Filling loop assembly consisting of an in-line isolation valve, an in-line double check valve assembly (suitable for back flow protection against fluid category 3) that incorporates an isolation valve and a stainless-steel braided EPDM lined hose. Maximum working pressure 10.0 bar. Maximum operating temperature 85°C.
Non-metallic materials and components comply with BS6920 at 85°C
Range of stainless-steel(SS304L) press fittings with EPDM ‘O’-rings for use with stainless-steel pipe to EN10312. Maximum working pressure 16.0 Bar. Maximum operating temperature 85°C.
U Profile range of press fittings incorporating EPDM ‘O’-rings. For use with Mingshi (S-1-0509/10/11/12/17/13) PEX-AL-PEX pipe. Maximum working pressure 10.0 bar. Maximum operating temperature 95°C
Multipipe range of M type press copper crimp fittings with EPDM ‘O’-rings for use with copper tube manufactured to EN 1057. The joints are achieved by means of a crimping tool. For above ground use. Maximum working pressure: 16.0 bar. Maximum operating temperature: 85°C
Range of stainless steel (SS304 or SS316L) press-fit fittings incorporating EPDM ‘O’-rings for use with *‐KJ600304 and *-KJ600316 stainless steel pipes. The "KJ6278" prefix models also incorporates an EPDM gasket on the union nut. Jointing is achieved via a crimping tool using a ‘M’ profile. For above and below ground use. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
‘Numepress’ range of stainless-steel crimp fittings incorporating EPDM and ‘O’-rings for use with 'Numepress' stainless steel pipe. Connection is achieved via M profile press jaws. For above ground use only. Maximum working pressure 16.0 bar. Maximum operating temperature 95°C.
Range of copper press fittings with EPDM seals for use with copper pipe (manufactured to EN1057). Jointing is achieved via a crimping tool using a ‘M’ profile. Maximum working pressure 16.0 bar. Maximum operating temperature 99°C.
‘HLBRxx’ range of brass or DZR brass compression fittings for use with copper pipe (manufactured to EN 1057). The HLBRTC‐1 tank connector, HLBRSS‐1 and HLBRBS‐1 tap connectors all incorporate an EPDM washer. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
‘3600xx’ range of brass compression fittings for use with copper pipe (manufactured to EN 1057). The 360014 tank connector, 360013 and 360017 tap connectors all incorporate an EPDM washer. Maximum working pressure 10.0 bar. Maximum operating temperature 85°C.
"PRESSTITE" range of press fittings with nickel plated brass bodies incorporating EPDM ‘O’-rings and stainless steel crimp sleeves for use with PEX/AL/PEX multilayer pipe (manufactured to EN ISO 21003). Jointing is achieved by a TH crimping profile. For above ground use only. Maximum working pressure 10.0 bar. 20 & 26mm pressfit sizes cold water use only. Threaded and pressfit 16mm size maximum operating temperature 95°C. From June 2025: The 20 & 26mm pressfit sizes maximum operating temperature 95°C.
Range of stainless-steel press fittings (SUS304 or 316L) with EPDM ‘O’-rings for use with stainless-steel pipe (SUS304 or 316L EN 10312), using an ‘M’ press profile. Maximum working pressure 16.0 Bar. Maximum operating temperature 85°C.
‘F17’ range of brass press fittings with EPDM ‘O’-rings for use with PEX/AL/PEX multilayer pipe (manufactured to EN ISO 21003). Jointing is achieved via a crimping tool using either a ‘U’, ‘TH’ or ‘H’ profile. Maximum working pressure 10.0 bar. Cold water use only.
Range of ‘M’ profile copper press fittings with EPDM ‘O’-rings for use with copper pipes (manufactured to EN 1057). Jointing is achieved via a crimping tool using a ‘M’ profile. For above and below ground use. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of brass press fittings with EPDM ‘O’-rings for use with PEX/AL/PEX multilayer pipe (manufactured to EN ISO 21003). Jointing is achieved via a crimping tool using either a ‘U’, ‘TH’ or ‘H’ profile. Maximum working pressure 10.0 bar. Cold water use only.
Range of end feed copper fittings for use with copper pipes (manufactured to EN 1057). The 5043G series and 5002G series models incorporate an EPDM ‘O’-ring on the captive nut connection. For above and below ground use. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of water meters with plastic bodies and EPDM ‘O’-rings. The inlets incorporate a plastic strainer. Maximum working pressure 10.0 Bar Maximum operating temperature 50.0°C
Range of in-line water meters incorporating bronze copper alloy bodies and EPDM O rings. Maximum working pressure 10.0 Bar Maximum operating temperature 30.0°C
Shock arrestors with a copper body, plastic shuttle and EPDM ‘O’-rings. Maximum working pressure 10.0 bar. Maximum operating temperature 85°C.
Range of flow sensors incorporating either brass, plastic or stainless steel bodies & EPDM ‘O’-rings. Maximum working pressure 10.0 bar for models VVXA, VVXC, VVXB. Maximum working pressure 16.0 bar for models VVXD & VVXE. Maximum operating temperature 90°C.
Range of EPDM expansion joints with flanged end conenctors. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of multistage centrifugal pumps with stainless-steel housings, stainless-steel impellers and EPDM ‘O’-rings. Maximum working pressure 10.0 bar. Maximum operating temperature 85°C.
CM(E) range of electronically operated pumps available in stainless steel, (‘EN 1.4301/AISI304’ or ‘EN 1.4401 /AISI316’) and cast iron. The pumps are supplied with Sic-Sic mechanical shaft seals and FKM or EPDM seals. Maximum operating parameters: Cast iron models: Maximum working pressure 6.0 bar @ 90°C. Maximum working pressure 10.0 bar @ 40°C. Stainless steel models (not self-priming variants): Maximum working pressure 10.0 bar @ 99°C. Maximum working pressure 16.0 bar @ 90°C. Stainless steel self-priming models (CM(E) 1, 3 & 5 (AISI 304) only): Maximum working pressure 10.0 or 16.0 bar @ 60°C.
Range of brass shower arms and plastic shower heads (various finishes) incorporating EPDM seals and ‘O’-rings, silicone seals and spray insert. The 26 469 xxx model is ceiling mounted & 26 470 xxx model is wall mounted. Maximum operating temperature 60°C. Open outlet use only.
Range of chromium plated stainless steel or brass interlocked shower hoses with an optional PVC outer layer. Incorporating either a PVC or TPE inner hose and EPDM gaskets. Maximum operating temperature 60°C.
Range of chromium plated stainless steel or brass interlocked shower hoses with an optional PVC outer layer. Incorporating either a PVC or TPE inner hose and EPDM gaskets. Maximum operating temperature 60°C.
Range of EVOX stainless steel or grey nylon braided polyethylene lined flexible hose assemblies incorporating EPDM ‘O’-rings with various end connections. Maximum working pressure 10.0 bar. Maximum operating temperature 70°C.
‘KM1001 series’ of stainless steel braided EPDM lined flexible hose assemblies. Compression end connections are for use with copper pipes (manufactured to EN 1057). Compression end connections are also available with brass bodied (nickel plated) isolation valves incorporating a chrome plated brass ball. Maximum working pressure 10.0 bar. Maximum operating temperature 85°C.
Range of stainless-steel braided, EPDM lined flexible hose assemblies. Maximum working pressure 10.0 bar. Maximum operating temperature: 60°C.
Range of EPDM braided hoses (various options) and optional end connections. Maximum working pressure 10.0 bar. Maximum operating temperature 85°C.
Range of Stainless-Steel braided EPDM lined flexible hose assemblies with various end connections. For use with copper pipe manufactured to EN1057 Maximum working pressure; 16 Bar Maximum operating temperature; 85°C
Range of stainless-steel braided EPDM lined flexible hose assemblies with a variety of end connections. Some models incorporate push-fit isolation valves. Compression connection to be used with DM LLDPE pipes or PEX barrier pipe manufactured to BS7291-3. Maximum working pressure and maximum operating temperature 12 bar @cold water use only & 7 bar @ 65°C.
‘DG10E PF series’ of stainless steel braided EPDM lined flexible hose assemblies with EPDM ‘O’-rings or gaskets available with a variety of end connections. The DN10 bore 15mm push fit connection is also available with a screwdriver operated isolation valve. Push-fit connections are for use with copper pipes (manufactured to EN 1057) and PEX pipes (manufactured to BS 7291-3). Maximum working pressure 10.0 bar. Cold water use only.
Range of flexible corrugated stainless-steel tubing with white plastic covering. Compression connections are for use with copper pipe (manufactured to EN 1057). Captive nut end connections incorporate an EPDM gasket. 2BACa0504 prefix models incorporate a servicing valve (chromium plated brass body with brass ball) on the compression end connection. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
502 series of automatic air venting valves with brass bodies, plastic float and EPDM ‘O’-rings. For non-potable water use only. Maximum working pressure 10.0 bar. Maximum operating temperature see models.
Range of air venting valves with a blue epoxy coated ductile iron body, plastic float, EPDM ‘O’-rings and seals. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Wall mounted thermostatic bar, shower valve, incorporating a ceramic disc headwork controlling the flow with a dome type operating member. The temperature is controlled independently via a thermostatic cartridge with a dome type operating member which incorporates a manual override button. Each inlet incorporates a combined EPDM washer and stainless-steel strainer and an approved check valve cartridge; however, the complete product has not been fully tested to demonstrate it provides backflow protection. The product is also supplied with a riser rail, shower hose and handset. Maximum working pressure 5.0 bar. Maximum operating temperature 60°C.
UNIWAT Range of wafer butterfly valves incorporating blue epoxy coated ductile iron bodies, EPDM seats and stainless-steel discs. The products are supplied with lever or gear operating members. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of wafer, lugged and flanged butterfly valves with blue, black or red epoxy coated ductile iron bodies, zinc coated (galvanised) discs and EPDM seats. F700L & F703L models incorporate a hand wheel operating members and F700G & F703G incorporate a worm gear operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 70°C.
Range of butterfly valves incorporating blue or green epoxy coated ductile iron bodies, discs and EPDM seals. Maximum working pressure 16.0 Bar Maximum operating temperature 65.0°C
Range of wafer or lugged butterfly valves incorporating blue epoxy coated ductile iron bodies, EPDM seats and stainless-steel discs. The LTDX71X-16Q DN40-150 size models are lever operated; all other models and sizes are gear operated. Maximum working pressure 10.0 bar or 16.0 bar. Maximum operating temperature 100°C.
Range of wafer, lugged and flanged butterfly valves with blue, black or red epoxy coated ductile iron bodies, zinc coated (galvanised) discs and EPDM seats. F700L & F703L models incorporate a hand wheel operating members and F700G & F703G incorporate a worm gear operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 70°C.
Range of butterfly valves incorporating blue epoxy coated ductile iron bodies, stainless-steel discs and EPDM seats. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of wafer, lug type and double flanged butterfly valves incorporating blue epoxy coated ductile iron bodies, with stainless steel (CF8 or CF8M) discs and an EPDM seat. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of double flanged butterfly valves with blue, lavender or bright blue epoxy coated ductile iron bodies, EPDM seats and either white or red epoxy coated ductile iron or stainless steel discs. The products are supplied with bare shaft without operating members. Maximum working pressure 16.0 bar. Maximum operating temperature 60°C.
Range of lugged butterfly valves incorporating black epoxy coated ductile iron bodies, EPDM seats and stainless-steel discs. From March 2023 the valves are also available with blue epoxy coated ductile iron bodies. The products are operated by: Gearbox or DRV gearbox operating members, or bare shaft without operating members. Maximum working pressures: RBV020-H models: 16.0 bar, RBV-S/PN25 models: 25.0 bar Maximum operating temperature 85°C.
Range of butterfly valves with blue epoxy coated ductile iron bodies, stainless-steel discs and EPDM or PTFE seats (see models). Maximum working pressure 16.0 Bar or10.0 Bar (see models). Maximum operating temperature 85°C.
Range of butterfly valves with blue epoxy coated ductile iron bodies and stainless-steel discs incorporating EPDM rubber seats. (DN40 - DN200) incorporate a lever type operating member and (DN250 – DN500) incorporates a hand wheel type operating member. Maximum working pressure - 16 Bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of wafer or lugged butterfly valves incorporating blue epoxy coated ductile iron bodies, EPDM seats and stainless-steel discs. The LTDX71X-16Q DN40-150 size models are lever operated; all other models and sizes are gear operated. Maximum working pressure 10.0 bar or 16.0 bar. Maximum operating temperature 100°C.
