500000). ABN elecpipe-socket-socket 90° equal tee: 75mm (DE1TSS0750000), 90mm (DE1TSS0900000), 110mm (DE1TSS1100000), 125mm (DE1TSS1250000). ABN elecpipe 90° unequal tee: 90x75x90mm (D1TR090075090), 110x75x110mm (DE1TR11075110), 110x90x110mm (DE1TR11090110). ABN elecpipe-socket-elecpipe 90° unequal tee: 75x50x75mm (DE1TRS0755007), 75x63x75mm (DE1TRS0756307), 90x63x90mm (DE1TRS0906309), 90x75x90mm (DE1TRS0907509), 110x63x110mm (DE1TRS1106311), 110x75x110mm (DE1TRS1107511), 110x90x110mm (DE1TRS1109011). ABN elecpipe PN16 full face flange: 75mm (DE1BP07500000), 90mm (DE1BP09000000), 110mm (DE1BP11000000), 125mm (DE1BP12500000). ABN elecpipe end cap: 75mm (DE1TA07500000), 90mm (DE1TA09000000), 110mm (DE1TA11000000), 125mm (DE1TA12500000). ABN elecpipe adaptor with hexagonal female thread: 75mmx2.5" (DE2ERHTE07521), 90mmx3" (DE2ERHTE09003), 110mmx4" (DE2ERHTE11004). ABN elecpipe adaptor with hexagonal male thread: 75mmx2.5" (DE2ERMTE07521), 90mmx3" (DE2ERMTE09003), 110mmx4" (DE2ERMTE11004).
Manufacturer:: ABN

Company Name
ABN
Address
Park Empresarial Medina On Autovia A-6 KM 152
Postcode
Spain

View All Listings by this Company

WRAS Approval Number: #1907302

‘Prineto’ sliding sleeve system consisting of brass fittings for use with ‘Prineto’ PE-x pipe (black). The connection is achieved by a sleeve over the pipe and fitting with the use of a sliding tool. Maximum working pressure 10.0 Bar. Maximum working temperature 90°C.

Section:: 1100 Fittings and Pipe - Compatible Systems
Section Subtitle:: Unless specified in the individual approval, the products within this section are not suitable for below ground use
WRAS Approval Number:: 1907302
Expiry date:: 31/07/2024
Size:: 16mm, 20mm, 25mm, 32mm.
Marking:: Fittings: IVT , dimensions , indication of material and supplier and certification marks (DVGW, KK) and batch numbers on body. Sleeve: IVT, Size, certification mark (DVGW), Supplier indicator and batch numbers on body. Pipes: PRINETO PE-X, dimensions and certification marks on pipe.
Installation Requirements:: R001
Model:: PRINETO Wall angle: Wall angle: 20-Rp 3/4 - (article no. 878 650 090), Wall angle: 25-Rp 3/4 - (article no. 878 650 100), PRINETO Ceiling Angle: Ceiling angle: 25-Rp 3/4 - (article no. 878 650 180), Ceiling angle: 32-Rp 3/4 - (article no. 878 650 240), PRINETO Angle 90°: Angle: 16 - (article no. 878 674 110), Angle: 20 - (article no. 878 674 220), Angle: 25 - (article no. 878 674 330), Angle: 32 - (article no. 878 674 440), PRINETO Angle 45°: Angle 45°: 16 - (article no. 878 675 110), Angle 45°: 20 - (article no. 878 675 220), Angle 45°: 25 - (article no. 878 675 330), Angle 45°: 32 - (article no. 878 675 440), PRINETO Angle transition with external thread: Angle transition: 16-R 3/4 - (article no. 878 674 160), Angle transition: 20-R 3/4 - (article no. 878 674 260), Angle transition: 25-R 3/4 - (article no. 878 674 360), Angle transition: 32-R 3/4 - (article no. 878 674 460), PRINETO Angle transition with internal thread: Angle transition: 16-Rp 3/4 - (article no. 878 672 160), Angle transition: 20-Rp 3/4 - (article no. 878 672 260), Angle transition: 25-Rp 3/4 - (article no. 878 672 360), Angle transition: 25-Rp 1 - (article no. 878 672 370), Angle transition: 32-Rp 3/4 - (article no. 878 672 460), Angle transition: 32-Rp 1 - (article no. 878 672 470), PRINETO Tee with inner threaded outlet: Tee: 20-Rp 3/4-20 - (article no. 878 662 262), Tee: 25-Rp 3/4-25 - (article no. 878 662 363), Tee: 32-Rp 3/4-32 - (article no. 878 662 464), PRINETO Tee: Tee: 16 - (article no. 878 660 111), Tee: 16-20-16 - (article no. 878 660 121), Tee: 16-25-16 - (article no. 878 660 131), Tee: 20-14-20 - (article no. 878 660 202), Tee: 20-16-16 - (article no. 878 660 211), Tee: 20-16-20 - (article no. 878 660 212), Tee: 20-20-16 - (article no. 878 660 221), Tee: 20 - (article no. 878 660 222), Tee: 20-25-20 - (article no. 878 660 232), Tee: 25-16-16 - (article no. 878 660 311), Tee: 25-16-20 - (article no. 878 660 312), Tee: 25-16-25 - (article no. 878 660 313), Tee: 25-20-16 - (article no. 878 660 321), Tee: 25-20-20 - (article no. 878 660 322), Tee: 25-20-25 - (article no. 878 660 323), Tee: 25-25-16 - (article no. 878 660 331), Tee: 25-25-20 - (article no. 878 660 332), Tee: 25 - (article no. 878 660 333), Tee: 25-32-25 - (article no. 878 660 343), Tee: 32-16-32 - (article no. 878 660 414), Tee: 32-20-25 - (article no. 878 660 423), Tee: 32-20-32 - (article no. 878 660 424), Tee: 32-25-20 - (article no. 878 660 432), Tee: 32-25-25 - (article no. 878 660 433), Tee: 32-25-32 - (article no. 878 660 434), Tee: 32 - (article no. 878 660 444), PRINETO Coupler: Coupler: 16 - (article no. 878 640 110), Coupler: 20 - (article no. 878 640 220), Coupler: 25 - (article no. 878 640 330), Coupler: 32 - (article no. 878 640 440), PRINETO Reducing coupler: Reducing coupler: 20-16 - (article no. 878 640 210), Reducing coupler: 25-16 - (article no. 878 640 310), Reducing coupler: 25-20 - (article no. 878 640 320), Reducing coupler: 32-25 - (article no. 878 640 430), PRINETO Transition with external thread: Transition: 16-R 3/4 - (article no. 878 641 160), Transition: 20-R 3/4 - (article no. 878 641 260), Transition: 25-R 3/4 - (article no. 878 641 360), Transition: 32-R 3/4 - (article no. 878 641 460), PRINETO Transition with internal thread: Transition: 16-Rp 3/4 - (article no. 878 642 160), Transition: 20-Rp 3/4 - (article no. 878 642 260), Transition: 25-Rp 3/4 - (article no. 878 642 360), Transition: 32-Rp 3/4 - (article no. 878 642 460), PRINETO Transition for radial pressing: Press-type: 16-P 15 - (article no. 878 643 190), Press-type: 20-P 18 - (article no. 878 643 290), Press-type: 20-P 22 - (article no. 878 643 294), Press-type: 25-P 22 - (article no. 878 643 390), Press-type: 32-P 28 - (article no. 878 643 490), PRINETO Blind plug: Blind plug: 16 - (article no. 878 343 150), Blind plug: 20 - (article no. 878 343 160), Blind plug: 25 - (article no. 878 643 170), Blind plug: 32 - (article no. 878 643 180), PRINETO PE-X plumbing pipe: Plumbing pipe 16 bundle: 16 - (article no. 878 510 100), Plumbing pipe 16, 4 m rod: 16 - (article no. 878 610 100), Plumbing pipe 20 bundle: 20 - (article no. 878 510 200), Plumbing pipe 20, 4 m rod: 20 - (article no. 878 610 200), Plumbing pipe 25 bundle: 25 - (article no. 878 510 300), Plumbing pipe 25, 4 m rod: 25 - (article no. 878 610 300), Plumbing pipe 32 bundle: 32 - (article no. 878 510 400), Plumbing pipe 32, 4 m rod: 32 - (article no. 878 610 400).
Factor:: IVT Installations – und Verbindungstechnik GmbH & Co. KG

Company Name
IVT Installations – und Verbindungstechnik GmbH & Co. KG
Address
Gewerbering Nord 5 91189 Rohr Germany
Phone
+49/9876/9786-0
General Email
info@ivt-rohr.de

View All Listings by this Company

WRAS Approval Number: #1909066

Yonggao ‘ERA 03’ range of PP compression fittings for use with ‘ERA 04’ PE 100 pipe. Maximum working pressure 16.0bar (DN20) & 10.0bar (DN75). For above and below ground use. Cold water use only.

Section:: 1100 Fittings and Pipe - Compatible Systems
Section Subtitle:: Unless specified in the individual approval, the products within this section are not suitable for below ground use
WRAS Approval Number:: 1909066
Expiry date:: 30/09/2024
Size:: DN20 and DN75 sizes only.
Marking:: ERA® (registered trademark of Yonggao Co. Ltd.) & WRAS on the fitting nut. ERA® (registered trademark of Yonggao Co. Ltd.), PE100, SDR11, WRAS, ISO4427-2 and date of manufacture (yyy/mm/dd) on pipe.
Installation Requirements:: R001
Model:: ‘ERA 03’ fittings: 90° elbow, End cap, Female thread elbow with bracket, Female thread elbow, Female thread socket, Female thread tee, Male thread elbow, Male thread socket, Male thread tee, Reducing socket, Reducing tee, Socket, Tee. ‘ERA 04’ pipe.
Manufacturer:: ERA Piping (Zhejiang) Co.,Ltd.

Company Name
ERA Piping (Zhejiang) Co.,Ltd.
Address
No.1118 Huangjiao Road, Huangyan Economic Development Zone, Taizhou, Zhejiang
Country
China

View All Listings by this Company

WRAS Approval Number: #1907062

DMFit range of black and grey plastic pushfit fittings with EPDM ‘O’-rings for use with DM LLDPE pipes. Supplied with black pipe inserts. LLDPE pipes are available in black, natural (appearance is white), white, red and blue colours. Operating parameters: Black metric fittings with LLDPE pipes 4, 5, 6, 8, 10, 12 & 15mm – 12.0 bar @ Cold Water Use Only. Black metric fittings with LLDPE pipes 10, 12 & 15mm – 7.0 bar @ 65°C. Grey imperial fittings with LLDPE pipes 5/32”, 3/16”, ¼”, 5/16”, ⅜” & ½” – 12.0 bar @ Cold Water Use Only. Grey imperial fittings with LLDPE pipes ½” – 7.0 bar @ 65°C.

