#1905080

Dutypoint ‘VMV’ range of cold water supply booster sets, incorporating 2 to 8 pumps with a modular stainless steel manifold system. VMV2, VMV3 and VMV4 pump sets are available with DN80 to DN150 manifolds depending on application. VMV5, VMV6, VMV7 and VMV8 pump sets are available with DN150 to DN200 manifolds, depending on application. The product incorporates gate valves on the suction and discharge manifolds, and non-return valves, expansion vessels, isolation valves, a pressure gauge and transducers on the discharge manifold. Maximum working pressure 16.0 bar. Cold water supply only.

Section:
1610 Pumps
Section Subtitle:
Wholesome water use.
WRAS Approval Number:
1905080
Expiry date:
31/05/2024
Size:
Flanged manifold connections on suction and discharge manifolds Sizes 80mm to 200mm
Marking:
Dutypoint, model number and technical information on adhesive label on control box.
Installation Requirements:
R001 R415
Model:
VMV(i)-(ii)-(iii)(iv) Where: (i) = Number of pumps 2-8 (ii) = Nominal Flow Rate (l/sec) (iii) = Pump/Inverter Manufacturer denoted by the letter V or H, (iv) = Motor size (kWx10) As an example: VMV2-15-V110 Number of pumps = 2 Nominal flowrate (l/sec) = 15 Pump inverter manufacturer = V for Vasco, H for Hydrovar Motor size (kW x 10)
Manufacturer:
Dutypoint Ltd.
Company Name
Dutypoint Ltd.
Address
Olympus Park, Quedgeley Gloucestershire
Postcode
GL2 4DH

View All Listings by this Company

Print This Approval


#1906076

`Monsoon` range of universal single & twin, shower booster pumps with brass bodies, brass impellers and nitrile seals. Pumps incorporate an anti-surge device, flow switch and a pressure vessel. The outlets incorporate isolation valves, plastic strainers and approved single check valve cartridges however, the complete assembly has not been fully tested to demonstrate that it provides adequate backflow protection. Models 46414, 46498, 46413, 46505, 46411, and 46412: maximum working pressure 6.0 bar Model 46410: maximum working pressure 3.0 bar. Maximum operating temperature 65°C.

Section:
1610 Pumps
Section Subtitle:
Wholesome water use.
WRAS Approval Number:
1906076
Expiry date:
30/06/2024
Note:
Expansion vessels should be installed in the vertical orientation and located so that the length of the connecting pipework is kept to a minimum.
Size:
Stainless steel braided EPDM lined hoses with 22mm push fit female inlet/outlet connections incorporating Isolation valve. ROI Models - Stainless steel braided EPDM lined hoses with 21mm push fit female inlet/outlet connections incorporating Isolation valve. EXP Models - Stainless steel braided, EPDM lined hoses with ¾” captive nut x ¾” BSP (F) connections
Marking:
Stuart Turner on adhesive label.
Installation Requirements:
R001 R120 R415
Model:
Monsoon U1.5 bar Twin 46505 Monsoon U2.0 bar Single 46498 Monsoon U2.0 bar Twin 46480 Monsoon U4.5 bar Single 46414 Monsoon U3.0 bar Single 46413 Monsoon U4.55 bar Twin 46412 Monsoon U4.0 bar Twin 46411 Monsoon U3.0 bar Twin 46410 Monsoon U3.0 bar Twin 44427 Monsoon U2.0 bar Twin 44426 Monsoon U2.0 bar Single 44425 Monsoon U2.0 bar Twin, OEM 44340 Monsoon U1.5 bar Twin, 44753 Monsoon U1.5 bar Twin 46505ROI Monsoon U2.0 bar Single 46498ROI Monsoon U2.0 bar Twin 46480ROI Monsoon U4.5 bar Single 46414ROI Monsoon U3.0 bar Single 46413ROI Monsoon U4.5 bar Twin 46412ROI Monsoon U4.0 bar Twin 46411ROI Monsoon U3.0 bar Twin 46410ROI Monsoon U1.5 bar Twin 46505EXP Monsoon U2.0 bar Single 46498EXP Monsoon U2.0 bar Twin 46480EXP Monsoon U4.5 bar Single 46414EXP Monsoon U3.0 bar Single 46413EXP Monsoon U4.5 bar Twin 46412EXP Monsoon U4.0 bar Twin 46411EXP Monsoon U3.0 bar Twin 46410EXP
Manufacturer:
Stuart Turner Ltd
Company Name
Stuart Turner Ltd
Address
47 Market Place Henley-on-Thames Oxfordshire
Postcode
RG9 2AD
Country
United Kingdom
Phone
01491 572655

View All Listings by this Company

Print This Approval


#1906092

Range of multistage centrifugal pumps with stainless steel bodies and impellers. Maximum working pressure 25.0 bar. Maximum operating temperature 100ºC.