Range of lever operated butterfly valves with blue epoxy coated cast iron bodies, stainless steel discs and EPDM ‘O’ rings and seals. Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of butterfly valves with blue epoxy coated ductile iron bodies, stainless-steel discs and EPDM or PTFE seats (see models). Maximum working pressure 16.0 Bar or10.0 Bar (see models). Maximum operating temperature 85°C.
A range of non-return valve with blue epoxy coated ductile iron bodies, stainless-steel disc and EPDM seats. Maximum working pressure 16.0 Bar Maximum operating temperature 85.0°C
Range of dual plate non-return valves with blue epoxy coated ductile iron bodies, stainless steel discs and an EPDM seat. Maximum working pressure 16.0 bar. Maximum operating temperature 99°C.
Range of spring-loaded resilient trim, non-return valves with blue epoxy coated ductile iron bodies, stainless steel discs, PTFE stem gaskets and EPDM seat. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of dual plate non-return valves with blue epoxy coated ductile iron bodies, stainless steel discs and an EPDM seat. Maximum working pressure 16.0 bar. Maximum operating temperature 99°C.
Range of dual plate non-return valves with blue epoxy coated ductile iron bodies, stainless steel discs and an EPDM seat. Maximum working pressure 16.0 bar. Maximum operating temperature 99°C.
Range of pilot operated pressure reducing control valves with ductile iron bodies (blue epoxy coating) and EPDM diaphragm and O-rings. The products are supplied with auxiliary fittings: spheerical valves, pressure gauges, a pilot valve and a needle valve. Maximum inlet supply pressure 25.0 bar. The outlet pressure is adjustable between 1.5 - 17 bar. Maximum operating temperature 85°C.
Range of adjustable, pilot operated pressure reducing control valves with ductile iron bodies (blue epoxy coated) EPDM diaphragms, stainless steel tubing, isolation valves and needle valves. The product also incorporates both upstream and downstream pressure gauges. Maximum working pressure 10 Bar Maximum operating temperature 85°C Maximum outlet pressure 2 – 8bar
Solenoid valve with a brass body, EPDM diaphragm and ‘O’-rings. Maximum operating pressure 10.0 bar. Cold water use only.
Solenoid valve with a plastic body, incorporating an EPDM diaphram and EPDM sealing rings. Maximum working pressure 8.0 bar. Maximum operating temperature 65°C.
Range of inline or angled screwdriver and lever operated isolation and servicing valves (See models), (chrome plated brass bodies) and ball, incorporating EPDM ‘O’-rings. For use with copper pipe manufactured to EN1057 Maximum working pressure: 10 bar. Maximum working temperature: 99°C.
Range of inline brass bodied or chrome plated brass bodied spherical valves, with a chrome plated brass ball and EPDM ‘O’-rings. SVB66MB and SV44MB models are lever operated. SV66MBC and SVT64MBC are screwdriver operated. The products are for use with PE-X pipe (manufactured to BS 7291-3), PB pipe (manufactured to BS 7291-2) and copper pipe (manufactured to EN 1057). Maximum working pressure 10.0 bar. Cold water use only. From March 2026: Maximum operating temperature 65°C.
Range of spherical valves with various means of operation some via handle some with actuators, see models, comprising of a bronze valve body, spindle and ball valve, and EPDM O rings Maximum working pressure 16 bar Maximum operating temperature 90˚C.
Spherical valves incorporating a brass bodies and ball, PTFE seat, EPDM and NBR ‘O’-rings. The valve 8 718 657 822 incorporates a branch which is intended to connect to the primary circuit of a combination boiler. Maximum working pressure 10.0 Bar. Cold water use only.
Range of angled (S0273 and S0274 suffix models only) or in-line spherical valves with a nickel plated brass body, chromium plated brass ball and PTFE or EPDM seats. The products are either screwdriver operated or supplied with a T-handle (S0233BH-1 and S0233BH-2 models only). Compression ends are for use with copper pipes (manufactured to EN1057). Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of screwdriver operated spherical valves incorporating brass bodies, brass balls (chrome plated) and EPDM ‘O’-rings. For use with copper pipe to (EN1057). Maximum working pressure 16 Bar Maximum operating temperature 85°C.
Range of spherical valve with a brass body (chrome plated) and chrome plated brass ball, incorporating EPDM o-rings. Compression connection to be used with copper pipe EN1057. Maximum working pressure 16 Bar. Maximum operating temperature 85°C.
In-line spherical valve with a chrom eplasted DZR brass body, brass ball and EPDM ‘O’-rings, incorporating a single check valve cartridge (verified by test, suitable for fluid catergory 2) with a lever operating member. To be used with copper pipe manufactured to EN1057. verified Maximum working pressure 10.0 bar. Maximum operating temperature 85°C.
Range of screwdriver operated spherical valves incorporating brass bodies, brass ball, and EPDM ‘O’-rings. Compression connections are for use with copper pipe (manufactured to EN1057). Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Isolation valves with nickel plated brass bodies, chrome plated brass balls and EPDM O-rings. Compression connection to be used with copper pipe EN1057. Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of inline plastic bodied ball valves with EPDM ‘O-rings and lever operated. For use with PVC-U pressure pipe in accordance with BS EN 1452 standard Maximum working pressure. Sizes 20mm – 63mm & 1/2" – 2”: 16.0 Bar Sizes 110mm & 2 1/2” – 4”: 10.0 Bar Cold water only
Range of PVC-U double union ball valves incorporating EPDM O-rings. Maximum working pressure 16.0 Bar. Cold water use only
Range of gate valves with ductile iron bodies (blue epoxy coated), EPDM coated wedge and EPDM O - rings. Maximum working pressure – 10.0 bar (DN900 and DN1000 only) and 16.0 bar (DN350 – DN800). Maximum operating temperature - 85°C
Range of gate valves with blue epoxy coated ductile iron bodies, EPDM coated ductile iron wedge and EPDM seals. Valves are operated via a non-rising spindle headwork. Maximum working pressure 16.0 Bar Maximum operating temperature 100.0°C
Range of gate valves with blue, black or red epoxy coated ductile iron bodies, incorporating ductile iron wedges encapsulated in EPDM and hand wheel operating members. Maximum working pressure - 16 Bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of gate valves incorporating a blue epoxy coated cast iron body, EPDM gate and seals and a non-rising stem with a handwheel operating member Maximum working pressure 16.0 bar, Maximum operating temperature 85ºC.
Range of gate valves with blue epoxy ductile iron bodies, ductile iron wedge encapsulated in EPDM. Maximum working pressure 16.0 Bar. Maximum operating temperature 85°C.
Range of gate valves with brass bodies and stems, EPDM O-rings, with non-rising spindles with hand wheel operating members. Maximum working pressure 20.0 bar. Maximum operating temperature 100°C.
Range of flanged gate valves with blue epoxy coated ductile iron bodies and EPDM O-rings and disc. The valves are operated via a non-rising spindle headwork with a wheel type operating member. Maximum working pressure 16.0 Bar
Non-metallic materials and components comply with BS6920 at 80°C
AMEXSA range of resilient seated gate valves with blue epoxy coated ductile iron bodies and bonnets and ductile iron wedges encapsulated in EPDM. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 80°C.
Range of blue or green polyethylene coated ductile iron gate valves incorporating an EPDM Wedge. The valves operate via a non-rising spindle headwork with hand wheel operating member. Maximum working pressure 16.0 Bar Maximum operating temperature 65.0°C
Range of resilient seated gate valves with cast iron bodies (blue epoxy coated), EPDM coated cast iron wedges and a handwheel operating member. Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of hand wheel operated gate valves with blue epoxy coated ductile iron bodies and EPDM wedges. Maximum working pressure 10.0 Bar or 16.0 Bar Maximum operating temperature 40.0°C
Range of hand wheel operated gate valves with blue epoxy coated ductile iron bodies, ductile iron wedge encapsulated in EPDM. Maximum working pressure 16.0 Bar Maximum operating temperature 65.0°C
Range of gate valves incorporating blue epoxy coated ductile iron bodies and EPDM coated ductile iron wedges. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves with blue epoxy ductile iron bodies, ductile iron wedge encapsulated in EPDM. Maximum working pressure 16.0 Bar. Maximum operating temperature 85°C.
Range of resilient seated gate valves with blue epoxy coated ductile iron bodies and bonnets and ductile iron wedges encapsulated in EPDM. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 80°C.
Range of gate valves with ductile iron bodies (blue epoxy coated), EPDM coated wedge and EPDM O - rings. Maximum working pressure – 10.0 bar (DN900 and DN1000 only) and 16.0 bar (DN350 – DN800). Maximum operating temperature - 85°C
Range of gate valves with blue epoxy coated ductile iron bodies, EPDM wedge and a non-rising spindle. Maximum working pressure 16.0. Maximum operating temperature 85°C.
Range of gate valves with blue epoxy coated ductile iron bodies, EPDM coated ductile iron wedge and EPDM seals. Valves are operated via a non-rising spindle headwork. Maximum working pressure 16.0 Bar Maximum operating temperature 100.0°C
Range of resilient seated gate valves with blue epoxy coated ductile iron bodies, bonnets and ductile iron wedges encapsulated in EPDM. The valves operate via a non-rising spindle headwork with hand wheel, bevel gear, electric actuator & stem cap operator operating methods. Maximum working pressure 10.0 or 16.0 bar. Maximum operating temperature 100°C.
Range of gate valves with blue epoxy coated ductile iron bodies and EPDM coated ductile iron wedges. The valves are operated via a non-rising spindle headwork with a hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 80°C.
Range of gate valves incorporating blue epoxy coated ductile iron bodies, EPDM coated wedges. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 16.0 Bar. Maximum operating temperature 85°C.
Range of gate valves with blue epoxy ductile iron bodies and a ductile iron wedge encapsulated in EPDM. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of Gate valves with ductile iron bodies (blue epoxy coated), EPDM rubber coated wedges, non-rising spindles with hand wheel operating members. Maximum working pressure 16.0 Bar Maximum operating temperature 85.0°C
Range of gate valves with blue epoxy coated ductile iron bodies and disks, with EPDM O seats. The valves are operated via a non-rising spindle headwork and hand wheel. Maximum working pressure 16.0 Bar
Non-metallic materials and components comply with BS6920 at 85°C
Range of gate valves incorporating a blue epoxy coated cast iron body, EPDM gate and seals and a non-rising stem with a handwheel operating member Maximum working pressure 16.0 bar, Maximum operating temperature 85ºC.
Range of gate valves incorporating blue epoxy coated ductile iron bodies, EPDM coated wedges. The valves are operated via a non-rising spindle with a hand wheel operating member. Maximum working pressure 16.0 Bar. Maximum operating temperature 85°C.
Range of screw down stop valves incorporating brass or bronze bodies and EPDM gaskets. Valves with compression connections are for use with copper pipe (manufactured to EN1057). Maximum working pressure 16.0 bar. Maximum operating temperature 80°C.
Range of screw down stop valves with brass bodies, incorporating EPDM gaskets. Compression connection to be used with copper pipe EN1057. Maximum working pressure 16 Bar. Maximum operating temperature 85°C.
Range of screw down stop valves with brass or chrome plated brass bodies and EPDM seals. For use with copper pipe to EN1057. Maximum working pressure 16.0 Bar Maximum operating temperature 85 °C.
Range of manually operated balancing valves incorporating bronze bodies, non-rising spindle balancing mechanism, EPDM washer & ‘O’-rings with either a metal or rubber seat. Maximum working pressure 25.0 bar. Maximum operating temperature 85ºC.
Range of regulating balancing valves with blue epoxy coated ductile iron bodies incorporating EPDM gaskets and hand wheel operating member. Maximum working pressure 16.0 Bar. Maximum operating temperature 85°C.
Range of manually operated balancing valves incorporating bronze bodies, non-rising spindle balancing mechanism, EPDM washer & ‘O’-rings with either a metal or rubber seat. Maximum working pressure 25.0 bar. Maximum operating temperature 85ºC.
Range of regulating balancing valves with blue epoxy coated ductile iron bodies incorporating EPDM gaskets and hand wheel operating member. Maximum working pressure 16.0 Bar. Maximum operating temperature 85°C.