Section:: 1100 Fittings and Pipe - Compatible Systems
Section Subtitle:: Unless specified in the individual approval, the products within this section are not suitable for below ground use
WRAS Approval Number:: 1907062
Expiry date:: 31/07/2024
Note:: R008 applies to the natural (white), white, red and blue pipes only. Black metric fittings sizes 8, 10, 12 & 15mm must use the supplied pipe inserts. Grey imperial fittings sizes 5/16”, ⅜” & ½” must use the supplied pipe inserts. Black metric fittings sizes 4, 5 & 6mm are only approved for use without pipe inserts. Grey imperial fittings sizes 5/32”, 3/16” & ¼” are only approved for use without pipe inserts.
Size:: 4 - 15mm push fit, 5/32” - ½” push fit.
Marking:: DM logo and size on fittings. DM Tube, DMT, model number, pipe material (LDPE), size, temperature and pressure, WRAS, NSF and production code on the pipe. (Production code denotes traceability and includes date of manufacture, e.g. 02A8L18, where 02 = extruder No 2, A8 = year 2018; where A = 1, B = 2 etc., L = month - December and 18 = day).
Installation Requirements:: R001 R008
Model:: Metric: AMC1004M: 10mm tube x 1/4"BSPT AMC1006M: 10mm tube x 3/8"BSPT AMC1007M: 10mm tube x 1/2"BSPT AMC1506M: 15mm tube x 3/8"BSPT AMC1507M: 15mm tube x 1/2"BSPT AEU1010M: 10mm tube x 10mm tube AEU1515M: 15mm tube x 15mm tube AME1004M: 10mm tube x 1/4"BSPT AME1006M: 10mm tube x 3/8"BSPT AME1506M: 15mm tube x 3/8"BSPT AME1507M: 15mm tube x 1/2"BSPT AMCB1004M: 10mm tube x 1/4"BSP(P) AMCB1006M: 10mm tube x 3/8"BSP(P) AMCB1007M: 10mm tube x 1/2"BSP(P) AMCB1507M: 15mm tube x 1/2"BSP(P) AMES1004M: 10mm tube x 1/4"BSPT AMES1006M: 10mm tube x 3/8"BSPT ARD1012M: 10mm tube x 12mm stem ARD1015M: 10mm tube x 15mm stem ARD1518M: 15mm tube x 18mm stem ARD1522M: 15mm tube x 22mm stem AMESB1004M: 10mm tube x 1/4"BSP(P) AMESB1006M: 10mm tube x 3/8"BSP(P) AMESB1007M: 10mm tube x 1/2"BSP(P) ATEU1010M: 10mm tube x 10mm stem ATEU1012M: 10mm tube x 12mm stem ATEU1212M: 12mm tube x 12mm stem ATEU1515M: 15mm tube x 15mm tube SATEU6766B: 15mm tube x 15mm tube (Long) AFA1002M: 10mm x 1/8"BSPT AFA1004M: 10mm x 1/4"BSPT AFA1507M: 15mm x 1/2"BSPT AFAUN081/2VM: 8mm x 1/2-16 UN AFAUN101/2VM: 10mm x 1/2-16 UN AFAUF107/16CM: 10mm x 7/16-20UNF-Cone Type AFAU107/16CM: 10mm x 7/16-24 UNS AFAB1006CM: 10mm tube x 3/8 BSP(P) Cone Type AFAB1007CM: 10mm tube x 1/2"BSP(P) Cone Type AFAB1004FM: 10mm tube x 1/4" BSP(P) Flat Type AFAB1007FM: 10mm tube x 1/2"BSP(P) Flat Type AFAB1507M: 15mm tube x 1/2" BSP(P) AFAUF107/16VM: 10mm x 7/16-20UNF-V Type AMRSB1004M: 10mm tube x 1/4"BSP(P) AMRSB1006M: 10mm tube x 3/8"BSP(P) AMRSB1007M: 10mm tube x 1/2"BSP(P) AMRS1004M: 10mm tube x 1/4"BSPT AMRS1006M: 10mm tube x 3/8"BSPT AMRS1007M: 10mm tube x 1/2"BSPT AMTSB1004M: 10mm tube x 1/4"BSP(P) AMTSB1006M: 10mm tube x 3/8"BSP(P) AMTSB1007M: 10mm tube x 1/2"BSP(P) AOC1006M: 10mm tube x 6mm tube AMTS1004M: 10mm tube x 1/4"BSPT AMTS1006M: 10mm tube x 3/8"BSPT AMTS1007M: 10mm tube x 1/2"BSPT ASAB1004M: 10mm stem x 1/4"BSP(P) ASAB1006M: 10mm stem x 3/8"BSP(P) ASAB1007M: 10mm stem x 1/2"BSP(P) ASAB1506M: 15mm stem x 3/8"BSP(P) ASAB1507M: 15mm stem x 1/2" BSP(P) ASA1004M: 10mm stem x 1/4"BSPT ASA1006M: 10mm stem x 3/8"BSPT ASA1007M: 10mm stem x 1/2"BSPT ACR1010M: 10mm tube ATU101010M: 10mm tube ATU151010M: 15mm run x 10mm run x 10mm branch ATU151510M: 15mm run x 15mm run x 10mm branch ATU151515M: 15mm tube AUB1010M: 10mm tube AUB1515M: 15mm tube AUC1010M: 10mm tube x 10mm tube AUC1510M: 15mm tube x 10mm tube AUC1515M: 15mm tube x 15mm tube AUC15M07: 15mm tube x 1/2" tube ATWD1010M: 10mm in & out ATWD1515M: 15mm in & out ATES10M: 10mm tube ATES15M: 15mm tube APL10M: 10mm plug APL15M: 15mm plug ATBC1010M: 10mm stem x 10mm barb ATEB1010M: 10mm stem x 10mm barb AEL1008M: 8mm stem - 10mm tube AEL1510M: 10mm stem - 15mm tube AEL1512M: 12mm stem - 15mm tube AEL15M07: 1/2" stem x 15mm tube ABU1010M: 10mm tube x 10mm tube ASEU1507M: 15mm tube x 1/2"BSP(P) ASUC1507M: 15mm tube x 1/2"BSP(P) ABBC 1510M: 15mm tube x 10mm barb ABBC1610M: 16mm tube x 10mm barb ABBC15M09: 15mm tube x 9mm barb ABBC15M10: 15mm tube x 10mm barb ABBC15M13: 15mm tube x 13mm barb ATC15M: 15mm tube AEFCB1507M: 15mm tube x 1/2"BSP(P) ASFCB1507M: 15mm tube x 1/2"BSP(P) ASFCB1509M: 15mm tube x 3/4"BSP(P) ADA1509M: 15mm x 3/4" NPSH ATS 10M: 10mm x 7mm ATS15M: 15mm x 11.4mm ATS16M: 16mm x 12mm DPE 10M: 10MMX150MTR LLDPE TUBE DPE 15M: 15MMX70MTR LLDPE TUBE AMC0402M: 4mm tube x 1/8"BSPT AMC0404M: 4mm tube x 1/4"BSPT AMC0502M: 5mm tube x 1/8"BSPT AMC0504M: 5mm tube x 1/4"BSPT AMC0602M: 6mm tube x 1/8"BSPT AMC0604M: 6mm tube x 1/4"BSPT AMC0606M: 6mm tube x 3/8"BSPT AMC0607M: 6mm tube x 1/2"BSPT AMC0802M: 8mm tube x 1/8"BSPT AMC0804M: 8mm tube x 1/4"BSPT AMC0806M: 8mm tube x 3/8"BSPT AMC1206M: 12mm tube x 3/8"BSPT AMC1207M: 12mm tube x 1/2"BSPT AEU0404M: 4mm tube x 4mm tube AEU0505M: 5mm tube x 5mm tube AEU0606M: 6mm tube x 6mm tube AEU0804M: 8mm tube x 4mm tube AEU0805M: 8mm tube x 5mm tube AEU0806M: 8mm tube x 6mm tube AEU0808M: 8mm tube x 8mm tube AEU1206M: 12mm tube x 6mm tube AEU1208M: 12mm tube x 8mm tube AEU1210M: 12mm tube x 10mm tube AEU1212M: 12mm tube x 12mm tube AME0602M: 6mm x 1/8"BSPT AME0604M: 6mm tube x 1/4"BSPT AME0606M: 6mm tube x 3/8"BSPT AME0804M: 8mm tube x 1/4"BSPT AME0806M: 8mm tube x 3/8"BSPT AME1206M: 12mm tube x 3/8"BSPT AME1207M: 12mm tube x 1/2"BSPT AMCB0402M: 4mm tube x 1/8"BSP(P) AMCB0404M: 4mm tube x 1/4"BSP(P) AMCB0502M: 5mm tube x 1/8"BSP(P) AMCB0504M: 5mm tube x 1/4"BSP(P) AMCB0602M: 6mm tube x 1/8"BSP(P) AMCB0604M: 6mm tube x 1/4"BSP(P) AMCB0802M: 8mm tube x 1/8"BSP(P) AMCB0804M: 8mm tube x 1/4"BSP(P) AMCB0806M: 8mm tube x 3/8"BSP(P) AMCB0807M: 8mm tube x 1/2"BSP(P) AMCB1206M: 12mm tube x 3/8"BSP(P) AMCB1207M: 12mm tube x 1/2"BSP(P) AMES0402M: 4mm tube x 1/8"BSPT AMES0404M: 4mm tube x 1/4"BSPT AMES0502M: 5mm tube x 1/8"BSPT AMES0602M: 6mm tube x 1/8"BSPT AMES0604M: 6mm tube x 1/4"BSPT AMES0802M: 8mm tube x 1/8"BSPT AMES0804M: 8mm tube x 1/4"BSPT AMES0806M: 8mm tube x 3/8"BSPT AMES1206M: 12mm tube x 3/8"BSPT AMES1207M: 12mm tube x 1/2"BSPT ARD0405M: 4mm tube x 5mm stem ARD0406M: 4mm tube x 6mm stem ARD0408M: 4mm tube x 8mm stem ARD0506M: 5mm tube x 6mm stem ARD0508M: 5mm tube x 8mm stem ARD0608M: 6mm tube x 8mm stem ARD0610M: 6mm tube x 10mm stem ARD0810M: 8mm tube x 10mm stem ARD0812M: 8mm tube x 12mm stem ARD1215M: 12mm tube x 15mm stem AMESB0402M: 4mm tube x 1/8"BSP(P) AMESB0404M: 4mm tube x 1/4"BSP(P) AMESB0502M: 5mm tube x 1/8"BSP(P) AMESB0504M: 5mm tube x 1/4"BSP(P) AMESB0602M: 6mm tube x 1/8"BSP(P) AMESB0604M: 6mm tube x 1/4"BSP(P) AMESB0802M: 8mm tube x 1/8"BSP(P) AMESB0804M: 8mm tube x 1/4"BSP(P) AMESB0806M: 8mm tube x 3/8"BSP(P) AMESB1206M: 12mm tube x 3/8"BSP(P) AMESB1207M: 12mm tube x 1/2"BSP(P) ATEU0404M: 4mm tube x 4mm stem ATEU0410M: 4mm tube x 10mm stem ATEU0505M: 5mm tube x 5mm stem ATEU0606M: 6mm tube x 6mm stem ATEU0610M: 6mm tube x 10mm stem AFA0602M: 6mm x 1/8"BSPT AFA0604M: 6mm x 1/4"BSPT AFA0802M: 8mm x 1/8"BSPT AFA0804M: 8mm x 1/4"BSPT AFA1607M: 16mm x 1/2"BSPT AFAUN081/2VM: 8mm x 1/2-16UN AFAUN121/2VM: 12mm x 1/2-16 UN AFAUF067/16CM: 6mm x 7/16-20UNF- Cone Type AFAUF087/16CM: 8mm x 7/16-20UNF-Cone Type AFAU067/16CM: 6mm x 7/16-24 UNS AFAU087/16CM: 8mm x 7/16-24 UNS AFAB0606CM: 6mm tube x 3/8 BSP(P) Cone Type AFAB0607CM: 6mm tube x 1/2"BSP(P) Cone Type AFAB0806CM: 8mm tube x 3/8 BSP(P) Cone Type AFAB0807CM: 8mm tube x 1/2"BSP(P) Cone Type AFAB1206CM: 12mm tube x 3/8" BSP(P) Cone Type AFAB0804FM: 8mm tube x 1/4" BSP(P) Flat Type AFAB 1206FM: 12mm tube x 3/8"BSP(P) Flat Type AFAB1207FM: 12mm tube x 1/2"BSP(P) Flat Type AFAUF067/16VM: 6mm x 7/16-20UNF-V Type AFAUF087/16VM: 8mm