Section:
1610 Pumps
Section Subtitle:
Wholesome water use.
WRAS Approval Number:
1906092
Expiry date:
30/06/2024
Marking:
KQ on body. KQ, model, date of manufacture (YYYY/MM) & Shanghai Kaiquan Pumps on data label.
Installation Requirements:
R001 R415
Model:
KQDQ40-10C – DN40 flanged inlet and outlet. KQDQ50-12C – DN50 flanged inlet and outlet. KQDQ50-15C – DN50 flanged inlet and outlet. KQDQ50-20C – DN50 flanged inlet and outlet. KQDQ65-32C – DN65 flanged inlet and outlet.
Manufacturer:
Shanghai Kaiquan Pump (Group) Co. Ltd.
Company Name
Shanghai Kaiquan Pump (Group) Co. Ltd.
Address

View All Listings by this Company

Print This Approval


#1906314

Range of multistage close coupled centrifugal pumps incorporating 304 or 316 stainless steel cased bodies and impellers. Maximum working pressure 10.0 bar. Cold water use only.

Section:
1610 Pumps
Section Subtitle:
Wholesome water use.
WRAS Approval Number:
1906314
Expiry date:
30/06/2024
Size:
1” BSP (F) - 3” BSP (F). DN50 - DN80 flange.
Marking:
Calpeda, model, and other technical information on adhesive label on motor housing.
Installation Requirements:
R001 R415
Model:
MXH Series: (304 stainless models) MXH/MXHM 202, 203, 204, 205, 206. MXH/MXHM 402, 403, 404, 405, 406. MXH/MXHM 802, 803, 804, 805. MXH/MXHM 1602, 1603, 1604, 1605, 1606. MXH/MXH-F 2001, 2002, 2003, 2004, 2005. MXH/MXH-F 3201, 3202, 3203, 3204. MXH/MXH-F 4801, 4802, 4803. (316 stainless models) MXHL/MXHLM 202, 203, 204, 205, 206. MXHL/MXHLM 402, 403, 404, 405, 406. MXHL/MXHLM 802, 803, 804, 805. A letter may be added at the end of the pump model to identify the current motor model fitted to the pump e.g. MXH203* where * can be E, /A, /B, /C etc. Example MXH203/A, MXH204/B etc.
Manufacturer:
Calpeda S.p.A
Company Name
Calpeda S.p.A
Address
Via Roggia Di Mezzo 39 36050 Montoro Vicentino Vicenza
Country
Italy

View All Listings by this Company

Print This Approval


#1906096

Range of multi-stage pumps with stainless steel bodies (PVMX models) or black coated cast iron bodies (PVM models), stainless steel impellers, EPDM gaskets and seals. Maximum working pressure: Cast iron body round or oval flange: DN25-32 = 25.0 bar, DN40 = 16.0 bar. Stainless steel body round flange: DN40-50 = 16.0 bar (PVMX-10 (stages 1-16), PVMX-15 (stages 1-10), PVMX-20 (stages 1-10). DN25-50 = 25.0 bar (PVMX-1 (stages 2-36), PVMX-3 (stages 2-36), PVMX-5 (stages 2-36), PVMX-10 (stages 17-22), PVMX-15 (stages 12-17), PVMX-20 (stages 12-17). DN65 = 16.0 bar (PVMX-32 (stages (1-1)-7), 30.0 bar (PVMX-32 (stages (8-2)-14). Stainless steel body Victaulic connection: DN32 = 25.0 bar. Maximum operating temperature 100°C.

Section:
1610 Pumps
Section Subtitle:
Wholesome water use.
WRAS Approval Number:
1906096
Expiry date:
30/06/2024
Size:
(Number in brackets denotes Nominal Flow m³/h) PVM F Range Size: Round Flange available in sizes DN25 & DN32 (01, 03 & 05), DN40 (10). PVM A Range Size: Oval Flange available in sizes DN25 & DN32 (01, 03 & 05), DN40 (10). PVMX F Range Size: Round Flange available in sizes DN25 & DN32 (01, 03 & 05), DN40 (10), DN50 (15 & 20), DN65 (32). PVMX V Range Size: Victaulic Connection available in size R1¼ DN32 (01, 03 & 05).
Marking:
Pentair Logo, model, PN, maximum temperatures and product information on adhesive label on body. Flow arrow on body.
Installation Requirements:
R001 R415
Model:
PVM F Range – Cast Iron Body, Round Flanges. PVM A Range – Cast Iron Body, Oval Flanges. PVMX F Range – Stainless Steel Body, Round Flanges. PVMX V Range – Stainless Steel Body, Victaulic Connections. Key: NAME x-y(-z) C P M Frq (Model Code for Key, explained below) NAME = Model (PVM or PVMX) x = Nominal Flow m³/h y = Number of Stages z = Reduced Diameter Stages (Part of total if any, supressed if 0) C = Connection Type (F = Round Flanges, A = Oval Flanges, V = Victaulic Connections) P = Phases (T or 3/400/690 or 3x230/400 = Three Phase, M or 1x230 = Single Phase) M = Motor Efficiency (IE1, IE2 or IE3) Frq = Frequency (50 = 50Hz, 6- = 60Hz) E.g. PVMX-15-4-F-T-IE2-50
Factor:
Pentair International S.a.r.l.
Company Name
Pentair International S.a.r.l.
Address
Avenue de Sévelin 20, CH - 1004 Lausanne
Country
Switzerland