'EP60PF - EP80PF 'O' rings, gaskets & seals'. Black coloured, compression moulded EPDM 'O' rings, gaskets & seals. Shore hardness between 60 & 80. Tested in-radius size between 0.75mm & 2.66m. For use with water up to 85°C.
'GJ-yzxj-V40 EPDM valve seat'. Black coloured, compression moulded EPDM valve seat. Shore hardness 70. Tested in-radius size 3.5mm. For use with water up to 85°C.
'10 EPR 'O' rings'. Black coloured, injection moulded EPDM 'O' rings. Shore hardness 70. Tested in-radius size 1.5mm. For use with water up to 85°C.
'Polymax E708DW 'O' rings'. Black coloured, compression moulded EPDM 'O' rings. Shore hardness 70A. Tested in-radius size 1.85mm. For use with water 85°C.
'51M7531'. Black coloured, injection moulded EPDM rubber 'O'-ring. Shore hardness 75. Tested in-radius 1.5mm. For use with water up to 85°C.
'B1-4773' Lip Seals and 'O' rings. Black coloured, EPDM components with shore hardness of 70. Compression moulded Lip Seals have an in-radius size of 2.7mm. Compression moulded ‘O’ rings have an in-radius size of 1.5mm. Injection moulded ‘O’ rings have an in-radius size of 1.0mm. For use with water up to 85°C.
'70 EP111p' Lip Seals and 'O' rings. Black coloured, EPDM components with shore hardness of 70. Compression moulded Lip Seals have an in-radius size of 2.7mm. Compression moulded ‘O’ rings have an in-radius size of 1.5mm. Injection moulded ‘O’ rings have an in-radius size of 1.0mm. For use with water up to 85°C.
'TIMO 5-70 Gaskets & ‘O’ rings'. Black coloured, injection moulded EPDM gaskets & ‘O’ rings. Shore hardness 70. Tested in-radius size between 0.50mm & 2.66mm. For use with water up to 85°C.
'MBMS0715'. Black coloured, compression moulded EPDM 'O' rings. Shore hardness 70. Tested in-radius size between 0.35mm and 5.0mm. For use with water up to 85°C.
'51M5536'. Black coloured, injection moulded EPDM material. Shore hardness 55 ShA. Tested in-radius size 0.5mm. For use with water up to 23°C.
'EXJ2024'. Black coloured, compression moulded EPDM material. Shore hardness 65. Tested in-radius size 1.0mm. For use with water up to 85°C.
'HT5697-50'. Black coloured, injection moulded EPDM material. Shore hardness 67 ShA. Tested in-radius size 1.0mm. For use with water up to 60°C.
‘EPDM-W 70817’. Black coloured, compression moulded EPDM rubber material. Shore hardness 80A. Tested in-radius size 0.98mm. For use with water up to 85°C.
'DLYY E6202'. Black coloured, compression moulded EPDM material. Shore hardness 60. Tested in-radius size 1.1mm. For use with water up to 23°C.
'WE-HR-01'. Black coloured, compression moulded EPDM rubber material. Shore hardness 75. Tested in-radius size 0.99mm. For use with water up to 85°C.
'Dutral K-Co-054'. Black coloured, compression moulded EPDM materials. Shore hardness between 52A & 80A. Tested in-radius size 1.0mm. For use with water up to 65°C.
'EP500'. Black coloured, injection moulded EPDM rubber material. Shore hardness 70. Tested in-radius size 1.0mm. For use with water up to 85°C.
'SM177'. Black coloured, compression moulded EPDM rubber. Shore hardness 70. Tested in-radius size 1.56mm. For use with water up to 23°C.
'EPDM E282'. Black coloured, compression moulded EPDM sheet material. Shore hardness 80A. Tested in-radius size 1.0 For use with water up to 85°C.
'EP0E7001P-WRC'. Black coloured, compression moulded EPDM sheet material. Shore hardness 70. Tested in-radius size 1.1mm. For use with water up to 85°C.
'E7581'. Black coloured, injection moulded EPDM rubber material. Shore hardness 70. Tested in-radius size 1.0mm. For use with water up to 85°C.
'ECL/EP/50 & ECL/EP/80'. Black coloured, compression moulded EPDM materials. Shore hardness between 50 & 80. Tested in-radius size 1.0mm. For use with water up to 85°C.
'E7131'. Black coloured, injection moulded EPDM rubber material. Shore hardness 70. Tested in-radius size 1.0mm. For use with water up to 85°C.
'7571E'. Black coloured, injection moulded EPDM material. Shore hardness 55. Tested in-radius size 1.0mm. For use with water up to 23°C.
'JHSX-02'. Black coloured, compression moulded EPDM rubber material. Shore hardness 50. Tested in-radius size 1.05mm. For use with water up to 85°C.
'XX-01'. Black coloured, compression moulded EPDM rubber material. Shore hardness 50. Tested in-radius size 1.05mm. For use with water up to 85°C.
'NK8650W-EPDM'. Black coloured, compression moulded EPDM material. Shore hardness 65. Tested in-radius size 1.1mm. For use with water up to 65°C.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MGA024BTM | Black | 1/2" BSP (F) | 9 bar | 65 °C | Mediclinics | Body | No | Solenoid | Not Applicable | Aerator |
Range of spherical valves with DZR brass bodies, chromium plated brass balls, PTFE seats and EPDM rubber ‘O’-ring. The products also incorporate a ‘Y’- Patterned stainless steel strainer. Compression connection to be used with copper EN1057. AI-0396A062815CR incorporates an approved single check valve cartridge, verified by test - suitable for backflow protection against fluid category 2. Maximum working pressure: 25.0 bar. Maximum operating temperature: 100°C (model AI-0396A062815CR 65°).
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| JD-PS***-**-**** | F1/2, M15*1 | Open outlet use only bar | 85 °C | Kind, WRAS, Production date(MM.YYYY) | Ferrule | No |
Note: 1. 1st *** denotes the hose length: 15-300cm: E.g., 015 = 15cm, 100 = 100cm, 200 = 200cm. 2. 2nd ** denotes the hose size: 06=DN6, 07=DN7 3. 3rd **** denotes the connections, and can be replaced with any of the following: 01=F1/2 05=M15*1
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SH001* | Various | ½” BSP (F) conical nut x ½” BSP(F) conical nut | For open outlet use only bar | 85 °C | WINSDRUM | On conical nut | No | Not applicable | Not Applicable | Not Applicable | |
| SH002* | Various | ½” BSP (F) conical nut x M15x1 | For open outlet use only bar | 85 °C | WINSDRUM | On conical nut | No | Not applicable | Not Applicable | Not Applicable |
1) The products are interlock type 2) * denotes finish and can be replaced by: C - Chrome RG - Rose Gold BTG - Brushed Titanium gold BZG - Brushed Zirconium gold BRG - Brushed Rose gold MW - Matte white BS - Brushed stainless BN - Brushed nickel PN - Polished nickel GM - Gunmetal B - Matte black TG - Titanium gold ZG - Zirconium gold BC - Black+chrome W - White CW - Chrome+white Q - Quartzite ZGC - Zirconium gold+chrome TGC - Titanium gold+chrome M - Medieval A - Antique bronze CP - Champagne BL - Brushed lead BP - Polished Black
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Wastes | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| KM FRZ BAS3.5 C | Chrome | 15mm compression | 5 bar | 65 °C | Bristan | Operating member | No | Ceramic cartridge | C-plate | Aerator | Click Type | Flow Regulator Fitted, |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Wastes | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 10 003 xx0 | Where xx0 denotes the surface finish (which is a non-water contact part). It will always be 3 digits, which can be any combination of numbers and/or letters, as examples: 000 = chrome optic finish, 800 = PVD stainless steel optic finish | G 3/8 | 10 bar | 60 °C | AXOR | on the body | Yes | Ceramic cartridge | Metal Backnuts | Aerator | ||
| 10 001 xx0 | Where xx0 denotes the surface finish (which is a non-water contact part). It will always be 3 digits, which can be any combination of numbers and/or letters, as examples: 000 = chrome optic finish, 800 = PVD stainless steel optic finish | G 3/8 | 10 bar | 60 °C | AXOR | on the body | Yes | Ceramic cartridge | Metal Backnuts | Aerator | Pop Up | |
| 10 007 xx0 | Where xx0 denotes the surface finish (which is a non-water contact part). It will always be 3 digits, which can be any combination of numbers and/or letters, as examples: 000 = chrome optic finish, 800 = PVD stainless steel optic finish | G 3/8 | 10 bar | 60 °C | AXOR | on the body | Yes | Ceramic cartridge | Metal Backnuts | Aerator | Pop Up | |
| 10 102 xx0 | Where xx0 denotes the surface finish (which is a non-water contact part). It will always be 3 digits, which can be any combination of numbers and/or letters, as examples: 000 = chrome optic finish, 800 = PVD stainless steel optic finish | G 3/8 | 10 bar | 60 °C | AXOR | on the body | Yes | Ceramic cartridge | Metal Backnuts | Aerator | Pop Up | |
| 10 103 xx0 | Where xx0 denotes the surface finish (which is a non-water contact part). It will always be 3 digits, which can be any combination of numbers and/or letters, as examples: 000 = chrome optic finish, 800 = PVD stainless steel optic finish | G 3/8 | 10 bar | 60 °C | AXOR | on the body | Yes | Ceramic cartridge | Metal Backnuts | Aerator |
Where xx0 denotes the surface finish (which is a non-water contact part). It will always be 3 digits, which can be any combination of numbers and/or letters, as examples: 000 = chrome optic finish, 800 = PVD stainless steel optic finish.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 32002 | chromium plated | ½” BSF (F) Captive nut | 10bar bar | 60℃ °C | Bokeya | on body | No | Ceramic cartridge | C-plate | Aerator | |
| 41202 | chromium plated | ½” BSF (F) Captive nut | 10bar bar | 60℃ °C | Bokeya | on body | No | Ceramic cartridge | C-plate | Aerator | |
| 41802 | chromium plated | ½” BSF (F) Captive nut | 10bar bar | 60℃ °C | Bokeya | on body | No | Ceramic cartridge | C-plate | Aerator | |
| 41802L | chromium plated | ½” BSF (F) Captive nut | 10bar bar | 60℃ °C | Bokeya | on body | No | Ceramic cartridge | C-plate | Aerator | |
| 81202 | chromium plated | ½” BSF (F) Captive nut | 10bar bar | 85℃ °C | Bokeya | on body | No | Ceramic cartridge | C-plate | ||
| 81202L | chromium plated | ½” BSF (F) Captive nut | 10bar bar | 85℃ °C | Bokeya | on body | No | Ceramic cartridge | C-plate | ||
| 81402 | chromium plated | ½” BSF (F) Captive nut | 10bar bar | 85℃ °C | Bokeya | on body | No | Ceramic cartridge | C-plate | ||
| 81402L | chromium plated | ½” BSF (F) Captive nut | 10bar bar | 85℃ °C | Bokeya | on body | No | Ceramic cartridge | C-plate | ||
| 91202 | chromium plated | ½” BSF (F) Captive nut | 10bar bar | 85℃ °C | Bokeya | on body | No | Ceramic cartridge | C-plate |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| TPASHMONO3 | Chromed | 1/2" Captive nut | 10 bar | 60 °C | Lecico bathrooms | Rear of body | No | Ceramic cartridge | C-plate | Aerator | |
| TPSOUMONO3 | Chromed | 1/2" Captive nut | 10 bar | 60 °C | Lecico bathrooms | Rear of body | No | 1/4 Turn ceramic disc | C-plate | Aerator |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 2720032 | Chromed | ½” captive nut | 10 bar | 60 °C | MVI | Rear of body | No | Ceramic cartridge | C-plate | Aerator | |
| 2720034 | Chromed | ½” captive nut | 10 bar | 60 °C | MVI | Rear of body | No | Ceramic cartridge | C-plate | Aerator | |
| 2720068 | Chromed | ½” captive nut | 10 bar | 60 °C | MVI | Rear of body | No | 1/4 Turn ceramic disk | C-plate | Aerator |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| CNN EFSNK FL6 C | Chrome | 1/2" BSP (M) | 5 bar | 60 °C | Bristan | Operating member | No | Ceramic cartridge | C-plate | Aerator |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 2720055 | Chromed | ½" captive nut | 10 bar | 85 °C | MVI | Rear of body | No | 1/4 Turn ceramic disk | C-plate | Flow Straightener | |
| 2720060 | Chromed | ½" captive nut | 10 bar | 85 °C | MVI | Rear of body | No | 1/4 Turn ceramic disk | C-plate | Open Outlet | |
| 2720062 | Chromed | ½" captive nut | 10 bar | 85 °C | MVI | Rear of body | No | 1/4 Turn ceramic disk | C-plate | Open Outlet |
Fastwarm range of M type press copper crimp fittings with EPDM ‘O’-rings for use with copper tube manufactured to EN 1057. The joints are achieved by means of a crimping tool. For above ground use. Maximum working pressure: 16.0 bar. Maximum operating temperature: 85°C
Range RP of M type press copper crimp fittings with EPDM ‘O’-rings for use with copper tube manufactured to EN 1057. The joints are achieved by means of a crimping tool. For above ground use. Maximum working pressure: 16.0 bar. Maximum operating temperature: 85°C
'Instantor’ range of stainless-steel crimp fittings incorporating EPDM and ‘O’-rings for use with 'Instantor’ stainless steel pipe. Connection is achieved via M profile press jaws. For above ground use only. Maximum working pressure 16.0 bar. Maximum operating temperature 95°C.