x 7/16-20UNF-V Type AMRSB0402M: 4mm tube x 1/8"BSP(P) AMRSB0404M: 4mm tube x 1/4"BSP(P) AMRSB0502M: 5mm tube x 1/8"BSP(P) AMRSB0504M: 5mm tube x 1/4"BSP(P) AMRSB0602M: 6mm tube x 1/8"BSP(P) AMRSB0604M: 6mm tube x 1/4"BSP(P) AMRSB0802M: 8mm tube x 1/8"BSP(P) AMRSB0804M: 8mm tube x 1/4"BSP(P) AMRSB0806M: 8mm tube x 3/8"BSP(P) AMRSB1206M: 12mm tube x 3/8"BSP(P) AMRSB1207M: 12mm tube x 1/2"BSP(P) AMRS0402M: 4mm tube x 1/8"BSPT AMRS0404M: 4mm tube x 1/4"BSPT AMRS0502M: 5mm tube x 1/8"BSPT AMRS0504M: 5mm tube x 1/4"BSPT AMRS0602M: 6mm tube x 1/8"BSPT AMRS0604M: 6mm tube x 1/4"BSPT AMRS0802M: 8mm tube x 1/8"BSPT AMRS0804M: 8mm tube x 1/4"BSPT AMRS0806M: 8mm tube x 3/8"BSPT AMRS1206M: 12mm tube x 3/8"BSPT AMRS1207M: 12mm tube x 1/2"BSPT AMTSB0402M: 4mm tube x 1/8"BSP(P) AMTSB0404M: 4mm tube x 1/4"BSP(P) AMTSB0502M: 5mm tube x 1/8"BSP(P) AMTSB0504M: 5mm tube x 1/4"BSP(P) AMTSB0602M: 6mm tube x 1/8"BSP(P) AMTSB0604M: 6mm tube x 1/4"BSP(P) AMTSB0802M: 8mm tube x 1/8"BSP(P) AMTSB0804M: 8mm tube x 1/4"BSP(P) AMTSB0806M: 8mm tube x 3/8"BSP(P) AMTSB1206M: 12mm tube x 3/8"BSP(P) AMTSB1207M: 12mm tube x 1/2"BSP(P) AOC1208M: 12mm tube x 8mm tube AMTS0402M: 4mm tube x 1/8"BSPT AMTS0404M: 4mm tube x 1/4"BSPT AMTS0502M: 5mm tube x 1/8"BSPT AMTS0504M: 5mm tube x 1/4"BSPT AMTS0602M: 6mm tube x 1/8"BSPT AMTS0604M: 6mm tube x 1/4"BSPT AMTS0802M: 8mm tube x 1/8"BSPT AMTS0804M: 8mm tube x 1/4"BSPT AMTS0806M: 8mm tube x 3/8"BSPT AMTS1206M: 12mm tube x 3/8"BSPT AMTS1207M: 12mm tube x 1/2"BSPT ASAB0402M: 4mm stem x 1/8"BSP(P) ASAB0404M: 4mm stem x 1/4"BSP(P) ASAB0502M: 5mm stem x 1/8"BSP(P) ASAB0504M: 5mm stem x 1/4"BSP(P) ASAB0602M: 6mm stem x 1/8"BSP(P) ASAB0604M: 6mm stem x 1/4"BSP(P) ASAB0802M: 8mm stem x 1/8"BSP(P) ASAB0804M: 8mm stem x 1/4"BSP(P) ASAB0806M: 8mm stem x 3/8"BSP(P) ASAB1206M: 12mm stem x 3/8"BSP(P) ASAB1207M: 12mm stem x 1/2"BSP(P) ASA0402M: 4mm stem x 1/8"BSPT ASA0402M: 4mm stem x 1/8" BSPT ASA0404M: 4mm stem x 1/4"BSPT ASA0502M: 5mm stem x 1/8"BSPT ASA0504M: 5mm stem x 1/4"BSPT ASA0602M: 6mm stem x 1/8"BSPT ASA0604M: 6mm stem x 1/4"BSPT ASA0802M: 8mm stem x 1/8"BSPT ASA0804M: 8mm stem x 1/4"BSPT ASA0806M: 8mm stem x 3/8"BSPT ASA1206M: 12mm stem x 3/8"BSPT ASA1207M: 12mm stem x 1/2"BSPT ACR0404M: 4mm tube ACR0606M: 6mm tube ACR0808M: 8mm tube ACR1212M: 12mm tube ATHWD1006M: 10mm tube x 6mm tube ATHWD1210M: 12mm tube x 10mm tube ATU040404M: 4mm tube ATU050505M: 5mm tube ATU060606M: 6mm tube ATU080808M: 8mm tube ATU121212M: 12mm tube AUB0606M: 6mm tube AUB0808M: 8mm tube AUB1212M: 12mm tube AUC0404M: 4mm tube x 4mm tube AUC0505M: 5mm tube x 5mm tube AUC0604M: 6mm tube x 4mm tube AUC0605M: 6mm tube x 5mm tube AUC0606M: 6mm tube x 6mm tube AUC0804M: 8mm tube x 4mm tube AUC0805M: 8mm tube x 5mm tube AUC0806M: 8mm tube x 6mm tube AUC0808M: 8mm tube x 8mm tube AUC1208M: 12mm tube x 8mm tube AUC1210M: 12mm tube x 10mm tube AUC1212M: 12mm tube x 12mm tube ATWD0404M: 4mm in & out ATWD0606M: 6mm in & out ATWD0808M: 8mm in & out ATWD1212M: 12mm in & out ATES06M: 6mm tube ATES08M: 8mm tube ATES12M: 12mm tube APL04M: 4mm plug APL05M: 5mm plug APL06M: 6mm plug APL08M: 8mm plug APL12M: 12mm plug ATBC0604M: 6mm stem x 4mm barb ATBC0606M: 6mm stem x 6mm barb ATBC0806M: 8mm stem x 6mm barb ATBC0808M: 8mm stem x 8mm barb ATBC1210M: 12mm stem x 10mm barb AEL1210M: 10mm stem - 12mm tube AEL1610M: 10mm stem - 16mm tube AEL1612M: 12mm stem - 16mm tube ABU0404M: 4mm tube ABU0505M: 5mm tube ABU0606M: 6mm tube ABU0610M: 6mm tube x 10mm tube ABU0808M: 8mm tube ABU1006M: 10mm tube x 6mm tube ABU1212M: 12mm tube ABBC 1210M: 12mm tube x 10mm barb ATS06M: 6mm x 4mm ATS 08M: 8mm x 6mm ATS 12M: 12mm x 9mm DPE 04M: 4MMX500MTR LLDPE TUBE DPE 05M: 5MMX400MTR LLDPE TUBE DPE 06M: 6MMX300MTR LLDPE TUBE DPE 08M: 8MMX200MTR LLDPE TUBE DPE 12M: 12MMX100MTR LLDPE TUBE Models added July 2020: ABBC1507M: 15mm X 1/2" ABBC1607M: 15mm X 1/2" AFAB1008CM: 10mm tube x 5/8 BSP(P) Cone Type AFAB0808FM: 8mm tube x 5/8 BSP(P) Flat Type AFAB0809FM: 8mm tube x 3/4" BSP(P) Flat Type AFAB1008FM: 10mm tube x 5/8 BSP(P) Flat Type AFAB1009FM: 10mm tube x 3/4" BSP(P) Flat Type AFAB1208FM: 12mm tube x 5/8 BSP(P) Flat Type AFAUF105/8VM: 10mm x 5/8-18UNF-V Type AMC1002M: 10mm tube x 1/8"BSPT AMCB1509M: 15mm tube x 3/4"BSP(P) ASEU1509M: 15mm tube x 3/4"BSP(P) ASUC1509M: 15mm tube x 3/4"BSP(P)
Imperial: AMC0102: 5/32"tube x 1/8"NPTF AMC0104: 5/32"tube x 1/4"NPTF AMC0302: 3/16"tube x 1/8"NPTF AMC0402: 1/4"tube x 1/8"NPTF AMC0404: 1/4"tube x 1/4"NPTF AMC0406: 1/4"tube x 3/8"NPTF AMC0407: 1/4"tube x 1/2"NPTF AMC0502: 5/16"tube x 1/8"NPTF AMC0504: 5/16"tube x 1/4"NPTF AMC0506: 5/16"tube x 3/8"NPTF AMC0602: 3/8"tube x 1/8"NPTF AMC0604: 3/8"tube x 1/4"NPTF AMC0606: 3/8"tube x3/8"NPTF AMC0607: 3/8"tube x 1/2"NPTF AMC0706: 1/2"tube x 3/8"NPTF AMC0707: 1/2"tube x 1/2"NPTF AEU0101: 5/32"tube x 5/32"tube AEU0303: 3/16"tube x 3/16"tube AEU0404: 1/4"tube x 1/4"tube AEU0501: 5/16"tube x 5/32"tube AEU0503: 5/16"tube x 3/16"tube AEU0504: 5/16"tube x 1/4"tube AEU0505: 5/16"tube x 5/16"tube AEU0603: 3/8"tube x 3/16"tube AEU0604: 3/8"tube x 1/4"tube AEU0605: 3/8"tube x 5/16"tube AEU0606: 3/8"tube x 3/8"tube AEU0704: 1/2"tube x 1/4"tube AEU0705: 1/2"tube x 5/16"tube AEU0706: 1/2"tube x 3/8"tube AEU0707: 1/2"tube x 1/2"tube AME0302: 3/16"tube x 1/8"NPTF AME0402: 1/4"tube x 1/8"NPTF AME0404: 1/4"tube x 1/4"NPTF AME0406: 1/4"tube x 3/8"NPTF AME0504: 5/16"tube x 1/4"NPTF AME0506: 5/16"tube x 3/8"NPTF AME0604: 3/8"tube x 1/4"NPTF AME0606: 3/8"tube x 3/8"NPTF AME0706: 1/2"tube x 3/8"NPTF AME0707: 1/2"tube x 1/2"NPTF AMCB0102: 5/32"tube x 1/8"BSP(P) AMCB0104: 5/32"tube x 1/4"BSP(P) AMCB0302: 3/16"tube x 1/8"BSP(P) AMCB0304: 3/16"tube x 1/4"BSP(P) AMCB0402: 1/4"tube x 1/8"BSP(P) AMCB0404: 1/4"tube x 1/4"BSP(P) AMCB0502: 5/16"tube x 1/8"BSP(P) AMCB0504: 5/16"tube x 1/4"BSP(P) AMCB0506: 5/16"tube x 3/8"BSP(P) AMCB0602: 3/8"tube x 1/8"BSP(P) AMCB0604: 3/8"tube x 1/4"BSP(P) AMCB0606: 3/8"tube x 3/8"BSP(P) AMCB0607: 3/8"tube x 1/2"BSP(P) AMCB0706: 1/2"tube x 3/8"BSP(P) AMCB0707: 1/2"tube x 1/2"BSP(P) AMCBB0602: 3/8"tube x 1/8" BSP(P) spot face seal AMCBB0604: 3/8"tube x 1/4" BSP(P) spot face seal AMES0102: 5/32"tube x 1/8"NPTF AMES0104: 5/32"tube x 1/4"NPTF AMES0302: 3/16"tube x 1/8"NPTF AMES0402: 1/4"tube x 1/8"NPTF AMES0404: 1/4"tube x 1/4"NPTF AMES0502: 5/16"tube x 1/8"NPTF AMES0504: 5/16"tube x 1/4"NPTF AMES0506: 5/16"tube x 3/8"NPTF AMES0604: 3/8"tube x 1/4"NPTF AMES0606: 3/8"tube x 3/8"NPTF AMES0706: 1/2"tube x 3/8"NPTF AMES0707: 1/2"tube x 1/2"NPTF ARD0104: 5/32"tube x 1/4"stem ARD0305: 3/16"tube x 5/16"stem ARD0306: 3/16"tube x 3/8"stem ARD0405: 1/4"tube x 5/16"stem ARD0406: 1/4"tube x 3/8"stem ARD0506: 5/16"tube x 3/8"stem ARD0507: 5/16"tube x 1/2"stem ARD0607: 3/8"tube x 1/2"stem AMESB0604: 3/8" tube x 1/4" BSP(P) AMESB0606: 3/8" tube x 3/8" BSP(P) AMESB0607: 3/8" tube x 1/2" BSP(P) AMESB0707: 1/2" tube x 1/2" BSP(P) ATEU0101: 5/32"tube x 5/32"stem ATEU0303: 3/16"tube x 3/16"stem ATEU0306: 3/16" tube X 3/8" stem ATEU0404: 1/4"tube x 1/4"stem ATEU0406: 1/4"tube x 3/8"stem ATEU0505: 5/16"tube x 5/16"stem ATEU0506: 5/16"tube x 3/8"stem ATEU0606: 3/8"tube x 3/8"stem ATEU0607: 3/8" tub X 1/2" stem ATEU0707: 1/2"tube x 1/2"stem AFA0402: 1/4"tube x 1/8"NPTF AFA0404: 1/4"tube x 1/4"NPTF AFA0502: 5/16"tube x 1/8"NPTF AFA0504: 5/16"tube x 1/4"NPTF AFA0602: 3/8"tube x 1/8"NPTF AFA0604: 3/8"tube x 1/4"NPTF AFAUN051/2V: 5/16" tube x 1/2-16 UN AFAUN061/2V: 3/8" tube x 1/2-16 UN AFAUN071/2V: 1/2" tube x 1/2-16 UN AFAUF047/16C: 1/4´´ tube x 7/16-20UNF- Cone Type AFAUF057/16C: 5/16´´ tube x 7/16-20UNF- Cone Type AFAUF067/16C: 3/8´´ tube x 7/16-20UNF- Cone Type AFAB0406C: 1/4"tube x 3/8 BSP(P) cone type AFAB0407C: 1/4"tube