View All Listings by this Company

Print This Approval


#1906126

Twin, shower booster pump with brass bodies, brass impellers and nitrile seals. Pumps incorporate an anti-surge device, flow switch and a pressure vessel. The outlets incorporate isolation valves, plastic strainers and approved single check valve cartridges however, the complete assembly has not been fully tested to demonstrate that it provides adequate backflow protection. maximum working pressure 3.0 bar. Maximum operating temperature 65°C.

Section:
1610 Pumps
Section Subtitle:
Wholesome water use.
WRAS Approval Number:
1906126
Expiry date:
30/06/2024
Note:
Expansion vessels should be installed in the vertical orientation and located so that the length of the connecting pipework is kept to a minimum.
Size:
Stainless steel braided EPDM lined hoses with 22mm push fit female inlet/outlet connections incorporating Isolation valve.
Marking:
ARJO U3.0 BAR TWIN, 44344 & TECHNICAL INFORMATION ON ADHESIVE LABEL ON PUMP
Installation Requirements:
R001 R120 R415
Model:
44344 ARJO U3.0 SHOWER BOOSTER PUMP
Factor:
Aquamo Ltd.
Company Name
Aquamo Ltd.
Address
Applewick, Longdon, Tewkesbury
Postcode
GL20 6AX
Country
Gloucestershire

View All Listings by this Company

Print This Approval


#1909097

Range of IVS and DE Booster pumps and manifolds consisting of multistage centrifugal pumps, 25L expansion vessels, spherical valves and gauges. Some models incorporate approved non-return valves (not suitable for backflow protection). Others incorporate an approved check valve cartridge, however, the complete product has not been fully tested to demonstrate it provides backflow protection. Maximum working pressure 16.0 bar. Cold water use only

Section:
1610 Pumps
Section Subtitle:
Wholesome water use.
WRAS Approval Number:
1909097
Expiry date:
30/09/2024
Size:
IVS models: threaded: 2” - 4” BSP male or flanged: DN150 – DN300. DE models: flanged DN50 – DN200.
Marking:
Armstrong Logo, model & technical information on data plate on booster set baseplate.
Installation Requirements:
R001 R415
Model:
6800 DE & 6800 IVS - Multi-pump Variable Speed Booster Sets with the following sizes: 2-5 Pump VMS 4, 6, 10, 15, 25, 40, 60, 85 (VMS 4 is only in 6800 DE boosters) From October 2020 models are available with an alternative pump: 6800 DE & 68XX IVS - Multi-pump Variable Speed Booster Sets with the following sizes: 2-5 Pump VMS 4, 6, 10, 15, 25, 40, 60, 85 (VMS 4 is only in 6800 DE boosters, VMS 85 is only in 68XX IVS boosters)
Manufacturer:
Armstrong Fluid Technology
Company Name
Armstrong Fluid Technology
Address
1 Woverton Street Manchester M11 2ET
Postcode
M11 2ET
Country
United Kingdom

View All Listings by this Company

Print This Approval


#1910306

Range of multistage vetical water pumps with stainless steel bodies and impellers incorporating EPDM ‘o’ rings and seals. With various nominal flow rates depending on number of impellers and inlet connection size. Maximum working pressure 16.0 bar. Maximum operating temperature 50°C