‘EPS’, ‘EPT & ‘EPL’ ranges of PPSU press fittings (TH press profile) with EPDM ‘O’-rings for use with ‘EFIELD EA’ PE-Xb/AL/PE-Xb multilayer pipes. Maximum working pressure: 10 bar. Maximum operating temperature: 95°C
Range of press fittings (brass bodies) with stainless steel press (‘TH’ profile) collars and EPDM o-rings for use with ‘EA’ PE-Xb/AL/PE-Xb’ multilayer pipe (for press fitting connections) or copper pipe manufactured to EN1057 (compression connections). Maximum working pressure: 10 bar. Maximum operating temperature: 95 °C.
Range of brass press fittings with EPDM ‘O’-rings for use with copper pipe (manufactured to EN1057). Jointing is achieved via a crimping tool using a ‘M’ profile. For above and below ground use. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of brass press fittings with EPDM ‘O’-rings for use with copper pipe (manufactured to EN1057). Jointing is achieved via a crimping tool using a ‘M’ profile. For above and below ground use. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
‘SLD’ range of copper press fittings with ‘V’ and ‘M’ press profiles and EPDM ‘O’ rings. Fittings to be used with copper pipe manufactured to EN1057. Maximum working pressure: 16 Bar. Maximum operating temperature: 85°C.
Flowflex Range of press-fit fittings with stainless steel bodies incorporating EPDM ‘O’-rings for use with SS316L pipes. Maximum working pressure 16 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of copper or chrome plated copper (CP suffix models) press fittings with EPDM ‘O’-rings for use with copper pipe (manufactured to EN1057). Jointing is achieved via a crimping tool using a ‘M’ profile. For above and below ground use. Maximum working pressures: 12mm to 54mm: 16.0 bar, 66.7mm to 108mm: 10.0 bar. Maximum operating temperature 85°C.
Range of copper or brass press fittings with EPDM ‘O’-rings for use with copper pipe (manufactured to EN1057). Jointing is achieved via a crimping tool using a ‘V’ profile. For above ground use only. Maximum working pressure 10.0 bar. Maximum operating temperature 95°C.
Range of high flow water meters with black epoxy coated ductile iron bodies and EPDM gaskets. Maximum working pressure; 16 Bar Maximum operating temperature Cold water only
Range of ultrasonic water meters with a blue epoxy coated ductile iron body and EPDM ‘O’ rings. Maximum working pressure 16.0 Bar. Maximum operating temperature 50°C.
Range of water meters with plastic bodies and plastic working chamber and EPDM ‘O’ rings. The inlets incorporate a plastic filter. Maximum working pressure 16.0 Bar. Maximum operating temperature 50°C.
Range of water meters with plastic bodies and plastic working chamber and EPDM ‘O’ rings. The inlets incorporate a plastic filter. Maximum working pressure 16.0 Bar. Maximum operating temperature 50°C.
Range of electromagnetic flow meters with stainless steel bodies, EPDM inner liner and SUS316L electrodes. Maximum working pressure 16 Bar. Maximum operating temperature 40°C.
Range of in-line flow sensors incorporating either brass (type 230, 235 & 236) or plastic (type 200 & 210) bodies & EPDM ‘O’-rings. Maximum working pressure 12.0 Bar Maximum operating temperature 100.0°C
Range of metering stations with DZR brass bodies and EPDM ‘O’-rings. Maximum working pressure 25.0 bar. Maximum operating temperature 85°C.
Range of stainless-steel pressure sensors. Maximum working pressures: B83.a-b-C5-3-f-g-h-i-j-k-l-m-n-o (Thread G1): 10.0 bar. B83.a-b-cd-e-f-g-h-i-j-k-l-m-n-o with METEC - metallic measuring cell: 25.0 bar, B83.a-b-cd-e-f-g-h-i-j-k-l-m-n-o with Piezoresistive - metallic measuring cell: 40.0 bar. Maximum operating temperature 100°C
Range of EPDM expansion joints. Maximum working pressures: YXY6: 6.0 bar, YXY10: 10.0 bar, YXY16: 16.0 bar, YXY25: 25.0 bar. Maximum operating temperature 85°C.
Range of isolation valves incorporating brass bodies and EPDM ‘O’-rings. Maximum working pressure 5.0 bar. Maximum operating temperature 60°C.
Range of horizontal multistage pumps with stainless steel bodies, diffuser and impellers and EPDM ‘O’-rings. The products incorporate a graphite-SiC-EPDM shaft seal. The products incorporate a drain plug. Maximum working pressure 8.5 bar. Maximum operating temperature 35°C.
Range of horizontal multistage pumps with stainless steel bodies, diffuser and impellers and EPDM ‘O’-rings. The products incorporate a graphite-SiC-EPDM shaft seal. The products incorporate a drain plug. Maximum working pressure 8.5 bar. 9Maximum operating temperature 80°C.
Range of overhead shower outlets with (stainless steel bodies - various finishes). The inlet incorporates a combined EPDM washer and an approved check valve cartridge: however, the complete product has not been fully tested to demonstrate it provides backflow protection. Maximum working pressure: Open outlet use only. Maximum operating temperature 65.0°C
Range of Y type strainers with blue epoxy coated ductile iron bodies and EPDM ‘O’-rings. Maximum working pressure 25.0 bar. Maximum operating temperature 85°C
Flexible safety hose assembly with PVC, composite inner hose and corrugated outer cover incorporating EPDM gaskets. The inlet of the hose incorporates a plastic strainer. The hose is fitted with an integral device which is intended to stop the flow of water (please note that this function has not been verified by test). Maximum working pressure 10.0 bar. Maximum operating temperature 60°C.
Range of stainless steel, interlocked shower hoses with EPDM liner and O-rings. Open outlet use only. Maximum operating temperature 65°C.
Range of stainless-steel braided, EPDM lined flexible hose assemblies. The captive nut end connections incorporate a washer, the M10 connection incorporates an ‘O’-ring. Maximum working pressure 10.0 bar. Maximum operating temperature 90°C.
A7255AA range of PEX lined shower hoses incorporating corrugated interlocking metal hoses with various finishes. All hoses incorporate EPDM washers. Maximum operating temperature 65°C.
Range of ‘THINK-A-FLEX’, EPDM lined, stainless steel braided flexible hose assemblies incorporating various end connections Maximum working pressure: 10 BAR Maximum operating temperature: 65°C
Wall mounted thermostatic bar shower mixer (matte black plated brass), incorporating a ceramic disc diverter headwork controlling the flow between shower handset and overhead shower with a dome type operating member and a thermostatic cartridge controlling the temperature with a dome type operating member that incorporates a manual override button. The inlets incorporate stainless-steel EPDM strainer washers and approved check valve cartridges; (however, the complete product has not been fully tested to demonstrate it provides backflow protection). The product is supplied with screwdriver operated isolation valves, an overhead shower incorporating an EPDM washer at the inlet, shower handset, shower hose incorporating an EPDM washer at the captive nut and a stainless-steel EPDM strainer washer in the conical nut & riser rail assembly. Maximum working pressure 10.0 bar.
Non-metallic materials and components comply with BS6920 at 60°C
Wall mounted, exposed, thermostatic shower mixing valve (chromium plated brass). The products incorporate a ¼ turn ceramic disc. Temperature is controlled independently via a thermostatic cartridge with a manual override button. The products have dome type operating members. Each inlet incorporates a combined EPDM washer and stainless steel strainer and an approved check valve cartridge, however, the complete product has not been fully tested to demonstrate it provides backflow protection. Maximum working pressure 6.0 bar. Maximum operating temperature 65°C.
Range of wall mounted, exposed, thermostatic shower mixing valves (chromium plated brass). Incorporating a ¼ turn ceramic disc or a 2-way ceramic disc diverter headwork (see model). Temperature is controlled independently via a thermostatic cartridge with a manual override button. The products have cube, dome or single lever type operating members. Each inlet incorporates a combined EPDM washer and stainless steel strainer and an approved check valve cartridge, however, the complete product has not been fully tested to demonstrate it provides backflow protection. Maximum working pressure 6.0 bar. Maximum operating temperature 65°C.
Range of lugged and wafer type butterfly valves with blue epoxy coated bodies, incorporating EPDM rubber ‘O’-rings and seat, and either a bronze (AB2), stainless steel (CF8 & CF8M) or blue epoxy coated or nickel plated, ductile iron (DI) disc. Maximum working pressure 25.0 bar. Maximum operating temperature 85°C.
Range of butterfly valves with blue epoxy coated, ductile iron bodies and either blue epoxy coated ductile iron or stainless-steel discs and EPDM seats and ‘O’-rings. Maximum working pressure 16.0 Bar. Maximum operating temperature 85°C
Range of butterfly valves with blue epoxy coated ductile iron bodies, ductile iron or stainless steel discs with EPDM seats and a lever operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 80°C.
Range of lugged and wafer type butterfly valves with blue epoxy coated bodies, incorporating EPDM rubber ‘O’-rings and seat, and either a bronze (AB2), stainless steel (CF8 & CF8M) or blue epoxy coated or nickel plated, ductile iron (DI) disc. Maximum working pressure 25.0 bar. Maximum operating temperature 85°C.
Range of butterfly valves with blue epoxy coated ductile iron bodies, stainless steel discs with EPDM seats and a lever operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of eccentric flanged type butterfly valves with ductile iron bodies and disc (blue epoxy coated) and EPDM seats. Maximum working pressure 16.0 Bar. Maximum operating temperature 85°C
Range of wafer, lugged and flanged butterfly valves with blue epoxy coated ductile iron bodies, nickel plated ductile iron discs, EPDM seat and NBR ‘O’-rings. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
BV266 Range of butterfly valves with blue epoxy coated ductile iron bodies and discs, and EPDM seals with a wheel type operating member. Maximum working pressure 16.0 Bar Maximum operating temperature 85.0°C
Non-metallic materials and components comply with BS6920 at 85°C
Range of lugged, wafer or double flanged butterfly valves incorporating blue epoxy coated ductile iron bodies, EPDM seats and stainless steel or blue epoxy coated ductile iron discs. The products can be supplied with a gear box and handheel operating member (all models) or a lever operating members (all models except TB-RF). Maximum working pressure 10.0 bar, 16.0 bar or 25.0 bar (see model). Maximum operating temperature 85°C.
VF900 Range of wafer butterfly valves with blue, black or red epoxy coated ductile iron bodies, zinc coated (galvanised) discs and EPDM seats, incorporating hand wheel operating members. Maximum working pressure 16.0 bar. Maximum operating temperature 70°C.
Range of butterfly valves with blue epoxy coated ductile iron bodies, stainless-steel discs and EPDM or PTFE seats (see models). Maximum working pressure 16.0 Bar or10.0 Bar (see models). Maximum operating temperature 85°C.