x 1/2"BSP(P) cone type AFAB0506C: 5/16"tube x 3/8 BSP(P) cone type AFAB0507C: 5/16"tube x 1/2"BSP(P) cone type AFAB0606C: 3/8"tube x 3/8 BSP(P) cone type AFAB0607C: 3/8"tube x 1/2"BSP(P) cone type AFAB0608C: 3/8"tube x 5/8 BSP(P) cone type AFAB0708C: 1/2"tube x 5/8 BSP(P) cone type AFAB0407F: 1/4"Tube X 1/2" BSP(P) flat type AFAB0507F: 5/16" tube x 1/2" BSP(P) flat type AFAB0607F: 3/8"tube x 1/2 BSP(P) flat type AFAB0706F: 1/2"tube x 3/8 BSP(P) flat type AFAB0707F: 1/2"tube x 1/2"BSP(P) flat type AFAUF047/16V: 1/4´´ tube x 7/16-20UNF- V Type AFAUF057/16V: 5/16´´ tube x 7/16-20UNF- V Type AFAUF067/16V: 3/8´´ tube x 7/16-20UNF- V Type AMRSB0604: 3/8" tube x 1/4" BSP(P) AMRSB0606: 3/8" tube x 3/8" BSP(P) AMRSB0706: 1/2" tube x 3/8" BSP(P) AMRSB0707: 1/2" tube x 1/2" BSP(P) AMRS0102: 5/32"tube x 1/8"NPTF AMRS0104: 5/32"tube x 1/4"NPTF AMRS0302: 3/16"tube x 1/8"NPTF AMRS0402: 1/4"tube x 1/8"NPTF AMRS0404: 1/4"tube x 1/4"NPTF AMRS0502: 5/16"tube x 1/8"NPTF AMRS0504: 5/16"tube x 1/4"NPTF AMRS0506: 5/16"tube x 3/8"NPTF AMRS0604: 3/8"tube x 1/4"NPTF AMRS0606: 3/8"tube x 3/8"NPTF AMRS0706: 1/2"tube x 3/8"NPTF AMRS0707: 1/2"tube x 1/2"NPTF AMTSB0604: 3/8" tube x 1/4" BSP(P) AMTSB0606: 3/8" tube x 3/8" BSP(P) AMTSB0706: 1/2" tube x 3/8" BSP(P) AMTSB0707: 1/2" tube x 1/2" BSP(P) AMTSBT0606: 3/8" tube x 3/8" BSPT AMTSBT0706: 1/2" tube x 3/8" BSPT AMTSBT0707: 1/2" tube x 1/2" BSPT AOC0604: 3/8" tube x 1/4" tube AOC0705: 1/2" tube x 5/16" tube AMTS0102: 5/32"tube x 1/8"NPTF AMTS0104: 5/32"tube x 1/4"NPTF AMTS0302: 3/16"tube x 1/8"NPTF AMTS0402: 1/4"tube x 1/8"NPTF AMTS0404: 1/4"tube x 1/4"NPTF AMTS0502: 5/16"tube x 1/8"NPTF AMTS0504: 5/16"tube x 1/4"NPTF AMTS0506: 5/16"tube x 3/8"NPTF AMTS0604: 3/8"tube x 1/4"NPTF AMTS0606: 3/8"tube x 3/8"NPTF AMTS0706: 1/2"tube x 3/8"NPTF AMTS0707: 1/2"tube x 1/2"NPTF ASAB0604: 3/8"stem x 1/4"BSP(P) ASAB0606: 3/8"stem x 3/8"BSP(P) ASAB0607: 3/8"stem x 1/2"BSP(P) ASAB0707: 1/2"stem x 1/2"BSP(P) ASABT0302: 3/16"stem x 1/8"BSPT(PT) ASABT0504: 5/16"stem x 1/4"BSPT(PT) ASABT0506: 5/16"stem x 3/8"BSPT(PT) ASABT0604: 3/8"stem x 1/4"BSPT(PT) ASABT0606: 3/8"stem x 3/8"BSPT(PT) ASABT0707: 1/2"stem x 1/2"BSPT(PT) ACR0101: 5/32" tube ACR0404: 1/4" tube ACR0505: 5/16" tube ACR0606: 3/8" tube ACR0707: 1/2" tube ATU0101: 5/32" tube ATU0303: 3/16" tube ATU0404: 1/4" tube ATU040405: 1/4" x 5/16" branch ATU0505: 5/16" tube ATU0604: 3/8" run x 1/4" branch ATU0606: 3/8" tube ATU0706: 1/2" run x 3/8" branch ATU0707: 1/2" tube AUB0404: 1/4" tube AUB0505: 5/16" tube AUB0606: 3/8" tube AUB0707: 1/2" tube AUC0101: 5/32"tube x 5/32"tube AUC0303: 3/16"tube x 3/16"tube AUC0401: 1/4"tube x 5/32"tube AUC0403: 1/4"tube x 3/16" tube AUC0404: 1/4"tube x 1/4"tube AUC0501: 5/16"tube x 5/32"tube AUC0503: 5/16"tube x 3/16"tube AUC0504: 5/16"tube x 1/4" tube AUC0505: 5/16"tube x 5/16"tube AUC0601: 3/8"tube x 5/32"Tube AUC0603: 3/8"tube x 3/16"tube AUC0604: 3/8"tube x 1/4"tube AUC0605: 3/8"tube x 5/16"tube AUC0606: 3/8"tube x 3/8"tube AUC067.5: 3/8" X 7.5mm AUC0705: 1/2"tube x 5/16"tube AUC0706: 1/2"tube x 3/8"tube AUC0707: 1/2"tube x 1/2"tube ATWD0101: 5/32" in & out ATWD0404: 1/4" in & out ATWD0505: 5/16" in & out ATWD0605: 3/8" in & 5/16" out ATWD0606: 3/8" in & out ATWD0607: 3/8" in & 1/2" out ATWD0707: 1/2" in & out ATES04: 1/4" tube ATES05: 5/16"tube ATES06: 3/8"tube ATES07: 1/2"tube APL01: 5/32" plug APL03: 3/16" plug APL04: 1/4" plug APL05: 5/16" plug APL06: 3/8" plug APL07: 1/2" plug ATBC0403: 1/4"stem x 3/16"barb ATBC0404: 1/4"stem x 1/4"barb ATBC0405: 1/4"stem x 5/16"barb ATBC0503: 5/16"stem x 3/16"barb ATBC0504: 5/16"stem x 1/4"barb ATBC0505: 5/16"stem x 5/16"barb ATBC0506: 5/16"stem x 3/8"barb ATBC0604: 3/8"stem x 1/4"barb ATBC0605: 3/8'stem x 5/16"barb ATBC0606: 3/8"stem x 3/8"barb ATBC0607: 3/8"stem x 1/2"barb ATBC0706: 1/2"stem x 3/8"barb ATBC0707: 1/2"stem x 1/2"barb ATEB0404: 1/4"stem x 1/4"barb ATEB0405: 1/4"stem x 5/16"barb ATEB0504: 5/16"stem x 1/4"barb ATEB0505: 5/16"stem x 5/16"barb ATEB0604: 3/8"stem x 1/4"barb ATEB0605: 3/8"stem x 5/16"barb ATEB0606: 3/8"stem x 3/8"barb AEL0605: 5/16" stem - 3/8" tube AEL0706: 3/8" stem - 1/2" tube ABU0101: 5/32" tube ABU0303: 3/16" tube ABU0404: 1/4" tube ABU0406: 1/4"tube x 3/8" tube ABU0505: 5/16" tube ABU0604: 3/8"tube x 1/4" tube ABU0606: 3/8" tube ABU0707: 1/2" tube AMCBT0102: 5/32"tube x 1/8"BSPT AMCBT0104: 5/32"tube x 1/4"BSPT AMCBT0302: 3/16"tube x 1/8"BSPT AMCBT0304: 3/16"tube x 1/4"BSPT AMCBT0402: 1/4"tube x 1/8"BSPT AMCBT0404: 1/4"tube x 1/4"BSPT AMCBT0406: 1/4"tube x 3/8"BSPT AMCBT0407: 1/4"tube x 1/2"BSPT AMCBT0502: 5/16"tube x 1/8"BSPT AMCBT0504: 5/16"tube x 1/4"BSPT AMCBT0506: 5/16"tube x 3/8"BSPT AMCBT0602: 3/8"tube x 1/8"BSPT AMCBT0604: 3/8"tube x 1/4"BSPT AMCBT0606: 3/8"tube x 3/8"BSPT AMCBT0607: 3/8"tube x 1/2"BSPT AMCBT0706: 1/2"tube x 3/8"BSPT AMCBT0707: 1/2"tube x 1/2"BSPT AMCF0505: 5/16" tube x 1/2"-20 UNF AMCF0604: 3/8" tube x 7/16"-20 UNF AMCW0507: 5/16" tube x 1/2"-24 BSW AMCW0607: 3/8" tube x 1/2" - 24 BSW AFAU047/16C: 1/4"tube x 7/16-24 UNS AFAU057/16C: 5/16"tube x 7/16-24 UNS AFAU067/16C: 3/8"tube x 7/16-24 UNS ASA0102: 5/32"stem x 1/8"NPTF ASA0104: 5/32"stem x 1/4"NPTF ASA0302: 3/16"stem x 1/8"NPTF ASA0402: 1/4"stem x 1/8"NPTF ASA0404: 1/4"stem x 1/4"NPTF ASA0502: 5/16"stem x 1/8"NPTF ASA0504: 5/16"stem x 1/4"NPTF ASA0506: 5/16"stem x 3/8"NPTF ASA0604: 3/8"stem x 1/4"NPTF ASA0606: 3/8"stem x 3/8"NPTF ASA0706: 1/2"stem x 3/8"NPTF ASA0707: 1/2"stem x 1/2"NPTF ATHWD0604: 3/8" tube x 1/4" tube ATHWD0606: 3/8" tube x 3/8" tube ATHWD0706: 1/2" tube x 3/8" tube AMSEBT0104: 5/32" tube x 1/4" BSPT AMESBT0302: 3/16" tube x 1/8"BSPT AMESBT0306: 3/16" x 3/8" BSPT AMESBT0406: 1/4" x 3/8" BSPT AMESBT0407: 1/4" x 1/2" BSPT AMESBT0504: 5/16" tube x 1/4" BSPT AMESBT0506: 5/16" tube x 3/8" BSPT AMESBT0507: 5/16" x 1/2" BSPT AMESBT0604: 3/8" tube x 1/4" BSPT AMESBT0606: 3/8" tube x 3/8" BSPT AMESBT0706: 1/2" tube x 3/8" BSPT AMESBT0707: 1/2" tube x 1/2" BSPT ASAW059/16: 5/16" x 9/16" BSW ASAW0607: 3/8" x 1/2" BSW ASAW069/16: 3/8" X 9/16 BSW ADST0606: 3/8" ADEU0606: 3/8" ASTU04004: 1/4" x 1/4" x 1/4" ASTU060606: 3/8" x 3/8" x 3/8" ASTU070707: 1/2" x 1/2" 1/2" AMTUR040404: 1/4" x 1/4" x 1/4" AMTUR060606: 3/8" x 3/8" x 3/8" ABTU040404: 1/4" x 1/4" x 1/4" ABTU060606: 3/8" x 3/8" x 3/8" ABTU070707: 1/2" x 1/2" 1/2" ATS04: 1/4" x 0.170" ATS 05: 5/16" x 0.216" ATS 06: 3/8'' x 1/4" ATS 07: 1/2" x 3/8'' DPE 01: 5/32"X1500FT LLDPE TUBE DPE 03: 3/16"X1350FT LLDPE TUBE DPE 04: 1/4"X1000FT LLDPE TUBE DPE 05: 5/16"X650FT LLDPE TUBE DPE 06: 3/8"X500FT LLDPE TUBE DPE 07: 1/2"X300FT LLDPE TUBE Models added July 2020: AFAB0409F: 1/4"tube x 3/4"BSP(P) flat type AFAB0409FP: 1/4" tube x 3/4 BSP(P) AFAB0508F: 5/16"tube x 5/8 BSP(P) flat type AFAB0509F: 5/16"tube x 3/4"BSP(P) flat type AFAB0608F: 3/8"tube x 5/8 BSP(P) flat type AFAB0609F: 3/8"tube x 3/4"BSP(P) flat type AFAB0609FP: 3/8" tube x 3/4" BSP(P) AFAB0708F: 1/2"tube x 5/8"BSP(P) flat type AFAB0709FP: 1/2" tube x 3/4" BSP(P) AFAU047/16C: 1/4"tube x 7/16-24 UNS AFAU057/16C: 5/16"tube x 7/16-24 UNS AFAU067/16C: 3/8"tube x 7/16-24 UNS AFAUF047/16V: 1/4´´ tube x 7/16-20UNF- V Type AFAUF057/16V: 5/16´´ tube x 7/16-20UNF- V Type AFAUF65/8V: 3/8" tube X 5/8"-18UNF- V Type AMCB0609: 3/8"tube x 3/4"BSP(P) AMCF0507N: 5/16" tube x 3/4"-16 UNF AMCF0607N: 3/8" tube x 3/4" - 16 UNF AMCW049/16: 1/4" tube x 9/16"-24 BSW AMCW059/16: 5/16" tube x 9/16" - 24 BSW AMCW069/16: 3/8" tube x 9/16" - 24 BSW AMTSBT0302: 3/16" tube x 1/8" BSPT AMTSBT0504: 5/16" tube x 1/4" BSPT AMTSBT0506: 5/16" tube x 3/8" BSPT AMTSBT0604: 3/8" tube x 1/4" BSPT ASAW069/16: 3/8" X 9/16 BSW ASSA15M06: 15mm stem x 3/8" stem
Factor:: The Fluidconnections Co. (UK) Ltd

