Section Code 0503 : Two hole, metal, single outlet, fixed, self cancelling diverter to shower.
Back To Directory SectionsGrohe ‘GRT 1000 Cosmopolitan’ wall mounted, two hole, single outlet (fixed) combination tap assembly (chromium plated brass), incorporating a non-rising spindle headwork controlling the flow using a dome type operating member. The temperature is controlled independently via a thermostatic cartridge, also using a dome type operating member. The product also incorporates a self-cancelling diverter to shower. The spout outlet incorporates a plastic aerator. The inlets and outlet connection to shower incorporate approved check valve cartridges, however, the complete assembly has not been fully tested to demonstrate that it provides adequate backflow protection. Maximum working pressure 10.0 Bar. Maximum operating temperature 60°C.
Grohe ‘Atrio’ range of floor mounted, single outlet (fixed) combination tap assemblies (chromium plated brass – various finishes) incorporating a ceramic cartridge headwork controlling the flow using a single lever type operating member. The product has a self-cancelling diverter to shower and the spout outlet incorporates a plastic aerator. The outlet connection to shower incorporates an approved check valve cartridge but the complete assembly has not been fully tested to demonstrate that it provides adequate backflow protection. Supplied with a shower hose and handset and installation set 45.984.001. Maximum working pressure 10.0 bar. Maximum operating temperature 60°C.
Range of floor mounted single outlet (fixed) combination tap assemblies (chromium plated brass). Incorporating quarter turn ceramic disc headworks, single lever or cross top operating members and self-cancelling diverter to shower outlet. Outlet incorporates an approved single check valve (however the complete assembly has not been tested to demonstrate that it provided adequate backflow protection). The spout outlet incorporates a plastic aerator and the product is supplied with a pop up waste. Maximum working pressure 5.0 bar. Maximum operating temperature 60°C.
Two hole, single outlet (fixed) combination tap assembly (chromium plated brass). Incorporating quarter turn ceramic disc headworks, single lever type operating members and self-cancelling diverter to shower outlet. The shower outlet also incorporates approved check valve cartridge, however, the complete product has not been fully tested to demonstrate it provides backflow protection. The spout outlet incorporates a plastic flow straightener. Product is supplied with metal backnuts. Maximum working pressure 10.0 bar. Maximum operating temperature 60°C
Range of two hole, single outlet (fixed) combination tap assemblies (chromium plated or matt black brass) incorporating quarter turn ceramic disc headworks with single lever operating members and a self-cancelling diverter to shower outlet. The spout outlet incorporates a plastic flow straightener. The product is supplied with metal back nuts. Maximum working pressure 10.0 bar. Maximum operating temperature 60°C.
Two hole metal single outlet (fixed) combination tap assembly (chromium plated brass) incorporating quarter turn ceramic disc headwork with single lever operating members and a self-cancelling diverter to shower outlet. The spout outlet incorporates a plastic flow straightener and the product is supplied with metal backnuts, hose and handset. Maximum working pressure 10.0 bar. Maximum operating temperature 70°C.
Two hole metal single outlet (fixed) combination tap assembly (chromium plated brass) incorporating quarter turn ceramic disc headwork with single lever operating members and a self-cancelling diverter to shower outlet. The spout outlet incorporates a plastic flow straightener and the product is supplied with metal backnuts, hose and handset. Maximum working pressure 10.0 bar. Maximum operating temperature 70°C.
Range of two hole, single outlet (fixed) combination tap assemblies (various finishes). Incorporating ceramic disc headworks, single lever operating members and self-cancelling diverter to shower outlet. The spout outlet incorporates a plastic flow straightener. The products are supplied with a shower hose, shower handset and plastic back nuts. Maximum working pressure 10.0 bar. Maximum operating temperature 60°C.
Range of two hole, single outlet (fixed) combination tap assemblies (chromium plated or matt black brass) incorporating quarter turn ceramic disc headworks with single lever operating members and a self-cancelling diverter to shower outlet. The spout outlet incorporates a plastic flow straightener. The product is supplied with metal back nuts. Maximum working pressure 10.0 bar. Maximum operating temperature 60°C.
Two hole metal single outlet (fixed) combination tap assembly (chromium plated brass) incorporating quarter turn ceramic disc headwork with single lever operating members and a self-cancelling diverter to shower outlet. The spout outlet incorporates a plastic flow straightener and the product is supplied with metal backnuts, hose and handset. Maximum working pressure 10.0 bar. Maximum operating temperature 70°C.