Range of combined pre-set temperature and pressure relief valves incorporating Bronze body, DZR brass seat and plunger, EPDM ‘O’-rings, PTFE seal and silicone diaphragm. The valves incorporate a manually operated lever easing gear. The valves are factory pre-set between 0.7 bar and 12.5 bar. Maximum operating temperature 90°C. Maximum working pressure between 0.7 bar and 12.5 bar. Maximum operating temperature 90.0°C
Range of BOSS 958 combined pre-set temperature and pressure relief valves incorporating Bronze body, DZR brass seat and plunger, EPDM ‘O’-rings, PTFE seal and silicone diaphragm. The valves incorporate a manually operated lever easing gear. The valves are factory pre-set between 0.7 bar and 12.5 bar. Maximum operating temperature 90°C. Maximum working pressure between 0.7 bar and 12.5 bar. Maximum operating temperature 90.0°C
Range of pilot operated flow control valves with blue epoxy coated ductile Iron bodies and EPDM ‘O’-rings. Auxiliary components include stainless steel tube with fittings and ball valves. Maximum working pressure 16.0 bar. Maximum operating temperature 60°C.
Range of spring loaded, non-return valves with ductile iron bodies (blue epoxy powder coated) with stainless steel discs, springs and shafts and EPDM seat. Maximum working pressure 25.0 bar. Maximum operating temperature 85°C.
Non-metallic materials and components comply with BS6920 at 85°C
Range of wafer non-return valves with stainless steel (SUS304 or 316) or galvanized carbon steel (A105) bodies, stainless steel discs (CF8 or CF8M) and either EPDM or FKM ‘O’-rings. Maximum working pressure 16.0 bar. Maximum operating temperature 100°C.
Range of wafer non-return valves with blue epoxy coated ductile iron bodies, nickel plated or blue epoxy coated ductile iron or stainless steel discs and EPDM seals. Maximum working pressure 10.0 bar or 16.0 bar. Maximum operating temperature 85°C.
Range of swing gate, non-return valves with blue epoxy coated ductile iron bodies and EPDM swing gates. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of pilot operated pressure reducing valves with blue epoxy coated ductile iron bodies, Stainless-steel filter, EPDM ‘O’-rings and diaphragm. The valves have an adjustable pressure reducing facility controlled via a pilot valve (see note), with auxiliary components including stainless-steel tubing and fittings, strainer and stainless-steel spherical valves. Maximum working pressure 16.0 Bar. Maximum operating temperature 60°C.
Range of pilot operated pressure reducing valves with ductile iron bodies (blue epoxy coating) and EPDM diaphragm and O-rings. The products are supplied with auxiliary fittings: spherical valves, pressure gauges, a pilot valve, a needle valve and stainless steel tubes. The DN400 model also includes a Y-pattern strainer. Maximum inlet supply pressure 16.0 bar. The outlet pressure is adjustable between 0.7~16.0 bar. Maximum operating temperature 65°C.
Range of pilot operated pressure reducing valves with ductile iron bodies (blue epoxy coating) and EPDM diaphragm and O-rings. The products are supplied with auxiliary fittings: spherical valves (bronze or stainless steel), pressure gauges, a pilot valve, a needle valve and stainless steel or copper tubes. Maximum inlet supply pressure 16.0 bar. The outlet pressure is adjustable between 0.67~16.0 bar. Maximum operating temperature 85°C.
Solenoid valve with a nickel plated brass body, incorporating an EPDM diaphram and sealing rings. The product incorporates a stainless-steel strainer in the inlet. Maximum working pressure 8.0 bar. Maximum operating temperature 70°C.
Range of bistable solenoid valves incorporating a plastic body, EPDM diaphragm and ‘O’-rings. The 51.005.101 model incorporates a stainless-steel strainer on the inlet. Maximum operating pressures: 51.005.100: 5.0 bar, 51.005.101: 10.0 bar. Maximum operating temperature 70°C.
Solenoid valve with a plastic body, incorporating an EPDM diaphram and NBR sealing rings. The inlet incorporates a plastic filter. The pushfit connections are for use with LLDPE pipes (manufactured to DIN 8072). Maximum working pressure 8.0 bar. Cold water use only.
Range of electrically (A20 & A150 series) or battery (E20 & E22 series) operated motorised spherical valves incorporating brass or stainless-steel bodies, stainless steel balls and EPDM ‘O’-rings. Maximum working pressure 10.0 bar. Maximum operating temperature 90°C.
Range of electrically or battery operated motorised spherical valves incorporating brass, DZR brass or stainless-steel bodies, stainless steel balls and EPDM ‘O’-rings. Maximum working pressure 10.0 bar. Maximum operating temperature 90°C.
Lever operated spherical valve with brass body (nickel plated), chrome plated brass balls, and EPDM ‘O’-rings. Compression connections are for use with copper pipe (manufactured to EN1057). Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of in-line lever operated spherical (SB2415) or screwdriver operated servicing (SB1915 & SB1922) valves with chromium plated brass bodies and balls, EPDM seals and ‘SharkBite’ push fit end connections. For use with PB pipe manufactured to EN7291-2:2010, PEX Pipe Manufactured to EN 7291-3:2010 and copper pipe manufactured to EN1057. Maximum working pressure: 12.5 Bar at 20°C (PEX & PB Pipe) 6.0 Bar at 95°C (PEX & PB Pipe) 20.0 Bar at 20°C (Copper Pipe) 16.0 Bar at 95°C (Copper Pipe)
Range of spherical valves incorporating brass bodies and balls (nickel plated), EPDM rubber ‘O’-rings, PTFE seats and red or blue coloured lever type operating members. Maximum working pressure; 10 Bar Maximum operating temperature; 65°c
Screwdriver operated angled spherical valve with a brass body and ball, PTFE seats and EPDM ‘O’-rings. Compression connection is to be used with copper pipe EN1057. Maximum working pressure 12.0 bar. Maximum operating temperature 85°C.
Motorised spherical valve incorporating nickel plated brass body, chrome plated brass ball and EPDM ‘O’-rings. Maximum working pressure 25.0 bar. Maximum operating temperature 85°C.
Range of plastic bodied inline, tee and angled spherical or servicing valves with EPDM ‘O’-rings. The products are either lever or screwdriver operated (see model). The products are for use with PE-X pipe (manufactured to BS 7291-3) and copper pipe (manufactured to EN 1057). Maximum working pressure 10.0 bar. Cold water use only. From March 2026: Maximum operating temperature 65°C for all models except AVT67665SM, AVT67661SM and AVT67445SM.
Range of hand wheel operated gate valves with blue epoxy coated ductile iron bodies, ductile iron wedge encapsulated in EPDM. Maximum working pressure 16.0 Bar. Maximum operating temperature 85.0°C
Range of resilient seated gate valves with blue epoxy coated ductile iron bodies, and an EPDM wedge, gasket and ‘O’-ring. Non-rising spindle, with a handwheel operating member. Maximum working pressure 25.0 bar. Maximum operating temperature 85°C.
Range of gate valves with brass bodies, bronze bonnet, EPDM ‘O’-ring and PTFE seat. The valves are operated via a non-rising stem and a handwheel operating member. Maximum working pressure 20.0 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating cast iron bodies (blue epoxy coated), EPDM coated wedges and non-rising spindles with hand wheel operating member. Maximum working pressure 10.0 bar (Z45X-10Q model). Maximum working pressure 16.0 bar (Z45X-16Q models). Maximum operating temperature 80°C.
OS & Y Range of gate valves with blue, black or red epoxy coated ductile iron bodies, incorporating ductile iron wedges encapsulated in EPDM and hand wheel operating members. Maximum working pressure - 16 Bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of gate valves incorporating cast iron bodies (blue epoxy coated), EPDM rubber coated wedges and non-rising spindles with hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves with blue epoxy coated ductile iron bodies, EPDM coated ductile iron wedges. The valves operate via a non-rising spindle headwork with hand wheel operating member. Maximum working pressure –16.0 bar. Maximum operating temperature - 85°C
Range of gate valves with blue epoxy coated ductile iron bodies and EPDM coated ductile iron wedges. The valves operate via a non-rising spindle headwork with hand wheel operating member or electronic remote-control system (see model). Maximum working pressure 16.0 bar. Cold water use only.
Range of gate valves with blue epoxy coated ductile iron bodies and EPDM coated ductile iron wedges, incorporating a hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 80°C.
Range of screw down stop valves with brass bodies, EPDM gaskets and PTFE washers. For use with copper pipe to EN 1057. Maximum working pressure 16.0 Bar. Maximum operating temperature 99°C.
Range of press fit screw down stop valves with brass bodies and EPDM seals. For use with copper pipe to EN1057. Maximum working pressure 16.0 Bar Maximum operating temperature 85 °C.
Range of press fit screw down stop valves with brass bodies and EPDM seals. For use with copper pipe to EN1057. Maximum working pressure 16.0 Bar Maximum operating temperature 85 °C.
Range of DZR brass combination valves consisting of an in-line adjustable pressure reducing valve (2.1 - 16.0 bar for ILG22-2 model and 1.4 - 6.0 bar for all other models), a pressure relief valve (set @ 6.0 bar) and EPDM gaskets and ‘O’-rings. The product incorporates a stainless-steel mesh and a check valve cartridge, verified by test (suitable for backflow protection against Fluid Category 2). For use with copper pipe (manufactured to BS EN 1057). Maximum inlet supply pressure 16.0 bar. Maximum operating temperature 90°C.
Range of manually operated balancing valves incorporating bronze bodies, rising spindle balancing mechanism, EPDM washer & ‘O’-rings with either a metal or rubber seat. Maximum working pressure 10.0 Bar Maximum operating temperature 100.0°C
Range of regulating balancing valves with blue epoxy coated ductile iron bodies incorporating EPDM gaskets and hand wheel operating member. Maximum working pressure 16.0 Bar. Maximum operating temperature 85°C.
'EP10/7/7 BLK gaskets & 'O' rings'. Injection moulded, black coloured EPDM gaskets & 'O' rings. Shore hardness 70. The gaskets have an in-radius size of 0.75mm. The ‘O’ rings have an in-radius size of 1.0mm. For use with water up to 85°C.
'GJ-yzxj-V40 EPDM valve seat'. Black coloured, compression moulded EPDM valve seat. Shore hardness 70. Tested in-radius size 3.5mm. For use with water up to 85°C.
'JSP/SF-02'. Black coloured, compression moulded EPDM rubber material. Shore hardness 50. Tested in-radius size 1.05mm. For use with water up to 85°C.
'EW-001'. Black coloured, compression moulded EPDM material. Shore hardness 65. Tested in-radius size 1.0mm. For use with water up to 23°C.
'EP2504 (NSF)'. Black coloured, compression moulded EPDM material. Shore hardness 70. Tested in-radius size 1.20mm. For use with water up to 85°C.
'JJSXEPDMIRHD50 (shore hardness 50) & JJSXEPDMIRHD70 (shore hardness 70)'. Black coloured, compression moulded EPDM materials. Tested in-radius size 0.99mm. For use with water up to 85°C.