Company Name
The Fluidconnections Co. (UK) Ltd
Address
Rufford House, Darwin Drive, Sherwood Energy Village
Postcode
NG22 9GW
Country
New Ollerton,
Phone
+44 (0) 1623 836 814

View All Listings by this Company
Manufacturer:: DMT

Company Name
DMT
Address
143B-3L Namdong-Gu Incheon
Country
Korea

View All Listings by this Company

WRAS Approval Number: #1907063

Polypipe ‘MecFlow’ range of Socket fusion (20-125mm), Electrofusion (75-125mm), Clickweld (75-125mm) and Buttweld (160-200mm) plastic fittings for use with Polypipe ‘MecFlow’ Series 3 (20-32mm) and Series 5 (40-200mm) multi-layer pipe. Sizes 20mm to 32mm have a maximum working pressure of 31.7 bar @cold water use only and 8.1 bar@80°C. Sizes 40mm to 200mm have a maximum working pressure of 20.3 bar @cold water use only and 8.1 bar@80°C

Section:: 1100 Fittings and Pipe - Compatible Systems
Section Subtitle:: Unless specified in the individual approval, the products within this section are not suitable for below ground use
WRAS Approval Number:: 1907063
Expiry date:: 31/07/2024
Size:: see model
Marking:: POLYPIPE LOGO OR POLYPIPE ON BODY OF FITTINGS. SIZE, MATERIAL, DIN8078, POLYPIPE, WRAS, MECFLOW, SERIES & DATE OF MANUFACTURE DD/MM/YY ON PIPE
Installation Requirements:: R001
Model:: POLYPIPE SECONDARY MecFlow Series 3 pipe 3m: 20mm (3000.3.20.30G), 25mm (3000.3.25.30G), 32mm (3000.3.32.30G). MecFlow Series 5 pipe 3m: 40mm (3000.5.40.30G), 50mm (3000.5.50.30G), 63mm (3000.5.63.30G), 75mm (3000.5.75.30G), 90mm (3000.5.90.30G), 110mm (3000.5.110.30G). MecFlow Series 5 pipe 5.8m: 125mm (3000.5.125.58G), 160mm (3000.5.160.58G), 200mm (3000.5.200.58G). MecFlow Series 5 socketed pipe 3m: 40mm (3000S.5.40.30G), 50mm (3000S.5.50.30G), 63mm (3000S.5.63.30G), 75mm (3000S.5.75.30G), 90mm (3000S.5.90.30G), 110mm (3000S.5.110.30G). MecFlow 125mm Series 5 socketed pipe 5.8m: 125mm (3000S.5.125.58G). MecFlow Welding Socket: 20mm (3011S.20G), 25mm (3011S.25G), 32mm (3011S.32G), 40mm (3011S.40G), 50mm (3011S.50G), 63mm (3011S.63G), 75mm (3011S.75G), 90mm (3011S.90G), 110mm (3011S.110G), 125mm (3011S.125G). MecFlow 90° equal tee: 20mm (3004S.20.90G), 25mm (3004S.25.90G), 32mm (3004S.32.90G), 40mm (3004S.40.90G), 50mm (3004S.50.90G), 63mm (3004S.63.90G), 75mm (3004S.75.90G), 90mm (3004S.90.90G), 110mm (3004S.110.90G), 125mm (3004S.125.90G). MecFlow 90° unequal tee: 25x20x20mm (3004S.25x20x20.90G), 25x20x25mm (3004S.25x20x25.90G), 32x25x25mm (3004S.32x25x25.90G), 32x20x32mm (3004S.32x20x32.90G), 32x25x32mm (3004S.32x25x32.90G), 40x20x40mm (3004S.40x20x40.90G), 40x25x40mm (3004S.40x25x40.90G), 40x32x40mm (3004S.40x32x40.90G), 50x25x50mm (3004S.50x25x50.90G), 50x32x50mm (3004S.50x32x50.90G), 50x40x50mm (3004S.50x40x50.90G), 63x25x63mm (3004S.63x25x63.90G), 63x32x63mm (3004S.63x32x63.90G), 63x40x63mm (3004S.63x40x63.90G), 63x50x63mm (3004S.63x50x63.90G), 75x50x75mm (3004S.75x50x75.90G), 75x63x75mm (3004S.75x63x75.90G), 90x63x90mm (3004S.90x63x90.90G), 90x75x90mm (3004S.90x75x90.90G), 110x63x110mm (3004S.110x63x110.90G), 110x75x110mm (3004S.110x75x110.90G), 110x90x110mm (3004S.110x90x110.90G). MecFlow 90° elbow: 20mm (3001S.20.90G), 25mm (3001S.25.90G), 32mm (3001S.32.90G), 40mm (3001S.40.90G), 50mm (3001S.50.90G), 63mm (3001S.63.90G), 75mm (3001S.75.90G), 90mm (3001S.90.90G), 110mm (3001S.110.90G), 125mm (3001S.125.90G). MecFlow 45° elbow: 20mm (3001S.20.45G), 25mm (3001S.25.45G), 32mm (3001S.32.45G), 40mm (3001S.40.45G), 50mm (3001S.50.45G), 63mm (3001S.63.45G), 75mm (3001S.75.45G), 90mm (3001S.90.45G), 110mm (3001S.110.45G), 125mm (3001S.125.45G). MecFlow welding reducer: 25x20mm (3024S.25x20G), 32x20mm (3024S.32x20G), 32x25mm (3024S.32x25G), 40x25mm (3024S.40x25G), 40x32mm (3024S.40x32G), 50x32mm (3024S.50x32G), 50x40mm (3024S.50x40G), 63x25mm (3024S.63x25G), 63x32mm (3024S.63x32G), 63x40mm (3024S.63x40G), 63x50mm (3024S.63x50G), 75x32mm (3024S.75x32G), 75x40mm (3024S.75x40G), 75x50mm (3024S.75x50G), 75x63mm (3024S.75x63G), 90x63mm (3024S.90x63G), 90x75mm (3024S.90x75G), 110x63mm (3024S.110x63G), 110x75mm (3024S.110x75G), 110x90mm (3024S.110x90G), 125x110mm (3024S.125x110G). MecFlow end cap: 20mm (3030S.20G), 25mm (3030S.25G), 32mm (3030S.32G), 40mm (3030S.40G), 50mm (3030S.50G), 63mm (3030S.63G), 75mm (3030S.75G), 90mm (3030S.90G), 110mm (3030S.110G), 125mm (3030S.125G). MecFlow cross-over section: 20mm (3002.20G), 25mm (3002.25G), 32mm (3002.32G). MecFlow stub flange adaptor: 40mm (3012S.40G), 50mm (3012S.50G), 63mm (3012S.63G), 75mm (3012S.75G), 90mm (3012S.90G), 110mm (3012S.110G), 125mm (3012S.125G). MecFlow plastic backing ring: 40mm (3016.40G), 50mm (3016.50G), 63mm (3016.63G), 75mm (3016.75G), 90mm (3016.90G), 110mm (3016.110G), 125mm (3016.125G). MecFlow Back plate elbow 90°: 20mmx0.5" (3015S.20x05.90G), 25mmx0.5" (3015S.25x05.90G). MecFlow elbow 90° with female thread: 20mmx0.5" (3016S.20x05.90G), 25mmx0.5" (3016S.25x05.90G), 25mmx0.75" (3016S.25x075.90G), 32mmx0.75" (3016S.32x075.90G). MecFlow 32mm x 1'' elbow 90° with hexagonal female thread: 32mmx1" (3016S.32x1.90G). MecFlow elbow 90° with male thread: 20mmx0.5" (3017S.20x05.90G), 20mmx0.75" (3017S.20x075.90G), 25mmx0.75" (3017S.25x075.90G), 32mmx0.75" (3017S.32x075.90G). MecFlow 32mm x 1'' elbow 90° with hexagonal male thread: 32mmx1" (3017S.32x1.90G). MecFlow tee 90° with female thread: 20mmx0.5" (3004S.20x05.90G), 25mmx0.5" (3004S.25x05.90G), 25mmx0.75" (3004S.25x075.90G), 32mmx0.75" (3004S.32x075.90G). MecFlow 32mm x 1'' tee 90° with hexagonal female thread: 32mmx1" (3004S.32x1.90G). MecFlow adaptor with female thread: 20mmx0.5" (3016S.20x05G), 25mmx0.5" (3016S.25x05G), 25mmx0.75" (3016S.25x075G), 32mmx0.75" (3016S.32x075G). MecFlow adaptor with hexagonal female thread: 32mmx1" (3016S.32x1G), 40mmx1.25" (3016S.40x125G), 50mmx1.5" (3016S.50x15G), 63mmx2" (3016S.63x2G), 75mmx2.5" (3016S.75x25G), 90mmx3" (3016S.90x3G), 110mmx4" (3016S.110x4G). MecFlow adaptor with male thread: 20mmx0.5" (3017S.20x05G), 20mmx0.75" (3017S.20x075G), 25mmx0.5" (3017S.25x05G), 25mmx0.75" (3017S.25x075G), 32mmx0.75" (3017S.32x075G). MecFlow