Two hole, single outlet (fixed) combination tap assembly brass body(in various finishes), incorporating quarter turn ceramic disc headwork with single lever operating members and a self-cancelling diverter to shower outlet. The inlet to the shower handset incorporates an approved check valve cartridge, however, the complete product has not been fully tested to demonstrate it provides backflow protection. The spout outlet incorporates a plastic flow straightener and the product is supplied with a shower hose, shower handset and plastic backnuts. Maximum working pressure 10.0 bar. Maximum operating temperature 60°C.
Range of two hole, metal single outlet (fixed) combination tap assemblies (various finishes). Incorporating either quarter turn ceramic disc or non-rising headwork with various operating members and a self-cancelling diverter to shower outlet. The spout outlets incorporate a plastic flow straightener and the product is supplied with plastic or metal backnuts, hose and handset. Maximum working pressure 10.0 bar. Maximum operating temperature 60°C.
Two hole, single outlet (fixed) combination tap assembly (chromium plated brass), incorporating quarter turn ceramic disc headworks with single lever operating members and a self-cancelling diverter to shower outlet. The spout outlet incorporates a waterfall outlet. The products are supplied with a shower hose and handset, and metal backnuts. Maximum working pressure 5.0 bar. Maximum operating temperature 60°C.
Two hole, single outlet (fixed) combination tap assembly with brass body (chrome plated), incorporating quarter turn ceramic disc headworks, single lever operating member and self cancelling diverter to shower outlet. The temperature is controlled independently via a thermostatic cartridge with single lever operating member. The shower outlet incorporates an approved check valve cartridge, however, the complete product has not been fully tested to demonstrate it provides backflow. The spout outlet incorporates a plastic aerator. Maximum working pressure 10.0 bar. Maximum operating temperature 65°C.
Two hole, single outlet (fixed) combination tap assembly with chrome plated brass body incorporating a ceramic cartridge headwork, single lever operating member and self-cancelling diverter to shower outlet. The spout outlet incorporates a plastic flow straightener. Supplied with a shower handset, hose and metal backnuts. Maximum working pressure 10.0 bar Maximum operating temperature 60°C
Range of two hole, single outlet (fixed) combination tap assembly with brass body (chrome plated), incorporating quarter turn ceramic disc headworks, single lever operating member and a lockable self- cancelling diverter to shower outlet. The product is supplied with a shower hose and shower handset. The spout outlet incorporates a plastic aerator (model SAVV2106). Maximum working pressure 6.0 bar. Maximum operating temperature 60°C.
Two hole, single outlet (fixed) combination tap assembly with brass body (chrome plated), incorporating quarter turn ceramic disc headworks, single lever operating member and a lockable self-cancelling diverter to shower outlet. The product is supplied with a shower hose and shower handset. Maximum working pressure 6.0 bar. Maximum operating temperature 60°C.
Range of two-hole, single outlet (fixed) combination tap assemblies (brass bodies, various finishes – see models) incorporating half turn manual diverter headworks with single lever operating members controlling the flow to an overhead shower and a bath spout with an off position and a self-cancelling diverter to shower outlet on the bath spout. The temperature is controlled independently via a thermostatic cartridge with a single lever operating member with a manual override button. The spout outlet incorporates a plastic aerator, and the inlets incorporate approved check valve cartridges; however, the complete product has not been fully tested to demonstrate it provides backflow protection. The product is supplied with a shower hose, handset and an overhead shower. Maximum working pressure 10.0 bar.
Non-metallic materials and components comply with BS6920 at 60°C
Range of wall mounted, two-hole, single outlet (fixed) combination tap assembly (chrome plated brass body) incorporating a ceramic cartridge headwork with a single lever operating member and self-cancelling diverter to shower outlet. The shower outlet incorporates an approved check valve cartridge, however, the complete product has not been fully tested to demonstrate it provides backflow protection. The spout outlet incorporates a plastic aerator. Maximum working pressure 10.0 bar. Maximum operating temperature 60°C
A range of wall mounted two-hole, single outlet (fixed) combination tap assemblies with brass bodies (various finishes see models), incorporating quarter turn ceramic disc headworks, dome type operating members and self-cancelling diverter to shower outlets. The temperature is controlled independently via thermostatic cartridges with dome type operating members. Both operating members incorporate a manual override. Spout outlet incorporates a plastic aerator. Products are supplied with shower hose, shower handset and overhead shower. The inlets incorporate approved check valve cartridges; however, the complete product has not been fully tested to demonstrate it provides backflow protection. Maximum working pressure 10.0 Bar.
Non-metallic materials and components comply with BS6920 at 60°C