'E40D'. Black coloured, compression moulded EPDM material. Shore hardness 70. Tested in-radius size 1.20mm. For use with water up to 85°C.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| F9920-** | Various | 1/2" Captive nut | 10 bar | 60 °C | LAN BIAO | Handle | No | Ceramic cartridge | Not Applicable | Aerator |
**Representing different surface color treatments： No Suffix = Chrome, H: Black DYB: Matte White BZ: Pearl White HGTS: Red Antique Bronze HTL: Yellow Bronze Brushed Q: Bronze QTSL: Bronze Brushed Bright QTS: Bronze Brushed Matte STS: Acid Copper Brushed SDMGJ: Water-Plated Rose Gold N: Nickel Brushed Bright NP: Nickel Brushed TJ: Titanium Gold TJLS: Titanium Gold Brushed G: Zirconium gold GJS: Zirconium Gold Brushed GJSY: Zirconium Gold Brushed Matte PGJFY: Zirconium Gold Brushed Bright PLSJ: Brushed Gold LSJY: Brushed Gold Matte MGJ: Rose Gold MGJL: Rose Gold Brushed DMGJ: Light Rose Gold Brushed HTS: Red Copper Brushed QHP: Gunmetal Gray LSQH: Gunmetal Gray Brushed LHMGJ: Brushed Yellow Rose Gold
Range of multi-layer shower hoses with a PVC inner hose, supplied with EPDM ‘O’-rings. Maximum operating temperature 60.0°C Open outlet use only.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 5001JC45-1 | Chrome | 1/2 BSP(F) | 10 bar | 85 °C | HUANRI | BODY | No | Ceramic cartridge | C-plate | Aerator |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| K001* | Various | 1/2" Captive nut | 5 bar | 65 °C | WINSDRUM | On body | No | Ceramic cartridge | Not Applicable | Aerator | |
| K002* | Various | 1/2" Captive nut | 5 bar | 65 °C | WINSDRUM | On body | No | Ceramic cartridge | Not Applicable | Aerator |
* denotes finish and can be replaced by: C - Chrome RG - Rose Gold BTG - Brushed Titanium gold BZG - Brushed Zirconium gold BRG - Brushed Rose gold MW - Matte white BS - Brushed stainless BN - Brushed nickel PN - Polished nickel GM - Gunmetal B - Matte black TG - Titanium gold ZG - Zirconium gold BC - Black+chrome W - White CW - Chrome+white Q - Quartzite ZGC - Zirconium gold+chrome TGC - Titanium gold+chrome M - Medieval A - Antique bronze CP - Champagne BL - Brushed lead BP - Polished Black
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Wastes | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4001JC45-1 | Chrome | 1/2BSP(F) | 10 bar | 85 °C | HUANRI | BODY | No | Ceramic cartridge | C-plate | Aerator | Click Type | |
| 4001JC45-3 | Chrome | 1/2BSP(F) | 10 bar | 85 °C | HUANRI | BODY | No | Ceramic cartridge | C-plate | Aerator |
The model 4001JC45-1 and 4001JC45-3 taps are same, except that 4001JC45-1 comes with a click-type waste fitting included during sale, while the 4001JC45-3 model does not.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| T5002 | Chrome plating | ½” BSF (F) Captive nut | 5 bar | 65 °C | SONAS | on operating member | No | Ceramic cartridge | C-plate | Aerator |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 3320-** | Various | 1/2" BSP (F) | 5 bar | 65 °C | CARLOTA | Handle | No | Ceramic cartridge | C-plate | Aerator | |
| 3188-** | Various | 1/2" BSP (F) | 5 bar | 65 °C | CARLOTA | Handle | No | Ceramic cartridge | C-plate | Aerator | |
| 3313-** | Various | 1/2" BSP (F) | 5 bar | 65 °C | CARLOTA | Handle | No | Ceramic cartridge | C-plate | Aerator | |
| 3322-** | Various | 1/2" BSP (F) | 5 bar | 65 °C | CARLOTA | Handle | No | Ceramic cartridge | C-plate | Aerator | |
| 3322A-** | Various | 1/2" BSP (F) | 5 bar | 65 °C | CARLOTA | Handle | No | Ceramic cartridge | C-plate | Aerator | |
| 3322B-** | Various | 1/2" BSP (F) | 5 bar | 65 °C | CARLOTA | Handle | No | Ceramic cartridge | C-plate | Aerator | |
| 3274-** | Various | 1/2" BSP (F) | 5 bar | 65 °C | CARLOTA | Handle | No | Ceramic cartridge | C-plate | Aerator | |
| 3271-** | Various | 1/2" BSP (F) | 5 bar | 65 °C | CARLOTA | Handle | No | Ceramic cartridge | C-plate | Aerator |
Where ** represents finish and can be replaced by: CR = Chrome plated, MB = Matt black， BB = Brushed brass， BN = Brushed nickel, GM = Gun Metal
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 61402 | Chrome plated | 1/2'' BSP (F) | 10 bar | 60 °C | Bokeya | Body | No | 1/4 Turn ceramic disc | C-plate | Flow Straightener | |
| 61102 | Chrome plated | 1/2'' BSP (F) | 10 bar | 60 °C | Bokeya | Body | No | 1/4 Turn ceramic disc | C-plate | Flow Straightener |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| UBR0274 | Various | 1/2" BSP (F) | 5 bar | 65 °C | SONAS | Body | No | Ceramic cartridge | C-plate | Aerator | |
| UBR0275 | Various | 1/2" BSP (F) | 5 bar | 65 °C | SONAS | Body | No | Ceramic cartridge | C-plate | Aerator |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| USH0229 | chrome plated | ½” BSF (F) Captive nut | 5 bar | 65 °C | SONAS | on operating member | No | Ceramic cartridge | C-plate | Flow Straightener |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| ROC2MB | MATT BLACK | 1/2" BSP | 5 bar | 60 °C | cleanwater | on bottom of faucet | No | Ceramic Cartridge | C-plate | Aerator | |
| ROC2RC | REGENCY COPPER | 1/2" BSP | 5 bar | 60 °C | cleanwater | on bottom of faucet | No | Ceramic Cartridge | C-plate | Aerator | |
| ROC2AB | ARTISAN BRASS | 1/2" BSP | 5 bar | 60 °C | cleanwater | on bottom of faucet | No | Ceramic Cartridge | C-plate | Aerator | |
| ROC2BN | BRUSHED NICKEL | 1/2" BSP | 5 bar | 60 °C | cleanwater | on bottom of faucet | No | Ceramic Cartridge | C-plate | Aerator | |
| ROC2CP | CHROME | 1/2" BSP | 5 bar | 60 °C | cleanwater | on bottom of faucet | No | Ceramic Cartridge | C-plate | Aerator | |
| ROC2BB | BRUSHED BRASS | 1/2" BSP | 5 bar | 60 °C | cleanwater | on bottom of faucet | No | Ceramic Cartridge | C-plate | Aerator | |
| ROC2PB | PATINATED BRASS | 1/2" BSP | 5 bar | 60 °C | cleanwater | on bottom of faucet | No | Ceramic Cartridge | C-plate | Aerator | |
| TU81073BV | MATT BLACK | 1/2" BSP | 5 bar | 60 °C | cleanwater | on bottom of faucet | No | Ceramic Cartridge | C-plate | Aerator | |
| TU81073RC | REGENCY COPPER | 1/2" BSP | 5 bar | 60 °C | cleanwater | on bottom of faucet | No | Ceramic Cartridge | C-plate | Aerator | |
| TU81073AB | ARTISAN BRASS | 1/2" BSP | 5 bar | 60 °C | cleanwater | on bottom of faucet | No | Ceramic Cartridge | C-plate | Aerator | |
| TU81073PB | PATINATED BRASS | 1/2" BSP | 5 bar | 60 °C | cleanwater | on bottom of faucet | No | Ceramic Cartridge | C-plate | Aerator | |
| TU81073CP | CHROME | 1/2" BSP | 5 bar | 60 °C | cleanwater | on bottom of faucet | No | Ceramic Cartridge | C-plate | Aerator | |
| TU81073BB | BRUSHED BRASS | 1/2" BSP | 5 bar | 60 °C | cleanwater | on bottom of faucet | No | Ceramic Cartridge | C-plate | Aerator | |
| TU81073BS | BRUSHED NICKEL | 1/2" BSP | 5 bar | 60 °C | cleanwater | on bottom of faucet | No | Ceramic Cartridge | C-plate | Aerator | |
| VITCP | CHROME | 1/2" BSP | 5 bar | 60 °C | cleanwater | on bottom of faucet | No | Ceramic Cartridge | C-plate | Aerator | |
| VITPB | PATINATED BRASS | 1/2" BSP | 5 bar | 60 °C | cleanwater | on bottom of faucet | No | Ceramic Cartridge | C-plate | Aerator | |
| VITBS | BRUSHED NICKEL | 1/2" BSP | 5 bar | 60 °C | cleanwater | on bottom of faucet | No | Ceramic Cartridge | C-plate | Aerator | |
| SA2CP | CHROME | 1/2" BSP | 5 bar | 60 °C | cleanwater | on bottom of faucet | No | Ceramic Cartridge | C-plate | Aerator | |
| SA2PB | PATINATED BRASS | 1/2" BSP | 5 bar | 60 °C | cleanwater | on bottom of faucet | No | Ceramic Cartridge | C-plate | Aerator | |
| SA2BN | BRUSHED NICKEL | 1/2" BSP | 5 bar | 60 °C | cleanwater | on bottom of faucet | No | Ceramic Cartridge | C-plate | Aerator | |
| SA2CP | CHROME | 1/2" BSP | 5 bar | 60 °C | cleanwater | on bottom of faucet | No | Ceramic Cartridge | C-plate | Aerator | |
| ZO3BB | BRUSHED BRASS | 1/2" BSP | 5 bar | 60 °C | cleanwater | on bottom of faucet | No | Ceramic Cartridge | C-plate | Aerator | |
| ZO2BB | BRUSHED BRASS | 1/2" BSP | 5 bar | 60 °C | cleanwater | on bottom of faucet | No | Ceramic Cartridge | C-plate | Aerator |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| EMB20CP | CHROME | 1/2" BSP | 5 bar | 65 °C | cleanwater | on bottom of faucet | No | Ceramic Cartridge | C-plate | Aerator | |
| EMB20BN | BRUSHED NICKEL | 1/2" BSP | 5 bar | 65 °C | cleanwater | on bottom of faucet | No | Ceramic Cartridge | C-plate | Aerator | |
| EMB20MB | MATT BLACK | 1/2" BSP | 5 bar | 65 °C | cleanwater | on bottom of faucet | No | Ceramic Cartridge | C-plate | Aerator | |
| EMB20AB | ARTISAN BRASS | 1/2" BSP | 5 bar | 65 °C | cleanwater | on bottom of faucet | No | Ceramic Cartridge | C-plate | Aerator | |
| EMB20BB | BRUSHED BRASS | 1/2" BSP | 5 bar | 65 °C | cleanwater | on bottom of faucet | No | Ceramic Cartridge | C-plate | Aerator | |
| EMB20PB | PATINATED BRASS | 1/2" BSP | 5 bar | 65 °C | cleanwater | on bottom of faucet | No | Ceramic Cartridge | C-plate | Aerator |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 61409 | Chrome plated | 1/2" BSP (F) | 10 bar | 85 °C | Bokeya | Body | No | 1/4 Turn ceramic disc | C-plate | Flow Straightener | |
| 61109 | Chrome plated | 1/2" BSP (F) | 10 bar | 85 °C | Bokeya | Body | No | 1/4 Turn ceramic disc | C-plate | Flow Straightener |
Two-hole, deck mounted, single outlet (fixed) combination tap assembly, (brass bodies - various finishes), incorporating a ceramic cartridge headwork with a single lever operating member. The product is supplied with metal back nuts, a plastic aerator and stainless steel braided EPDM lined interconnecting hoses. Maximum working pressure: 5.0 bar. Maximum operating temperature: 60°C.
Four-hole, single outlet (fixed) combination tap assembly (various finishes). Incorporating quarter turn ceramic disc headworks, with various operating members and stainless steel braided EPDM lined interconnecting hoses. The spout outlet incorporates a self-cancelling diverter to the shower outlet with a Type HC backflow protection device (verified by test - suitable for backflow protection against Fluid Category 3).and a plastic flow straightener with stainless steel mesh strainer. The product is supplied with a shower handset that incorporates a single check valve cartridge; however, the complete product has not been fully tested to demonstrate it provides backflow protection Maximum working pressure 3.5 bar. Maximum operating temperature 60°C
AQUASYSTEM Expansion Vessels with a carbon steel body and EPDM membrane. Maximum working pressure 10.0 bar. Maximum operating temperature 85°C.
SOUTH COAST SALES 'PU71’ ranges of PPSU press fittings (TH press profile) with EPDM ‘O’-rings for use with ‘South Press EA’ PE-Xb/AL/PE-Xb multilayer pipes. Maximum working pressure: 10 bar. Maximum operating temperature: 95°C
U Profile range of press fittings incorporating EPDM ‘O’-rings. For use with Mingshi (S-1-0509/10/11/12/17/13) PEX-AL-PEX pipe. Maximum working pressure 10.0 bar. Maximum operating temperature 95°C
Range of stainless steel (304 or 316L) ‘M’ profile press fittings with EPDM ‘O’-rings and stainless steel (304 or 316L) pipes. Jointing is achieved via a crimping tool using a ‘M’ profile. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of press fittings (brass bodies) “KMU” with stainless steel press (‘U’ profile) collars and EPDM O-rings for use with “KELOX” range of PERT/AL/PERT multilayer pipe (‘butt welded’ variant 16mm-63mm & ‘lap welded’ variant 16mm-20mm). Maximum working pressure: 10 bar. Maximum operating temperature: 85°C.