adaptor with hexagonal male thread: 32mmx1" (3017S.32x1G), 40mmx1.25" (3017S.40x125G), 50mmx1.5" (3017S.50x15G), 63mmx2" (3017S.63x2G), 75mmx2.5" (3017S.75x25G), 90mmx3" (3017S.90x3G), 110mmx4" (3017S.110x4G). MecFlow electrofusion coupling: 20mm (3010.20G), 25mm (3010.25G), 32mm (3010.32G), 40mm (3010.40G), 50mm (3010.50G), 63mm (3010.63G), 75mm (3010.75G), 90mm (3010.90G), 110mm (3010.110G), 125mm (3010.125G), 160mm (3010.160G), 200mm (3010.200G). MecFlow weld in saddle: 50x20mm (3054.50x20G), 63x20mm (3054.63x20G), 75x20mm (3054.75x20G), 90x20mm (3054.90x20G), 110x20mm (3054.110x20G), 125x20mm (3054.125x20G), 160x20mm (3054.160x20G), 200x20mm (3054.200x20G), 50x25mm (3054.50x25G), 63x25mm (3054.63x25G), 75x25mm (3054.75x25G), 90x25mm (3054.90x25G), 110x25mm (3054.110x25G), 125x25mm (3054.125x25G), 160x25mm (3054.160x25G), 200x25mm (3054.200x25G), 50x32mm (3054.50x32G), 63x32mm (3054.63x32G), 75x32mm (3054.75x32G), 90x32mm (3054.90x32G), 110x32mm (3054.110x32G), 125x32mm (3054.125x32G), 160x32mm (3054.160x32G), 200x32mm (3054.200x32G), 90x40mm (3054.90x40G), 110x40mm (3054.110x40G), 125x40mm (3054.125x40G), 160x40mm (3054.160x40G), 200x40mm (3054.200x40G), 90x50mm (3054.90x50G), 110x50mm (3054.110x50G), 125x50mm (3054.125x50G), 160x50mm (3054.160x50G), 200x50mm (3054.200x50G), 110x63mm (3054.110x63G), 125x63mm (3054.125x63G), 160x63mm (3054.160x63G), 200x63mm (3054.200x63G). MecFlow 160mm series 5 90° Butt - weld elbow: 160mm (3001B.5.160.90G). MecFlow 160mm series 5 45° Butt - weld elbow: 160mm (3001B.5.160.45G). MecFlow 160mm series 5 90° Butt - weld tee: 160mm (3004B.5.160.90G). MecFlow 160x110mm series 5 Butt - weld reducer: 160x110mm (3024B.5.160x110G). MecFlow 160mm series 5 Butt - weld stub flange adaptor: 160mm (3012B.5.160G). MecFlow 160mm series 5 Butt - weld end cap: 160mm (3030B.5.160G). MecFlow series 5 90° elbow: 160mm (3001.5.160.90G), 200mm (3001.5.200.90G). MecFlow series 5 45° elbow: 160mm (3001.5.160.45G), 200mm (3001.5.200.45G). MecFlow series 5 90° equal tee: 160mm (3004.5.160.90G), 200mm (3004.5.200.90G). MecFlow series 5 90° unequal tee: 160x110mm (3004.5.160x110.90G), 200x110mm (3004.5.200x110.90G), 200x125mm (3004.5.200x125.90G), 200x160mm (3004.5.200x160.90G). MecFlow series 5 end cap: 160mm (3030.5.160G), 200mm (3030.5.200G). MecFlow series 5 segmented reducer: 160x110mm (3024.5.160x110G), 160x125mm (3024.5.160x125G), 200x110mm (3024.5.200x110G), 200x125mm (3024.5.200x125G), 200x160mm (3024.5.200x160G). MecFlow series 5 stub flange adaptor: 160mm (3012.5.160G), 200mm (3012.5.200G). MecFlow Series 5 socketed Clickweld pipe: 75mmx5.8m (3000ES.5.75.58G), 90mmx5.8m (3000ES.5.90.58G), 110mmx5.8m (3000ES.5.110.58G), 125mmx5.8m (3000ES.5.125.58G), 75mmx0.5m (3000ES.5.75.05G), 90mmx0.5m (3000ES.5.90.05G), 110mmx0.5m (3000ES.5.110.05G), 125mmx0.5m (3000ES.5.125.05G), 75mmx1m (3000ES.5.75.10G), 90mmx1m (3000ES.5.90.10G), 110mmx1m (3000ES.5.110.10G), 125mmx1m (3000ES.5.125.10G). MecFlow Series 5 Clickweld pipe 0.5m: 75mmx0.5m (3000E.5.75.05G), 90mmx0.5m (3000E.5.90.05G), 110mmx0.5m (3000E.5.110.05G), 125mmx0.5m (3000E.5.125.05G), 75mmx1m (3000E.5.75.10G), 90mmx1m (3000E.5.90.10G), 110mmx1m (3000E.5.110.10G), 125mmx1m (3000E.5.125.10G). MecFlow Clickweld socket connector: 75mm (3010ES.75G), 90mm (3010ES.90G), 110mm (3010ES.110G), 125mm (3010ES.125G). MecFlow Clickweld double spigot connector: 75mm (3010E.75G), 90mm (3010E.90G), 110mm (3010E.110G), 125mm (3010E.125G). MecFlow Clickweld socket to socket fusion: 75mm (3011ES.75G), 90mm (3011ES.90G), 110mm (3011ES.110G), 125mm (3011ES.125G). MecFlow Clickweld socket coupling: 75mm (3011E.75G), 90mm (3011E.90G), 110mm (3011E.110G), 125mm (3011E.125G). MecFlow Clickweld reducer: 90x75mm (3024E.90x75G), 110x75mm (3024E.110x75G), 110x90mm (3024E.110x90G), 125x110mm (3024E.125x110G). MecFlow Clickweld to socket fusion reducer: 75x32mm (3024ES.75x32G), 75x40mm (3024ES.75x40G), 75x50mm (3024ES.75x50G), 75x63mm (3024ES.75x63G), 90x63mm (3024ES.90x63G), 90x75mm (3024ES.90x75G), 110x63mm (3024ES.110x63G), 110x75mm (3024ES.110x75G), 110x90mm (3024ES.110x90G), 125x110mm (3024ES.125x110G). MecFlow 90° Clickweld elbow: 75mm (3001E.75.90G), 90mm (3001E.90.90G), 110mm (3001E.110.90G), 125mm (3001E.125.90G). MecFlow 45° Clickweld elbow: 75mm (3001E.75.45G), 90mm (3001E.90.45G), 110mm (3001E.110.45G), 125mm (3001E.125.45G). MecFlow 90° Clickweld to socket fusion elbow: 75mm (3001ES.75.90G), 90mm (3001ES.90.90G), 110mm (3001ES.110.90G), 125mm (3001ES.125.90G). MecFlow 45° Clickweld to socket fusion elbow: 75mm (3001ES.75.45G), 90mm (3001ES.90.45G), 110mm (3001ES.110.45G), 125mm (3001ES.125.45G). MecFlow Clickweld 90° equal tee: 75mm (3004E.75.90G), 90mm (3004E.90.90G), 110mm (3004E.110.90G), 125mm (3004E.125.90G). MecFlow Clickweld-socket-Clickweld 90° equal tee: 75mm (3004ESE.75.90G), 90mm (3004ESE.90.90G), 110mm (3004ESE.110.90G), 125mm (3004ESE.125.90G). MecFlow Clickweld-socket-socket 90° equal tee: 75mm (3004ESS.75.90G), 90mm (3004ESS.90.90G), 110mm (3004ESS.110.90G), 125mm (3004ESS.125.90G). MecFlow Clickweld 90° unequal tee: 90x75x90mm (3004E.90x75x90.90G), 110x75x110mm (3004E.110x75x110.90G), 110x90x110mm (3004E.110x90x110.90G). MecFlow Clickweld-socket-Clickweld 90° unequal tee: 75x50x75mm (3004ESE.75x50x75.90G), 75x63x75mm (3004ESE.75x63x75.90G), 90x63x90mm (3004ESE.90x63x90.90G), 90x75x90mm (3004ESE.90x75x90.90G), 110x63x110mm (3004ESE.110x63x110.90G), 110x75x110mm (3004ESE.110x75x110.90G), 110x90x110mm (3004ESE.110x90x110.90G). MecFlow Clickweld PN16 full face flange: 75mm (3013E.75G), 90mm (3013E.90G), 110mm (3013E.110G), 125mm (3013E.125G). MecFlow Clickweld end cap: 75mm (3030E.75G), 90mm (3030E.90G), 110mm (3030E.110G), 125mm (3030E.125G). MecFlow Clickweld adaptor with hexagonal female thread: 75mmx2.5" (3016E.75x25G), 90mmx3" (3016E.90x3G), 110mmx4" (3016E.110x4G). MecFlow Clickweld adaptor with hexagonal male thread: 75mmx2.5" (3017E.75x25G), 90mmx3" (3017E.90x3G), 110mmx4" (3017E.110x4G).
Factor:: Polypipe Building Services