Section:
1610 Pumps
Section Subtitle:
Wholesome water use.
WRAS Approval Number:
1910306
Expiry date:
31/10/2024
Marking:
WILO on pump body.
Installation Requirements:
R001 R415
Model:
MVIS Nominal flow rate - 2 m3/h with 2 to 10 impellers – inlet connection 1 1/4” BSP(F), 4 m3/h with 2 to 10 impellers – inlet connection 1 1/4” BSP(F) 8 m3/h with 2 to 6 impellers – inlet connection 2” BSP(F) The product name of the MVIS range for which approval is sought is built as: Example :MVIS403-1/16/K/3-400-50-2 Where: ‘4’ Nominal flow (m3/h) (other possible values are 2 and 8) ‘03’ Number of Impeller (other posible values see table above)) ‘-1’ Pump housing in stainless steel AISI 304 ‘/16’ Maximal pressure (bar) ‘/K’ EPDM material for O ring ‘/3-400-50-2’ Motor definition : Three phases 400 Volts-50 HZ 2poles MVISE range Nominal flow rate - 2 m3/h with 6 an 10 impellers – inlet connection 1 1/4” BSP(F), 4 m3/h with 4,6 and 10 impellers – inlet connection 1 1/4” BSP(F) 8 m3/h with 3 and 6 impellers – inlet connection 2” BSP(F) The product name of the MVIS range for which approval is sought is built as: Example :MVISE210-1/16/K/3-2-3G Where: ‘2’ Nominal flow (m3/h) (other possible values are 2 and 8) ‘10’ Number of stage (other posible values see table above) ‘-1’ Stainless steel AISI 304 ‘ /16’ Maximal pressure (bar) ‘/K’ EPDM material ‘/3-2-3G’ 3 phases 2 poles third generation of converter
Factor:
Wilo SE
Company Name
Wilo SE
Address
Werk Hof, Heimgartenstr. 1-3, 95030 Hof/Saale
Country
Germany

View All Listings by this Company
Manufacturer:
Wilo Salmson France
Company Name
Wilo Salmson France
Address
80 Boulevard de l'Industrie CS 90527 F-53005 LAVAL Cedex
Country
France
Phone
+33 2 43 59 54 00

View All Listings by this Company

Print This Approval


#1910316

Range of booster sets consisting of two to four electronically controlled pumps which are connected in parallel and mounted on a common base provided with suction and discharge manifolds, spherical valves, expansion vessels and pressure gauge/transducers and non return valves. Cold water use only. Maximum working pressure 10 bar where the MTPA vessel is installed. 16 bar where the MTMB vessel is used.

Section:
1610 Pumps
Section Subtitle:
Wholesome water use.
WRAS Approval Number:
1910316
Expiry date:
31/10/2024
Size:
SP2V – 2” BSP(M) inlet x 1 ½” BSP(M) outlet SP3V – 2 ½” BSP(M) inlet x 1 ½” BSP(M) outlet SP4V – 3” BSP(M) inlet x 1 ½” BSP(M) outlet
Marking:
Model, year of manufacture YYYY, serial number and Fluid Water or Stuart Turner on adhesive label on rear of control panel
Installation Requirements:
R001 R415
Model:
Cold Water booster sets series SP2V, SP3V, SP4V (Horizontal pump version) Cold Water booster sets series SP2V, SP3V, SP4V (Vertical pump version) Where the following codes can be applied: SP = Product Range Name A = Number of Pumps (2,3 or 4 pumps) V = Variable Speed B = Pump Model (Horizontal or Vertical) C = Controller type (MAB-MARB) D = Power input (T = 3 Phase – M = 1Phase) E = Vessel Capacity (24= 1 of 24 litre Vessel), (48= 2 of 24 litre Vessels), (72= 3 of 24 litre Vessels), (96= 4 of 24 litre Vessels) Example: SP2V-5HM06S-MAB-T/24 SP = Product Range Name A = 2 Pumps V = Variable Speed B = 5HM06S C = MAB D = T – 3 Phase E = Vessel Capacity 24L
Factor:
Stuart Turner Ltd
Company Name
Stuart Turner Ltd
Address
Unit 6 North Point Business Park Selby Road Eggborough East Yorkshire
Postcode
DN14 0JT
Country
United Kingdom
Phone
01977 801911
General Email
aquaboost@stuart-turner.co.uk

View All Listings by this Company

Print This Approval


#1910013

Range of booster sets incorporating pumps, expansion vessels, Isolation valves and non-return valves (not suitable for backflow protection). Maximum working pressures: SI boost 16.0 bar, CO R 10.0 bar. Cold water use only.

Section:
1610 Pumps
Section Subtitle:
Wholesome water use.
WRAS Approval Number:
1910013
Expiry date:
31/10/2024
Size:
DN100, DN125, DN150 & DN200 flange. 1½”, 2”, 2 ½" & 3” BSP.
Marking:
Wilo logo, model name, maximum temperature and PN rating on adhesive label on body.
Installation Requirements:
R001 R415
Model:
COR 2-3MHI*** SCe-EM COR 2-3MHIE*** SCe-DM SIBOOST SMART 2-4 HELIX VE**** SIBOOST SMART 2-4 HELIX V**** SIBOOST SMART 2-4 EXCEL **** Note: **** = Pump Hydraulics (flow and/ stages)
Manufacturer:
Wilo UK
Company Name
Wilo UK
Address
Second Avenue Centrum 100 Burton on Trent
Postcode
DE14 2WJ
Country
Staffordshire

View All Listings by this Company

Print This Approval