Range of stainless-steel (304/316L) press fittings with EPDM ‘O-rings to be used with stainless-steel (304/316L) pipes. The HF fittings also incorporate an EPDM gasket. Jointing is achieved via a crimping tool using a ‘V’ profile. For above ground use. Maximum working pressure 25.0 bar. Maximum operating temperature 100°C.
VSH XPRESS Range of ‘M’ profile stainless steel press fittings with EPDM ‘O’-rings for use with VSH SudoXPress stainless steel tube. Maximum working pressure 16.0 bar. Maximum operating temperature 100°C.
Range of blue epoxy coated carbon steel flanged dismantling joints with EPDM sealing rings. Maximum working pressure 16.0 bar. Maximum operating temperature 100°C.
Electric vented mains water heater with metal housing and silicon rubber gaskets. The inlet incorporates a combined EPDM washer and stainless-steel strainer and an approved check valve cartridge, however, the complete product has not been fully tested to demonstrate it provides backflow protection. Maximum operating temperature 98°C. Open outlet use only.
Range of ultrasonic water meters with brass (DN15-50) or plastic (DN15-20 only) bodies, EPDM ‘O’-rings and a plastic strainer. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Water shock absorber incorporating a stainless-steel body and EPDM membrane. Maximum working pressure 15.0 bar. Maximum operating temperature 85°C.
Range of flanged ball type non-return valves with blue epoxy coated ductile iron bodies, EPDM lined ductile iron balls, and EPDM gaskets. Above ground use only. Maximum working pressure 16.0 bar. Maximum operating temperature 100°C.
Range of electromagnetic flow meters with an epoxy coated (grey) carbon steel bodies, EPDM inner liner and stainless-steel electrodes. Maximum working pressure 16.0 bar. Maximum operating temperature 50°C.
Range of flow-compensated (thermostatic) temperature controllers incorporating a brass body with EPDM ‘O’-rings and gaskets. The valves incorporate a non-rising spindle headwork for temperature regulation. Maximum working pressure 16.0 bar. Maximum operating temperature 65°C
Range of pressure sensors with stainless steel bodies, EPDM ‘O’-ring and ceramic measuring cell. Maximum working pressure 25.0 bar. Cold water use only.
Range of pressure transmitters with stainless steel bodies. The DST P140 G1/4 A (with O-ring) model also incorporates an EPDM ‘O’-ring. Maximum working pressure 50.0 bar. Maximum operating temperatures: DST P140 G1/4 A (with O-ring): 85°C, All other models: 90°C.
Range of flexible joints incorporating an EPDM (inner & outer) joint with a steel reinforcing ring and two carbon steel flanges. Maximum operating pressure 16.0 bar. Maximum operating temperature 65°C.
Range of rotary vane pumps with either brass, stainless-steel or plastic bodies, stainless steel impellor and EPDM ‘O’ rings. Maximum working pressure 20 Bar. Cold water use.
Range of electronic booster pumps with variable speed, incorporating stainless-steel bodies, impellers and shaft, EPDM gaskets and seals and an expansion vessel on the outlet. The pumps incorporate a drain port. Maximum working pressure 10.0 bar. Cold water use only.
Range of inline (301) or angle pattern (302) radiator valves with nickel-plated brass bodies, PTFE seats and EPDM sealing rings. The products are supplied with a dome operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 100°C.
Range of draining taps with brass or chrome plated brass bodies. Incorporating a rising spindle headwork, EPDM or NBR seals and washers. Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of TPE and ISIFLEX flexible hose assemblies incorporating EPDM ‘O’-rings and various end connections. Maximum operating temperature 60°C. Open outlet use only.
Range of stainless-steel braided EPDM lined flexible hose assemblies with various end connections. The 4GANc32 and 4GANc41 models incorporate an isolation valve. Max working pressure:10bar Max working temperature:85°c
Range of stainless-steel braided EPDM lined flexible hose assemblies with a variety of brass end connections (see models). “DN 9.5 ½” compression with ISO valve” model also incorporates a screwdriver operated isolation valve. Maximum working pressure 10.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
Range of stainless steel, stainless steel with nylon or nylon braided, EPDM lined flexible hose assemblies with DZR brass end connections. Some models incorporate spherical valves. Pushfit and compression connections are for use with copper pipe (manufactured to EN 1057). Maximum working pressure 10.0 bar. Maximum operating temperature 85°C
Range of stainless steel braided, EPDM lined flexible hose assemblies with DZR brass end connections. Maximum working pressure 10.0 bar. Maximum operating temperature 85°C
Range of stainless steel or stainless steel with nylon, EPDM lined flexible hose assemblies with DZR brass end connections. Models 128-3009 CST & YU-JQAL222A are stainless steel wire, all other models are stainless steel with black nylon outer. Some models incorporate spherical valves, see models. Pushfit and compression connections are for use with copper pipe (manufactured to EN 1057). Maximum working pressure 10.0 bar. Maximum operating temperature 85°C
Range of stainless steel braided or nylon braided EPDM lined hose assemblies available with a variety of end connectors. Maximum operating pressure 10.0 bar. Maximum operating temperature 90°C.
Range of air venting valves with blue epoxy coated ductile iron bodies, stainless steel floats and EPDM seals. Maximum working pressure 16.0 bar. Maximum operating temperature 100°C.
Range of eccentric flanged type butterfly valves with ductile iron bodies and disc (blue epoxy coated) and EPDM seats. Maximum working pressure 16.0 Bar. Maximum operating temperature 85°C
Range of lugged and wafer type butterfly valves with blue epoxy coated bodies, incorporating EPDM rubber ‘O’-rings and seat, and either a bronze (AB2), stainless steel (CF8 & CF8M) or blue epoxy coated or nickel plated, ductile iron (DI) disc. Maximum working pressure 25.0 bar. Maximum operating temperature 85°C.
Range of butterfly valves incorporating blue epoxy coated ductile iron bodies, stainless-steel discs and EPDM seats. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of butterfly valves with blue epoxy coated ductile iron bodies and discs with EPDM seats and a hand wheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of butterfly valves with blue epoxy coated ductile iron bodies, stainless steel discs and EPDM seats. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of wafer non-return valves with blue epoxy coated ductile iron bodies, stainless steel discs and EPDM seals. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of wafer non-return valves with blue epoxy coated ductile iron bodies, stainless steel discs and EPDM seals. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of flanged non-return valves with blue epoxy coated ductile iron bodies, EPDM lined ductile iron discs, and EPDM gaskets. Above ground use only. Maximum working pressure 16.0 bar. Maximum operating temperature 100°C.
Range of adjustable pressure reducing valves with stainless steel bodies and an EPDM diaphragm. The JXP200X model: ½” - 2” sizes also include a gauge port. Maximum inlet supply pressure 16.0 bar. Outlet pressures are adjustable as follows: XXP150X and J2XP100X models between 1.0 to 16.0 bar, JXP200X models between 0.6 to 16.0 bar. Maximum operating temperature 85°C.
Range of pilot operated pressure reducing valves with ductile iron bodies (blue epoxy coating) and EPDM diaphragm and O-rings. The products are supplied with auxiliary fittings: spherical valves (bronze or stainless steel), pressure gauges, a pilot valve, a needle valve and stainless steel or copper tubes. Maximum inlet supply pressure 16.0 bar. The outlet pressure is adjustable between 0.67~16.0 bar. Maximum operating temperature 85°C.
Range of pilot operated pressure reducing valves with ductile iron bodies (blue epoxy coating) and EPDM diaphragm and gaskets. The products are supplied with auxiliary fittings: spherical valves, pressure gauges, a pilot valve, a needle valve and copper tubes. Maximum inlet supply pressure 16.0 bar. The outlet pressure is adjustable between 0.6~16.0 bar. Maximum operating temperature 85°C.
Range of latching solenoid valves with DZR brass bodies, EPDM diaphragms and ‘O’-rings. Maximum working pressure 10.0 bar. Maximum operating temperature 70°C
Latching solenoid valve with a black plastic body and an EPDM diaphragm. Maximum working pressure 10.0 Bar Maximum operating temperature 85.0°C
Range of single lever ball valves with stainless steel bodies, ball, EPDM O-rings and PTFE gaskets. The press fit connection is to be used with stainless steel pipe manufactured to EN 10312. Maximum working pressure 16 bar. Maximum operating temperature 85°C.
Range of spherical isolation valves incorporating brass bodies (nickel plated), brass ball (chrome plated), brass stem and EPDM ‘O’-rings (screwdriver operated or T-type handle). For use with copper pipe (EN1057). Maximum working pressure 16.0 bar (model HC-60982-15) Maximum working pressure 25.0 bar (model HC-62022-15) Maximum operating temperature 85°C.
Range of in-line spherical valves with brass or nickel-plated brass bodies (see model), chrome plated ball, PTFE seats and EPDM O-rings. The products are supplied with either a lever operating member, magnetic lockable operating member, red or yellow butterfly handle or short lever operating member (see model). Compression and pressfit connections are for use with PEX/AL/PEX multilayer pipes manufactured to EN ISO 21003. The pressfit connection jointing is achieved via a crimping tool using a ‘U’ or ‘TH’ profile. Maximum working pressures: 255, 256 and 257 models: 20.0 bar, All other models: 16.0 bar. Maximum operating temperatures: 201, 207 and 209 models: 90°C, All other models: cold water only.
Range of in-line spherical valves with a nickel-plated brass body, chromium plated brass ball, PTFE seats and EPDM ‘O’-rings. The products are supplied with a lever or a butterfly handle (models with BH suffix). Compression end connections are for use with copper pipe or Irish copper pipe ((IS) models) (manufactured to EN1057). Maximum working pressures: S0231 prefix models: 16.0 bar. S0232 prefix models: 25.0 bar. Maximum operating temperature 85°C.
Range of flanged gate valves with blue epoxy coated ductile iron bodies and EPDM O-rings and disc. The valves are operated via a non-rising spindle headwork with a wheel type operating member. Maximum working pressure 16.0 Bar
Non-metallic materials and components comply with BS6920 at 80°C
Range of gate valves with ductile iron bodies (blue epoxy coated), EPDM coated wedge and EPDM O - rings. Maximum working pressure – 10.0 bar (DN900 and DN1000 only) and 16.0 bar (DN350 – DN800). Maximum operating temperature - 85°C
Gate valves with a blue epoxy coated ductile iron body, ductile iron wedge encapsulated in EPDM and EPDM ‘O’-rings. The valves operate via a non-rising spindle headwork with a hand wheel operating member. Maximum working pressures: DN50 - DN300: 25.0 bar. DN350 - 600: 16.0 bar. Maximum operating temperature 85°C.
Range of blue epoxy coated ductile iron gate valves with an EPDM coated ductile iron wedge. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves with ductile iron bodies (blue epoxy coated), EPDM coated wedges and non-rising spindles with hand wheel operating members. Maximum working pressure 16.0 Bar Maximum operating temperature 85.0°C
Range of gate valves with blue epoxy coated ductile iron bodies and EPDM wedges. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves with blue epoxy coated ductile iron bodies, EPDM coated ductile iron wedges. The valves operate via a non-rising spindle headwork with hand wheel operating member. Maximum working pressure –16.0 bar. Maximum operating temperature - 85°C
Range of flanged gate valves with blue epoxy coated ductile iron bodies and EPDM O-rings and disc. The valves are operated via a non-rising spindle headwork with a wheel type operating member. Maximum working pressure 16.0 Bar
Non-metallic materials and components comply with BS6920 at 80°C
Range of gate valves with blue epoxy coated ductile iron bodies, EPDM coated ductile iron wedges and a non-rising spindle with a handwheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of gate valves with blue epoxy coated ductile iron bodies, EPDM coated ductile iron wedges and a handwheel operating member. Maximum working pressure 16.0 bar. Maximum operating temperature 100°C.
Range of resilient seated gate valves with blue epoxy coated ductile iron bodies, and an EPDM wedge, gasket and ‘O’-ring. The model has a non-rising spindle and has a handwheel operating member. Maximum working pressure 25.0 bar. Maximum operating temperature 85°C.
Range of gate valves incorporating blue epoxy coated ductile iron bodies. EPDM coated ductile iron wedges and a non-rising spindle headwork. Some models incorporate a bypass. Maximum working pressure 16.0 bar. Maximum operating temperature 45°C.