Company Name
Polypipe Building Services
Address
New Hythe Business Park, College Road, Aylesford, Kent
Postcode
ME20 7PJ

View All Listings by this Company

WRAS Approval Number: #1911045

Range of brass metal crimp fittings, PPSU synthetic crimp fittings and PPSU synthetic pushfit fittings for use with multiskin 2 PERT/AL/PERT multilayer pipe. Crimp joint is achieved by a TH profile crimp jaws. All types of fittings incorporate EPDM O-rings. Maximum working pressure 10.0 bar. Maximum operating temperature 95°C

Section:: 1100 Fittings and Pipe - Compatible Systems
Section Subtitle:: Unless specified in the individual approval, the products within this section are not suitable for below ground use
WRAS Approval Number:: 1911045
Expiry date:: 30/11/2024
Size:: see model
Marking:: Crimp fittings - Comap, size, Date stamp (MM/YY) and DVGW on crimp sleeve. Pushfit fitting - COMAP, Date stamp (MM/YY), size on fitting body.
Installation Requirements:: R001
Model:: METAL CRIMP FITTINGS 45° Equal Elbow Code Description Size 7041W26 45° Equal Elbow 26 x 3 90° Equal Elbow Code Description Size 7090W16 90° Equal Elbow 16 x 2 7090W20 90° Equal Elbow 20 x 2 7090W26 90° Equal Elbow 26 x 3 Elbow/Female Threaded Code Description Size 7090GW1612 Elbow/Female Threaded 16 x 2-1/2" 7090GW2012 Elbow/Female Threaded 20 x 2-1/2" 7090GW2034 Elbow/Female Threaded 20 x 2-3/4" 7090GW2634 Elbow/Female Threaded 26 x 3-3/4" 7090GW261 Elbow/Female Threaded 26 x 3-1" Elbow/Male Threaded Code Description Size 7092GW1612 Elbow/Male Threaded 16 x 2-1/2" 7092GW2012 Elbow/Male Threaded 20 x 2-1/2" 7092GW2034 Elbow/Male Threaded 20 x 2-3/4" 7092GW2634 Elbow/Male Threaded 26 x 3-3/4" 7092GW261 Elbow/Male Threaded 26 x 3-1" Equal Tee Code Description Size 7130W16 Equal Tee 16 x 2 7130W20 Equal Tee 20 x 2 7130W26 Equal Tee 26 x3 Reducing Tee Code Description Size 7130RW162016 Reducing Tee 16 x 2-20 x 2-16 x 2 7130RW201616 Reducing Tee 20 x 2-16 x 2-16 x 2 7130RW201620 Reducing Tee 20 x 2-16 x 2-20 x 2 7130RW202016 Reducing Tee 20 x 2-20 x 2-16 x 2 7130RW202616 Reducing Tee 20 x 2-26 x 3-16 x 2 7130RW202620 Reducing Tee 20 x 2-26 x 3-20 x 2 7130RW261616 Reducing Tee 26 x 3-16 x 2-16 x 2 7130RW261620 Reducing Tee 26 x 3-16 x 2-20 x 2 7130RW261626 Reducing Tee 26 x 3-16 x 2-26 x 3 7130RW262016 Reducing Tee 26 x 3-20 x 2-16 x 2 7130RW262020 Reducing Tee 26 x 3-20 x 2-20 x 2 7130RW262026 Reducing Tee 26 x 3-20 x 2-26 x 3 7130RW262616 Reducing Tee 26 x 3-26 x 3-16 x 2 7130RW262620 Reducing Tee 26 x 3-26 x 3-20 x 2 Straight Coupling Code Description Size 7270W16 Crimp Coupling 16 x 2 7270W20 Crimp Coupling 20 x 2 7270W26 Crimp Coupling 26 x 3 Reducing Coupling Code Description Size 7240W2016 Reducing Coupling 20 x 2-16 x 2 7240W2616 Reducing Coupling 26 x 3-16 x 3 7240W2620 Reducing Coupling 26 x 3-20 x 2 Straight Coupling/Female Threaded Code Description Size 7270GW1612 Straight Coupling/Female Threaded 16 x 2-1/2" 7270GW2012 Straight Coupling/Female Threaded 20 x 2-1/2" 7270GW2034 Straight Coupling/Female Threaded 20 x 2-3/4" 7270GW2634 Straight Coupling/Female Threaded 26 x 3-3/4" 7270GW261 Straight Coupling/Female Threaded 26 x 3-1" Straight Coupling/Male Threaded Code Description Size 7243GW1612 Straight Coupling/Male Threaded 16 x 2 - 1/2" 7243GW2012 Straight Coupling/Male Threaded 20 X 2 - 1/2" 7243GW2034 Straight Coupling/Male Threaded 20 x 2 - 3/4" 7243GW2634 Straight Coupling/Male Threaded 26 x 3 - 3/4" 7243GW261 Straight Coupling/Male Threaded 26 x 3 - 1" Crimp Cap Code Description Size 7300W16 Crimp Cap 16x2 7300W20 Crimp Cap 20x2 7300W26 Crimp Cap 26x3 SYNTHETIC PUSH FIT (PPSU) 90° Equal Elbow Code Description Size 9090P16 90° Equal Elbow 16 x 2 9090P20 90° Equal Elbow 20 x 2 9090P26 90° Equal Elbow 26 x 3 90° Elbow with female thread Code Description Size 9090GP1612 90 Degree Elbow with Female thread 16 x 1/2" 9090GP2012 90 Degree Elbow with Female thread 20 x 1/2" 9090GP2034 90 Degree Elbow with Female thread 20 x 3/4" 9090GP2634 90 Degree Elbow with Female thread 26 x 3/4" Equal Tee Code Description Size 9130P16 Equal Tee 16 x 2 9130P20 Equal Tee 20 x 2 9130P26 Equal Tee 26 x 3 Reducing Tee Code Description Size 9130RP162016 Reducing Tee 16 x 2 - 20 x 2 - 16 x 2 9130RP201616 Reducing Tee 20 x 2 - 16 x 2 - 16 x 2 9130RP201620 Reducing Tee 20 x 2 - 16 x 2 - 20 x 2 9130RP202016 Reducing Tee 20 x 2 - 20 x 2 - 16 x 2 9130RP261626 Reducing Tee 26 x 3 - 16 x 2 - 26 x 3 9130RP262026 Reducing Tee 26 x 3 - 20 x 2 - 26 x 3 9130RP262020 Reducing Tee 26 x 3 - 20 x 2 - 20 x 2 Tee/Female Threaded Code Description Size 9130GP161216 Tee/Female Threaded 16 x 2 - 1/2 - 16 x 2 9130GP201220 Tee/Female Threaded 20 x 2 - 1/2 - 20 x 2 9130GP263426 Tee/Female Threaded 26 x 3 - 3/4 - 26 x 3 Equal Coupling Code Description Size 9270P16 Equal Coupling 16 x 2 9270P20 Equal Coupling 20 x 2 9270P26 Equal Coupling 26 x 3 Reducing Coupling Code Description Size 9240P2016 Reducing Coupling 20 x 2 -16 x 2 9240P2616 Reducing Coupling 26 x 3 - 16 x 2 9240P2620 Reducing Coupling 26 x 3 - 20 x 2 Push Fit Cap Code Description Size 9300P16 Push Fit Cap 16 x 2 9300P20 Push Fit Cap 20 x 2 9300P26 Push Fit Cap 26 x 3 Straight Coupling/Female Threaded Code Description Size 9270GP1612 Straight Coupling/Female Threaded 16 x 2 - 1/2" 9270GP2012 Straight Coupling/Female Threaded 20 x 2 - 1/2" 9270GP2034 Straight Coupling/Female Threaded 20 x 2 - 3/4" 9270GP2634 Straight Coupling/Female Threaded 26 x 3 - 3/4" 9270GP261 Straight Coupling/Female Threaded 26 x 3 - 1" SYNTHETIC CRIMP FITTINGS (PPSU) 45° Equal Elbow Code Description Size 9041W26 45° Equal Elbow 26 x 3 9041w32 45° Equal Elbow 32 x 3 90° Equal Elbow Code Description Size 9090W16 90° Equal Elbow 16 x 2 9090W20 90° Equal Elbow 20 x 2 9090W26 90° Equal Elbow 26 x 3 9090W32 90° Equal Elbow 32 x 3 Elbow/Female Threaded Code Description Size 9090GW1612 Elbow/Female Threaded 16 x 1/2" 9090GW2012 Elbow/Female Threaded 20 x 1/2" Equal Tee Code Description Size 9130W16 Equal Tee 16 x 2 9130W20 Equal Tee 20 x 2 9130W26 Equal Tee 26 x 3 9130W32 Equal Tee 32 x 3 Crimp Cap Code Description Size 9300W16 Crimp Cap 16 x 2 9300W20 Crimp Cap 20 x 2 9300W26 Crimp Cap 26 x 3 Reducing Tee Code Description Size 9130RW162016 Reducing Tee 16 x 2 - 20 x 2 - 16 x 2 9130RW201616 Reducing Tee 20 x 2 - 16 x 2 - 16 x 2 9130RW201620 Reducing Tee 20 x 2 - 16 x 2 - 20 x 2 9130RW202016 Reducing Tee 20 x 2 - 20 x 2 - 16 x 2 9130RW202616 Reducing Tee 20 x 2 - 26 x 3 - 16 x 2 9130RW202620 Reducing Tee 20 x 2 - 26 x 3 - 20 x 2 9130RW261616 Reducing Tee 26 x 3 - 16 x 2 - 16 x 2 9130RW261620 Reducing Tee 26 x 3 - 16 x 2 - 20 x 2 9130RW261626 Reducing Tee 26 x 3 - 16 x 2 - 26 x 3 9130RW262020 Reducing Tee 26 x 3 - 20 x 2 - 20 x 2 9130RW262026 Reducing Tee 26 x 3 - 20 x 2 - 26 x 3 9130RW262616 Reducing Tee 26 x 3 - 26 x 3 - 16 x 2 9130RW262620 Reducing Tee 26 x 3 - 26 x 3 + 20 x 2 9130RW321632 Reducing Tee 32 x 3 - 16 x 2 - 32 x 3 9130RW322032 Reducing Tee 32 x 3 - 20 x 2 - 32 x 3 9130RW322626 Reducing Tee 32 x 3 - 26 x 3 - 26 x 3 9130RW322632 Reducing Tee 32 x 3 - 26 x 3 - 32 x 3 Straight Coupling/Female Threaded Code Description Size 9270GW1612 Straight Coupling/Female Threaded 16 x 1/2" 9270GW2012 Straight Coupling/Female Threaded 20 x 1/2" Straight Coupling Code Description Size 9270W16 Straight Coupling 16 x 2 9270W20 Straight Coupling 20 x 2 9270W26 Straight Coupling 26 x 3 9170W32 Straight Coupling 32 x 3 Reduced Coupling Code Description Size 9240W2016 Reduced Coupling 20 x 2 - 16 x 2 9240W2616 Reduced Coupling 26 x 3 - 16 x 2 9240W2620 Reduced Coupling 26 x 3 - 20 x 2 9240W3216 Reduced Coupling 32 x 3 - 16 x 2 9240W3220 Reduced Coupling 32 x 3 - 20 x 2 9240W3226 Reduced Coupling 32 x 3 - 26 x 3 PERT / AL / PERT MULTISKIN 2 MLCP Code Description Size B212002001 Plain Coils 16 x 2 - 100m B212002002 Plain Coils 16 x 2 - 200m B212002004 Plain Coils 16 x 2 - 400m B212002007 Plain Coils 16 x 2 - 600m B212004001 Plain Coils 20 x 2 - 100m B212005001 Plain Coils 26 x 3 - 50m B212006001 Plain Coils 32 x 3 - 50m Code Description Size B231002001 Insulated Pipe Blue 6mm 16 x 2 - 50m - 6mm B231002002 Insulated Pipe Blue 6mm 16 x 2 - 100m - 6mm B231004001 Insulated Pipe Blue 6mm 20 x 2 - 50m - 6mm B231005001 Insulated Pipe Blue 6mm 26 x 3 - 25m - 6mm Code Description Size B231011001 Insulated Pipe Blue 9mm 16 x 2 - 50m - 9mm B231008001 Insulated Pipe Blue 9mm 20 x 2 - 50m - 9mm B231009001 Insulated Pipe Blue 9mm 26 x 3 - 25m - 9mm B231010001 Insulated Pipe Blue 9mm 32 x 3 - 25m - 9mm Code Description Size B231012001 Insulated Pipe Blue 13mm 20 x 2 - 50m - 13mm B231013001 Insulated Pipe Blue 13mm 26 x 3 - 25m - 13mm Code Description Size B221003001 Corrugated Pipe Blue 16 x 2 - 50m B221001001 Corrugated Pipe Blue 16 x 2 - 100m B221004001 Corrugated Pipe Blue 20 x 2 - 50m B221005001 Corrugated Pipe Blue 26 x 3 - 50m Code Description Size B232002001 Insulated Pipe Red 6mm 16 x 2 - 50m - 6mm B232002002 Insulated Pipe Red 6mm 16 x 2 - 100m - 6mm B232004001 Insulated Pipe Red 6mm 20 x 2 - 50m - 6mm B232005001 Insulated Pipe Red 6mm 26 x 3 - 25m - 6mm Code Description Size B232011001 Insulated Pipe Red 9mm 16 x 2 - 50m - 9mm B232008001 Insulated Pipe Red 9mm 20 x 2 - 50m - 9mm B232009001 Insulated Pipe Red 9mm 26 x 3 - 25m - 9mm B232010001 Insulated Pipe Red 9mm 32 x 3 - 25m - 9mm Code Description Size B222003001 Corrugated Pipe Red 16 x 2 - 50m B222001001 Corrugated Pipe Red 16 x 2 - 100m B222004001 Corrugated Pipe Red 20 x 2 - 50m B222005001 Corrugated Pipe Red 26 x 3 - 50m
Factor:: Comap UK Limited

Company Name
Comap UK Limited
Address
Unit C6 William Way Moss Ind Estate St Helens Road
Postcode
WN7 3PT
Country
Leigh

View All Listings by this Company

WRAS Approval Number: #1911055

Section:: 1100 Fittings and Pipe - Compatible Systems
Section Subtitle:: Unless specified in the individual approval, the products within this section are not suitable for below ground use
WRAS Approval Number:: 1911055
Expiry date:: 30/11/2024
Size:: see model
Marking:: Crimp fittings - Comap, size, Date stamp (MM/YY) and DVGW on crimp sleeve. Pushfit fitting - COMAP, Date stamp (MM/YY), size on fitting body. Pipe- COMAP, MULTISKIN2, PERT, size, pressure & maximum temperature on body of pipe.
Installation Requirements:: R001
Model:: METAL CRIMP FITTINGS 45° Equal Elbow Code Description Size 7041W26 45° Equal Elbow 26 x 3 90° Equal Elbow Code Description Size 7090W16 90° Equal Elbow 16 x 2 7090W20 90° Equal Elbow 20 x 2 7090W26 90° Equal Elbow 26 x 3 Elbow/Female Threaded Code Description Size 7090GW1612 Elbow/Female Threaded 16 x 2-1/2" 7090GW2012 Elbow/Female Threaded 20 x 2-1/2" 7090GW2034 Elbow/Female Threaded 20 x 2-3/4" 7090GW2634 Elbow/Female Threaded 26 x 3-3/4" 7090GW261 Elbow/Female Threaded 26 x 3-1" Elbow/Male Threaded Code Description Size 7092GW1612 Elbow/Male Threaded 16 x 2-1/2" 7092GW2012 Elbow/Male Threaded 20 x 2-1/2" 7092GW2034 Elbow/Male Threaded 20 x 2-3/4" 7092GW2634 Elbow/Male Threaded 26 x 3-3/4" 7092GW261 Elbow/Male Threaded 26 x 3-1" Equal Tee Code Description Size 7130W16 Equal Tee 16 x 2 7130W20 Equal Tee 20 x 2 7130W26 Equal Tee 26 x3 Reducing Tee Code Description Size 7130RW162016 Reducing Tee 16 x 2-20 x 2-16 x 2 7130RW201616 Reducing Tee 20 x 2-16 x 2-16 x 2 7130RW201620 Reducing Tee 20 x 2-16 x 2-20 x 2 7130RW202016 Reducing Tee 20 x 2-20 x 2-16 x 2 7130RW202616 Reducing Tee 20 x 2-26 x 3-16 x 2 7130RW202620 Reducing Tee 20 x 2-26 x 3-20 x 2 7130RW261616 Reducing Tee 26 x 3-16 x 2-16 x 2 7130RW261620 Reducing Tee 26 x 3-16 x 2-20 x 2 7130RW261626 Reducing Tee 26 x 3-16 x 2-26 x 3 7130RW262016 Reducing Tee 26 x 3-20 x 2-16 x 2 7130RW262020 Reducing Tee 26 x 3-20 x 2-20 x 2 7130RW262026 Reducing Tee 26 x 3-20 x 2-26 x 3 7130RW262616 Reducing Tee 26 x 3-26 x 3-16 x 2 7130RW262620 Reducing Tee 26 x 3-26 x 3-20 x 2 Straight Coupling Code Description Size 7270W16 Crimp Coupling 16 x 2 7270W20 Crimp Coupling 20 x 2 7270W26 Crimp Coupling 26 x 3 Reducing Coupling Code Description Size 7240W2016 Reducing Coupling 20 x 2-16 x 2 7240W2616 Reducing Coupling 26 x 3-16 x 3 7240W2620 Reducing Coupling 26 x 3-20 x 2 Straight Coupling/Female Threaded Code Description Size 7270GW1612 Straight Coupling/Female Threaded 16 x 2-1/2" 7270GW2012 Straight Coupling/Female Threaded 20 x 2-1/2" 7270GW2034 Straight Coupling/Female Threaded 20 x 2-3/4" 7270GW2634 Straight Coupling/Female Threaded 26 x 3-3/4" 7270GW261 Straight Coupling/Female Threaded 26 x 3-1" Straight Coupling/Male Threaded Code Description Size 7243GW1612 Straight Coupling/Male Threaded 16 x 2 - 1/2" 7243GW2012 Straight Coupling/Male Threaded 20 X 2 - 1/2" 7243GW2034 Straight Coupling/Male Threaded 20 x 2 - 3/4" 7243GW2634 Straight Coupling/Male Threaded 26 x 3 - 3/4" 7243GW261 Straight Coupling/Male Threaded 26 x 3 - 1" Crimp Cap Code Description Size 7300W16 Crimp Cap 16x2 7300W20 Crimp Cap 20x2 7300W26 Crimp Cap 26x3 SYNTHETIC PUSH FIT (PPSU) 90° Equal Elbow Code Description Size 9090P16 90° Equal Elbow 16 x 2 9090P20 90° Equal Elbow 20 x 2 9090P26 90° Equal Elbow 26 x 3 90 Degree Elbow with female thread Code Description Size 9090GP1612 90 Degree Elbow with Female thread 16 x 1/2" 9090GP2012 90 Degree Elbow with Female thread 20 x 1/2" 9090GP2034 90 Degree Elbow with Female thread 20 x 3/4" 9090GP2634 90 Degree Elbow with Female thread 26 x 3/4" Equal Tee Code Description Size 9130P16 Equal Tee 16 x 2 9130P20 Equal Tee 20 x 2 9130P26 Equal Tee 26 x 3 Reducing Tee Code Description Size 9130RP162016 Reducing Tee 16 x 2 - 20 x 2 - 16 x 2 9130RP201616 Reducing Tee 20 x 2 - 16 x 2 - 16 x 2 9130RP201620 Reducing Tee 20 x 2 - 16 x 2 - 20 x 2 9130RP202016 Reducing Tee 20 x 2 - 20 x 2 - 16 x 2 9130RP261626 Reducing Tee 26 x 3 - 16 x 2 - 26 x 3 9130RP262026 Reducing Tee 26 x 3 - 20 x 2 - 26 x 3 9130RP262020 Reducing Tee 26 x 3 - 20 x 2 - 20 x 2 Tee/Female Threaded Code Description Size 9130GP161216 Tee/Female Threaded 16 x 2 - 1/2 - 16 x 2 9130GP201220 Tee/Female Threaded 20 x 2 - 1/2 - 20 x 2 9130GP263426 Tee/Female Threaded 26 x 3 - 3/4 - 26 x 3 Equal Coupling Code Description Size 9270P16 Equal Coupling 16 x 2 9270P20 Equal Coupling 20 x 2 9270P26 Equal Coupling 26 x 3 Reducing Coupling Code Description Size 9240P2016 Reducing Coupling 20 x 2 -16 x 2 9240P2616 Reducing Coupling 26 x 3 - 16 x 2 9240P2620 Reducing Coupling 26 x 3 - 20 x 2 Push Fit Cap Code Description Size 9300P16 Push Fit Cap 16 x 2 9300P20 Push Fit Cap 20 x 2 9300P26 Push Fit Cap 26 x 3 Straight Coupling/Female Threaded Code Description Size 9270GP1612 Straight Coupling/Female Threaded 16 x 2 - 1/2" 9270GP2012 Straight Coupling/Female Threaded 20 x 2 - 1/2" 9270GP2034 Straight Coupling/Female Threaded 20 x 2 - 3/4" 9270GP2634 Straight Coupling/Female Threaded 26 x 3 - 3/4" 9270GP261 Straight Coupling/Female Threaded 26 x 3 - 1" SYNTHETIC CRIMP FITTINGS (PPSU) 45° Equal Elbow Code Description Size 9041W26 45° Equal Elbow 26 x 3 9041w32 45° Equal Elbow 32 x 3 90° Equal Elbow Code Description Size 9090W16 90° Equal Elbow 16 x 2 9090W20 90° Equal Elbow 20 x 2 9090W26 90° Equal Elbow 26 x 3 9090W32 90° Equal Elbow 32 x 3 Elbow/Female Threaded Code Description Size 9090GW1612 Elbow/Female Threaded 16 x 1/2" 9090GW2012 Elbow/Female Threaded 20 x 1/2" Equal Tee Code Description Size 9130W16 Equal Tee 16 x 2 9130W20 Equal Tee 20 x 2 9130W26 Equal Tee 26 x 3 9130W32 Equal Tee 32 x 3 Crimp Cap Code Description Size 9300W16 Crimp Cap 16 x 2 9300W20 Crimp Cap 20 x 2 9300W26 Crimp Cap 26 x 3 Reducing Tee Code Description Size 9130RW162016 Reducing Tee 16 x 2 - 20 x 2 - 16 x 2 9130RW201616 Reducing Tee 20 x 2 - 16 x 2 - 16 x 2 9130RW201620 Reducing Tee 20 x 2 - 16 x 2 - 20 x 2 9130RW202016 Reducing Tee 20 x 2 - 20 x 2 - 16 x 2 9130RW202616 Reducing Tee 20 x 2 - 26 x 3 - 16 x 2 9130RW202620 Reducing Tee 20 x 2 - 26 x 3 - 20 x 2 9130RW261616 Reducing Tee 26 x 3 - 16 x 2 - 16 x 2 9130RW261620 Reducing Tee 26 x 3 - 16 x 2 - 20 x 2 9130RW261626 Reducing Tee 26 x 3 - 16 x 2 - 26 x 3 9130RW262020 Reducing Tee 26 x 3 - 20 x 2 - 20 x 2 9130RW262026 Reducing Tee 26 x 3 - 20 x 2 - 26 x 3 9130RW262616 Reducing Tee 26 x 3 - 26 x 3 - 16 x 2 9130RW262620 Reducing Tee 26 x 3 - 26 x 3 + 20 x 2 9130RW321632 Reducing Tee 32 x 3 - 16 x 2 - 32 x 3 9130RW322032 Reducing Tee 32 x 3 - 20 x 2 - 32 x 3 9130RW322626 Reducing Tee 32 x 3 - 26 x 3 - 26 x 3 9130RW322632 Reducing Tee 32 x 3 - 26 x 3 - 32 x 3 Straight Coupling/Female Threaded Code Description Size 9270GW1612 Straight Coupling/Female Threaded 16 x 1/2" 9270GW2012 Straight Coupling/Female Threaded 20 x 1/2" Straight Coupling Code Description Size 9270W16 Straight Coupling 16 x 2 9270W20 Straight Coupling 20 x 2 9270W26 Straight Coupling 26 x 3 9170W32 Straight Coupling 32 x 3 Reduced Coupling Code Description Size 9240W2016 Reduced Coupling 20 x 2 - 16 x 2 9240W2616 Reduced Coupling 26 x 3 - 16 x 2 9240W2620 Reduced Coupling 26 x 3 - 20 x 2 9240W3216 Reduced Coupling 32 x 3 - 16 x 2 9240W3220 Reduced Coupling 32 x 3 - 20 x 2 9240W3226 Reduced Coupling 32 x 3 - 26 x 3 PERT / AL / PERT MULTISKIN 2 MLCP Code Description Size B212002001 Plain Coils 16 x 2 - 100m B212002002 Plain Coils 16 x 2 - 200m B212002004 Plain Coils 16 x 2 - 400m B212002007 Plain Coils 16 x 2 - 600m B212004001 Plain Coils 20 x 2 - 100m B212005001 Plain Coils 26 x 3 - 50m B212006001 Plain Coils 32 x 3 - 50m Code Description Size B231002001 Insulated Pipe Blue 6mm 16 x 2 - 50m - 6mm B231002002 Insulated Pipe Blue 6mm 16 x 2 - 100m - 6mm B231004001 Insulated Pipe Blue 6mm 20 x 2 - 50m - 6mm B231005001 Insulated Pipe Blue 6mm 26 x 3 - 25m - 6mm Code Description Size B231011001 Insulated Pipe Blue 9mm 16 x 2 - 50m - 9mm B231008001 Insulated Pipe Blue 9mm 20 x 2 - 50m - 9mm B231009001 Insulated Pipe Blue 9mm 26 x 3 - 25m - 9mm B231010001 Insulated Pipe Blue 9mm 32 x 3 - 25m - 9mm Code Description Size B231012001 Insulated Pipe Blue 13mm 20 x 2 - 50m - 13mm B231013001 Insulated Pipe Blue 13mm 26 x 3 - 25m - 13mm Code Description Size B221003001 Corrugated Pipe Blue 16 x 2 - 50m B221001001 Corrugated Pipe Blue 16 x 2 - 100m B221004001 Corrugated Pipe Blue 20 x 2 - 50m B221005001 Corrugated Pipe Blue 26 x 3 - 50m Code Description Size B232002001 Insulated Pipe Red 6mm 16 x 2 - 50m - 6mm B232002002 Insulated Pipe Red 6mm 16 x 2 - 100m - 6mm B232004001 Insulated Pipe Red 6mm 20 x 2 - 50m - 6mm B232005001 Insulated Pipe Red 6mm 26 x 3 - 25m - 6mm Code Description Size B232011001 Insulated Pipe Red 9mm 16 x 2 - 50m - 9mm B232008001 Insulated Pipe Red 9mm 20 x 2 - 50m - 9mm B232009001 Insulated Pipe Red 9mm 26 x 3 - 25m - 9mm B232010001 Insulated Pipe Red 9mm 32 x 3 - 25m - 9mm Code Description Size B222003001 Corrugated Pipe Red 16 x 2 - 50m B222001001 Corrugated Pipe Red 16 x 2 - 100m B222004001 Corrugated Pipe Red 20 x 2 - 50m B222005001 Corrugated Pipe Red 26 x 3 - 50m
Factor:: COMAP SA

Company Name
COMAP SA
Address
16 AVENUE PAUL SANTY 69008 LYON
Postcode
FRANCE

View All Listings by this Company

WRAS Approval Number: #2003015

Range of stainless-steel press sleeve fittings for use with WRW compatible Multi-Layer Pipe (PE-RT Type II/AL/PE-RT II). Connection is achieved via U profile press jaws. Fittings incorporate EPDM ‘O’-rings. Maximum working pressure 10.0 bar. Maximum operating temperature 70°C.

Section:: 1100 Fittings and Pipe - Compatible Systems
Section Subtitle:: Unless specified in the individual approval, the products within this section are not suitable for below ground use
WRAS Approval Number:: 2003015
Expiry date:: 31/03/2025
Size:: See model
Marking:: Multitubo, temperature and pressure, size, material, DVGW, made in Germany and date of manufacture (day/minute/year/hour/month) on pipe. Multitubo logo on press sleeve and fitting body.
Installation Requirements:: R001
Model:: Press adaptor M22075 (75mm to 110mm Crimp Fitting) M22090 (75mm to 110mm Crimp Fitting) M22110 (75mm to 110mm Crimp Fitting) Base body Elbow 90° M23000 (75mm to 110mm Crimp Fitting) Base body elbow 45° M23200 (75mm to 110mm Crimp Fitting) Base body T-Piece M25000 (75mm to 110mm Crimp Fitting) Connector MT M20212 (75mm to 110mm Crimp Fitting by 2 ½” BSP (M)) M20300 (75mm to 110mm Crimp Fitting by 3” BSP (M)) Connector FT M21034 (75mm to 110mm Crimp Fitting by ¾” BSP (F)) M21200 (75mm to 110mm Crimp Fitting by 2” BSP (F)) M21212 (75mm to 110mm Crimp Fitting by 2 ½” BSP (F)) M21300 (75mm to 110mm Crimp Fitting by 3” BSP (F)) Blind cap M29500 (75mm to 110mm Crimp Fitting) Gripper clamp with sealing M28000 (Adjustable 75mm to 110mm) M28010 (Adjustable 75mm to 110mm)
Factor:: DW Verbundrohr GmbH

Company Name
DW Verbundrohr GmbH
Address
Langer Rain 38, D-97437 Hassfurt
Country
Germany
Phone
+49 (0) 9521 95356-0

View All Listings by this Company

WRAS Approval Number: #2005323

Range of brass press fittings with EPDM ‘O’-rings for use with Rifeng B1 PEX/AL/PEX multilayer pipe. Maximum working pressure 10.0 bar. Maximum operating temperature 95°C.

Section:: 1100 Fittings and Pipe - Compatible Systems
Section Subtitle:: Unless specified in the individual approval, the products within this section are not suitable for below ground use
WRAS Approval Number:: 2005323
Expiry date:: 31/05/2025
Size:: 12mm, 16mm, 20mm , 25mm, 26mm & 32mm
Marking:: Size, Rifeng, date of manufacture (YYYYMMDD) on body of fittings. Size, Rifeng, date of manufacture and time (YYYYMMDDHHMMSS) & batch no on pipe.
Installation Requirements:: R001
Model:: F1C compression fittings & F5 press fittings for use with B1 multilayer PEX/AL/PEX pipe. Models added July 2022: Added F5 Connector core press fittings: 16mm – 25mm. Added F1 Connector core compression fittings: 16mm – 25mm. Added F5 Wall plated female elbow press fittings: 16mm – 20mm.
Factor:: Rifeng Enterprise Group Co.,Ltd.

Company Name
Rifeng Enterprise Group Co.,Ltd.
Address
Rifeng Building No16 Zumiao Road Foshan City
Country
Guangdong Province 528000

View All Listings by this Company