Range of gate valves with ductile iron bodies (blue epoxy coated), EPDM discs and non-rising spindles with hand wheel operating members. Maximum working pressure 10.0 Bar Maximum operating temperature 80.0°C
Range of gate valves with ductile iron bodies (blue epoxy coated), EPDM coated wedge and EPDM O - rings. Maximum working pressure – 10.0 bar (DN900 and DN1000 only) and 16.0 bar (DN350 – DN800). Maximum operating temperature - 85°C
Range of resilient seated gate valves with blue epoxy coated ductile iron body and an EPDM coated ductile iron wedge. Maximum working pressure 16.0 bar. Maximum operating temperature 70°C.
Range of gate valves with blue epoxy coated ductile iron bodies and either an EPDM coated brass wedge (¾” - 1¼” of ASCENT01 models) or EPDM coated ductile iron wedge (all other models). The ASCENT01 models incorporate a square operating nut and the ASCENT02 models incorporate a hand wheel operating member. Maximum working pressures: ASCENT01 models: 16.0bar, ASCENT02 models: 10.0 or 16.0bar. Maximum operating temperature 85°C.
Range of screw down stop valves with brass or DZR brass bodies. Valves incorporate EPDM seat washers and PTFE seals. Maximum working pressure: 16 bar. Maximum operating temperature: 95°C
Range of balancing valves with blue epoxy coated ductile iron bodies incorporating blue epoxy coated ductile iron (DN50~DN150) or stainless steel discs (DN200~DN300), EPDM gaskets and ‘O’-rings, handwheel operating member and a measuring port at each flanged end. Maximum working pressure 16.0 bar. Maximum operating temperature 85°C.
Range of regulating valves with blue epoxy coated ductile iron bodies incorporating EPDM gaskets and hand wheel operating member. Maximum working pressure 25.0 bar. Maximum operating temperature 85°C.
Range of UV disinfection units with stainless steel bodies and EPDM seals. The UV lamps are housed inside quartz tubes. Maximum working pressure 10.3 bar. Maximum operating temperature 40°C.
'EP-G70B' Gaskets and 'O' rings. Black coloured, compression moulded, EPDM gaskets and 'O' rings. Shore hardness 70. Tested in-radius size 1.6mm. For use with water up to 23°C.
‘E4028WCC, E4510WCC, E5076WCC, E5522WCC, E6020WCC, E6020, E6541WCC, E7091WCC, E7091, E7528WCC, E8027WCC, E8506WCC & E9011WCC ‘O’ rings’. Black coloured, compression moulded EPDM ‘O’ rings. Shore hardness between 40 & 90. Tested in-radius size between 0.5mm & 3.5mm. ‘E4028WCC Gaskets’. Black coloured, compression moulded EPDM gaskets. Shore hardness 40. Tested in-radius size 0.8mm. For use with water up to 85°C.
'SISTO-MaXX EPDM Diaphragm'. Black coloured, compression moulded EPDM Diaphragm. Shore hardness 70. Tested in-radius size 2.6mm. For use with water up to 85°C.
'Spira Power 4070 gaskets'. Black coloured, compression moulded EPDM rubber gaskets. Shore hardness 70. Tested in-radius size between 1.53mm & 4.01mm. For use with water up to 23°C.
'EPDM-825-cmk (H80)/mld'. Black coloured, compression moulded EPDM material. Shore hardness 80 ShA. Tested in-radius size 1.13mm. For use with water up to 23°C.
'YL-EA-70'. Black coloured, compression moulded EPDM material. Shore hardness 70. Tested in-radius size 1.11mm. For use with water up to 65°C.
'Chemiline AG 030 FB 62'. Black coloured, EPDM material manufactured by calendaring. Shore hardness 60A. Tested in-radius size 1.0mm. For use with water up to 65°C.
'603.0703.046 - EPDM PX Black SH 78'. Black coloured, injection moulded EPDM material. Shore hardness 78. Tested in-radius size 1.0mm. For use with water up to 85°C.
'EPDM-LJHY'. Black coloured, compression moulded EPDM materials. Shore hardness between 50 & 75. Tested in-radius size 1.0mm. For use with water up to 85°C.
'EP70B002'. Black coloured, compression moulded EPDM material. Shore hardness 70. Tested in-radius size 1.0mm. For use with water up to 23°C.
‘AquaFlex T 5818’. Black coloured, compression moulded EPDM material. Shore hardness 70. Tested in-radius size 1.1mm. For use with water up to 23°C.
'KB60-E'. Black coloured, compression moulded EPDM material. Shore hardness 60. Tested in-radius size 1.2mm. For use with water up to 23°C.
'FOWRY-190920'. Black coloured, compression moulded EPDM rubber. Shore hardness 75. Tested in-radius size 3.0mm. For use with water up to 85°C.
'E7015'. Black coloured, compression moulded EPDM material. Shore hardness 70. Tested in-radius size 1.19mm. For use with water up to 23°C.
‘RSG-TW-BWGL, RSG-TW-V-BWGL & RSG-TW-K-BWGL’. Black coloured, compression moulded EPDM sheet materials. Shore hardness 70. Tested in-radius size 1.15mm. For use with water up to 85°C.
'EDW-70'. Black coloured, compression moulded EPDM material. Shore hardness 71 ShA. Tested in-radius size 0.5mm. For use with water up to 60°C.
Range of concealed WC flushing cisterns with a side entry BS 1212-4(2016) float operated inlet valve providing a type AG air gap arrangement and a dual flush outlet valve. The flush volume is operated by a two button assembly for a 6 or 3 litre flush volume. The cistern incorporates a servicing valve and a stainless-steel braided EPDM lined flexible hose assembly installed prior to the inlet valve. Maximum working pressure 10.0 Bar, Cold Water use only
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| F9009K-** | Various | BSP 3/4" (M) | 10 bar | 85 °C | LAN BIAO | Spout | No | 1/4 Turn ceramic disc | Metal Backnuts | Flow Straightener | Interconnecting Hoses, |
** denotes finish: No Suffix = Chrome, H = Black, DYB = Matte white, BZ = Perl white painted, HGTS = Red bronze, HTL = Yellow bronze brushed, Q = Bronze, QTSL = Bronze brushed bright, QTS = Bronze brushed matte, STS = Acid copper brushed, SDMGJ = Water plated rose gold, N = Nickel brushed bright light, NP = Nickel brushed, TJ = Titanium gold, TJLS = Titanium gold brushed, G = Gold, GJS = Gold brushed, GJSY = Zirconium gold wire drawing matte, PGJFY = Zirconium gold wire drawing matte bright light, PLSJ = Brushed gold, LSJY = Brushed gold matte, MGJ = Rose gold, MGJL = Rose gold brushed, DMGJ = Light rose gold brushed, HTS = Red bronze brushed, QHP = Grey, LSQH = Grey brushed, LHMGJ = Brushed yellow rose gold.
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| F2300120012060 | Chrome plated | ½” BSP (F) conical nut x ½” BSP(F) nut | Open outlet use only bar | 85 °C | Justlink WRAS 2025 | Nut | No | Open Outlet |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| JD-744* ** | Various | BSP 1/2" (M) | Open outlet use only bar | 60 °C | Kind | Handle | No | Not applicable | Not Applicable | Open Outlet | Flow Regulator Fitted, Shower Hose, Handset, |
| SJS-200* ** | Various | BSP 1/2" (M) | Open outlet use only bar | 60 °C | Kind | Handle | No | Not applicable | Not Applicable | Open Outlet | Flow Regulator Fitted, Shower Hose, Handset, |
| JD-795* ** | Various | BSP 1/2" (M) | Open outlet use only bar | 60 °C | Kind | Handle | No | Not applicable | Not Applicable | Open Outlet | Flow Regulator Fitted, Shower Hose, Handset, |
| JD-300* ** | Various | BSP 1/2" (M) | Open outlet use only bar | 60 °C | Kind | Handle | No | Not applicable | Not Applicable | Open Outlet | Flow Regulator Fitted, Shower Hose, Handset, |
| JD-798* ** | Various | BSP 1/2" (M) | Open outlet use only bar | 60 °C | Kind | Handle | No | Not applicable | Not Applicable | Open Outlet | Flow Regulator Fitted, Shower Hose, Handset, |
The first * stands for the different handle A, B,C and D, if there is no handle, no first * ** represents different types of finishes as follows: C: Chrome NS: Nickel brushed RP: Red powder coated TS: Zr gold brushed RS: Rose gold brushed GS: Gold brushed GM: Gun metal brushed B: Electroplated matte black W: White CB: Matte black and chrome CW: White and chrome TG: Zr gold plated RG: Rose gold plated G: Gold plated GP: Gun metal plated BS: Gun gray brushed
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| S009* | Various | 1/2" BSP (M) | 10 bar | 65 °C | WINSDRUM | On body | No | Rotary Cartridge headwork | Not Applicable | Not Applicable | Shower Hose, Handset, Fixed Head, Riser Rail, |
| S011* | Various | 3/4" BSP (F) | 10 bar | 65 °C | WINSDRUM | On cover plate | No | Ceramic cartridge | Not Applicable | Not Applicable | Shower Hose, Handset, Fixed Head, |
* denotes finish and can be replaced by: C - Chrome RG - Rose Gold BTG - Brushed Titanium gold BZG - Brushed Zirconium gold BRG - Brushed Rose gold MW - Matte white BS - Brushed stainless BN - Brushed nickel PN - Polished nickel GM - Gunmetal B - Matte black TG - Titanium gold ZG - Zirconium gold BC - Black+chrome W - White CW - Chrome+white Q - Quartzite ZGC - Zirconium gold+chrome TGC - Titanium gold+chrome M - Medieval A - Antique bronze CP - Champagne BL - Brushed lead BP - Polished Black
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| DU SNK FL5.6 C | Chrome | 1/2" BSP | 5 bar | 60 °C | Bristan | Body | No | 1/4 Turn ceramic disk | C-plate | Aerator | Flow Regulator Fitted, |
| Product Identification | Surface finish | Inlet Dimension | Max Wrk. Pressure | Max Op. Temp. | Marking | Marking Location | All metals in the water pathway are on the 4msi positive list | Headwork | Fixing Type | Spout Outlet | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| CHV EFSNK C | Chrome | 15mm | 10 bar | 60 °C | Bristan | Body | No | 1/4 Turn ceramic disc | C-plate | Flow Straightener | |
| 7329V | Chrome | 15mm | 10 bar | 60 °C | Bristan | Body | No | 1/4 Turn ceramic disc | C-plate | Flow Straightener |
72329V - Screwfix selling code.
Expansion vessels incorporating a stainless steel body and EPDM membrane. Maximum working pressure 10.0 bar. Maximum operating temperature 100˚C.
Range of stainless steel, stainless steel with nylon or nylon braided, EPDM lined flexible hose assemblies with DZR brass end connections. Some models incorporate spherical valves. Compression connections are for use with copper pipe (manufactured to EN 1057). Maximum working pressure 10.0 bar. Maximum operating temperature 85°C
Range of resilient seated gate valves with cast iron bodies (blue epoxy coated), EPDM coated cast iron wedges and a handwheel operating member. Maximum working pressure 16.0 bar.
Non-metallic materials and components comply with BS6920 at 85°C
'E7053AA'. Black coloured, compression moulded EPDM 'O' rings. Shore hardness 70. Tested in-radius size between 0.35mm and 5.0mm. For use with water up to 85°C.
'5594903 'O' rings'. Black coloured, compression moulded EPDM 'O' rings. Shore hardness 90. Tested in-radii sizes between 0.4mm and 3.65mm. For use with water up to 85°C.
'5594821'. Black coloured, compression moulded EPDM rubber material. Shore hardness 80. Tested in-radius size 1.0mm. For use with water up to 85°C.
'5594610'. Black coloured, compression moulded EPDM material. Shore hardness 60. Tested in-radius size 1.0mm. For use with water up to 85°C.
'5594710'. Black coloured, compression moulded EPDM material. Shore hardness 72. Tested in-radius size 1.0mm. For use with water up to 85°C.
Page 3 of 3
We use cookies to give you the best possible experience with WRAS. Some are essential to provide website functions and ensure the website is secure. We also use cookies to help us understand how people use the site and to make improvements. Click "Accept All" to enable recommended settings or click "Manage cookies" to adjust your settings. For more details, see our Cookie Policy.
